TOYOTA C-HR 2019 Owners Manual (in English)

4317-2. Steps to take in an emergency
7
When trouble arises
C-HR_OM_USA_OM10569U
The warning lights and warning buzzers operate as follows depending
on the content of the message. If a message indicates the need for
inspection by a dealer, have the vehicle inspected by your Toyota
dealer immediately.
*: A buzzer sounds the first time a message is shown on the multi -informa-
tion display
Messages and warnings
System
warning lightWarning
buzzer
*Warning
 Sounds • Indicates an important situation, such as
when a system related to driving is malfunc-
tioning or that danger may result if the correc-
tion procedure is not performed
• Indicates a situation, such as when damage
to the vehicle or danger may result
Comes on or
flashes
Sounds
Indicates an important situation, such as when
the systems shown on the multi-information dis-
play may be malfunctioning
Does not
sound
• Indicates a condition, such as malfunction of electrical components, their condition, or indi-
cates the need for maintenance
• Indicates a situation, such as when an opera- tion has been performed incorrectly, or indi-
cates how to perform an operation correctly

4327-2. Steps to take in an emergency
C-HR_OM_USA_OM10569U
■Warning messages
The warning messages explained below may differ from the actual messages
according to operation conditions and vehicle specifications.
■ If “Visit Your Dealer” is shown
The system or part shown on the multi-information display is malfunctioning.
Have the vehicle inspected by your Toyota dealer.
■ If a message about an operation is shown
● If a message about an operation of the accelerator pedal or bra ke pedal is
shown
A warning message about an operation of the brake pedal may be shown
while the driving assist systems such as PCS (Pre-Collision Sys tem) or the
dynamic radar cruise control with full-speed range is operating . If a warning
message is shown, be sure to decelerate the vehicle or follow t he instruction
shown on the multi-information display.
● A warning message is shown when B rake Override System or Drive-Start
Control operates ( P. 158). Follow the instructions on the multi-informa-
tion display.
● If a message about an operation of the engine switch is shown
An instruction for operation of the engine switch is shown when the incorrect
procedure for starting the engine is performed or the engine switch is oper-
ated incorrectly. Follow the instructions shown on the multi -i nformation dis-
play to operate the engine switch again.
● If a message about a shift lever operation is shown
To prevent the shift lever from being operated incorrectly or t he vehicle from
moving unexpectedly, a message that requires shifting the shift lever may
be shown on the multi-information display. In that case, follow the instruction
of the message and shift the shift lever.
● If a message or image about an open/close state of a part or replenishment
of a consumable is shown
Confirm the part indicated by the multi-information display or a warning light,
and then perform the coping method such as closing the open doo r or
replenishing a consumable.

4337-2. Steps to take in an emergency
7
When trouble arises
C-HR_OM_USA_OM10569U■
If “See Owner’s Manual” is shown
●If “Braking Power Low Stop in a Safe Place See Owner’s Manual” is shown,
this may be a malfunction. Immediately stop the vehicle in a sa fe place and
contact your Toyota dealer. Continuing to drive the vehicle may be danger-
ous.
● Vehicles with a smart key system:
If “Entry & Start System Malfunction See Owner’s Manual” is shown, there
may be a malfunction. Immediately have the vehicle inspected by your
Toyota dealer.
■ If “Charging System Malfunction” is shown
Indicates a malfunction in the vehicle’s charging system. Immed iately stop
the vehicle in a safe place and contact your Toyota dealer. Con tinuing to drive
the vehicle may be dangerous.
■ If “Engine Coolant Temperature High” is shown
Indicates that the engine coolant temperature is too high. Imme diately stop
the vehicle in a safe place. ( P. 455)
■ If “Engine Oil Pressure Low” is shown
Indicates that the engine oil pressure is too low. Immediately stop the vehicle
in a safe place and contact your Toyota dealer.
■ If “Maintenance Required Soon” is shown (U.S.A. only)
Indicates that all maintenance according to the driven distance on the mainte-
nance schedule
* should be performed soon.
Comes on approximately 4500 miles (7200 km) after the message has been
reset.
If necessary, perform maintenance. Please reset the message aft er the main-
tenance is performed. ( P. 337)
*: Refer to the separate “Scheduled Maintenance Guide” or “Owner ’s Manual
Supplement” for the maintenance interval applicable to your vehicle.
■ If “Maintenance Required Visit Your Dealer.” is shown (U.S.A. o nly)
Indicates that all maintenance is required to correspond to the driven distance
on the maintenance schedule
*.
Comes on approximately 5000 miles (8000 km) after the message has been
reset. (The indicator will not work properly unless the message has been
reset.)
Perform the necessary maintenance. Please reset the message aft er the
maintenance is performed. ( P. 337)
*: Refer to the separate “Scheduled Maintenance Guide” or “Owner ’s Manual
Supplement” for the maintenance interval applicable to your vehicle.

4347-2. Steps to take in an emergency
C-HR_OM_USA_OM10569U■
If “A New Key has been Registered Contact Your Dealer for Detai ls” is
shown (vehicles with a smart key system)
This message will be displayed each time the driver's door is o pened when
the doors are unlocked from the outside for approximately one w eek after a
new electronic key has been registered.
If this message is displayed but you have not had a new electro nic key regis-
tered, ask your Toyota dealer to check if an unknown electronic key (other
than those in your possession) has been registered.
■ If “Front camera unavailable” or “Front camera vision blocked C lean and
demist windshield” is displayed.
The following systems may be suspended until the problem shown in the
message is resolved. ( P. 237, 422)
● PCS (Pre-Collision System)
● LDA (Lane Departure Alert with steering control)
● Dynamic radar cruise control with full-speed range
● Automatic High Beam
■ Warning buzzer
P. 427

4357-2. Steps to take in an emergency
C-HR_OM_USA_OM10569U
7
When trouble arises
If you have a flat tire
●Stop the vehicle in a safe place on a hard, flat surface.
● Set the parking brake.
● Shift the shift lever to P.
● Stop the engine.
● Turn on the emergency flashers. ( P. 408)
Your vehicle is equipped with a spare tire. The flat tire can b e
replaced with the spare tire.
For details about tires: P. 3 6 5
WARNING
■If you have a flat tire
Do not continue driving with a flat tire.
Driving even a short distance wit h a flat tire can damage the tire and the
wheel beyond repair, which cou ld result in an accident.
Before jacking up the vehicle

4367-2. Steps to take in an emergency
C-HR_OM_USA_OM10569U
Location of the spare tire, jack and tools
To w i n g e y e l e t
Wheel nut wrench
JackJack handle
Spare tire

4377-2. Steps to take in an emergency
7
When trouble arises
C-HR_OM_USA_OM10569U
WARNING
■Using the tire jack
Observe the following precautions.
Improper use of the tire jack may cause the vehicle to suddenly fall off
the jack, leading to death or serious injury.
●Do not use the tire jack for any purpose other than replacing t ires or
installing and removing tire chains.
●Only use the tire jack that comes with this vehicle for replacing a flat
tire.
Do not use it on other vehicles, and do not use other tire jack s for
replacing tires on this vehicle.
●Do not put any part of your body under the vehicle while it is supported
by the jack.
●Do not start the engine or drive the vehicle while the vehicle is sup-
ported by the jack.
●Do not raise the vehicle w hile someone is inside.
●When raising the vehicle, do not put an object on or under the jack.
●Do not raise the vehicle to a height greater than that required to
replace the tire.
●Use a jack stand if it is nece ssary to get under the vehicle.
●When lowering the vehicle, make sure that there is no-one near the
vehicle. If there are people nearb y, warn them vocally before lowering.
●Put the jack properly in its jack point.
(  P. 439)

4387-2. Steps to take in an emergency
C-HR_OM_USA_OM10569U
Remove the deck board. (P. 310)
Take out the jack.
Remove the deck board. ( P. 310)
Remove the cushion.
Loosen the center fastener that
secures the spare tire.
Taking out the jack
1
2
Taking out the spare tire
1
2
3
WARNING
■When storing the spare tire
Be careful not to catch fingers or other body parts between the spare
tire and the body of the vehicle.

4397-2. Steps to take in an emergency
7
When trouble arises
C-HR_OM_USA_OM10569U
Chock the tires.
Slightly loosen the wheel nuts
(one turn).
Turn the tire jack portion by
hand until the center of the
recessed portion of the jack is
in contact with the center of the
jack point.
Replacing a flat tire
1
Flat tireWheel chock positions
FrontLeft-hand sideBehind the rear right-hand side tire
Right-hand sideBehind the rear left-hand side tire
RearLeft-hand sideIn front of the front right-hand side tire
Right-hand sideIn front of the front left-hand side tire
2
3

4407-2. Steps to take in an emergency
C-HR_OM_USA_OM10569U
Assemble the jack handle and
the wheel nut wrench as shown
in the illustration.
Raise the vehicle until the tire is
slightly raised off the ground.
Remove all the wheel nuts and
the tire.
When resting the tire on the
ground, place the tire so that the
wheel design faces up to avoid
scratching the wheel surface.
4
5
6
