TOYOTA CAMRY 2000 Service Repair Manual

INSTALLATION
1. Temporarily install the new parts and mea-
sure each part in accordance with body di-
mension diagram.
BODY PANEL REPLACEMENTRE-9

RADIATOR SUPPORT (ASSY)
REMOVAL
Front Side Member
Extension
1. After removing the front side member exten-
sion, removing the radiator support.
BODY PANEL REPLACEMENTRE-10

INSTALLATION
1. Temporarily install the new parts and mea-
sure each part in accordance with the body
dimension diagram.
HINT: First install the hood lock support.
BODY PANEL REPLACEMENTRE-11

FRONT FENDER FRONT APRON (ASSY)
REMOVAL (With the radiator support removed.)
BODY PANEL REPLACEMENTRE-12

INSTALLATION
1. Temporarily install the new parts and mea-
sure each part in accordance with the body
dimension diagram.
BODY PANEL REPLACEMENTRE-13

FRONT APRON TO COWL SIDE MEMBER
(ASSY)
REMOVAL (With the front fender front apron, cowl top
side panel removed.)
Front Apron to Cowl
Side Upper Member
Front Apron to Cowl
Side Lower Member
1. After removing the front apron to cowl side
lower member, remove the front apron to
cowl side upper member.

BODY PANEL REPLACEMENTRE-14

INSTALLATION
Assembly Mark
1. When temporarily installing the new parts,
determine the installation position by the as-
sembly mark. Then measure each part in ac-
cordance with the body dimension diagram.2. Temporarily install the front fender and hood,
and check the fit.
BODY PANEL REPLACEMENTRE-15

FRONT FENDER APRON (ASSY)
REMOVAL (With the radiator support, cowl top side panel
removed.)
BODY PANEL REPLACEMENTRE-16

INSTALLATION
Assembly Mark
1. When temporarily installing the new parts,
determine the installation position by the as-
sembly mark.
2. Measurements must be accurate with the
body dimension diagram, as this affects the
front wheel alignment.3. Temporarily install the front fender and hood,
and check the fit.
BODY PANEL REPLACEMENTRE-17

COWL TOP SIDE PANEL (ASSY)
REMOVAL
Cut with disc
sander, etc.
Cut with disc
sander, etc.
BODY PANEL REPLACEMENTRE-18
