BO1LG-03
H07960
: Specified torque
N´m (kgf´cm, ft´lbf)

Non-reusable partHeadrest Headrest Support
Seatback Frame
Seatback Pad
Seatback Cover
Seat Cushion Cover
Seat Cushion Pad
Reclining Adjuster
Release Handle
Rear No. 2 Seat Reclining
Adjuster Cover Seat Leg Bracket Cover
Rear Seat Stay
Seat Leg Rear
Cover
Seat Leg Cover Seat Leg No.1 Stay Fold Seat Stopper
No. 2 BandRear No. 2 Seat
Reclining Adjuster
Rear Seat Reclining
Inner CoverSeat Adjuster
Control CableRear No. 2 Lap Type
Center with Inner Belt

Hog Ring
Seat Cushion Frame
Seat Leg
Seat Leg Bracket
Rear Seat Lock
Control Cable
Seat Cushion
Under Cover
Seat Lock Striker Cover
41 (420, 30)
18 (184, 13)
37 (380, 27)
41 (420, 30)
41 (420, 30)
41 (420, 30)
Seat Leg
Cover
Seat LegCushion
- BODYREAR NO.2 SEAT
BO-133
2707 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR NO.2 SEAT
COMPONENTS

BO21F-02
H04085
H04086
H04087
H04089
A
BA
B BO-134
- BODYREAR NO.2 SEAT
2708 Author
: Date
:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. REMOVE RECLINING ADJUSTER RELEASE HANDLE
(a) Using a screwdriver, remove the cover.
HINT:
Tape the screwdriver tip before use.
(b) Remove the screw and reclining adjuster release handle.
2. REMOVE REAR NO. 2 SEAT RECLINING ADJUSTER
COVERS
Remove the No. 2 rear seat reclining covers.
3. REMOVE SEATBACK ASSEMBLY
(a) Disengage the hook.
(b) Remove the 4 bolts and seatback assembly.
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
4. REMOVE HEADREST
Remove the headrest.
5. REMOVE SEATBACK COVER
(a) Remove the headrest supports.
(b) Remove the cushion.
(c) Remove the seatback cover with pad from the seatback
frame.
(d) Remove the seatback cover from the seatback pad.
6. REMOVE REAR NO. 2 LAP TYPE CENTER WITH IN-
NER BELT
Remove the nut and rear No. 2 lap type center with inner belt.
7. REMOVE REAR SEAT LOCK CONTROL CABLE
8. REMOVE REAR SEAT STAY
Remove the 2 bolts and rear seat stay.
9. REMOVE ADJUSTER
(a) Remove the 3 nuts.
(b) Remove the 4 bolts.
Torque:
A bolt: 18 N´m (185 kgf´cm, 13 ft´lbf)
B bolt: 37 N´m (380 kgf´cm, 27 ft´lbf)
(c) Remove the adjuster.
(d) Remove the seat leg bracket cover.
(e) Remove the 2 screws and seat leg No. 1 stay.

H04090
H04091
H04093
- BODYREAR NO.2 SEAT
BO-135
2709 Author
: Date
:
2004 LAND CRUISER (RM1071U)
10. REMOVE SEAT LEG BRACKET
11. REMOVE SEAT LEG REAR COVER
12. REMOVE SEAT LEG COVER
13. REMOVE SEAT CUSHION UNDER COVER
(a) Remove the assist grip.
(b) Using a screwdriver, disengage the hooks.
HINT:
Tape the screwdriver tip before use.
(c) Remove the 8 screws.
(d) Remove the seat cushion under cover.
14. REMOVE SEAT ADJUSTER CONTROL CABLE
15. REMOVE SEAT RECLINING INNER COVERS
16. REMOVE REAR NO. 2 SEAT RECLINING ADJUSTERS
(a) Remove the 4 bolts.
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
(b) Remove the rear No. 2 seat reclining adjusters.
17. REMOVE SEAT CUSHION COVER
(a) Remove hog rings and seat cushion frame.
HINT:
At the time of reassembly, please refer to the following item.
When installing hog rings, take care to prevent wrinkles as little
as possible.
(b) Remove the seat cushion cover from the seat cushion
pad.
18. REMOVE HOLD SEAT STOPPER NO. 2 BAND
(a) Remove the screw.
(b) Remove the hold seat stopper No. 2 band.

BO1LP-02
BO-136
- BODYREAR NO.2 SEAT
2710 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO-134).

BO1KP-04
H18921
Dome Light
Lens
Roof Headlining
Rear Trim
Roof Headlining Double Visor
Map Lamp
Center Pillar Garnish
Rear Mat
Set Plate
Striker Plate
Upper Roof
Side Inner Garnish Assist Grip
Cowl Side Trim Front Door Scuff Plate
Center Pillar Lower
Garnish CoverRear Door
Scuff PlateQuarter Trim PanelQuarter Trim
Jack Cover
Front Pillar Garnish Front Door
Opening TrimRear Door
Opening Trim Sun Visor
Holder
Assist Grip
Plug
Overhead
Console Box
Striker Plate
Center Pillar
Lower Garnish
Front Assist Grip
Front Assist Grip
Center Assist Gripw/ Curtain Shield Airbag:
42 (430, 31)
Adjustable
AnchorRear A/C Register
Rear A/C Register
Rear A/C Control Panel Rear A/C Register
Striker Plate
Striker Plate
Center Assist Grip
Center Assist Grip
Assist Grip
Rear
Assist Grip
x5Striker Plate
Center Assist Grip w/ Curtain Shield Airbag:
Adjustable
Anchor
Center Pillar Garnish
Center
Pillar
Garnish
: Specified torqueN´m (kgf´cm, ft´lbf)Rear Mat42 (430, 31)
Cap
Cap
Holder
rear
Assist Grip
w/ Curtain Shield Airbag:
Assist Grip
Assist Grip
Assist Grip Plug
w/ Curtain Shield Airbag:
Assist
Grip
Assist Grip Plug
Assist Grip
42 (430, 31)
Lens
Room Temperature
Sensor
BO-96
- BODYROOF HEADLINING
2670 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ROOF HEADLINING
COMPONENTS

BO1KR-01
- BODYROOF HEADLINING
BO-101
2675 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page BO-97).

BO4IZ-01
H05257
: 5 Clips
H05258
H05259
H07941
11 Clips
- BODYROOF HEADLINING
BO-97
2671 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE ROOF HEADLINING REAR TRIM
Using a screwdriver, remove the roof headlining rear trim.
HINT:
Tape up the screwdriver tip before use.
2. REMOVE REAR NO. 2 SEATS
3. REMOVE REAR MAT SET PLATE
(a) Remove the 5 screws.
(b) Using a screwdriver, remove the rear mat set plate.
HINT:
Tape up the screwdriver tip before use.
4. REMOVE STRIKER PLATES
(a) Remove the 6 screws.
(b) Using a screwdriver, remove the striker plates.
HINT:
Tape up the screwdriver tip before use.
5. REMOVE REAR MAT
6. REMOVE REAR NO. 2 SEAT OUTER BELT FLOOR AN-
CHOR
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
7. REMOVE REAR NO. 1 SEAT OUTER BELT FLOOR AN-
CHOR
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
8. REMOVE REAR DOOR SCUFF PLATES
9. REMOVE REAR DOOR OPENING TRIMS
10. REMOVE QUARTER TRIM PANEL LH
(a) Remove the quarter trim jack cover.
(b) Using a clip remover, remove the 2 clips.
(c) Remove the quarter trim panel LH, then disconnect the
connector.

H18922
10 Clips
H18906
: 9 Clips
H18904
H05264
Claw
BO-98
- BODYROOF HEADLINING
2672 Author
: Date
:
2004 LAND CRUISER (RM1071U)
11. REMOVE QUARTER TRIM PANEL RH
(a) Using a clip remover, remove the clip.
(b) Remove the quarter trim panel RH.
12. REMOVE REAR NO. 2 SEAT OUTER BELT SHOUL-
DER ANCHORS
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
13. REMOVE REAR NO. 1 SEAT OUTER BELT SHOUL-
DER ANCHORS
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
14. REMOVE UPPER ROOF SIDE INNER GARNISHES
(a) Using a screwdriver, remove the 2 assist grip plugs, then
remove the 2 screws and the assist grip.
HINT:
Tape up the screwdriver tip before use.
(b) Using a clip remover, remove the clip.
(c) Using a screwdriver, remove the upper roof side inner gar-
nish.
HINT:
Tape up the screwdriver tip before use.
(d) Use the same manner described above to the other side.
15. REMOVE FRONT DOOR SCUFF PLATES
16. REMOVE COWL SIDE TRIMS
17. REMOVE FRONT DOOR OPENING TRIMS
18. REMOVE FRONT ASSIST GRIP
(a) Using a screwdriver, remove the 2 assist grip plugs, then
remove the 2 screws and front assist grip.
HINT:
Tape up the screwdriver tip before use.
(b) Use the same manner described above to the other side.
19. REMOVE FRONT PILLAR GARNISH
(a) Using a screwdriver, remove the front pillar garnish.
HINT:
Tape up the screwdriver tip before use.
(b) Use the same manner described above to the other side.
20. REMOVE CENTER PILLAR LOWER GARNISH
(a) Using a screwdriver, remove the center pillar garnish cov-
er.
HINT:
Tape up the screwdriver tip before use.

H05265
: 4 Clips
H21424
w/ Curtain Shield Airbag
w/o Curtain Shield Airbag
H21425
w/ Curtain Shield Airbag
w/o Curtain Shield Airbag
- BODYROOF HEADLINING
BO-99
2673 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(b) Using a screwdriver, remove the center pillar lower gar-
nish as shown in the illustration.
HINT:
Tape up the screwdriver tip before use.
(c) Use the same manner described above to the other side.
21. REMOVE CENTER PILLAR GARNISH
(a) Using a screwdriver, remove the seat belt anchor cover
cap.
HINT:
Tape up the screwdriver tip before use.
(b) Remove the bolt and the front seat outer belt shoulder an-
chor.
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
(c) Using a clip remover, remove the clip.
(d) Using a screwdriver, remove the center pillar garnish.
HINT:
Tape up the screwdriver tip before use.
(e) Use the same manner described above to the other side.
22. REMOVE SUN VISOR
(a) Using a screwdriver, remove the caps.
HINT:
Tape the screwdriver tip before use.
(b) Remove the screws, then disconnect the connectors.
(c) Remove the sun visors.
23. REMOVE DOUBLE VISOR
Remove the screws and the double visors.
24. REMOVE HOLDER
Remove the screws and the holders.

H05268
H05270
H21423
4 Clips
H18926
BO-100
- BODYROOF HEADLINING
2674 Author
: Date
:
2004 LAND CRUISER (RM1071U)
25. REMOVE DOME LIGHT
(a) Using a screwdriver, remove the lens as shown in the il-
lustration.
HINT:
Tape up the screwdriver tip before use.
(b) Remove the 4 screws and the dome light, then disconnect
the connector.
26. REMOVE MAP LAMP
(a) Using a screwdriver, remove the lens as shown in the il-
lustration.
HINT:
Tape up the screwdriver tip before use.
(b) Remove the 4 screws and the map lamp, then disconnect
the connector.
27. REMOVE OVERHEAD CONSOLE BOX
(a) Remove the bolt.
(b) Using a screwdriver, remove the overhead console box,
then disconnect the connector.
HINT:
Tape up the screwdriver tip before use.
28. REMOVE REAR A/C CONTROL PANEL
Using a screwdriver, release the 4 claws and pull out the rear
A/C control panel, then disconnect the connector.
HINT:
Tape up the screwdriver tip before use.
29. REMOVE ROOM TEMPERATURE SENSOR
Using a scrwedriver, pull out the room temperature sensor, then
disconnect the connector.
HINT:
Tape up the screwdriver tip before use.
30. REMOVE ASSIST GRIPS
31. w/o Curtain Shield Airbag:
REMOVE CENTER ASSIST GRIPS
32. REMOVE ROOF HEADLINING
Using a clip remover, remove the 3 clips and the roof headlining.
33. REMOVE REAR A/C REGISTER
34. w/ Curtain Shield Airbag:
REMOVE ADJUSTABLE ANCHOR
Remove the 2 bolts and the adjustable anchor.
Torque: 42 N´m (430 kgf´cm, 31 ft´lbf)
35. w/ Curtain Shield Airbag:
REMOVE CENTER ASSIST GRIPS
