TOYOTA LAND CRUISER 1998 Factory Repair Manual

BO1L4-03
- BODYREAR NO.1 SEAT (LH)
BO-125
2699 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page BO-1 19).

BO1L3-01
BO-124
- BODYREAR NO.1 SEAT (LH)
2698 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO-120).

BO1L1-04
- BODYREAR NO.1 SEAT (LH)
BO-1 19
2693 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
REMOVE REAR NO. 1 SEAT
(a) Fold the seatback down.
(b) Unlock the seat lock, and swing the whole seat up and forward.
(c) Using a screwdriver, remove the seat leg covers.
HINT:
Tape the screwdriver tip before use.
(d) Remove the 4 bolts and rear No. 1 seat.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)

BO1L5-05
H07958
Headrest
Headrest Support
Seatback Cover Seatback Pad
Seatback Frame No. 1 ProtectorSeatback BoardNo. 1 Reclining Cover
Corner Pad No. 1 Seat Adjuster
Rear No. 1
Seat Inner Belt Reclining
Inner
Cover
Hinge Cover
Reclining Inner CoverReclining
Connecting Wire
No. 1 Seat
Adjuster
Hinge Cover
No. 1
Reclining
Cover Corner Pad
Reclining Adjuster
Release HandleSeat Cushion
Under Cover
Seat Cushion
Under CoverSeat Cushion
Under Cover
Sub-Assembly
Rear Seat
Lock Striker Cover Fold Seat
Stopper Band
No. 1 Seat Leg StaySeat Leg Rear Seat
Lock
No. 2 Fold Seat
Lock Control CableLock Cover
Reclining Remote
Control Lever Knob
: Specified torque
N´m (kgf´cm, ft´lbf)

Non-reusable part

Hog Ring
Hinge Cover
Cushion

Hog Ring
Seat Cushion Cover
Seat Cushion Pad
Seat Cushion Frame
37 (380, 27)
41 (420, 30)
37 (380, 27)
BO-126
- BODYREAR NO.1 SEAT (RH)
2700 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR NO.1 SEAT (RH)
COMPONENTS

BO1L7-05
H05302
H06471
H05305
H05306
BO-128
- BODYREAR NO.1 SEAT (RH)
2702 Author
: Date
:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. REMOVE HEADREST
2. REMOVE SEATBACK BOARD
Using a screwdriver, remove the seatback board as shown in
the illustration.
HINT:
Tape the screwdriver tip before use.
3. REMOVE RECLINING ADJUSTER RELEASE HANDLE
(a) Using a screwdriver, remove the cover.
HINT:
Tape the screwdriver tip before use.
(b) Remove the screw and reclining adjuster release handle.
4. REMOVE NO. 1 RECLINING COVER
(a) Remove the 4 hog rings and open the seatback cover.
HINT:
At the time of reassembly, please refer to the following item.
When installing hog rings, take care to prevent wrinkles as little
as possible.
(b) Remove the 2 corner pads.
(c) Remove the 2 screws and 2 No. 1 reclining covers as
shown in the illustration.
5. REMOVE RECLINING CONNECTING WIRE
(a) Loosen the nuts, then remove the reclining connecting
wire of RH side edge.
(b) Remove the reclining connecting wire of LH side edge.
(c) Remove the clamp and reclining connecting wire.
6. REMOVE SEATBACK ASSEMBLY
Remove the 4 bolts and seatback assembly.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)

H05307
H05308
- BODYREAR NO.1 SEAT (RH)
BO-129
2703 Author
: Date
:
2004 LAND CRUISER (RM1071U)
7. REMOVE SEATBACK FRAME
(a) Remove the 4 screws and reclining inner cover.
(b) Remove the 2 hog rings.
HINT:
At the time of reassembly, please refer to the following item.
When installing hog rings, take care to prevent wrinkles as little
as possible.
(c) Disengage the hook, then remove the headrest supports.
(d) Remove the seatback frame.
(e) Remove the 2 No. 1 protectors from the seatback frame.
8. REMOVE SEATBACK COVER
Remove the hog rings and seatback cover.
HINT:
At the time of reassembly, please refer to the following item.
When installing hog rings, take care to prevent wrinkles as little
as possible.
9. REMOVE SEAT CUSHION UNDER COVER
Remove the 2 screws and 2 seat cushion under covers.
10. REMOVE SEAT CUSHION COVER WITH PAD
(a) Using a screwdriver, disengage the hooks as shown in the
illustration.
HINT:
Tape the screwdriver tip before use.
(b) Remove the seat cushion cover with pad.
11. REMOVE SEAT CUSHION COVER
Remove the hog rings and seatback cover.
HINT:
At the time of reassembly, please refer to the following item.
When installing hog rings, take care to prevent wrinkles as little
as possible.
12. REMOVE CUSHION
Remove the screw and cushion from the seat cushion under
cover sub-assembly.
13. REMOVE LOCK COVER
Remove the screw and lock cover.
14. REMOVE RECLINING REMOTE CONTROL LEVER
KNOB
Remove the screw and reclining remote control lever knob.
15. REMOTE FOLD SEAT STOPPER BAND
Remove the bolt and fold seat stopper band.
16. REMOVE SEAT CUSHION UNDER COVERS
Remove the 2 screws and 2 seat cushion under covers.

H05309
H05310
H07955
BO-130
- BODYREAR NO.1 SEAT (RH)
2704 Author
: Date
:
2004 LAND CRUISER (RM1071U)
17. REMOVE REAR SEAT CUSHION UNDER COVER
SUB-ASSEMBL Y
Remove the 8 screws and rear seat cushion under cover.
18. REMOVE REAR NO. 1 SEAT ADJUSTER
(a) Remove the 2 bolts and rear No. 1 seat outer adjuster.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)
(b) Remove the 2 bolts and rear No. 1 seat inner adjuster.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)
(c) Remove the 2 hinge covers from the outer and inner ad-
justers.
19. REMOVE REAR NO. 1 SEAT INNER BELT
Loosen the bolt, then remove the rear No. 1 seat inner belt.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
20. REMOVE NO. 2 FOLD SEAT LOCK CONTROL CABLE
Loosen the clamp and No. 2 fold seat lock control cable as
shown in the illustration.
21. REMOVE NO. 1 SEAT LEG STAY
(a) Using a screwdriver, remove the spring nut and E-ring.
HINT:
Tape the screwdriver tip before use.
(b) Remove the No. 1 seat leg stay.
22. REMOVE REAR SEAT CUSHION HINGE
(a) Using a screwdriver, remove the 2 E-rings.
HINT:
Tape the screwdriver tip before use.
(b) Remove the 2 hinge pins, 2 cushion spacers, 2 cushion
support springs and 2 rear seat cushion hinges.
23. REMOVE REAR SEAT LOCK

BO1L9-01
BO-132
- BODYREAR NO.1 SEAT (RH)
2706 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page BO-127).

BO1L8-02
- BODYREAR NO.1 SEAT (RH)
BO-131
2705 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO-128).

BO1L6-03
- BODYREAR NO.1 SEAT (RH)
BO-127
2701 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
REMOVE REAR NO.1 SEAT
(a) Fold the seatback down.
(b) Unlock the seat lock, and swing the whole seat up and forward.
(c) Using a screwdriver, remove the seat leg covers.
HINT:
Tape the screwdriver tip before use.
(d) Remove the 4 bolts and rear No.1 seat.
Torque: 37 N´m (380 kgf´cm, 27 ft´lbf)
