BO1JZ-03
BE3367
2 - 2.5 mm
(0.028 - 0.030 in.)0.7 - 0.75 mm(0.079 - 0.098 in.)
- BODYREAR WIPER AND WASHER
BO-41
2615 Author: Date:
2004 LAND CRUISER (RM1071U)
ADJUSTMENT
ADJUST WASHER NOZZLE
Using a tool like the one shown in the illustration, change the
direction of the nozzle hole to adjust the point where washer
fluid hits the back door glass.
Page 472 of 3115
BO1JW-03
H18909
Rear Wiper Arm
Center Back Door Garnish
Back Door GarnishAssist Grip
Assist Grip PlugInside Handle Bezel Grommet
Rear Wiper Motor
and Link Assembly
5.4 (55, 48 in.´lbf)
: Specified torqueN´m (kgf´cm, ft´lbf)
5.4 (55, 48 in.´lbf)
5.4 (55, 48 in.´lbf)
5.4 (55, 48 in.´lbf)
- BODYREAR WIPER AND WASHER
BO-37
2611 Author: Date:
2004 LAND CRUISER (RM1071U)
REAR WIPER AND WASHER
COMPONENTS
Page 473 of 3115
BO1JY-03
H18919
BA C
E
F D
G
BO-40
- BODYREAR WIPER AND WASHER
2614 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
INSPECT WASHER NOZZLE
While operating the washer, check if the point where the washer
fluid hits the back door glass is within the range indicated in the
illustration.
A: Approx. 40 mm (1.57 in.)
B: Approx. 180 mm (7.09 in.)
C: Approx. 40 mm (1.57 in.)
D: Approx. 30 mm (1.18 in.)
E: Approx. 120 mm (4.72 in.)
F: Approx. 90 mm (3.54 in.)
G: Approx. 15 mm (0.59 in.)
Page 474 of 3115
BO1K0-03
H18908
H05251
A BO-42
- BODYREAR WIPER AND WASHER
2616 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL REAR WIPER MOTOR AND LINK AS-
SEMBLY
(a) Install the wiper motor and link assembly with 5 bolts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(b) Connect the connector.
2. INSTALL BACK DOOR GARNISH
3. INSTALL CENTER BACK DOOR GARNISH
4. INSTALL INSIDE HANDLE BEZEL
5. INSTALL ASSIST GRIP
Install the assist grip with the 2 screws, then install the 2 assist
grip plugs.
6. INSTALL REAR WIPER ARM
(a) Install the grommet.
(b) Operate the wiper once and turn the wiper switch OFF.
(c) Install the wiper arm and tighten the nut by hand.
(d) Adjust the installation position of the wiper arm to the posi-
tion as shown in the illustration.
A: Approx. 38 ± 10 mm (1.50 ± 0.39 in.)
(e) Torque the nut.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(f) Close the cover.
Page 475 of 3115
BO1JX-03
H04849
H04847
ab
a - ab - b : 9 Clips
ab
H04848
: 10 Clips BO-38
- BODYREAR WIPER AND WASHER
2612 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE REAR WIPER ARM
(a) Open the cover.
(b) Remove the nut and rear wiper arm.
(c) Remove the grommet.
2. REMOVE ASSIST GRIP
(a) Using a screwdriver, remove the 2 assist grip plugs.
HINT:
Tape up the screwdriver tip before use.
(b) Remove the 2 screws and assist grip.
3. REMOVE INSIDE HANDLE BEZEL
4. REMOVE CENTER BACK DOOR GARNISH
Using a screwdriver, remove the center back door garnish.
HINT:
Tape up the screwdriver tip before use.
5. REMOVE BACK DOOR GARNISH
Using a screwdriver, remove the back door garnish.
HINT:
Tape up the screwdriver tip before use.
Page 476 of 3115
H18908
- BODYREAR WIPER AND WASHER
BO-39
2613 Author: Date:
2004 LAND CRUISER (RM1071U)
6. REMOVE REAR WIPER MOTOR AND LINK AS-
SEMBLY
(a) Disconnect the connector.
(b) Remove the 2 bolts.
(c) Unfasten the 3 bolts and remove the rear wiper motor with
link assembly.
Page 477 of 3115
BO1LL-02
AB0152
SST BO-144
- BODYSEAT BELT PRETENSIONER
2718 Author: Date:
2004 LAND CRUISER (RM1071U)
DISPOSAL
HINT:
When scrapping vehicle equipped with an SRS or disposing of
a front seat outer belt (with seat belt pretensioner), always first
deploy the airbag in accordance with the procedure given in RS
section or activate the seat belt pretensioner. If any abnormality
occurs with the airbag deployment or seat belt pretensioner ac-
tivation, contact the SERVICE DEPT. of TOYOTA MOTORS
SALES, U.S.A., INC.. When disposing of a front seat outer belt
(with seat belt pretensioner) activated in a collision, follow the
same procedure given in step 1-(d) in ºDISPOSALº.
CAUTION:
Never dispose of front seat outer belt which has inac-
tivated pretensioner.
The seat belt pretensioner produces a sizeable ex-
ploding sound when it activates, so perform the op-
eration out-of-door and where it will not create a nui-
sance to nearby residents.
When activating the seat belt pretensioner, always
use the specified SST. (SRS Airbag Deployment Tool)
Perform the operation in a place away from electrical
noise.
SST 09082-00700, 09082-00740
When activating a front seat outer belt (with seat belt
pretensioner), perform the operation at least 10 m (33
ft) away from the front seat outer belt.
Use gloves and safety glasses when handling a front
seat outer belt with activated pretensioner.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a front seat outer belt with
activated pretensioner.
Page 478 of 3115
AB0158
SSTBattery
AB0152
SST
AB0158
SSTBattery
H01580
SST
- BODYSEAT BELT PRETENSIONER
BO-145
2719 Author: Date:
2004 LAND CRUISER (RM1071U)
1. SEAT BELT PRETENSIONER ACTIVATION WHEN
SCRAPPING VEHICLE
HINT:
Have a battery ready as the power source to activate the seat
belt pretensioner.
(a) Check functioning of SST.
CAUTION:
When activating the seat belt pretensioner, always use the
specified SST: SRS Airbag Deployment Tool.
SST 09082-00700, 09082-00740
(1) Connect the SST to battery.
Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip to the battery neg-
ative (-) terminal.
HINT:
Do not connect the yellow connector which will be connected
with the seat belt pretensioner.
(2) Check functioning of SST.
Press the SST activation switch, and check the LED
of the SST activation switch lights up.
CAUTION:
If the LED lights up when the activation switch is not being
pressed, SST malfunction is probable, so definitely do not
use the SST.
(b) Disconnect the pretensioner connector.
(1) Remove the front door scuff plate.
(2) Remove the front door opening trim.
(3) Remove the rear door scuff plate.
(4) Remove the rear door opening trim.
(5) Remove the center pillar lower garnish.
Page 479 of 3115
H04094
A
B
H04098
SST
SST
R13455
10 m (33 ft) or more BO-146
- BODYSEAT BELT PRETENSIONER
2720 Author: Date:
2004 LAND CRUISER (RM1071U)
(6) Disconnect the pretensioner connector in the order
ºAº and ºBº as shown in the illustration.
(c) Install the SST.
(1) Connect the 2 SST each other, then connect them
to the seat belt pretensioner.
SST 09082-00700, 09082-00740
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock secondary lock of the twin lock.
(2) Move the SST to at least 10 m (33 ft) away from the
front of the vehicle.
(3) Close all the doors and windows of the vehicle.
NOTICE:
Take care not to damage the SST wire harness.
(4) Connect the SST red clip to the battery positive (+)
terminal and the black clip to the negative (-) termi-
nal.
(d) Activate seat belt pretensioner.
(1) Confirm that no one is inside the vehicle or within 10
m (33 ft) area around the vehicle.
(2) Press the SST activation switch and activate the
seat belt pretensioner.
HINT:
The seat belt pretensioner operates simultaneously as the LED
of the SST activation switch lights up.
(e) Dispose of the front seat outer belt (with seat belt preten-
sioner).
CAUTION:
The front seat outer belt is very hot when the seat belt
pretensioner is activated, so leave it alone for at least
30 minutes after activation.
Use gloves and safety glasses when handling a front
seat outer belt with activated seat belt pretensioner.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a front seat outer belt with
activated seat belt pretensioner.
2. ACTIVATION WHEN DISPOSING OF FRONT SEAT
OUTER BELT ONLY
Page 480 of 3115
AB0158
SSTBattery
H04099
SST
SST
H04100
SST SST
- BODYSEAT BELT PRETENSIONER
BO-147
2721 Author: Date:
2004 LAND CRUISER (RM1071U)
HINT:
When scrapping a vehicle, activate the seat belt pretensioner
and scrap the vehicle with activated front seat outer belt still
installed.
NOTICE:
When disposing of the front seat outer belt (with seat
belt pretensioner) only, never use the customer's ve-
hicle to activate the seat belt pretensioner.
Be sure to follow the procedure given below when ac-
tivating the seat belt pretensioner.
HINT:
Have a battery ready as the power source to activate the seat
belt pretensioner.
(a) Remove the front seat outer belt (See page BO-137).
HINT:
Cut the belt near the seat belt retractor.
(b) Check functioning of SST (See step 1-(a)).
SST 09082-00700, 09082-00740
(c) Install the SST.
(1) Connect the 2 SST each other, then connect them
to the seat belt pretensioner.
SST 09082-00700, 09082-00740
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock.
(2) Place the front seat outer belt on the ground and
cover it with the disc wheel with tire.
NOTICE:
Place the front seat outer belt as shown in the illustration.
(3) Move the SST to at least 10 m (33 ft) away from the
disc wheel.
NOTICE:
Take care not to damage the SST wire harness.
