TOYOTA SEQUOIA 2020 Accessories, Audio & Navigation (in English)

1734-8. Rear seat entertainment system operation
4
Audio/visual system
2Input the 4-digit personal
code and then select “OK”.
 Select 10 times to reset
the personal code in case the
code was forgotten.
3 Input a restriction age (0-255)
and then select “OK”.
■Setting a quick playback
BD video
After inserting a BD disc you
can skip over to the first play-
back point and can immediately
playback the main story. 1
Each time “Quick Play” is
selected, “On” or “Off” can be
selected.
■Setting a sound dynamic
range
The difference between the low-
est and highest sound volumes
can be adjusted.
1 Select “Sound Dynamic
Range”.
2 Select the desired setting.
“MAX”: Maximum sound dynamic
range
“MID”: Medium sound dynamic
range
“MIN”: Minimum sound dynamic
range

1744-8. Rear seat entertainment system operation
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Selecting a track/fileSelecting a folder
Turning on the audio CD and
MP3/WMA/AAC mode
Repeat play
Random playback
1 Insert a disc or press the
“DISC” button.
 The player will start to play
the disc automatically.
1 Press or until
the desired track/file number
appears.
1 Press and hold or
.
Playing an audio CD
and MP3/WMA/AAC
discs
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
The player will start to play
the disc automatically.
Remote controller
A
B
C
D
E
F
&RQWUROVFUHHQ
7XUQLQJRQWKH\
&'PRGH
6HOHFWLQJDWUDFNIL\
OH
)DVWIRUZDUGL\
QJRU
UHZLQGLQJDW\
UDFNILOH
G
H
A
B

1754-8. Rear seat entertainment system operation
4
Audio/visual system
MP3/WMA/AAC
1 Press “ ” or “” on the
“FOLDER” button until the
desired folder number
appears.
 Press and hold “ ” on the
“FOLDER” button, the top file
stored in the top folder in the
disc will be selected.
1 Each time is selected,
the mode changes as follow:
Audio CD
track repeat  off
MP3/WMA/AAC
file repeat  folder repeat  off
1Each time is selected,
the mode changes as follow:
Audio CD
random  off
MP3/WMA/AAC
1 folder random  1 disc random
 off
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the option screen
Selecting a folder
Repeat play
Random playback
Playing an SD card
This system can play music,
still pictures and video that
are stored in an SD card.
Press the “SD” button if an
SD card has already been
inserted in the SD card slot.
Remote controller
A
B
C
D
E
F
G

1764-8. Rear seat entertainment system operation
Selecting a chapter
Turning on the SD card mode
Playing music (P.176)
Playing still pictures
( P.177)
Playing SD video ( P.179)
Playing AVCHD video
( P.179)
Playing movie ( P.179)
Formatting the SD card
( P.182)
Deleting the BD history data
( P.182)
1 Press the button to
play/pause.
 Press and hold the but-
ton while pausing, the video is
played slowly. 1
Press or until
the desired track/file number
appears.
1 Press and hold or
.
You can play music that is
stored on an SD card.
1 Select “Music”.
2 Music will start playing.
Repeat play
Main menu
Playing/pausing an SD
card media
H
I
A
B
C
D
E
F
G
6HOHFWLQJDFKDS
WHUWUDFNILOH
)DVWIRUZDUGL\
QJRU
UHZLQGLQJDF\
KDS
WHUWUDFNILOH
3OD\LQJPXVLF
A

1774-8. Rear seat entertainment system operation
4
Audio/visual system
Random playback
You can display still pictures that
are stored on an SD card.
1 Select “Picture”.
2 Select the desired still picture
to show.
 Select or to show the
next or previous page.
3 Selected picture is displayed
on the screen.
 Press the or button to display the next or previous
still picture.
 Press the “SD” button to
return to the SD menu screen.
Press the “OPTION” button
while displaying a still picture,
the following screen appears.
Press the “OPTION” button
once again or select “Hide But-
tons” to turn off the option
screen.
Turning off the option screen
Displaying the slideshow
setup screen
Returning to “Library View”
screen
Zooming out the still pictures
Rotating the still pictures
Displaying the detail informa-
tions of the still picture
Starting slideshow
You can display still pictures one
by one at a constant interval.
Playing still pictures
B
2SWLRQVFUHHQ
6WDUWLQJVOLGHVKRZ
A
B
C
D
E
F
G

1784-8. Rear seat entertainment system operation
1Select “Slideshow” to start
slideshow.
 When pressing the or
button during slideshow, the
previous or next still picture
will be shown, and the slide-
show will continue from that
picture.
 Press the “ENT” or “OPTION”
button to stop slideshow.
1 Select or to rotate a
still picture.
 The rotate information will be
maintained until the system is
turned off or the SD card is
removed.
1 Select to zoom out the
still pictures.
 Select again to cancel
zoom out.
 This function is only available
for smallsized still pictures.
1 Select “Detailed Information”. 2
Detail informations of the still
picture are displayed.
1 Select “Setup”.
2 The slideshow settings can
be changed. After the set-
tings are changed, select
“OK”.
Selects slideshow interval
time (seconds)
5  10  15  30  60
Selects slideshow effect
“Fade”  “Slide”  “Wipe1” 
“Wipe2”  “Dissolve”  “Zoom” 
“Off”
Selects on/off repeat slide-
show
Restores default settings
Rotating the still pictures
Zoom out the still pictures
Displaying the detail infor-
mations of the still picture
Slideshow setup
A
B
C
D

1794-8. Rear seat entertainment system operation
4
Audio/visual system
You can play video that are
stored in an SD card.
1Select “SD Video”, “SD
AVCHD” or “Movie”.
2 Video will start playing.
 Press the “SD” button to
return to the SD menu screen.
Press the “OPTION” button
while watching a video, the fol-
lowing screen appears.
Press the “OPTION” button
once again or select “Hide But-
tons” to turn off the option
screen.
When there are two pages,
select “>” or “<” to change the
page.
SD video
SD AVCHD
Playing video
Option screen

1804-8. Rear seat entertainment system operation
MovieTurning off the option screen
Displaying the detail informa-
tion
Rewind
Stop
Play/pause
Fast-forward
Searching for a title
Searching for a chapter
Changing the playback mode
Changing the audio channel
Displaying the top menu
screen
Returning to the predeter-
mined scene
Changing the audio language
Changing the subtitle lan-
guage
1 Select “Detailed Information”. 2
Detail informations of the
video are displayed.
SD video
SD AVCHD
Movie
SD video, SD AVCHD
1 Select “Title” or “Chapter”.
Displaying the detail infor-
mations of the video
A
B
C
D
E
F
G
H
I
J
K
L
M
N
6HDUFKLQJIRUDWL\
WOHRUFKDS
WHU

1814-8. Rear seat entertainment system operation
4
Audio/visual system
2Input the title number or
chapter number, and select
“OK”.
SD video
The audio channel can be
changed for SD card with multi-
ple audio channels.
1 Select “Multiplexed Audio”.
2 Each time “Audio” is
selected, the mode changes
in the following order:
“Main”: Main audio channel
“Sub”: Sub audio channel
“Main/Sub”: Both the main and sub
audio channels
SD video
The playback mode can be
changed to program mode or playlist mode. Playlist mode
cannot be selected if a playlist is
not stored on the SD card.
1
Select “Playback Mode”.
2 Each time “Playback Mode”
is selected, the mode
changes in the following
order:
“Program” mode: Playback the disc
in order of pr ogram number
“Playlist” mode: Playback the disc
in order of pla ylist number
SD AVCHD
The audio language can be
changed for SD card with multi-
ple audio languages.
1 Select “Audio”.
2 Each time “Audio” is
selected, another language
Changing the audio channel
Changing the playback mode
Changing the audio lan-
guage

1824-8. Rear seat entertainment system operation
available on the SD card is
selected.
SD AVCHD
The subtitle language can be
changed for SD card with multi-
ple subtitle languages.
1 Select “Subtitle”.
2 Each time “Subtitle” is
selected, another language
available on the SD card is
selected.
“Hide”: Subtitle can be hidden.
1Select “Format SD Card”.
2 Select “Yes” to format the SD
card.
 If the SD card is formatted, all
data on the card will be erased.
The BD history data such as
bookmarks and resume informa-
tion can be deleted.
1 Select “Clear BD Data”.
2 Select “Yes” to delete the BD
history data.
Changing the subtitle lan-
guage
Formatting the SD card
Deleting the BD history
data
