BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEMBC–159
BC
DESCRIPTION
The skid control ECU is connected to the combination meter via CAN and multiplex communications.
When the traction OFF switch is turned on, the TRAC OFF indicator light will come on (for 2WD model).
WIRING DIAGRAM
INSPECTION PROCEDURE
NOTICE:
When replacing the brake actuator assembly, perform zero point calibration (See page BC-70).
TRAC OFF Indicator Light Remains ON
C159741E02

BC–160BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEM
BC
(a) Check if the CAN communication system DTC is output
(See page CA-17).
Result
B
A
(a) Check if the multiplex communication system DTC is
output (See page MP-14).
Result
B
A
(a) Check if the skid control ECU connector is securely
connected.
OK:
The connector is securely connected.
NG
OK
(a) Check the battery voltage.
Standard voltage:
11 to 14 V
NG
OK
1CHECK CAN COMMUNICATION SYSTEM
Result Proceed to
CAN communication system DTC is not output A
CAN communication system DTC is outputB
INSPECT CAN COMMUNICATION SYSTEM
2CHECK MULTIPLEX COMMUNICATION SYSTEM
Result Proceed to
Multiplex communication system DTC is not output A
Multiplex communication system DTC is output B
INSPECT MULTIPLEX COMMUNICATION
SYSTEM
3CHECK IF SKID CONTROL ECU CONNECTOR IS SECURELY CONNECTED
CONNECT CONNECTOR TO ECU
CORRECTLY
4CHECK BATTERY
CHECK OR REPLACE CHARGING SYSTEM
OR BATTERY

BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEMBC–161
BC
(a) Disconnect the skid control ECU connector.
(b) Measure the resistance according to the value(s) in the
table below.
Standard resistance
NG
OK
(a) Reconnect the skid control ECU connector.
(b) Perform Active Test of the combination meter (meter
CPU) using the intelligent tester (See page ME-19).
OK:
The TRAC OFF indicator light turns on or off in
accordance with the intelligent tester.
HINT:
If troubleshooting has been carried out according to the
Problem Symptoms Table, refer back to the table and
proceed to the next step before replacing the part (See
page BC-79).
NG
OK
5INSPECT SKID CONTROL ECU (CSW TERMINAL)
C141673E25
Tester Condition Switch Condition Specified Condition
S3-43 (CSW) - Body
groundTraction OFF Switch
OFF (Not pressed)10 k
or higher
Go to step 7
6INSPECT COMBINATION METER ASSEMBLY
REPLACE COMBINATION METER
ASSEMBLY
REPLACE BRAKE ACTUATOR ASSEMBLY

BC–162BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEM
BC
(a) Disconnect the traction OFF switch connector.
(b) Measure the resistance according to the value(s) in the
table below.
Standard resistance
NG
OK
7INSPECT TRACTION OFF SWITCH
C156495E01
Tester Connection Switch Condition Specified Condition
3 (+) - 4 (E) Switch is pushed in Below 1
3 (+) - 4 (E) Switch is not pushed in 10 k or higher
REPLACE TRACTION OFF SWITCH

BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEMBC–163
BC
(a) Measure the resistance according to the value(s) in the
table below.
Standard resistance
HINT:
If troubleshooting has been carried out according to the
Problem Symptoms Table, refer back to the table and
proceed to the next step (See page BC-79).
NG
OK
8CHECK HARNESS AND CONNECTOR (SKID CONTROL ECU - TRACTION OFF SWITCH)
C159743E01
Tester Connection Condition Specified Condition
S3-43 (CSW) - T5-3 (+) Always Below 1
S3-43 (CSW) - Body
groundAlways 10 k or higher
T5-4 (E) - Body ground Always Below 1
REPAIR OR REPLACE HARNESS OR
CONNECTOR
REPLACE BRAKE ACTUATOR ASSEMBLY

BC–164BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEM
BC
DESCRIPTION
The skid control ECU is connected to the combination meter via CAN and multiplex communications.
When the traction OFF switch is turned on, the TRAC OFF indicator light will come on (for 2WD model).
WIRING DIAGRAM
Refer to TRAC OFF Indicator Light Remains ON (See page BC-157).
INSPECTION PROCEDURE
NOTICE:
When replacing the brake actuator assembly, perform zero point calibration (See page BC-70).
(a) Check if the CAN communication system DTC is output
(See page CA-17).
Result
B
A
(a) Check if the multiplex communication system DTC is
output (See page MP-14).
Result
B
A
(a) Connect the intelligent tester to the DLC3.
(b) Start the engine.
(c) Select the Active Test mode on the intelligent tester (See
page BC-85).
ABS / VSC:
TRAC OFF Indicator Light does not Come ON
1CHECK CAN COMMUNICATION SYSTEM
Result Proceed to
CAN communication system DTC is not output A
CAN communication system DTC is output B
INSPECT CAN COMMUNICATION SYSTEM
2CHECK MULTIPLEX COMMUNICATION SYSTEM
Result Proceed to
Multiplex communication system DTC is not output A
Multiplex communication system DTC is output B
INSPECT MULTIPLEX COMMUNICATION
SYSTEM
3CHECK TRAC OFF INDICATOR LIGHT
Tester Display Test Part Control Range Diagnostic Note
VSC / TRAC OFF IND TRAC OFF indicator light Indicator light ON / OFF Observe combination meter

BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEMBC–165
BC
(d) Check that "ON" and "OFF" of the TRAC OFF indicator
light are indicated on the combination meter when using
the intelligent tester.
OK:
The TRAC OFF indicator light turns on or off in
accordance with the intelligent tester.
HINT:
If troubleshooting has been carried out according to the
Problem Symptoms Table, refer back to the table and
proceed to the next step before replacing the part (See
page BC-79).
NG
OK
(a) Turn the ignition switch off.
(b) Perform Active Test of the combination meter (meter
CPU) using the intelligent tester (See page ME-19).
OK:
The TRAC OFF indicator light turns on or off in
accordance with the intelligent tester.
HINT:
If troubleshooting has been carried out according to the
Problem Symptoms Table, refer back to the table and
proceed to the next step (See page BC-79).
NG
OK Go to step 4
REPLACE BRAKE ACTUATOR ASSEMBLY
4INSPECT COMBINATION METER ASSEMBLY
REPLACE COMBINATION METER
ASSEMBLY
REPLACE BRAKE ACTUATOR ASSEMBLY

BC–166BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEM
BC
DESCRIPTION
The skid control ECU is connected to the combination meter via CAN and multiplex communications.
The SLIP indicator blinks during VSC and/or TRAC operation.
When the system fails, the SLIP indicator comes on to warn the driver.
WIRING DIAGRAM
INSPECTION PROCEDURE
NOTICE:
When replacing the brake actuator assembly, perform zero point calibration (See page BC-70).
(a) Check if the CAN communication system DTC is output
(See page CA-17).
Slip Indicator Light Remains ON
1CHECK CAN COMMUNICATION SYSTEM
C160968E04

BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEMBC–167
BC
Result
B
A
(a) Check if the multiplex communication system DTC is
output (See page MP-14).
Result
B
A
(a) Check if the skid control ECU connector is securely
connected.
OK:
The connector is securely connected.
NG
OK
(a) Check the battery voltage.
Standard voltage:
11 to 14 V
NG
OK
(a) Perform Active Test of the combination meter (meter
CPU) using the intelligent tester (See page ME-19).
Result Proceed to
CAN communication system DTC is not output A
CAN communication system DTC is output B
INSPECT CAN COMMUNICATION SYSTEM
2CHECK MULTIPLEX COMMUNICATION SYSTEM
Result Proceed to
Multiplex communication system DTC is not output A
Multiplex communication system DTC is output B
INSPECT MULTIPLEX COMMUNICATION
SYSTEM
3CHECK IF SKID CONTROL ECU CONNECTOR IS SECURELY CONNECTED
CONNECT CONNECTOR TO ECU
CORRECTLY
4CHECK BATTERY
CHECK OR REPLACE CHARGING SYSTEM
OR BATTERY
5INSPECT COMBINATION METER ASSEMBLY

BC–168BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEM
BC
OK:
The SLIP indicator light turns on or off in
accordance with the intelligent tester.
HINT:
If troubleshooting has been carried out according to the
Problem Symptoms Table, refer back to the table and
proceed to the next step before replacing the part (See
page BC-79).
NG
OKREPLACE COMBINATION METER
ASSEMBLY
REPLACE BRAKE ACTUATOR ASSEMBLY
