TOYOTA tC 2010 Accessories, Audio & Navigation (in English)

AUDIO/VIDEO SYSTEM
210
V573_E
The DVD player can play DVD video
discs.
For appropriate discs for this player, see
“Audio/video system operating hints” on
page 259.
For safety reasons, you can enjoy DVD
video discs only when the vehicle is
completely stopped with the engine
switch is in “ACC” or “IG−ON” mode and
the parking brake applied. While you are
driving, you can hear audio alone even in
the DVD video.
(a) Operating a DVD video disc
NOTE: The playback condition of some
DVD video discs may be determined by
a DVD video software producer. This
DVD player plays a disc as the soft-
ware producer intended. So some
functions may not work properly. Be
sure to read the manual for the DVD
video disc separately provided. For
the detailed information about DVD
video discs, see “(c) DVD player and
DVD video disc information” on page
222.
z Precautions on DVD video disc
When recording with a DVD video, audio
tracks may not record in some cases
while the menu is displayed. As audio
will not play in this case, verify that the
video tracks are playing and then acti-
vate playback.
When playback of a disc is completed:
z If a DVD video is playing, playback
will stop or the menu screen will be
displayed.
The title/chapter number and playback
time display may not appear while play-
ing back certain DVD video discs.
CAUTION
Conversational speech on some
DVDs is recorded at a low volume to
emphasize the impact of sound ef-
fects. If you adjust the volume as-
suming that the conversations rep-
resent the maximum volume level
that the DVD will play, you may be
startled by louder sound effects or
when you change to a different au-
dio source. The louder sounds may
have a significant impact on the
human body or pose a driving haz-
ard. Keep this in mind when you
adjust the volume.



— DVD
player operation

AUDIO/VIDEO SYSTEM
211
V573_E

z Playing a DVD video disc
Insert a DVD in the disc slot to auto-
matically turn on the power and play the
DVD. The DVD can also be played by
pushing the “AV” button with a DVD in
the disc slot and then touching “Disc”.

INFORMATION
Please note that there are certain
discs that do not playback auto-
matically, or do not playback unless
an item from the menu recorded on
the disc is selected. “Description of
DVD controls” (See page 212.)
z
Displaying DVD controls


If you touch a part of the screen, while
watching video, DVD controls will ap-
pear.
“Page 2”: Touching this will display on
the second page of DVD controls.
“Page 1”: Touching this will display the
top page of DVD controls.
“Hide Buttons”: Touching this will turn
off the controls from the screen.

INFORMATION
Each touch screen button displays
for approximately 6 seconds when
changed to the DVD operation
screen. Touch the screen to redis-
play the switches.

AUDIO/VIDEO SYSTEM
212
V573_E
z Description of DVD controls
TOP PAGE OF DVD VIDEO
CONTROLS
“Return”: Touching this will return to the
predetermined scene and start playing
from there.
“Search”: The title search screen ap-
pears. (See page 214.)
: Touch to pause the video screen.
: Touching this will stop the DVD
video disc.
: Touching this will resume normal
play after stop or pause.
: Touching this will fast reverse.
: Touch to fast forward during play-
back. Touch briefly while paused to
play slowly.
SECOND PAGE OF DVD VIDEO
CONTROLS
“Setup”: Touching this button will allow
you to change the screen size and set
the default settings. (See pages 216 and
217.)
“Top Menu” and “Menu”: If you touch
either button, the menu screen for DVD
video appears. (For the operation, see
the manual that come with the DVD
video disc provided separately.)
“Subtitle”: The subtitle changing screen
appears. (See page 215.)
“Audio”: The audio changing screen
appears. (See page 215.)
“Angle”: The angle selection screen
appears. (See page 216.)
: The menu control key appears on
the screen. (See page 213.)
z
Selecting a menu item
The menu stored on the disc can be op-
erated.
For details, see the manual that comes
with the DVD video disc provided sepa-
rately.
DISPLAYING THE DISC MENU
If the disc menu does not display when
the disc is loaded, the following method
can be used to display the menu.
1. Touch “Page 2”.
2. Touch either “Top Menu” or
“Menu”.
The touch screen button display area
moves UP or DOWN each time you
touch the “Layout”.
Operating from the direct touch op-
eration screen —
If the disc menu displays when the
disc is loaded, selections can be
made by touching the menu icons
directly.

AUDIO/VIDEO SYSTEM
213
V573_E

Operating with the touch screen but-
ton —

1. Touch “Key”.
The disc menu items will vary depending
on the disc. Furthermore, discs are
played based on the disc content and
therefore there may be times when the
selected operation does not function as
expected.
2. Touch “Page 2”.


3. Touch .

4. Touch , , , or to
select a menu.
Touch “Direct” to enable direct touch
operation.
When you touch
, the previous
screen returns.
5. Touch “Enter”.

AUDIO/VIDEO SYSTEM
214
V573_E
z Searching for desired footage
The desired video footage can be
searched for by title, chapter, or menu
number (number used to separate the
disc content).




SEARCHING BY CHAPTER
When you push the “ S” or “ T” button of
“TRACK/TUNE” , you can select a chap-
ter.
SEARCHING BY TITLE NUMBER
1. Touch “Search”.

2. Touch “+”, “ −”, “+10”, or “ −10”
and input the title number.
When you touch
, the previous
screen returns.
3. Touch “Enter”.
Playback is commenced from the input
title number.
SEARCHING BY MENU NUMBER
1. Touch
.

2. Touch “Code” to display the
menu number input screen.

3. Touch “+”, “
−”, “+10”, or “ −10”
and input the menu number.
When you touch
, the previous
screen
returns.
4. Touch “Enter”.

AUDIO/VIDEO SYSTEM
215
V573_E

z Changing the subtitle language

Each time you touch “Subtitle”, the
language is selected from the ones
stored in the discs and changed.
z
Changing the audio language

Each time you touch “Audio”, the lan-
guage is selected from the ones
stored in the discs and changed.

AUDIO/VIDEO SYSTEM
216
V573_E
z Changing the angle

The angle can be selected for discs that
are multi −angle compatible when the
angle mark appears on the screen.
Each time you touch “Angle”, the an-
gle changes.
z
Selecting screen size
1. Touch “Setup”.
2. Touch “Wide Mode” to display the
wide mode optional screen.

3. Touch “Normal”, “Wide”, or
“Zoom”.
“Normal”: Displays the 3 (H) × 4 (W)
screen with the remaining area at both
edges in black.
“Wide”: Displays the 3 (H) × 4 (W)
screen with the screen widened left and
right in the same ratio to fill the display
horizontally.
“Zoom”: Displays the 3 (H) × 4 (W )
screen with the screen stretched verti-
cally and horizontally in the same ratio to
fill the display.
Change to this mode to display a 9 (H) ×
16 (W) screen.
When you touch
, the previous
screen returns.

AUDIO/VIDEO SYSTEM
217
V573_E

NOTICE
There are no issues regarding the
viewing of visual material in wide−
screen format provided that it is for
personal use. However, compress-
ing or enlarging the screen for
commercial purposes, or to make
material available for public viewing,
may infringe upon the rights of the
author as protected by copyright
laws, and therefore care should be
exercised.

z
Default setting
1. Touch “Setup”

2. Touch “Default Setting” to display
the “Default setting” screen.

The initial setting can be changed.
After you change the initial setting, touch
“Enter” . The previous picture will be
displayed.

INFORMATION
If one of the switches used to
change the screen (“AV”) is pushed
without touching “Enter” after
changing settings at the default set-
tings screen, DVD playback will
stop. Touch
at the video op-
eration screen to resume playback.
(See page 212.)

AUDIO/VIDEO SYSTEM
218
V573_E
AUDIO LANGUAGE
You can change the audio language.
1. Touch “Audio Lang.”.
2. Touch the language you want to
hear on the “Select audio language”
screen.
If you cannot find the language you want
to hear on this screen, touch “Other”
and enter a language code. For the entry
of language code, see page 219.
SUBTITLE LANGUAGE
You can change the subtitle language.
1. Touch “Subtitle Lang.”.
2. Touch a language you want to
read on the “Select subtitle language”
screen.
If you cannot find the language you want
to read on this screen, touch “Other”
and enter a language code. For the entry
of language code, see page 219.
DVD LANGUAGE
You can change the language on the
DVD video menu.
1. Touch “Menu Lang.”.
2. Touch the language you want to
read on the “Select menu language”
screen.
If you cannot find the language you want
to read on this screen, touch “Other”
and enter a language code. For the entry
of language code, see page 219.
ANGLE ICON
The multi
−angle mark can be turned on
or off on the screen while the disc which
is multi −angle compatible is being
played.
Each time you touch “Angle Icon”, the
angle mark on the screen turns on or off
alternately.
PARENTAL LOCK
The level of viewer restrictions can be
changed.
1. Touch “Parental Lock”.
2. Enter the 4 −digit personal code
on the “Enter Personal Code” screen
and then touch “Enter”.
If you enter the wrong numbers, touch
to delete the numbers.
10 touches of
will initialized the per-
sonal code.
3. Touch a parental level (1—8) on
the “Select restriction level”.
4. Touch “Enter”.

AUDIO/VIDEO SYSTEM
219
V573_E

CHANGING THE VIDEO OUTPUT
The screen size changes each time
“Screen Aspect” is touched.
“16:9”: The screen displays in the nor-
mal wide size.
In the case of DVD software recorded
with a screen size of 4:3, both the left
and right edges display in black, or the
screen is stretched to the left and right.
“4:3 Letter Box”: The upper and lower
edges of the screen display in black.
In the case of DVD software recorded
with a screen size of 4:3, the video fits
the screen size perfectly (4:3).
“4:3 Pan Scan”: Both the left and right
edges of the screen are cut.
In the case of DVD software recorded
with a screen size of 4:3, the video fits
the screen size perfectly (4:3).

NOTICE
There are no issues regarding the
viewing of visual material in wide −
screen format provided that it is for
personal use. However, compress-
ing or enlarging the screen for
commercial purposes, or to make
material available for public viewing,
may infringe upon the rights of the
author as protected by copyright
laws, and therefore care should be
exercised.
z
Enter language code
If you touch “Other” on the “Select au-
dio language” screen, “Select subtitle
language” screen or “Select menu lan-
guage” screen, you can select the lan-
guage you want to hear or read by en-
tering a language code.

1. Enter the 4 −digit language code.
If you enter the wrong numbers, touch
to delete the numbers.
2. Touch “Enter”.

Code Language
1001 Japanese
0514 English
0618 French
0405 German
0920 Italian
0519 Spanish
2608 Chinese
1412 Dutch
1620 Portuguese
1922 Swedish
1821 Russian
1115 Korean
0512 Greek
