6-3
PERIODIC MAINTENANCE AND MINOR REPAIR
6
9
*Wheels•Check runout, spoke tightness and for damage.
•Tighten spokes if necessary.√√√√
10*Tires•Check tread depth and for damage.
•Replace if necessary.
•Check air pressure.
•Correct if necessary.√√√√ √
11*Wheel bearings•Check bearing for looseness or damage.√√√√
12*Swingarm•Check operation and for excessive play.√√√√
13 Drive chain•Check chain slack.
•Make sure that the rear wheel is properly aligned.
•Clean and lubricate.Every 500 km and after washing
the motorcycle or riding in the rain.
14*Steering bearings•Check bearing play and steering for roughness.√√√√√
•Lubricate with lithium-soap-based grease.Every 24,000 km
15*Chassis fasteners•Make sure that all nuts, bolts and screws are properly tightened.√√√√ √
16 Sidestand•Check operation.
•Lubricate.√√√√ √
17*Sidestand switch•Check operation.√√√√√ √
18*Front fork•Check operation and for oil leakage.√√√√
19*Shock absorber
assembly•Check operation and shock absorber for oil leakage.√√√√
20*Rear suspension relay
arm and connecting arm
pivoting points•Check operation.√√√√
•Lubricate with lithium-soap-based grease.√√ NO. ITEM CHECK OR MAINTENANCE JOBODOMETER READING (× 1,000 km)
ANNUAL
CHECK
1 6 12 18 24
3MB-9-E8 6/13/01 10:55 AM Page 40
Page 42 of 96
6-4
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03884
NOTE:
8The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
8Hydraulic brake service
9Regularly check and, if necessary, correct the brake fluid level.
9Every two years replace the internal components of the brake master cylinders and calipers, and change the
brake fluid.
9Replace the brake hoses every four years and if cracked or damaged.21
*Carburetor•Check starter (choke) operation.
•Adjust engine idling speed.√√√√√ √
22*Autolube pump•Check operation.
•Bleed if necessary.√√√√
23 Transmission oil•Check oil level.√√√√√ √
•Change.√√
24*Cooling system•Check coolant level and vehicle for coolant leakage.√√√√ √
•Change.Every 3 years
25*Front and rear brake
switches•Check operation.√√√√√ √
26 Moving parts and cables•Lubricate.√√√√ √
27*Lights, signals and
switches•Check operation.
•Adjust headlight beam.√√√√√ √ NO. ITEM CHECK OR MAINTENANCE JOBODOMETER READING (× 1,000 km)
ANNUAL
CHECK
1 6 12 18 24
3MB-9-E8 6/13/01 10:55 AM Page 41
Page 43 of 96
6-5
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU01065
Removing and installing
cowlingsThe cowlings shown above need to
be removed to perform some of the
maintenance jobs described in this
chapter.
2
1
1. Cowling A
2. Cowling B
EAU01534
Cowling A
To remove the cowlingRemove the cowling screws, and
then pull the cowling off as shown.
1
1. Screw (×2)
Refer to this section each time a
cowling needs to be removed and
installed.
1
1. Cowling C
3MB-9-E8 6/13/01 10:55 AM Page 42
Page 44 of 96
6-6
PERIODIC MAINTENANCE AND MINOR REPAIR
6 To install the cowling
Place the cowling in the original posi-
tion, and then install the screws.
To install the cowlingPlace the cowling in the original posi-
tion, and then install the screws.
EAU01534
Cowling B
To remove the cowlingRemove the cowling screws, and
then pull the cowling off as shown.
1
1. Screw (×3)
3MB-9-E8 6/13/01 10:55 AM Page 43
Page 45 of 96
6-7
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU01534
Cowling C
To remove the cowlingRemove the cowling screws, and
then pull the cowling off as shown.
1
1. Screw (×3)
EAU01122
Removing and installing
panelsThe panels shown above need to be
removed to perform some of the
maintenance jobs described in this
chapter.
1
1. Panel A
To install the cowlingPlace the cowling in the original posi-
tion, and then install the screws.
3MB-9-E8 6/13/01 10:55 AM Page 44
Page 46 of 96
6-8
PERIODIC MAINTENANCE AND MINOR REPAIR
6 Refer to this section each time a
panel needs to be removed and
installed.
1
1. Panel B
To install the panelPlace the panel in the original posi-
tion, and then install the screw.
1
2
1. Screw
2. Panel B
EAU04003
Panels A and B
To remove one of the panelsRemove the screw, and then pull the
panel off as shown.
1
2
1. Screw
2. Panel A
3MB-9-E8 6/13/01 10:55 AM Page 45
Page 47 of 96
6-9
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU01833
Checking the spark plugThe spark plug is an important
engine component, which is easy to
check. Since heat and deposits will
cause any spark plug to slowly erode,
the spark plug should be removed
and checked in accordance with the
periodic maintenance and lubrication
chart. In addition, the condition of the
spark plug can reveal the condition of
the engine.
To remove the spark plug
1. Remove the spark plug cap.
1
1. Spark plug cap
To check the spark plug
1. Check that the porcelain insula-
tor around the center electrode
of the spark plug is a medium-to-
light tan (the ideal color when the
motorcycle is ridden normally).NOTE:
If the spark plug shows a distinctly
different color, the engine could be
defective. Do not attempt to diagnose
such problems yourself. Instead,
have a Yamaha dealer check the
motorcycle.2. Check the spark plug for elec-
trode erosion and excessive car-
bon or other deposits, and
replace it if necessary. 2. Remove the spark plug as
shown, with the spark plug
wrench included in the owner’s
tool kit.
1
1. Spark plug wrench
Specified spark plug:
BR9ES (NGK)
BR8ES (NGK) (CH, A only)
3MB-9-E8 6/13/01 10:55 AM Page 46
Page 48 of 96
6-10
PERIODIC MAINTENANCE AND MINOR REPAIR
6 To install the spark plug
1. Measure the spark plug gap with
a wire thickness gauge and, if
necessary, adjust the gap to
specification.
2. Clean the surface of the spark
plug gasket and its mating sur-
face, and then wipe off any grime
from the spark plug threads.
3. Install the spark plug with the
spark plug wrench, and then
tighten it to the specified torque.
a
a. Spark plug gap
EAU04272
Transmission oilThe transmission oil level should be
checked before each ride. In addition,
the transmission oil must be changed
at the intervals specified in the peri-
odic maintenance and lubrication
chart.
To check the transmission oil level
1. Place the motorcycle on a level
surface and hold it in an upright
position.NOTE:
Make sure that the motorcycle is
positioned straight up when checking
the oil level. A slight tilt to the side
can result in a false reading.2. Start the engine, warm it up for
several minutes, and then turn it
off.
NOTE:
If a torque wrench is not available
when installing a spark plug, a good
estimate of the correct torque is
1/4–1/2 turn past finger tight.
However, the spark plug should be
tightened to the specified torque as
soon as possible.4. Install the spark plug cap.
Spark plug gap:
0.7–0.8 mmTightening torque:
Spark plug:
20 Nm (2.0 m0kgf)
3MB-9-E8 6/13/01 10:55 AM Page 47
Page 49 of 96
6-11
PERIODIC MAINTENANCE AND MINOR REPAIR
63. Wait a few minutes until the oil
settles, and then check the oil
level through the check window
located at the right side of the
crankcase.
NOTE:
The transmission oil should be at or
above the minimum level mark.4. If the oil is below the minimum
level mark, remove the oil filler
cap, add sufficient oil of the rec-
ommended type to raise it to the
correct level, and then install and
tighten the cap.
1
2
1. Transmission oil level check window
2. Minimum level mark
4. Install the transmission oil drain
bolt, and then tighten it to the
specified torque.
5. Add the specified amount of the
recommended transmission oil,
and then install and tighten the
oil filler cap.
1
1. Transmission oil drain bolt
To change the transmission oil
1. Start the engine, warm it up for
several minutes, and then turn it
off.
2. Place an oil pan under the trans-
mission to collect the used oil.
3. Remove the oil filler cap and
drain bolt to drain the oil from the
transmission.
1
1. Oil filler cap
Tightening torque:
Transmission oil drain bolt:
15 Nm (1.5 m0kgf)
3MB-9-E8 6/13/01 10:55 AM Page 48
Page 50 of 96
6-12
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EC000077
cC8In order to prevent clutch slip-
page (since the transmission
oil also lubricates the clutch),
do not mix any chemical addi-
tives with the oil.
8Make sure that no foreign
material enters the transmis-
sion.6. Start the engine, and then let it
idle for several minutes while
checking the transmission for oil
leakage. If oil is leaking, immedi-
ately turn off the engine and
check for the cause.
EAU01808
CoolantTo check the coolant level
1. Place the motorcycle on a level
surface and hold it in an upright
position.NOTE:
8The coolant level must be
checked on a cold engine since
the level varies with engine tem-
perature.
8Make sure that the motorcycle is
positioned straight up when
checking the coolant level. A
slight tilt to the side can result in
a false reading.
2. Remove panel A. (See page 6-8
for panel removal and installation
procedures.)
3. Check the coolant level in the
coolant reservoir.NOTE:
The coolant should be between the
minimum and maximum level marks.
2
1
1. Maximum level mark
2. Minimum level mark
Recommended transmission oil:
See page 8-1.
Oil quantity:
Periodic oil change:
0.75 L
Total amount (dry transmission):
0.8 L
