The shift timing indicator light has three set-
tings which can be adjusted.
Flashing pattern: this function allows you to
choose whether or not the indicator light
will come on and whether it should flash or
stay on when activated.
 Activation point: this function allows you to
select the engine speed at which the indi-
cator light is activated.
 Deactivation point: this function allows you
to select the engine speed at which the in-
dicator light is deactivated.
To adjust the shift timing indicator light1. Turn the key to “ ” (off).
2. Push and hold the “MODE” button.
3. Turn the key to “ ” (on), and then re- lease the “MODE” button after five sec-
onds. After all segments of the display
disappear and the shift timing indicator
light comes on, the shift timing indicator
light can be adjusted. To set the flashing pattern
1. Push the “RESET” button to select one of
the following flashing pattern settings:
On: the indicator light stays on when
activated. (The indicator light will con-
firm this setting by staying on.)
 Flash: the indicator light flashes when
activated. (The indicator light will con-
firm this setting by flashing four times
per second.)
 Off: the indicator light is deactivated; in
other words, it does not come on or
flash. (The indicator light will confirm
this setting by flashing once every two
seconds.)
2. Push the “MODE” button to confirm the selected flashing pattern. The control
mode changes to the activation point set-
ting mode. The shift timing indicator light
remains on and the tachometer shows
the current setting r/min for the activation
point.
U2HC7LE0.book Page 13 Wednesday, October 7, 2015 12:09 PM

4-14
4
To set the shift activation pointTIPThe shift timing indicator light activation
point can be set between 7000 r/min and
12000 r/min. The activation point can be set
in increments of 500 r/min.
 The tachometer needle will start over at
7000 r/min after 12000 r/min. 1. Push the “RESET” button to select the
desired engine speed for activating the
indicator light.
2. Push the “MODE” button to confirm the
selected engine speed. The shift timing
indicator light flashes and the tachometer
shows the current setting r/min for the
deactivation point. To set the deactivation point
TIP
The shift timing indicator light deactivation
point can be set between 7000 r/min and
12000 r/min. The deactivation point can be
set in increments of 500 r/min.
 Be sure to set the deactivation point to a
higher engine speed than for the activation
point, otherwise the shift timing indicator
light will not come on.
 The tachometer needle will start over at
7000 r/min after 12000 r/min. 1. Push the “RESET” button to select the
desired engine speed for deactivating the
indicator light.
2. Push the “MODE” button to confirm the selected engine speed. The display exits
the shift timing light control mode and re-
turns to the standard multi-function dis-
play mode.
U2HC7LE0.book Page 14 Wednesday, October 7, 2015 12:09 PM

4-15
4
EBU35470Light switch “ / / ”Set the switch to “ ” to turn on the low
beam and the taillight.
Set the switch to “ ” to turn on the high
beam and the taillight.
Set the switch to “ ” to turn off the head-
lights and taillight.NOTICEECB02060Do not use the headlights with the engine
turned off for an extended period of time.
The battery may discharge to the pointthat the starter motor will not operate
properly. If this should happen, remove the
battery and recharge it.
EBU31400On-Command drive knob
“2WD/4WD/DIFF LOCK”This vehicle is equipped with an On-Com-
mand drive knob to select the drive mode.
The knob has three positions: “2WD”, “4WD”,
and “DIFF LOCK”. Select the appropriate
drive according to terrain and conditions.
1. Light switch “ / / ”
L
H
1
L
HLH
1. On-Command drive knob “2WD/4WD/DIFF LOCK”
1
U2HC7LE0.book Page 15 Wednesday, October 7, 2015 12:09 PM

4-16
4
“2WD” (two-wheel drive): Power is supplied
to the rear wheels only.
 “4WD” (four-wheel drive): Power is sup-
plied to the rear and front wheels.
 “DIFF LOCK” (four-wheel drive with the dif-
ferential gear locked): Power is supplied to
the rear and front wheels with the differen-
tial gear locked. Unlike the “4WD” mode, all
wheels turn at the same speed regardless
of traction.EBU34961Reverse gear lock lever “REV.”To prevent the transmission from being acci-
dently shifted into reverse, this model is
equipped with a reverse gear lock mecha-
nism. To release the lock and be able to shift
the transmission into reverse, pull this lever
towards you.TIPSee page 6-5 for information on driving in re-
verse.
EBU31411Accelerator pedalPress the accelerator pedal to increase en-
gine speed. Spring tension returns the pedal
to the rest position when released. Always
check that the accelerator pedal returns nor-
mally before starting the engine.1. Reverse gear lock lever “REV.”
1
U2HC7LE0.book Page 16 Wednesday, October 7, 2015 12:09 PM

4-17
4
EBU34970Clutch pedalPress the clutch pedal to disengage the
clutch. To engage the clutch, release the
clutch pedal. The clutch pedal should be
pressed rapidly and released slowly for
smooth clutch operation.
EBU31420Brake pedalPress the brake pedal to slow or stop the ve-
hicle.
1. Accelerator pedal
1
1. Clutch pedal
1
U2HC7LE0.book Page 17 Wednesday, October 7, 2015 12:09 PM

4-18
4
EBU35640Parking brake leverThe parking brake lever is located at the right
side of the driver’s seat. Setting the parking
brake lever will help keep the vehicle from
moving while parked.
To set the parking brake, pull the lever up-
ward firmly.
To release the parking brake, pull slightly up-
ward on the lever, press the release button,
and then push the lever all the way down.
TIPSpring tension helps return the lever to the
released position.
 If you drive the vehicle with the parking
brake engaged, a buzzer will sound.
1. Brake pedal
1
1. Release button
2. Parking brake lever
12
U2HC7LE0.book Page 18 Wednesday, October 7, 2015 12:09 PM

4-19
4
EBU34981Shift leverThis model is equipped with a 5-speed se-
quential transmission with reverse gear. The
shift lever is used in combination with the
clutch pedal when shifting. See page 6-3 for
shift lever operation.
EBU31450Fuel tank capTo openRemove the fuel tank cap by turning it coun-
terclockwise.
To closeInstall the fuel tank cap by turning it clock-
wise.
1. Shift lever
1
1. Fuel tank cap
1
U2HC7LE0.book Page 19 Wednesday, October 7, 2015 12:09 PM

4-20
4
EBU35290DoorsThe door handle is located on the inside of
each door.
To open a door, pull the handle. To close a
door, push or pull the door inward until it is
securely latched. Be sure the door is SE-
CURELY LATCHED AFTER CLOSING IT.TIPWhen opening a door from the outside, use
the “ ” mark to locate the door handle.
EBU33461SeatsTo remove a seat cushion, lift the front of the
cushion, and then pull the cushion off.1. Door
2. Handle
3. “ ” mark
1
3
2
U2HC7LE0.book Page 20 Wednesday, October 7, 2015 12:09 PM

4-21
4
To install a seat cushion, insert the projec-
tions on the rear of the seat cushion under the
seat frame, and then insert the projection on
the front of the cushion into the grommet
while pushing the cushion downward. Make
sure the seats are properly secured before
starting off. WARNING! A loose seat could
cause the operator to lose control, or cau-
se the operator or passenger to fall.
[EWB03510]
1. Driver seat cushion
1. Passenger seat cushion
1
1
U2HC7LE0.book Page 21 Wednesday, October 7, 2015 12:09 PM

4-22
4
EBU34993Adjusting the driver seat positionThe driver seat position can be adjusted to
suit the driver’s preference. WARNING! Nev-
er adjust the seat position while operating
the vehicle, otherwise the seat may sud-
denly change position, which may lead to
an accident.
[EWB03990]
To adjust the driver seat position, pull the
driver seat position adjusting lever upward
and move the seat to the desired position.
TIPAdjust the driver seat position and make sure
it is locked in place before starting off. EBU35002Adjusting the steering wheel positionThe steering wheel position can be adjusted
to suit the driver’s preference. WARNING!
Never adjust the steering wheel position
while operating the vehicle, otherwise the
steering wheel may suddenly change posi-
tion, which may lead to an accident.
[EWB04000]
To adjust the steering wheel position, pull the
steering wheel position adjusting lever and
move the steering wheel to the desired posi-
tion.
1. Driver seat position adjusting lever
1
