Install battery2, negative ter-
minal first.
Engage retaining strap1.
Install the right side panel
( 99)
Set the clock ( 29)Removing right side panelMake sure the ground is level
and firm and place the motor-
cycle on its stand.
Remove the seat ( 41)Remove screw1at the front
right.
Remove screws2.
Begin by pulling the side panel
out of holder3, then pull it tothe rear to disengage it from
holder4.
Remove the side panel.
Installing right side panelBegin by seating the side pan-
el in holder4, then seat it in
holder3.
899zMaintenance

Install screws2.
Install screw1at the front
right.
Install the seat ( 42)
Number-plate carrierRemoving number-plate
carrierMake sure the ground is level
and firm and place the motor-
cycle on its stand.
Remove four screws1.Disconnect plug2.
Release the number-plate car-
rier with wire loop3and re-
move, working plug2with the
cable free.
8100zMaintenance

Installing number-plate
carrierManoeuvre the cable into po-
sition, hold the number-plate
carrier in position and push it
up.
Pin4engages with an audible
click.Install four screws1.
Connect plug2.
8101zMaintenance

8102zMaintenance

Care
Care
Care products..................... 104
Washing motorcycle............... 104
Cleaning easily damaged compon-
ents ................................ 104
Paint care.......................... 105
Protective wax coating . . ........... 106
Laying up motorcycle.............. 106
Restoring motorcycle to use . ...... 106
9103zCare

Care productsBMW Motorrad recommends
that you use the cleaning and
care products you can obtain
from your authorised BMW Mo-
torrad dealer. The substances in
BMW Care Products have been
tested in laboratories and in prac-
tice; they provide optimised care
and protection for the materials
used in your vehicle.
The use of unsuitable
cleaning and care products
can damage vehicle components.
Do not use solvents such as cel-
lulose thinners, cold cleaners,
fuel or the like, and do not use
cleaning products that contain
alcohol.Washing motorcycleBMW Motorrad recommends
that you use BMW insect re-
mover to soften and wash off
insects and stubborn dirt onpainted parts prior to washing
the motorcycle.
To prevent stains, do not wash
the motorcycle immediately after
it has been exposed to strong
sunlight and do not wash it in the
sun.
Make sure that the motorcycle
is washed frequently, especially
during the winter months.
To remove road salt, clean the
motorcycle with cold water im-
mediately after every trip.
After the motorcycle has
been washed, ridden
through water or ridden in
the rain, the brake discs and
pads might be wet and the
brakes might not take effect
immediately.
Apply the brakes in good time
until the brakes have dried out.
Warm water intensifies the
effect of salt.Use only cold water to wash off
road salt.
The high pressure of steam
cleaners can damage seals,
the hydraulic brake system, the
electrical system, and the seat.
Do not use a steam jet or high-
pressure cleaning equipment.
Cleaning easily
damaged componentsPlasticsClean plastic parts with water
and BMW plastic care emulsion.
This includes in particular:
Windscreen and slipstream de-
flectors
Headlight lens made of plastic
Glass cover of the instrument
cluster
Black, unpainted parts
If plastic parts are cleaned
using unsuitable cleaning
9104zCare

agents, the surfaces can be dam-
aged.
Do not use cleaning agents that
contain alcohol, solvents or ab-
rasives to clean plastic parts.
Even fly-remover pads or clean-
ing pads with hard surfaces can
produce scratches.
Soften stubborn dirt and
insects by covering the af-
fected areas with a wet cloth.ChromeUse plenty of water and BMW
shampoo to clean chrome, par-
ticularly if it has been exposed to
road salt. Use chrome polish for
additional treatment.RadiatorClean the radiator regularly to
prevent overheating of the en-
gine due to inadequate cooling.
For example, use a garden hose
with low water pressure.Cooling fins can be bent
easily.
Take care not to bend the fins
when cleaning the radiator.
RubberTreat rubber components with
water or BMW rubber-care
products.
Using silicone sprays for
the care of rubber seals can
cause damage.
Do not use silicone sprays or
other care products that contain
silicon.Paint careWashing the motorcycle regularly
will help counteract the long-term
effects of substances that dam-
age the paint, especially if your
motorcycle is ridden in areas
with high air pollution or natural
sources of dirt, for example tree
resin or pollen.Remove particularly aggressive
substances immediately, how-
ever, as otherwise the paint can
be affected or become discol-
oured. Substances of this nature
include spilt fuel, oil, grease,
brake fluid and bird droppings.
We recommend BMW vehicle
polish or BMW paint cleaner for
this purpose.
Marks on the paintwork are par-
ticularly easy to see after the
motorcycle has been washed.
Remove stains of this kind im-
mediately, using cleaning-grade
benzene or petroleum spirit on a
clean cloth or ball of cotton wool.
BMW Motorrad recommends
BMW tar remover for removing
specks of tar. Remember to wax
the parts treated in this way.
9105zCare

Protective wax coatingBMW Motorrad recommends
applying only BMW car wax or
products containing carnauba
wax or synthetic wax.
It is time to rewax the paint-
work when water "puddles" on
the surface, instead of forming
beads.Laying up motorcycleClean the motorcycle.
Remove the battery.
Spray the brake and clutch
lever pivots, the side stand
pivots and the centre stand
pivots (if the motorcycle is fit-
ted with a centre stand) with a
suitable lubricant.
Coat bright metal and chrome-
plated parts with an acid-free
grease (e.g. Vaseline).
Stand the motorcycle in a dry
room in such a way that there
is no load on either wheel.Before laying the vehicle
up out of use, have the en-
gine oil and the oil filter element
changed by a specialist work-
shop, preferably an authorised
BMW Motorrad dealer. Com-
bine work for laying up/restoring
to use with a BMW service or
inspection.
Restoring motorcycle
to useRemove the protective wax
coating.
Clean the motorcycle.
Install a charged battery.
Before starting: work through
the checklist.
Before removing the auxiliary
stand, check the air pressure in
the Air Damping System and
adjust if necessary.
9106zCare

Technical data
Technical data
Troubleshooting chart . . ........... 108
Threaded fasteners ................ 109
Engine . . ........................... 110
Fuel ................................ 111
Engine oil.......................... 111
Clutch . . ........................... 112
Transmission ...................... 112
Rear-wheel drive................... 113
Running gear ...................... 113
Brakes . . ........................... 114
Wheels and tyres . . ................ 115
Electrics ........................... 117
Frame . . ........................... 118
Dimensions . . ...................... 119
Weights . ........................... 119Riding specifications............... 120
10107zTechnical data

Troubleshooting chartEngine does not start at all or is difficult to start.Possible cause RemedyKill switch activated. Kill switch in operating position (run).
Side stand extended and gear engaged. Retract the side stand ( 46).
Gear engaged and clutch not disengaged. Select neutral or pull clutch lever ( 46).
No fuel in tank. Refuelling ( 52)
Battery not adequately charged. Charge the battery when connected ( 97)
10108zTechnical data
