BMW MOTORRAD G 650 XCHALLENGE 2007 Rider's Manual (in English)

If the wear indicating marks are
no longer clearly visible:
Have the brake pads replaced
by a specialist workshop,
preferably an authorised BMW
Motorrad dealer.Checking rear brake pad
thicknessMake sure the ground is level
and firm and place the motor-
cycle on its stand.
Brake pads worn past
the minimum permissible
brake-pad thickness can cause
a reduction in braking efficiencyand under certain circumstances
they can cause damage to the
brake system.
In order to ensure the dependab-
ility of the brake system, do not
permit the brake pads to wear
past the minimum permissible
brake-pad thickness.
Visually inspect rear brake
pads1from behind to
ascertain their thickness.
Brake-pad wear limit, rear
min 1 mm (Friction pad only,
without backing plate)Brake-pad wear limit, rear
The wear indicators must be
clearly visible.
If the wear indicating marks are
no longer visible:
Have the brake pads replaced
by a specialist workshop,
preferably an authorised BMW
Motorrad dealer.
Brake fluidChecking brake-fluid
level, front brakesMake sure the ground is level
and firm and hold the motor-
cycle upright.
Move the handlebars to the
straight-ahead position.
869zMaintenance

A low fluid level in the
brake reservoir can allow air
to penetrate the brake system.
This significantly reduces braking
efficiency.
Check the brake-fluid level at
regular intervals.
Check the brake fluid level in
front reservoir1.
Wear of the brake pads
causes the brake fluid level
in the reservoir to sink.Brake fluid level, front
DOT4 brake fluid
Do not permit the brake fluid
level to drop below the MIN
mark. (Brake-fluid reservoir
horizontal)
If the brake fluid level drops be-
low the permitted level:
Have the defect rectified as
quickly as possible by a spe-
cialist workshop, preferably
an authorised BMW Motorrad
dealer.
Checking brake-fluid
level, rear brakes
A low fluid level in the
brake reservoir can allow air
to penetrate the brake system.
This significantly reduces braking
efficiency.
Check the brake-fluid level at
regular intervals.
Check the brake fluid level in
rear reservoir1.
Wear of the brake pads
causes the brake fluid level
in the reservoir to sink.
870zMaintenance

Brake fluid level, rear
DOT4 brake fluid
Do not permit the brake fluid
level to drop below the MIN
mark. (Brake-fluid reservoir
horizontal)
If the brake fluid level drops be-
low the permitted level:
Have the defect rectified as
quickly as possible by a spe-
cialist workshop, preferably
an authorised BMW Motorrad
dealer.
CoolantChecking coolant levelMake sure the ground is level
and firm and hold the motor-
cycle upright.
Read off the coolant level on
scale1on the coolant expan-
sion tank.Coolant, specified level
Between MIN and MAX
marks on the expansion tank
If the coolant level is too low:
Top up the coolant.
If the coolant level is too high:
Seek the advice of a specialist
workshop, preferably an author-
ised BMW Motorrad dealer.
871zMaintenance

Topping up coolantPull cover of radiator cap1for-
ward to remove.
Open cap of the expansion
tank for coolant2.Top up the coolant to the spe-
cified level.
Close the cap of the expansion
tank for coolant.
Seat the cover of the radiator
cap in holders3. In this pro-
cess, guide the top edge of the
cover behind the bottom edge
of centre trim panel4.
ClutchChecking clutch-lever
playPull the clutch lever until resist-
ance is perceptible.
Measure clutch-lever playA.
Clutch-lever play
2...3 mm (Engine cold)
Clutch-lever play is out of toler-
ance:
Adjust clutch-lever play ( 73)
872zMaintenance

Adjusting clutch-lever
playPush back boot1.
Slacken locknut2.
Set clutch-lever play to spe-
cification by turning adjusting
screw3.
Turning clockwise: increases
play.
Turning counter-clockwise: re-
duces play.
Check the clutch-lever play
( 72)
Tighten locknut2.
Pull boot1back over the ad-
justing screw.
TyresChecking tyre tread depthMake sure the ground is level
and firm and place the motor-
cycle on its stand.
Measure the tyre tread depth
in the main tread grooves with
wear marks.
Tyres have wear indicators
integrated into the main
tread grooves. The tyre is worn
out when the tyre tread has worn
down to the level of the marks.
The locations of the marks are
indicated on the edge of the tyre,
e.g. by the letters TI, TWI or by
an arrow.
If the tyre tread no longer com-
plies with the minimum legally
required tread depth:
Replace tyre.
RimsChecking rimsMake sure the ground is level
and firm and place the motor-
cycle on its stand.
Visually inspect the rims for
defects.
Have damaged rims checked
and, if necessary, replaced by a
specialist workshop, preferably
an authorised BMW Motorrad
dealer.ChainLubricating chainSwitch the ignition off and se-
lect neutral.
Dirt, dust and inadequate
lubrication will result in ac-
celerated wear and significantly
shorten the drive chain's useful
life.
Clean and lubricate the drive
chain at regular intervals.
873zMaintenance

Clean the drive chain with a
suitable cleaning product, dry it
and apply chain lubricant.
Wipe off excess lubricant.Checking chain tensionMake sure the ground is level
and firm and place the motor-
cycle on its stand.
Use a screwdriver to push the
chain up and down and meas-
ure differenceA.Chain deflection
25...30 mm (Motorcycle sup-
ported on its side stand)
30...35 mm (Rear suspen-
sion extended)
If measured value is outside per-
mitted tolerance:
Adjust the chain tension
( 74)
Adjusting chain tensionMake sure the ground is level
and firm and place the motor-
cycle on its stand.Slacken quick-release axle
nut1.
Slacken locknuts2on left and
right by turning them counter-
clockwise.
Use adjusting screws3on left
and right to adjust chain ten-
sion.
Turning screws clockwise: re-
duces chain tension.
Turning screws counter-clock-
wise: increases chain tension.
Check the chain tension
( 74)
874zMaintenance

Make sure that scale read-
ings4are the same on left and
right.
Tighten locknuts2on left and
right by turning them clock-
wise.
Locknut of the final-drive
chain tensioning screw
25 Nm
Tighten quick-release axle
nut1to the specified tight-
ening torque.
Nut on quick-release
axle, rear
80 NmChecking chain wearMake sure the ground is level
and firm and place the motor-
cycle on its stand.Pull the chain back at the rear-
most point of the sprocket.
The tips of the sprocket teeth
must remain inside the chain
links.
If the chain can be pulled back
far enough to expose the tips of
the sprocket teeth:
Consult a specialist workshop,
preferably an authorised BMW
Motorrad dealer.
WheelsRecommended tyresFor each size of tyre BMW Mo-
torrad tests and classifies as
roadworthy certain makes. BMW
Motorrad cannot assess the suit-
ability or provide any guarantee
of road safety for other tyres.
BMW Motorrad recommends
using only tyres tested by BMW
Motorrad.
You can obtain detailed informa-
tion from your authorised BMW
Motorrad dealer or on the Inter-
net at www.bmw-motorrad.com.Removing front wheelPlace the motorcycle on a suit-
able auxiliary stand. BMW Mo-
torrad recommends the BMW
Motorrad auxiliary stand.
Install the auxiliary stand
( 81)
875zMaintenance

with OE BMW Motorrad ABS:
Remove screw1of the ABS
sensor and remove the ABS
sensor from the holder.
Use a suitable auxiliary stand to
lift the front wheel. BMW Mo-
torrad recommends the BMW
Motorrad front wheel stand.
Install the front wheel stand
( 82)Slacken left axle clamping
screws2.
Remove axle screw3.
Slacken right axle clamping
screws4.Use a screwdriver to remove
axle5.
Do not remove the grease from
the axle.
Hold left slider tube6and turn
the front wheel left to push the
brake pads apart.
Once the calipers have
been removed, there is
a risk of the brake pads being
pressed together to the extent
that they cannot be slipped back
over the brake disc on reas-
sembly.
Do not operate the handbrake
876zMaintenance

lever when the brake calipers
have been removed.
Roll the front wheel clear of the
forks.
Remove spacer sleeve7.
Installing front wheelInstall spacer sleeve7.
The front wheel must be
installed right way round to
rotate in the correct direction.
Note the direction-of-rotation ar-
rows on the tyre or the wheel
rim.
Roll the front wheel into posi-
tion between the forks, making
sure that the brake disc passes
between the brake pads.Install axle5.
Threaded fasteners not
tightened to the specified
torque can work loose or their
threads can suffer damage.
Always have the security of the
fasteners checked by a specialist
877zMaintenance

workshop, preferably an author-
ised BMW Motorrad dealer.
Tighten axle screw3to the
specified torque; if necessary
use a screwdriver to counter-
hold at the right-hand side.
Nut on quick-release
axle, front
80 Nm
Remove the front-wheel stand.
Without operating the brakes:
firmly compress the forks and
release; repeat the procedure
several times.
Tighten left axle clamping
screws2to the specified
tightening torque.
Front-axle retainer
10 NmTighten right axle clamping
screws4to the specified tight-
ening torque.
Front-axle retainer
10 Nmwith OE BMW Motorrad ABS:
Seat the ABS sensor in the
holder and install screw1of
the ABS sensor.
Remove the auxiliary stand.
Firmly pull the brake lever sev-
eral times to seat the brake
pads against the brake disc.
Removing rear wheelPlace the motorcycle on a suit-
able auxiliary stand. BMW Mo-
torrad recommends the BMW
Motorrad auxiliary stand.
878zMaintenance
