CADILLAC ESCALADE 2010 3.G Owners Manual

Adding or Changing Preset
Destinations
This feature allows additions or changes one of fivepreset destinations. When a destination has beenadded as a preset destination, it is available to selectfrom the Destination Entry screen. See“PresetDestination”previously for information on how to selecta preset destination as a final destination.
To store the current vehicle position as a presetdestination:
1. Select the Mark screen button from the mapscreen to add the current vehicle position to theaddress book. The Address Book screen appears.
2. Select the Name screen button. An alpha-keyboarddisplays. Enter the name. Press the OK screenbutton then the Back screen button to return to theaddress book information screen.
3. Press and hold one of the buttons at the bottom ofthe screen until the name appears in that presetdestination screen button. It is now available toselect from the Destination Entry screen.
To store an address book entry as a preset destination:
1. Select the CONFIG hard key.
2. Select the Nav screen button or press theCONFIG key until Nav is selected or touchthe Nav screen button.
3. Select the Edit/View screen button.
4. Select the address book entry to be storedas the preset destination. Select the Name screenbutton to add a name, if needed.
5. Press and hold one of the buttons at the bottom ofthe screen until the name appears in that presetdestination screen button. It is now available toselect from the Destination Entry screen.
5-41

Configure Menu
Press the CONFIG (Configure) hard key to adjustseveral of the system's features and preferences.The last selected CONFIG screen is the screen thatdisplays: Sound, Radio, Nav (navigation), Display,or Time.
Sound
Press the CONFIG key to enter the configure menuoptions, then press the CONFIG key repeatedly untilSound is selected or touch the Sound screen button tomake speaker and DSP (Digital Signal Processing)adjustments. See“Sound Menu”under,NavigationAudio Systemon page 5!60for more information.
Radio
Press the CONFIG key to enter the configure menuoptions, then press the CONFIG key repeatedly untilRadio is selected or touch the Radio screen button tomake changes for radio information displayed, presetpages, XM™categories, and Bose®AudioPilot®.See“Radio Menu”under,Navigation Audio Systemonpage 5!60for more information.
5-42

Nav (Navigation)
Press the CONFIG key to enter the configure menuoptions, then press the CONFIG key repeatedly untilNav is selected or touch the Nav screen button.
Voice Prompt
Voice Prompt :Touch the Voice Prompt screen buttonto change the volume of the voice prompts or to turnvoice guidance on and off.
Volume :Touch the + (plus) or!(minus) screen buttonsto increase or to decrease the volume of the voiceprompts. The system will respond with the adjustedvoice level.
Voice Guidance :Touch the On or Off screen buttonsto turn voice instructions on and off while traveling ona planned route.
Route Preference
Touch the Route Preference screen button to changeroute options when the system calculates a route.
Allow Major Roads :This feature allows the system touse major roads when calculating a planned route.
Allow toll road :This feature allows the system to usetoll roads when calculating a planned route.
Allow ferry :This feature allows the system to useferries when calculating a planned route.
Allow time and seasonal restricted road :Thisfeature allows the system to use time restricted andseasonal roads when calculating a planned route.
5-43

Edit Address Book—How to Add
To add an address to the address book, see“AddingDestinations to the Address Book”underDestinationonpage 5!24.
Edit Address Book—Edit/View
To edit the name of an address book:
1. Select the CONFIG hard key.
2. Select the NAV screen button.
3. Select the Edit/View Address Book screen button.
4. Select the Address book entry.
5. Touch the Name screen button and use the alphakeyboard to edit or add the name.
6. Touch the OK screen button to save your changes,then touch the Back screen button to return to theAddress Book information screen.
5-44

To add or change the phone number of an addressbook entry:
1. Select the CONFIG hard key.
2. Select the NAV screen button.
3. Select the Edit/View Address Book screen button.
4. Select the address book entry to change.
5. Touch the Phone # screen button and usethe numeric keyboard to input or change thephone number.
6. Touch the OK screen button to save your changes,then touch the Back screen button to return to theAddress Book information screen.
To change the map icon of an address book entry:
1. Select the CONFIG hard key.
2. Select the NAV screen button.
3. Select the Edit/View Address Book screen button.
4. Select the address book entry to change.
5. Select the Icon screen button.
6. Select an icon from the list.
To add a voice tag to an address book entry:
1. Select the CONFIG hard key.
2. Select the NAV screen button.
3. Select the Edit/View Address Book screen button.
4. Select the Add Voice Tag screen button.
5. The system will ask for you to state the name.You will have four seconds to state the name.The system will respond back with the name andprompt you to repeat the name for confirmation.
To delete an address book entry:
1. Select the CONFIG hard key.
2. Select the NAV screen button.
3. Select the Edit/View Address Book screen button.
4. Select the address book entry to delete.
5. Press the Delete screen button to delete theaddress book entry.
6. A confirmation pop-up will display. Select Ok todelete; select Cancel to cancel the operation.
To delete the entire address book:
1. Select the CONFIG hard key.
2. Select the NAV screen button.
3. Select the Edit/View Address Book screen button.
4. A list of all the address book entries will display.Press and hold the Clear All screen button.
5. A confirmation pop-up will display. Select Ok todelete; select Cancel to cancel the operation.
5-45

Map Database Information
Touch the Map Database Information screen button toview the coverage areas of the map DVD.
Off-Road Mode
To turn the Off-road mode on or off, do the following:
1. Press the CONFIG hard key.
2. Press the Nav screen button.
3. Press the Off-Road mode screen button. Thebutton will be highlighted when the feature is on.
When the off-road mode is turned on, the navigationsystem will show the path being traveled by thevehicle when not on a marked road. This path willbe a simulation since the map database coverage willnot have these roads on the DVD. This path will bestored in the navigation system's memory, see“Previous Destination”underDestinationon page 5!24for more information.
See“Off-Road Driving”in the Index of your vehicle'sowner manual for more information about off-roaddriving.
5-46

Traffic Options
Read the following Options descriptions to understandhow the XM NavTraffic™operates.
XM NavTraffic™(USA and Canada)
Vehicles with the navigation system have anXM NavTraffic™receiver. XM NavTraffic™is asubscription service provided via XM™Satellite Radio.XM NavTraffic™provides real-time traffic informationfully integrated to the navigation system to displaycurrent traffic conditions for a driver’s chosen route.XM NavTraffic™allows drivers to make the mostinformed, timesaving routing decisions.
If the Traffic touch screen button is pressed or if anattempt is made to turn on the traffic display in theNavigation Setup Menu without a subscription, aCaution screen displays indicating that XM traffic isnot activated.
Three types of traffic information for major roadways aredisplayed on the navigation system:
.Unscheduled traffic incident data, such asaccidents and disabled vehicles
.Scheduled traffic incident data, such as roadconstruction and road closures
.Traffic flow information (rate of speed data)
Traffic information is delivered to the vehicle bythe XM™Radio satellites. XM NavTraffic™makesit possible for the navigation system to providecontinuously updated traffic information personalizedfor a driver’s needs.
5-47

XM NavTraffic™currently broadcasts the trafficinformation for many markets nationally, and the servicemay be available in more cities in the future. Visitxmnavtraffic.com for more details on local coverage.
A service fee is required in order to receive theXM NavTraffic™service.
Turning XM NavTraffic™On and Off
To turn traffic on or off:
1. Press the CONFIG hard key, then press theCONFIG key repeatedly until Nav is selected orpress the Nav screen button.
2. Touch the Traffic Options button.
3. Touch the Traffic button. This button is highlightedwhen it is active.
Selecting Alert for Approaching Traffic Eventsenables the system to show a pop-up screen thatnotifies of possible traffic issues ahead.
When this feature is highlighted, while traveling ona route, accidents located on the route areindicated and can be avoided.
Traffic Icon
The Traffic Icon appears on the Traffic Tab, next to theword Traffic, when traffic is found in the local area.
The Traffic Icon has three different condition displays.These are:
ConditionTraffic Status Icon
.No XM NavTraffic™subscription..No Traffic is found inthe local area..The Traffic Featureis turned off.
5-48

ConditionTraffic Status Icon
Traffic events are in thearea, but none are on route.
Traffic events are on route.
Locations and Information of Traffic
Conditions
The system may take some time to sort the information.The list of traffic conditions display in the order ofdistance from the vehicle, up to approximately75 mi (125 km). With a route planned, the systemdefaults to list traffic events on your route. Without aroute planned, if travelling on a major interstate, the
system lists events immediately ahead on the interstatefirst. Then all other traffic events follow. Not all trafficconditions may be listed.
To view the traffic condition location and information onthe map:
1. Press the NAV key, then press the NAV keyrepeatedly until Traffic is selected, or touch theTraffic screen button. A list of traffic conditionswith distance from the vehicle's current positiondisplays.
An arrow may appear before the distance.The arrow indicates the distance is a straight linedistance and it shows the direction of the event
5-49

from the current vehicle's position. If no arrowappears, the distance indicates how far the eventis ahead on current Interstate highway or route.While the vehicle is moving, the traffic list up ordown, scroll arrows are limited to a maximum offour pages. No more than four pages of trafficevents may be viewed while the vehicle is moving.
2. Select a traffic condition to get more detailedinformation of the event.
Options
Select the Options screen button. A Traffic Optionsmenu displays. Select the desired traffic related option.
Traffic :Select to enable or disable the traffic function.
5-50
