4. Install countershaft and mainshaft bearing cups (2)
into adapter plate (2).
TRANSMISSION CASE
1. Install shift rail bushings with Installer 9368 and
Handle C-4171.
2. Install mainshaft bearing cup with Installer 9373 (2)
and Handle C-4171 (1).

3. Install countershaft bearing cup with Installer 9373
(2) and Handle C-4171 (1).
EXTENSION HOUSING
1. Install countershaft bearing (1) with Installer 9394
(2) and Handle C-4171 (3).

2. Install mainshaft roller bearing race (1) with
Installer 9392 (2) and Handle C-4171 (3).
3. Install mainshaft roller bearing race snap ring.
4. Install shift rail bushings with Installer 9368 and
Handle C-4171.
5. Install reverse idler gear shaft.
6. Install thrust washer, reverse idler gear (3) and
bearing (2).

7. Install idler gear bracket into the tail housing (1).
Install bolts (2) with Loctite
242 and tighten to 24
Nꞏm (18 ft. lbs.).
INPUT SHAFT
1. Install input shaft bearing cup with Installer 9380
(1) and Handle C-4171 (2).

2. Install input shaft bearing (3) with Installer 6052 (2)
and Tube MB991317 (1).
COUNTERSHAFT
1. Install countershaft (3) bearings (2) with Installer
MB998909 (1) and a press.

MAINSHAFT
CAUTION: Mainshaft snap rings are not inter-
changeable.
1. Install mainshaft (3) tapered bearing (2) with
Installer 9377 (1) and a press.
2. Install third gear bearing (2) and spacer (1) on
mainshaft.

3. Press third gear (1) and 3-4 synchronizer hub (2)
onto the mainshaft with Splitter 9375.
4. Install 3-4 synchronizer sleeve.
5. Install 3-4 synchronizer (1)originalornewsnap
ring (2).
6. Press second gear (1) and 1-2 synchronizer hub
(2) onto mainshaft with Splitter 9375.

7. Install 1-2 thrust washer and blocker ring (1)
assembly onto 1-2 synchronizer (2).
8. Installoriginalornew1-2 synchronizer (1) snap
ring (2) on mainshaft.
9. Install first gear (1) and bearing (2) on mainshaft.

10. Install rear mainshaft tapered bearing (1) on top
of first gear (2).
TRANSMISSION HOUSING
NOTE: During assembly refer to Adjustments for
Main shaft and Countershaft End Play
1. Install input shaft seal into adapter plate with
Installer 9366.
2. Install input shaft (2) into adapter plate (3).

3. Install countershaft (1) assembly into adapter.
4. Tilt countershaft (4) sideways then install mainshaft
(1) and shift rail (2) assemblies into adapter (3).
