FORD ASPIRE 1997 1.G Owners Manual

169 %
*
[MC43194(ALL)01/96]
Tire Inspection and Maintenance
*
[MC43196(ALL)05/96]
Inspect the tire treads and remove stones, nails,
glass or other objects that may be wedged in the
tread grooves. Check for holes or cuts that may
permit air to leak from the tire and make the
necessary repairs.
*
[MC43198(ALL)01/96]
Inspect the tire sidewalls for cuts, bruises and
other damage. If you suspect internal damage to
the tire, have it removed and checked. You may
need to repair or replace it.
%*
[MC43200(ALL)01/96]
Tire Rotation
*
[MC43202(ALL)01/96]
Because your vehicle's front and rear tires
perform different jobs, they often wear
differently. To make sure your tires wear evenly
and last longer, rotate them as indicated in the
following diagram.
*
[MC43204(ALL)01/96]
Do not include the spare tire as part of your
rotation.
*
[MC43206(ALL)02/96]
For tire rotation intervals, see theMaintenance
Schedulebooklet. If you notice the tires wearing
unevenly, have them checked.
[MC43208(ALL)01/96]
one third page art:0030224-E
Rotating the tires
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

170 %
*
[MC43210(ALL)01/96]
Replacing the Tires
[MC43212(ALL)01/96]
We recommend you use all weather tires when
you replace your tires.
*
[MC43214(ALL)01/96]
Replace any tires that show wear bands. When
your tire shows a wear band, it has only 1/16
inch (2 mm) of tread left.
*
[MC43216(ALL)01/96]
quarter page art:0060006-A
A worn-out tire
*
[MC43218(ALL)02/96]
Because your vehicle's tires may wear unevenly,
you may need to replace them before a wear
band appears across the entire tread.
*
[MC43220(ALL)01/96]
WARNING
When replacing full size tires, never mix
radial, bias-belted, or bias-type tires. Use
only the tire sizes that are listed on the
tire pressure decal. Make sure that all tires
are the same size, speed rating, and
load-carrying capacity. Use only the tire
combinations recommended on the decal.
If you do not follow these precautions,
your vehicle may not drive properly and
safely.
*
[MC43222(ALL)01/96]
Tires that are larger or smaller than your
vehicle's original tires may also affect the
accuracy of your speedometer.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

171 %
*
[MC43224(ALL)03/96]
Wheel and Tire Matching
*
[MC43226(ALL)03/96]
See an authorized tire dealer for proper
servicing procedures. Wheels and tires must be
properly removed, matched and remounted to
maintain the best possible ride.
%*
[MC43228(ALL)01/96]
Information About Tire Quality Grades
*
[MC43230(ALL)01/96]
New vehicles are fitted with tires that have their
Tire Quality Grade (described below) molded
into the tire's sidewall. These Tire Quality
Grades are determined by standards that the
United States Department of Transportation has
set.
*
[MC43232(ALL)01/96]
Tire Quality Grades apply to new pneumatic
tires for use on passenger cars. They do not
apply to deep tread, winter-type snow tires,
space-saver or temporary use spare tires, tires
with nominal rim diameters of 10 to 12 inches or
limited production tires as defined in Title 49
Code of Federal Regulations Part 575.104(c)(2).
*
[MC43234(ALL)01/96]
U.S. Department of Transportation Ð Tire
quality grades:The U.S. Department of
Transportation requires Ford to give you the
following information about tire grades exactly
as the government has written it.
%*
[MC43236(ALL)01/96]
Treadwear
*
[MC43238(ALL)01/96]
The treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified
government test course. For example, a tire
graded 150 would wear one and one-half (1 1/2)
times as well on the government course as a tire
graded 100. The relative performance of tires
depends upon the actual conditions of their use,
however, and may depart significantly from the
norm due to variations in driving habits, service
practices and differences in road characteristics
and climate.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

172
*
[MC43240(ALL)01/97]
Traction A B C
*
[MC43242(ALL)01/97]
The traction grades, from highest to lowest, are
A, B, and C, and they represent the tire's ability
to stop on wet pavement as measured under
controlled conditions on specified government
test surfaces of asphalt and concrete. A tire
marked C may have poor traction performance.
*
[MC43243(ALL)01/97]
WARNING
The traction grade assigned to this tire is
based on braking (straightahead) traction
tests and does not include cornering
(turning) traction.
*
[MC43244(ALL)01/97]
Temperature A B C
*
[MC43246(ALL)05/96]
The temperature grades are A (the highest), B,
and C, representing the tire's resistance to the
generation of heat and its ability to dissipate
heat when tested under controlled conditions on
a specified indoor laboratory test wheel.
Sustained high temperature can cause the
material of the tire to degenerate and reduce tire
life, and excessive temperature can lead to
sudden tire failure. The grade C corresponds to
a level of performance which all passenger car
tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A
represent higher levels of performance on the
laboratory test wheel than the minimum
required by law.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

173
*
[MC43247(ALL)01/97]
WARNING
The temperature grade for this tire is
established for a tire that is properly
inflated and not overloaded. Excessive
speed, underinflation, or excessive
loading, either separately or in
combination, can cause heat buildup and
possible tire failure.
%*
[MC43248(ALL)08/96]
Snow Tires and Chains
*
[MC43250(ALL)08/96]
The tires on your vehicle have all-weather treads
that provide traction in rain or snow. However,
during the winter months in some climates, you
may need to use snow tires and occasionally
chains for your tires.
*
[MC43252(ALL)01/96]
WARNING
Snow tires must be the same size and
grade as the tires you currently have on
your vehicle.
*
[MC43254(ALL)01/96]
Use chains on the tires only in an emergency or
if the law requires them where you live. If you
choose to use chains on your vehicle's tires, be
aware of the following:
*
[MC43256(ALL)01/96]
q
Local regulations may prohibit or restrict the
use of tire chains. Investigate the laws and
regulations in your area before installing
chains.
*
[MC43258(ALL)01/96]
q
Tire chains may scratch or chip aluminum
wheels. IT IS RECOMMENDED THAT TIRE
CHAINS ARE INSTALLED ON STEEL
WHEELS ONLY. Be sure to remove wheel
covers (if equipped) from steel rims before
using tire chains to avoid scratches or
damage.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

174
*
[MC43260(ALL)01/96]
q
Put the chains on the front tires tightly with
the ends held down securely. Retighten the
chains after driving 1/2 mile (1 km). Follow
the chain manufacturer's instructions.
*
[MC43262(ALL)01/96]
q
Do not drive faster than 30 mph (48 km/h)
or the chain manufacturer's recommended
speed limit, whichever is lower. Avoid
bumps, holes and sharp turns. If you can
hear the chains rub or bang against your
vehicle, remove the chains to prevent damage
to your vehicle.
*
[MC43264(ALL)01/96]
q
Tire chains may affect vehicle handling. Drive
carefully and avoid hard braking.
*
[MC43266(ALL)01/96]
q
Do not use chains on temporary spare tires.
They may damage the vehicle and the tire.
%
*
[MC43755(ALL)01/96]
Filling the Fuel Tank
[MC43760(ALL)01/96]
Your fuel hatch door is located on the driver's
side. To open the fuel door, simply pull the
hatch open.
[MC43765(ALL)01/96]
one third page art:0032224-B
Fuel hatch and fuel cap
*
[MC43770(ALL)01/96]
If you lose the fuel cap, replace it with an
authorized Motorcraft or equivalent part.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

175 %
*
[MC43775(ALL)01/96]
WARNING
If you do not use the proper fuel cap, the
pressure in the fuel tank can damage the
fuel system or cause it to work improperly
in a collision.
*
[MC43780(ALL)01/96]
NOTE: If you replace your fuel cap with an
aftermarket fuel filler cap, the customer
warranty may be void for any damage
to the fuel tank and/or fuel system.
*
[MC43785(ALL)08/96]
WARNING
The fuel system may be under pressure. If
the fuel cap is venting vapor or if you
hear a hissing sound, wait until it stops
before completely removing the cap.
*
[MC43795(ALL)08/96]
A venting fuel tank is not an abnormal
condition. It may be caused by:
*
[MC43800(ALL)08/96]
q
too volatile a fuel for the weather conditions.
Service stations sometimes sell winter grade
fuel in the summer.
*
[MC43805(ALL)08/96]
q
extended periods of idling with the engine
RPM increased above the normal idle range.
*
[MC43810(ALL)08/96]
q
parking the vehicle in full sunlight for
extended periods on extremely hot days.
*
[MC43815(ALL)01/96]
WARNING
Do not overfill the fuel tank. The pressure
in an overfilled tank may cause leakage
and lead to fuel spray and fire.
*
[MC43820(ALL)01/96]
Before you fill your vehicle with fuel, extinguish
all lit cigarettes, other smoking materials, and
any open flames.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

176
*
[MC43825(ALL)01/96]
To fill the tank properly:
*
[MC43830(ALL)01/96]
1. Remove the fuel cap. Proceed to add fuel to
the tank only if your vehicle is on level
ground.
[MC43835(ALL)01/96]
2. Make sure that you pump unleaded fuel and
put the nozzle all the way inside the fuel
filler pipe. The fuel tank is normally full
after three automatic shutoffs of the nozzle.
*
[MC43840(ALL)01/96]
3. If you spill any fuel on the body of your
vehicle, clean it off immediately. The fuel
may dull or soften the paint if you do not
wash it off.
[MC43845(ALL)01/96]
4. Replace the fuel cap tightly when you are
finished. Turn it clockwise until you hear at
least three clicks.
*
[MC43850(ALL)01/96]
5. Push the fuel door closed.
%*
[MC43855(ALL)08/96]
Choosing the Right Fuel
*
[MC43861(ALL)05/96]
Use only UNLEADED FUEL. The use of leaded
fuel is prohibited by law and could damage
your vehicle. The damage may not be covered
by your warranty.
*
[MC43866(ALL)08/96]
Your vehicle was not designed to use fuel
containing manganese-based additives such as
MMT. Additionally, vehicles certified to
California emission standards (indicated on the
underhood Vehicle Emissions Control
Information label) are designed to operate on
California reformulated gasolines. If California
reformulated gasoline is not available when you
refuel, your vehicle can be operated on
non-California fuels. However, even though your
engine will perform adequately on other
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

177
gasolines, the performance of the emission
control devices and systems may be adversely
affected. Repair of damage caused by using a
fuel that your vehicle was not designed for may
not be covered by your warranty.
%*
[MC43870(ALL)08/96]
Octane recommendation
*
[MC43876(ALL)05/96]
Your vehicle is designed to use regular gasoline
with an (R+M)/2 octane rating of 87.We do not
recommend gasolines labeled as ªregularº in
high altitude areas that are sold with octane
ratings of 86 or even less.
*
[MC43880(ALL)05/96]
one inch art:0060001-C
Typical octane rating label
*
[MC43891(ALL)08/96]
Do not be concerned if your vehicle sometimes
knocks lightly. However, if it knocks heavily
under most driving conditions on the
recommended octane fuel, see your dealer or a
qualified service technician to prevent any
engine damage.
%*
[MC43895(ALL)05/96]
Fuel quality
*
[MC43901(ALL)05/96]
If you are experiencing starting, rough idle or
hesitation problems try a different brand of fuel.
If the condition persists, see your dealer or a
qualified service technician.
*
[MC43904(ALL)08/96]
The American Automobile Manufacturers
Association (AAMA) issued a gasoline
specification to provide information on high
quality fuels that optimize the performance of
your vehicle. We recommend the use of
gasolines that meet the AAMA specification if
they are available.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

178
*
[MC43909(ALL)08/96]
It should not be necessary to add any
aftermarket products to your fuel tank if you
continue to use a high-quality fuel.
*
[MC43945(ALL)04/96]
Clean air
*
[MC43951(ALL)08/96]
Ford approves the use of gasolines to improve
air quality, including reformulated gasolines, that
contain oxygenates such as a maximum of 10%
ethanol or 15% MTBE. There should be no more
than 5% methanol with cosolvents and additives
to protect the fuel system.
%*
[MC43965(ALL)01/96]
Safety Information Relating to Automotive
Fuels
*
[MC43970(ALL)01/96]
WARNING
Automotive fuels can cause serious injury
or death if misused or mishandled.
*
[MC43975(ALL)05/96]
q
Turn vehicle off when refueling.
*
[MC43980(ALL)08/95]
q
Do not smoke when refueling. Fuels are
extremely flammable.
*
[MC43985(ALL)08/95]
q
Do not siphon any fuel by mouth.
*
[MC43990(ALL)02/96]
WARNING
Gasoline or gasoline blended with
methanol can cause blindness and
possible death when swallowed. If any
fuel is swallowed, call a physician or
poison control center immediately.
*
[MC43995(ALL)08/95]
q
Avoid breathing vapors while refueling.
*
[MC44000(ALL)08/95]
q
If fuel is splashed on the skin, wash with
soap and water.
*
[MC44005(ALL)08/95]
q
If fuel is splashed in the eyes, remove contact
lenses (if worn), flush with water for 15
minutes, and seek medical attention.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997
