5.STOP/EJECTbutton
Press to stop playback operation.
Press twice to eject the videocassette tape from the VCP.
6.REW(Rewind) button
Press to rewind the tape.
7.FF(Fast Forward) button
Press to fast-forward the tape.
Description
9
Page 12 of 76
VIDEO DISPLAY UNIT
The roof-mounted Video Display Unit is the most visible component of
your RSES. In essence, it is the ªnerve centerº of your system. In
addition to containing the flip-down LCD video screen, it contains many
of the system's main control buttons, important indicator lights, and
facilities to support both the wireless and optional wired headphones.
1.POWERbutton
Press this button to turn the RSES system On and Off alternately.
2.REMOTE CONTROL SENSOR
To operate the VCP with the remote control, aim it toward this location.
3.VOLUMEbuttons
Press (+) or (þ) button to decrease or increase audio volume through
thewiredheadphones.
Wired headphones are not supplied. Any headphones for portable
cassette and compact disc units can be used.
4.SELECTbutton
Press to select between AV1 and AV2.
POWER
BRIGHTNESS VOLUMESENSORSELECT
FREQUENCY
OFF 1 2AV 1 AV 2
54321
876
Description
10
Page 13 of 76
5.INDICATOR LAMPS
AV 1(VCP) illuminates when select button selects video play.
AV 2(Auxiliary) illuminates when select button selects auxiliary (game)
mode.
6.BRIGHTNESSbuttons
The up arrow increases screen brightness.
The down arrow decreases screen brightness.
7.SCREEN RELEASE
Slide in the direction of arrow to release the flip-down LCD screen.
8.FREQUENCY OFF/1/2Switch
To access this switch, release the flip-down LCD screen.
Slide to activate/deactivate audio over vehicle speakers. Slide to 1, and
set the radio to 88.7 MHz. Slide to 2 and set the radio to 89.1 MHZ.
9.INFRARED EMITTER ARRAY
for wireless headphones.
The audio signal which operates the
wireless headphones is sent from
this black lens area. If you block or
cover this lens, the wireless infrared
headphones will not operate.
10.HEADPHONEterminals
Standard 1/8º stereo headphone
jacks. You can connect wired stereo
headphones to these two headphone
jacks.
11.AUXinput jacks
You can connect a camcorder or
video game to these jacks.
YELLOW: Video
WHITE: Left Audio
RED: Right Audio
11
9
1010
Description
11
Page 14 of 76
REMOTE CONTROL
1.REW(Rewind) button
Press to rewind videotape.
2.PLAYbutton
Press to playback a tape.
3.FWD(Fast-Forward) button
Press to fast-forward tape.
4.STOPbutton
Press to stop tape playback.
5.REPLAYbutton
Press to rewind tape and play again.
6.POWERButton
Press to turn the pod on or off.
7.VIDEO or GAME
Press to choose between playing the
videocassette player or playing a
game.
8.WIRED HEADPHONE VOLUME CONTROL
Press + (plus) to increase the volume and press - (minus) to decrease
the volume. This does not affect the wireless headphones.
POWER
REW
FWD
PLAYSTOP
WIRED HEADPHONE
VOLUME CONTROL
REPLAY VIDEO
or GAME
+
–
56
1
2
8
7
3
4
Description
12
Page 15 of 76
BATTERY REPLACEMENT
Slide battery cover off as shown on
remote control to access the
batteries.
The remote control unit uses two
AAA batteries.
The need for battery replacement is
usually indicated if the remote
control only functions at extremely
close distances to the entertainment
center or not at all.
When replacing batteries, use two
new batteries (alkaline
recommended) and install with
correct orientation (+ and þ
polarities).
Description
13
Page 16 of 76
FLIP-DOWN SCREEN
The screen rotates down to view
and up into housing to store when
not in use. Be sure the screen is
latched into the housing when being
stored. For the best viewing angle,
move the screen all the way back
and adjust the brightness.
1. 6.8º (diagonal) color liquid crystal
display (LCD) screen.
2. Screen housing.
2
1
Description
14
Page 17 of 76
WIRELESS HEADPHONES
Your rear entertainment system is
equipped with 2 sets of wireless
headphones. Two AAA batteries are
needed to operate the headphones.
To install the batteries, lightly press
down on the top of the left earpiece
and slide the cover off.
When replacing the batteries, use
two new batteries (alkaline
recommended) and install them
with the correct + and Ð
orientation.
ON OFF
Description
15
Page 18 of 76
GENERAL OPERATION
²When the engine is not running, use the system sparingly otherwise it
will run the battery down.
²When the ignition is turned to OFF, the Rear Seat Entertainment
System is also turned OFF. When the ignition is turned ON, the RSES
is in the VCP mode. To play a videotape, insert a tape into the VCP..
²Do not leave the videocassette in the VCP overnight or for long
periods of time.
²When using the VCP, ensure that your audio system is set to 88.7 or
89.1 FM.
²When the ignition is turned ON, audio is through the wireless
headphones. If you are using wired headphones, press the (+) control
to increase volume. To listen through the vehicle's speaker system,
switch the external radio switch to F1 or F2.
Operating Instructions
16
Page 19 of 76
Inserting/removing cassette
Inserting cassette
Driver should never operate
any function of the VCP
mounted in the Floor Console
when the vehicle is moving. Give
full attention to driving and the
road. Pull off the road and park in
a safe place to insert or remove
video tapes from the VCP. A
remote control is included in the
system to allow rear seat
occupants to operate the VCP
functions without distracting the
driver.
²Open the RSES floor console cover, and slide a videocassette into the
cassette compartment.
Inserting a videocassette into the VCP automatically turns the power ON
(the RED power indicator lamp will illuminate) and the tape will begin
playback.
If the vehicle is traveling over rough terrain, it may be difficult to insert
the cassette because the machine attempts to hold the cassette firmly to
prevent vibration. If this condition is encountered, the passenger should
either press firmly or remove the cassette and insert it again. If a
cassette is inserted in the wrong position, the protection circuit will
automatically eject the cassette. If this occurs, the passenger should wait
a few seconds and insert the cassette again in the correct position.
²Once the cassette is completely inserted, close the console cover.
REMOTE
SENSOR
CST INDEWPOWER
REW
FFPLAY STOP/
EJECT
Operating Instructions
17
Page 20 of 76
Removing cassette
1. Open the console cover, and
press the STOP/EJECT button once.
2. Press the STOP/EJECT button
again. The tape will eject.
Playback operation
1. Press the power button on the pod.
2. Insert videocassette into the VCP.
3. Video should automatically begin playback.
²If video is not shown on the screen, press the SELECT button on the
RSES control panel to switch from AV2 to AV1 mode.
4. Tracking is automatically adjusted.
²If excessive video ªnoiseº (picture fluctuates up and down) occurs,
press the PLAY button on the remote control or on the VCP.
5. Press the STOP/EJECT button to discontinue playback. Press
STOP/EJECT again to remove the cassette.
REMOTE
SENSOR
CST INDEWPOWER
REW
FFPLAY STOP/
EJECT
Operating Instructions
18
