Hyundai Grandeur 2002 Service Manual
Manufacturer: HYUNDAI, Model Year: 2002, Model line: Grandeur, Model: Hyundai Grandeur 2002Pages: 230, PDF Size: 3.82 MB
Page 41 of 230
1- 28 FEATURES OF YOUR HYUNDAI
!WARNING:
o Do not install a child restraint seat at the center of the rear seat using the vehicle's ISOFIX an-chors. The ISOFIX anchors areonly provided for the left andright outboard rear seating posi-tions. Do not misuse the ISOFIX anchors by attempting to attach a child restraint seat in the middleof the rear seat to the ISOFIXanchors. In a crash, the childrestraint seat ISOFIX attachmentsmay not be strong enough to secure the child restraint seat properly in the center of the rearseat and may break, causing se-rious injury or death.
NOTE: An ISOFIX-child-seat can only be installed if the seat has a vehicle-specific approval according to ECE-R44. Before using the ISOFIX-child-seat, which was bought for an othercar, ask your Hyundai-dealer whether this seat-type is approved and recommended for yourHyundai. To secure the child restraint seat
B230E01L
1. To engage the child restraint seat to the ISOFIX anchor, insert the child restraint seat latch into the ISOFIXanchor. Listen for the audible "click"sound. 2. Connect the tether strap hook to the
child restraint hook holder andtighten to secure the seat. Refer to"Securing a Child Restraint SystemWith Tether Anchorage System" on page 1-26. o Do not mount more than one
child restraint to a child restraint lower anchorage point. The im-proper increased load may causethe anchorage points or tetheranchor to break, causing seriousinjury or death.
o Attach the ISOFIX or ISOFIX-com-
patible child restraint seat onlyto the appropriate locationsshown in the illustration.
o Always follow the installation and
use instructions provided by the manufacturer of the child re- straint.
Page 42 of 230
FEATURES OF YOUR HYUNDAI 1- 29
HXG229
B180B01HP-GAT Pre-tensioner Seat Belt Your Hyundai vehicle is equipped with driver's and front passenger's pre-tensioner seat belts. The purpose ofthe pre-tensioner is to make sure that the seat belts fit tightly against the occupant's body in certain frontal col-lisions.The pre-tensioner seat belts can beactivated alone or, where the frontalcollision is severe enough, together with the airbags. The pre-tensioner seat belt operatesin a similar way as an Emergency Locking Retractor (ELR) type of seatbelt. When the vehicle stops suddenly,or if the occupant tries to lean forwardtoo quickly, the seat belt retractor willlock into position. However, in certain frontal collisions, the pre-tensioner will activate and pull the seat belt intotighter contact against the occupant'sbody.
Rear
Center
Age Group Seating Position
UU
F
XUU F
X U, L1 UF XU FUF
Rear
Outboard
Front
Passenger
0 : Up to 10 kg (0 ~ 9 months)0+ : Up to 13 kg(0 ~ 2 years)I : 9kg to 18kg(9 months ~ 4years)II & III : 15kg to36kg (4 ~ 12 years) X
B230H01L-GAT Child Seat Restraint Suitability For Seat Position Use child safety seats that have been officially approved and are appropriatefor your children. When using the childsafety seats, refer to the following table.
U :Suitable for "universal" category
restraints approved for use in this mass group
UF :Suitable for forward-facing "uni- versal" category restraints ap- proved for use in this mass group L1: Suitable for "Römer ISOFIX GR1"
approved for use in this mass group
(Approval No: E1 R44-03301133)
X : Seat position not suitable for chil- dren in this mass group
Page 43 of 230
1- 30 FEATURES OF YOUR HYUNDAI
o Although it is harmless, the fine
dust may cause skin irritation and should not be breathed forprolonged periods. Wash yourhands and face thoroughly after an accident in which the pre- tensioner seat belts were acti-vated.
CAUTION:
o Because the sensor that activates the SRS airbag is connected withpre-tensioner seat belt, the SRSairbag warning light on theinstrument panel will blink for approximately 6 seconds after the ignition key has been turnedto the "ON" position, and then itshould turn off.
o If pre-tensioner seat belt is not working properly, this warning light will illuminate even if there is no malfunction of the SRSairbag. If the SRS airbag warninglight does not illuminate whenthe ignition key is turned to "ON"or if it remains illuminated after blinking for approximately 6 sec- onds, or if it illuminates while the
!
AIR
BAG
!
NOTE:
o Both the driver's and front
passenger's pre-tensioner seat belts will be activated in certainfrontal collisions. The pre-tensioner seat belts can be acti-vated alone or, where the frontal collision is severe enough, to- gether with the airbags.
o When the pre-tensioner seat belts
are activated, a loud noise maybe heard and fine dust, whichmay appear to be smoke, may be visible in the passenger compart- ment. These are normal operat-ing conditions and are not haz-ardous. WARNING:
To obtain maximum benefit from a pre-tensioner seat belt:
1. The seat belt must be worn cor- rectly.
2. The seat belt must be adjusted to the correct position.B180B02S
Driver's airbag1
2 3Passenger's airbag
The seat belt pre-tensioner systemconsists mainly of the following com- ponents. Their locations are shown in the illus- tration.
1. SRS airbag warning light
2. Seat belt pre-tensioner assembly
3. SRS control module
Page 44 of 230
FEATURES OF YOUR HYUNDAI 1- 31
B240A01L
B240A02Y-AAT SUPPLEMENTAL RESTRAINT (AIRBAG) SYSTEM (If Installed) Your Hyundai is equipped with a Supplemental Restraint (Airbag) Sys- tem. The indications of the system's presence are the letters "SRS AIRBAG" embossed on the airbag padcover in the steering wheel and thepassenger's side front panel pad abovethe glove box. The Hyundai SRS consists of airbags installed under the pad covers in thecenter of the steering wheel and thepassenger's side front panel above theglove box. The purpose of the SRS is to provide the vehicle's driver and/or
o Do not attempt to service or re-
pair the pre-tensioner seat belt system in any manner.
o Improper handling of the pre- tensioner seat belt assemblies,and failure to heed the warningsto not strike, modify, inspect, re- place, service or repair the pre- tensioner seat belt assembliesmay lead to improper operationor inadvertent activation and se-rious injury.
o Always wear the seat belts when driving or riding in a motor ve-hicle.
vehicle is being driven, please have an authorized Hyundai deal-er inspect the pre-tensioner seatbelt or SRS airbag system assoon as possible.
WARNING:
o Pre-tensioners are designed to operate only one time. After acti- vation, pre-tensioner seat beltsmust be replaced. All seat belts,of any type, should always bereplaced after they have beenworn during a collision.
o The pre-tensioner seat belt as-
sembly mechanisms become hotduring activation. Do not touchthe pre-tensioner seat belt as-semblies for several minutes af-ter they have been activated.
o Do not attempt to inspect or re-
place the pre-tensioner seat beltsyourself. This must be done byan authorized Hyundai dealer.
o Do not strike the pre-tensioner seat belt assemblies.!
Page 45 of 230
1- 32 FEATURES OF YOUR HYUNDAI
o Front airbags are not intended to
deploy in side-impact, rear-im- pact or rollover crashes. In addi-tion, airbags will not deploy infrontal crashes below the deploy-ment threshold speed.
o The driver should sit back as far as possible while still maintain-ing control of the vehicle. If youare sitting too close to the airbag,it can cause death or seriousinjury when it inflates.
o No objects should be placed over or near the airbag modules onthe steering wheel, instrumentpanel, and the front passenger'spanel above the glove box,because any such object couldcause harm if the vehicle is in a crash severe enough to cause the airbags to deploy.
o If the airbags deploy, they must
be replaced by an authorizedHyundai dealer.o The SRS is designed to deploythe airbags only when an impact is sufficiently severe and whenthe impact angle is less than 30°from the forward longitudinal axisof the vehicle and will not deployin side, rear or rollover impacts. Additionally, the airbags will only deploy once. Thus, seat beltsmust be worn at all times.
o Front airbags are not intended deploy in light collisions in whichprotection can be provided by the seat belt.
B240A02L
Rear impact
Side Impact Rollover
the front passenger with additional pro- tection than that offered by the seat-belt system alone, in case of a frontalimpact of sufficient severity. NOTE: Be sure to read information about the SRS on the labels provided on the backside of the sun visor and inthe glove box.
!WARNING:
o As its name implies, the SRS is designed to work with, and be supplemental to, the driver's andthe passenger's three point seatbelt systems and is not a substi- tute for them. Therefore, your seat belts must be worn at alltimes while the vehicle is in mo-tion. The airbags deploy only incertain frontal impact conditionssevere enough to likely cause significant injury to the vehicle occupants.
Page 46 of 230
FEATURES OF YOUR HYUNDAI 1- 33
B240B02A-GAT SRS Components and Functions
B240B01L
The SRS consists of the following com- ponents:
- Driver's Airbag Module
- Passenger's Airbag Module
- SRS Service Reminder Indicator (SRI)
- SRS Control Module (SRSCM) The SRSCM continually monitors all elements while the ignition is "ON" todetermine if a frontal or near-frontalimpact is severe enough to requireairbag deployment.
o For maximum safety protection
in all types of crashes, all occu-pants including the driver shouldalways wear their seat beltswhether or not an airbag is alsoprovided at their seating posi-tion to minimize the risk of se- vere injury or death in the event of a crash. Do not sit or leanunnecessarily close to the airbagwhile the vehicle is in motion.
o The SRS airbag system must de- ploy very rapidly to provide pro- tection in a crash. If an occupant is out of position because of notwearing a seat belt, the airbagmay forcefully contact the occu-pant causing serious or fatal in-juries.o Do not tamper with or discon-nect SRS wiring, or other com- ponents of the SRS system. Do-ing so could result in injury, dueto accidental firing of the airbagsor by rendering the SRS inopera-tive.
o Do not install a child restraint
system in the front passengerseat position. A child restraintsystem must never be placed inthe front seat. The infant or childcould be severely injured or killed by an airbag deployment in case of an accident.
o Do not allow children to ride in
the front passenger seat. If olderchildren (teenagers and older)must ride in the front seat, make sure they are always properly belted and that the seat is movedback as far as possible.
Page 47 of 230
1- 34 FEATURES OF YOUR HYUNDAI
Passenger's Airbag
B240B05L
B240B04L
Passenger's Airbag
After complete inflation, the airbag immediately starts deflating, enablingthe driver to maintain forward visibility.
B240B03L
The airbag modules are located bothin the center of the steering wheel andin the front passenger's panel abovethe glove box. When the SRSCM de-tects a considerable impact to the front of the vehicle, it will automatically de- ploy the airbags. Upon deployment, tear seams molded directly into the pad covers will sepa-rate under pressure from the expan- sion of the airbags. Further opening of the covers then allows full inflation ofthe airbags. A fully inflated airbag in combination with a properly worn seat belt slows the driver's or the passenger's forward motion, thus reducing the risk of heador chest injury.
B240B02L
The SRS service reminder indicator (SRI) on the instrument panel will blinkfor about 6 seconds after the ignitionkey is turned to the "ON" position or after the engine is started, after which the SRI should go out.
Page 48 of 230
FEATURES OF YOUR HYUNDAI 1- 35
B990A04Y-GAT PASSENGER PRESENCE DETECTION (If installed) The passenger presence detection system detects the presence of a pas-senger in the front seat. If no passen-ger is recognized on the front passen-ger seat, the deployment of the front passenger and/or side airbag and seat belt pretentioner will be inhibited.This system is designed primarily toprevent the replacement of airbag com-ponents that deploy needlessly in anaccident. NOTE: Luggage or other cargo heavier than 15 kg should not be placed on the passenger front seat. This can al-low the deployment of the frontpassenger and/or side air bag inthe case of an accident.
o The SRS can function only when
the ignition key is in the "ON"position. If the SRS SRI does notcome on, or continuously re-mains on, after flashing for about6 seconds when the ignition keyis turned to the "ON" position, or after the engine is started, comes on while driving, the SRS is notworking properly. If this occurs,have your vehicle immediatelyinspected by your Hyundaidealer.
o Before you replace a fuse or dis-
connect a battery terminal, turnthe ignition key to the "LOCK"position or remove the ignitionkey. Never remove or replace theair bag related fuse(s) when the ignition key is in the "ON" posi- tion. Failure to heed this warningwill cause the SRS SRI to illumi-nate.
WARNING:
o When the SRS is activated, there may be a loud noise and fine dustwill be released throughout thevehicle. These conditions arenormal and are not hazardous. However, the fine dust generated during airbag deployment maycause skin irritation. Wash yourhands and face thoroughly withlukewarm water and a mild soapafter an accident in which the airbags were deployed.
!
CAUTION:
When installing a container of liq- uid air freshener inside a vehicle, do not place it near the instrument cluster nor on the instrument panelpad surface. If there is any leakagefrom the air freshener onto theseareas (Instrument cluster, instru-ment panel pad or air ventilator), it may damage these parts. If the liq- uid from air freshener does leakonto these areas, wash them withwater immediately.!
Page 49 of 230
1- 36 FEATURES OF YOUR HYUNDAI
WARNING:
o The side impact airbag is supple- mental to the driver's and the passenger's three point seat beltsystems and is not a substitutefor them. Therefore your seatbelts must be worn at all timeswhile the vehicle is in motion. The airbags deploy only in cer- tain side impact conditions se-vere enough to cause significantinjury to the vehicle occupants. HXGS261
Side airbag sensor
B990B04Y-GAT Side Impact Airbag (If installed)
Your Hyundai is equipped with a side airbag in each front seat. The purposeof the airbag is to provide the vehicle'sdriver and/or the front passenger with additional protection than that offered by the seatbelt alone. The side impactairbags are designed to deploy onlyduring certain side impact collisions,depending on the crash severity, angle,speed and point of impact. The air bags are not designed to deploy in all side impact situations. B990B02Y
!
WARNING:
The Passenger Presence Detection system is not intended to preventairbag deployment while a child isin the front passenger's seat. It is intended only as a means to reduce unnecessary collision damage re-pair expense by preventing airbagand seat belt pretensioner deploy-ment when the right front passen-ger seat is unoccupied. Deployment is still possible if only a few pounds are placed upon the seat. There-fore, children must not be trans-ported in the front seat. All childrenmust be seated in the rear seat andproperly restrained with the vehicle's restraint system or a child restraint system appropriate for thechild's size and weight.!
Page 50 of 230
FEATURES OF YOUR HYUNDAI 1- 37
B240C02Y-GAT SRS Care The SRS is virtually maintenance-free and there are no parts you can safelyservice by yourself. The entire SRSsystem must be inspected by an au-thorized Hyundai dealer 10 years after the date that the vehicle was manufac- tured. Any work on the SRS system, such as removing, installing, repairing, or anywork on the steering wheel must be performed by a qualified Hyundai tech- nician. Improper handling of the SRSsystem may result in serious personalinjury.
o Do not place any objects (an
umbrella, bag, etc.) between thefront door and the front seat.Such objects may become dan-gerous projectiles and cause in-jury if the supplemental side im- pact air bag inflates.
o To prevent unexpected deploy- ment of the side impact air bag that may result in personal in-jury, avoid impact to the sideairbag sensor when the ignition key is on.
o For best protection from the side
airbag system and to avoid being injured by the deploying sideimpact airbag, both front seatoccupants should sit in an up- right position with the seat belt properly fastened. The driver'shands should be placed on thesteering wheel at the 9:00 and3:00 o'clock positions. Thepassenger's arms and hands should be placed in their laps.
o Do not use any accessory seat
covers.
o Use of seat covers could reduce
or prevent the effectiveness of the system.
o Do not install any accessories on
the side or near the side impactairbag.
o Do not use excessive force on
the side of the seat.
o Do not place any objects over the airbag or between the airbag andyourself.
