INFINITI FX35 2008 Service Manual

FRONT DOOR LOCKBL-137
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
10. Remove the TORX bolt of the outside handle bracket.
11. While pulling outside handle bracket, slide toward front of vehi- cle to remove outside handle bracket.
12. Reach to separate outside handle cable connection.
13. Remove the TORX bolts of door lock assembly.
14. Disconnect the door lock actuator connector and remove door lock assembly.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
To install each rod, be sure to rotate the rod holder until a click is felt.
PIIA7117E
PIIA3558E
PIIA6026E
PIIB5812E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-138
< SERVICE INFORMATION >
REAR DOOR LOCK
REAR DOOR LOCK
Removal and InstallationINFOID:0000000001327878
REMOVAL
1. Remove the rear door finisher. Refer to EI-36, "Component Parts Location".
2. Disconnect the inside handle knob cable and lock knob cable from the back side of the front door finisher.
3. Remove the rear door sealing, glass and corner piece assembly. Refer to GW-54, "
Removal and Installa-
tion".
4. Remove door side grommet, and remove outside handle escutcheon bolt from grommet hole. CAUTION:
1. Front gasket 2. Outside handle 3. Outside handle escutcheon
4. Rear gasket 5. Outside handle bracket 6. Grommet
7. TORX bolt 8. Outside handle cable 9. TORX bolts
10. Door lock assembly 11. Inside handle knob cable 12. Lock knob cable
13. Screw 14. Inside handle
PIIA6027E
PIIA4014E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

REAR DOOR LOCKBL-139
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
Do not forcibly remove the TORX bolt.
5. While pulling the outside handle, remove outside handle escutcheon.
6. While pulling outside handle, slide toward rear of vehicle to remove outside handle.
7. Remove the front gasket and rear gasket.
8. Remove the TORX bolt, and remove the outside handle bracket.
PIIA3553E
PIIA6344E
PIIA3555E
PIIA3557E
PIIA7117E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-140
< SERVICE INFORMATION >
REAR DOOR LOCK
9. While pulling outside handle, slide toward front of vehicle toremove outside handle bracket.
10. Reach to separate outside handle cable connection.
11. Remove the TORX bolts of door lock assembly.
12. Disconnect the door lock actuator connector and remove door lock assembly.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
To install each rod, be sure to rotate the rod holder until a click is felt.
PIIA3558E
PIIA5059E
PIIB5812E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BACK DOORBL-141
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
BACK DOOR
Fitting AdjustmentINFOID:0000000001327879
VERTICAL/LATERAL CLEARANCE ADJUSTMENT
1. With the striker released, loosen the bumper rubber lock nuts.
2. Close the back door lightly and adjust the surface height by rotating the bumper rubber and, then open the
back door to finally tighten the back door lock mounti ng bolts and bumper rubber lock nuts to the specified
torque.
Back Door AssemblyINFOID:0000000001327880
REMOVAL
1. Remove roof rear garnish assembly. Refer to EI-45, "Component Parts Location".
2. Disconnect the back door harness connector and AV antenna feeder.
3. Washer hose is separated in the connection part.
1. Bumper rubber 2. Back door striker 3. Screw
PIIB0208E
PIIA6028E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-142
< SERVICE INFORMATION >
BACK DOOR
4. Support the back door lock with a proper material to prevent itfrom falling.
WARNING:
Body injury may occur if no supporting rod is holding the
back door open when removing the damper stay.
5. Remove back door stay on back door.
6. Remove back door hinge mounting nuts on the back door and remove back door assembly.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
 After installing, check operation.
 After installing, perform fitting adjustment. Refer to BL-141, "
Fitting Adjustment".
INSPECTION
1. Check back door hinges for the following.
 Malfunction noise or door closing and opening effort
 Component wear or damage
2. Apply body grease to the rotating part of the back door hinge.
Removal and Installation of Back Door StrikerINFOID:0000000001327881
REMOVAL
PIIA6061E
PIIA6029E
PIIA6030E
PIIA6030E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BACK DOORBL-143
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
1. Remove rear plate assembly. Refer to EI-45, "Component Parts
Location".
2. Remove back door striker mounting screws, and remove back door striker from the vehicle.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
After installing, perform fi tting adjustment. Refer to BL-141, "
Fitting Adjustment".
Removal and Installation of Back Door StayINFOID:0000000001327882
REMOVAL
1. Support the back door lock with a proper material to prevent it
from falling.
WARNING:
Body injury may occur if no supporting rod is holding the
back door open when removing the damper stay.
2. Remove back door stay on back door.
3. Remove back door stay assembly on vehicle.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
After installing, check operation.
PIIA9325E
PIIA6061E
PIIA6029E
PIIA6031E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-144
< SERVICE INFORMATION >
BACK DOOR
Removal and Installation of Dave Tail Male & Female
INFOID:0000000001327883
REMOVAL
1. Remove the dave tail male.
2. Remove the rear bumper. Refer to EI-17, "
Component Parts Location".
3. Remove the dave tail female.
INSTALLATION
Install in the reverse order of removal.
Removal and Installation of Back Door Weather-stripINFOID:0000000001327884
REMOVAL
Pull up and remove engagement with body from weather-strip joint.
CAUTION:
After removal, do not pull st rongly on the weather-strip.
INSTALLATION
PIIA6078E
PIIA6079E
1. Weather-strip
PIIA6032E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BACK DOORBL-145
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
1. Working from the upper section, align weather-strip mark with vehicle center position mark and install
weather-strip onto the vehicle.
2. For the lower section, align the weathe r-strip seam with center of the striker.
3. After installation, pull the weather-strip gently to ensure that there is no loose section. NOTE:
Make sure the weather-strip is fit tightly at each corner and back door rear plate.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-146
< SERVICE INFORMATION >
BACK DOOR LOCK ASSEMBLY
BACK DOOR LOCK ASSEMBLY
Removal and Installation of Back Door Lock & Closure AssemblyINFOID:0000000001327885
REMOVAL
1. Remove back door finisher. Refer to EI-47, "Component Parts Location".
2. Disconnect the connector and the clip of the back door lock & closure assembly.
3. Remove the mounting bolts.
4. Disconnect the connector of the back door opener actuator.
5. Remove the mounting bolts, remove back door lock & closure assembly.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
 After installing, check operation.
 After installing, perform fitting adjustment. Refer to BL-141, "
Fitting Adjustment".
INSPECTION
1. Check back door lock for the following.
 Malfunction noise or door closing and opening effort
 Component wear or damage
2. Apply body grease to the rotating part of the back door lock.
Removal and Installation of Back Door Opener SwitchINFOID:0000000001327886
REMOVAL
1. Remove back door finisher. Refer to EI-47, "Component Parts Location".
2. Remove back door outside finisher. Refer to EI-47
.
3. Remove licence lamp. Refer to LT-135, "
License Plate Lamp".
4. Cut back door inner panel along with cutting groove line. CAUTION:
When cutting the back door panel, always wear safety
glasses, heavy gloves and a dust proof mask to prevent eye
and skin irritation from glass fiver splinters.
NOTE:
1. Bolt 2. Back door lock & closure assembly
PIIA6043E
PIIA6903E
