DETENTION SWITCHADP-67
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
DETENTION SWITCH
DescriptionINFOID:0000000001735500
Park position switch is installed on A/T shift selector. It is turned OFF when the A/T selector lever is in P posi-
tion. The driver seat control unit judges that the A/T selector lever is in P position if cont\
inuity does not exist in
this circuit.
Component Function CheckINFOID:0000000001735501
1. CHECK FUNCTION
1. Select “DETENT SW” signal in “Data monitor” mode with CONSULT-III.
2. Check park position switch signal under the following conditions.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-67, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000001735502
1. CHECK DTC WITH “BCM”
Check “Self Diagnostic Result” for BCM with CONSULT-lll.
Is any other DTC detected?
YES >> Check the DTC.
NO >> GO TO 2
2. CHECK PARK POSITION SWITCH INPUT SIGNAL
1. Turn ignition switch ON.
2. Mechanical key must be removed from the key switch.
3. Check voltage between driver seat control unit harness connec- tor and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> GO TO 3
3. CHECK PARK POSITION SWITCH CIRCUIT
Monitor item ConditionStatus
DETENT SW A/T selector lever P position
OFF
Other than
above ON
Driver seat
control unit connector Te r m i n a l
ConditionVoltage (V)
(Approx.)
(+) (-)
B202 21 Ground A/T selec-
tor leverP position
Battery volt-
age
Other than
above 0V
ALJIA0193ZZ
Revision: March 2010
2008 QX56

ADP-68
< COMPONENT DIAGNOSIS >
DETENTION SWITCH
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and A/T shift selector.
3. Check continuity between driver seat control unit harness con-nector (A) and A/T shift selector harness connector (B).
4. Check continuity between driver seat control unit harness con- nector (A) and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace harness.
4. CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace driver seat control unit.
NO >> Repair or replace the malfunctioning part.
AB Continuity
Connector Terminal Connector Terminal
B202 21 M203 6 Yes
A —Continuity
Connector Terminal
B202 21 Ground No
ALJIA0194ZZ
Revision: March 2010 2008 QX56

FRONT DOOR SWITCH (DRIVER SIDE)ADP-69
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
FRONT DOOR SWITCH (DRIVER SIDE)
DescriptionINFOID:0000000001735503
Detects front door LH open/close condition.
Component Function CheckINFOID:0000000001735504
1. CHECK FUNCTION
1. Select “DOOR SW-DR” in “Dat a monitor” mode with CONSULT-III.
2. Check the front door switch LH signal under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-69, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001735505
1. CHECK FRONT DOOR SWITCH LH CIRCUIT
1. Disconnect BCM.
2. Check continuity between BCM connector and front door switch LH connector.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace harness.
2. CHECK FRONT DOOR SWITCH LH
Refer to ADP-69, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 3
NO >> Replace front door switch LH.
3. CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-55, "Removal and Installation".
NO >> Repair or replace the malfunctioning part.
Component InspectionINFOID:0000000001735506
1. CHECK FRONT DOOR SWITCH LH
Monitor item ConditionStatus
DOOR SW-DR Front door switch LH Open
ON
Close OFF
BCM connector TerminalFront door switch
LH connector Terminal Continuity
M19 47B8 2Yes
BCM connector Terminal GroundContinuity
M19 47 No
LIIA1027E
Revision: March 2010 2008 QX56

ADP-70
< COMPONENT DIAGNOSIS >
FRONT DOOR SWITCH (DRIVER SIDE)
1. Turn ignition switch OFF.
2. Disconnect front door switch LH.
3. Check continuity between front door switch LH terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace front door switch LH.
Te r m i n a lCondition Continuity
Front door switch LH
2 Ground part of
door switch Front door switch
LH Pushed
No
Released Yes
LIIA2377E
Revision: March 2010 2008 QX56

SLIDING SENSORADP-71
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
SLIDING SENSOR
DescriptionINFOID:0000000001735507
• The sliding sensor is installed to the seat slide cushion frame.
• The pulse signal is input to the driver seat control unit when sliding is performed.
• The driver seat control unit counts the pulse and calculates the sliding amount of the seat.
Component Function CheckINFOID:0000000001735508
1. CHECK FUNCTION
1. Select “SLIDE PULSE” in “Data monitor” mode with CONSULT-III.
2. Check sliding sensor signal under the following conditions.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-71, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000001735509
1. CHECK SLIDING SENSOR SIGNAL
1. Turn ignition switch ON.
2. Read voltage signal between driver seat control unit harness connector and ground with osiloscope.
Is the inspection result normal?
YES >> GO TO 4
NO >> GO TO 2
2. CHECK SLIDING SENSOR CIRCUITS
Monitor item Condition Valve
SLIDE PULSE Seat slidingOperate (forward)
Change (increase)
Operate (backward) Change (decrease)
Release No change
Te r m i n a l s
ConditionVoltage signal
(+)
(–)
Driver’s
seat
control unit Te r m i -
nal
B202 24 Ground Seat
slidingOperate
Other
than
above
0 or 5
PIIA4556E
PIIA3277E
Revision: March 2010
2008 QX56

ADP-72
< COMPONENT DIAGNOSIS >
SLIDING SENSOR
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and sliding motor LH.
3. Check continuity between driver seat control unit harness con-nector and sliding motor LH harness connector.
4. Check continuity between driver seat control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK SEAT OPERATION
1. Connect driver seat control unit and sliding motor LH.
2. Check seat operation (except sliding operation) with memory function.
Is the inspection result normal?
YES >> Replace sliding motor LH. (Built in seat slide cushion frame).
NO >> Replace driver seat control unit.
4. CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace driver seat control unit.
NO >> Repair or replace the malfunctioning part.
Driver seat control unit connector Te r m i n a lSliding motor
LH connector Terminal Continuity
B202 16
B204 3
Ye s
24 2
31 1
Driver seat control unit connector Te r m i n a l
GroundContinuity
B202 16
No
24
31
LIIA0706E
Revision: March 2010 2008 QX56

RECLINING SENSORADP-73
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
RECLINING SENSOR
DescriptionINFOID:0000000001735510
• The reclining motor is installed to the seatback frame.
• The pulse signal is inputted to the driver seat control unit when the reclining is operated.
• The driver seat control unit counts the pulse and calculates the reclining amount of the seat.
Component Function CheckINFOID:0000000001735511
1. CHECK FUNCTION
1. Select “RECLN PULSE” in “Data monitor” mode with CONSULT-III.
2. Check reclining sensor signal under the following conditions.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-73, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000001735512
1. CHECK RECLINING SENSOR SIGNAL
1. Turn ignition switch ON.
2. Read voltage signal between driver seat control unit harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 4
NO >> GO TO 2
2. CHECK RECLINING SENSOR CIRCUIT
Monitor item Condition Value
RECLN PULSE Seat recliningOperate (forward)
Change (increase)
Operate (backward) Change (decrease)
Release No change
Te r m i n a l s
Condition Voltage signal
(+)
(–)
Driver
seat con-
trol unit Te r m i -
nal
B202 9 Ground Seat
reclin-
ingOperate
Other
than
above
0 or 5
PIIA4559E
SIIA0692J
Revision: March 2010
2008 QX56

ADP-74
< COMPONENT DIAGNOSIS >
RECLINING SENSOR
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and reclining motor LH.
3. Check continuity between driver seat control unit harness con-nector and reclining motor LH harness connector.
4. Check continuity between driver seat control unit harness con- nector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK SEAT OPERATION
1. Connect driver seat control unit and reclining motor LH connector.
2. Check seat operation (except reclining operation) with memory function.
Is the operation normal?
YES >> Replace reclining motor LH. (Built in seat slide cushion frame.)
NO >> Replace driver seat control unit.
4. CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace driver seat control unit.
NO >> Repair or replace the malfunctioning part.
Driver seat control unit connector Te r m i n a lReclining motor
connector Terminal Continuity
B202 9
B205 1
Ye s
31 2
Driver seat control unit connector Te r m i n a l
GroundContinuity
B202 9
No
31
LIIA0707E
Revision: March 2010 2008 QX56

LIFTING SENSOR (FRONT)ADP-75
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
LIFTING SENSOR (FRONT)
DescriptionINFOID:0000000001735513
• The lifting sensor (front) is installed to the seat slide cushion frame.
• The pulse signal is input to the driver seat control unit when the lifting (front) is operated.
• The driver seat control unit counts the pulse and ca lculates the lifting (front) amount of the seat.
Component Function CheckINFOID:0000000001735514
1.CHECK FUNCTION
1. Select “LIFT FR PULSE” in “Data monitor” mode with CONSULT-III.
2. Check the lifting sensor (front) signal under the following conditions.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-75, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000001735515
1. CHECK LIFTING SENSOR (FRONT) SIGNAL
1. Turn ignition switch ON.
2. Read the voltage signal between driver seat control unit harness connector and ground with an oscilloscope.
Is the inspection result normal?
YES >> GO TO 4
NO >> GO TO 2
2. CHECK LIFTING SENSOR (FRONT) CIRCUIT
Monitor item Condition Value
LIFT FR PULSE Seat lifting (front)Operate (up)
Change (increase)
Operate (down) Change (decrease)
Release No change
Te r m i n a l s
ConditionVoltage signal
(+)
(–)
Driver
seat con- trol unit
connector Te r m i -
nal
B202 25 Ground Seat
lifting
(front)Oper-
ate
Other
than
above
0 or 5
PIIA4561E
SIIA0691J
Revision: March 2010
2008 QX56

ADP-76
< COMPONENT DIAGNOSIS >
LIFTING SENSOR (FRONT)
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and lifting motor (front).
3. Check continuity between driver seat control unit harness con-nector and lifting motor (front) harness connector.
4. Check continuity between driver seat control unit harness con- nector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK SEAT OPERATION
1. Connect driver seat control unit and lifting motor (front) connector.
2. Check seat operation [except lifting (front) operation] with memory function.
Is the operation normal?
YES >> Replace lifting motor (front). (Built in seat slide cushion frame.)
NO >> Replace driver seat control unit.
4. CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace driver seat control unit.
NO >> Repair or replace the malfunctioning part.
Driver seat control unit connector Te r m i n a l
Lifting motor
(front) connector Terminal Continuity
B202 16
B206 3
Ye s
25 2
31 1
Driver seat control unit connector Te r m i n a l
Ground Continuity
B202 16
No
25
31
LIIA0708E
Revision: March 2010 2008 QX56
