DOOR MIRROR REMOTE CONTROL SWITCHADP-85
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
Is the inspection result normal?
YES >> INSPECTION END
NO >> Refer to ADP-85, "
MIRROR SWITCH : Diagnosis Procedure".
MIRROR SWITCH : Diagnosis ProcedureINFOID:0000000006248382
1.CHECK MIRROR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect door mirror remote control switch connector.
3. Turn ignition switch ON.
4. Check voltage between door mirror remote control switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK MIRROR SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit connector.
3. Check continuity between automatic drive posit ioner control unit harness connector and door mirror
remote control switch harness connector.
4. Check continuity between automatic drive positioner control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace automatic drive positioner control unit.
NO >> Repair or replace harness.
3.CHECK DOOR MIRROR REMOTE CONTROL SWITCH GROUND CIRCUIT
MIR CON SW-RH/LH When operating the mirror switch toward the right or left side. : ON
Other than the above. : OFF
Monitor item Condition
(+)
(-)Voltage (V)
(Approx.)
Door mirror remote
control switch
Connector Terminal
M8 4
Ground 5
5
6
14
Automatic drive positioner control unit Door mirror remote control switch Continuity
Connector Terminal Connector Terminal
M75 3
M8 6
Existed
45
15 14
16 4
Automatic drive positioner control unit GroundContinuity
Connector Terminal
M75 3
Not existed
4
15
16
Revision: 2010 May2011 QX56
Page 98 of 5598
SLIDING SENSORADP-89
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
SLIDING SENSOR
Component Function CheckINFOID:0000000006248386
1.CHECK FUNCTION
1. Select “SLIDE PULSE” in “Data monitor” mode with CONSULT-III.
2. Check sliding sensor signal under the following conditions.
*1 : The value at the seat position attained when the battery is connected is considered to be 32768.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-89, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000006248387
1.CHECK SLIDING SENSOR SIGNAL
1. Turn ignition switch ON.
2. Read voltage signal between driver seat contro l unit harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace driver seat control unit.
NO >> GO TO 2.
2.CHECK SLIDING SENSOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and sliding sensor connector.
3. Check continuity between driver seat control unit harness connector and sliding sensor harness connec-
tor.
4. Check continuity between driver s eat control unit harness connector and ground.
Monitor item Condition Value
SLIDE PULSE Seat sliding Operate (forward)
Change (increase)
*1
Operate (backward)Change (decrease)*1
Release
No change*1
(+)
(-) Condition Signal
(Reference value)
Driver seat control unit
Connector Terminals
B452 18 Ground Seat sliding Operate
Other than the
above
0 or 5
JMJIA0119ZZ
Driver seat control unit Sliding motor
Continuity
Connector Terminal Connector Terminal
B452 18 B461 18 Existed
Revision: 2010 May2011 QX56
Page 100 of 5598
RECLINING SENSORADP-91
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
RECLINING SENSOR
Component Function CheckINFOID:0000000006248388
1.CHECK FUNCTION
1. Select “RECLN PULSE” in “Data monitor” mode with CONSULT-III.
2. Check reclining sensor signal under the following conditions.
*1 : The value at the seat position attained when the battery is connected is considered to be 32768.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-91, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000006248389
1.CHECK RECLINING SENSOR SIGNAL
1. Turn ignition switch ON.
2. Read voltage signal between driver seat contro l unit harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace driver seat control unit.
NO >> GO TO 2.
2.CHECK RECLINING SENSOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and reclining motor connector.
3. Check continuity between driver seat control unit harness connector and reclining motor harness connec-
tor.
4. Check continuity between driver s eat control unit harness connector and ground.
Monitor item Condition Value
RECLN PULSE Seat reclining Operate (forward)
Change (increase)
*1
Operate (backward)Change (decrease)*1
Release
No change*1
(+)
(-) Condition Signal
(Reference value)
Driver seat control unit
Connector Terminals
B452 4 Ground Seat reclining Operate
Other than the
above
0 or 5
JMJIA0119ZZ
Driver seat control unit Reclining motor
Continuity
Connector Terminal Connector Terminal
B4524B4544Existed
Revision: 2010 May2011 QX56
Page 102 of 5598
LIFTING SENSOR (FRONT)ADP-93
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
LIFTING SENSOR (FRONT)
Component Function CheckINFOID:0000000006248390
1.CHECK FUNCTION
1. Select “LIFT FR PULSE” in “Data monitor” mode with CONSULT-III.
2. Check the lifting sensor (front) signal under the following conditions.
*1 : The value at the seat position attained when the battery is connected is considered to be 32768.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-93, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000006248391
1.CHECK LIFTING SENSOR (FRONT) SIGNAL
1. Turn ignition switch ON.
2. Read the voltage signal driver seat contro l unit harness connector and ground with an oscilloscope.
Is the inspection result normal?
YES >> Replace driver seat control unit.
NO >> GO TO 2.
2.CHECK LIFTING SENSOR (FRONT) CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and lifting motor (front) connector.
3. Check continuity between driver seat control uni t harness connector and lifting motor (front) harness con-
nector.
4. Check continuity between driver s eat control unit harness connector and ground.
Monitor item Condition Value
LIFT FR PULSE Seat lifting (front) Operate (up)
Change (increase)
*1
Operate (down)Change (decrease)*1
Release
No change*1
(+)
(-) Condition Voltage (V)
(Approx.)
Driver seat control unit
Connector Terminals
B452 19 Ground Seat Lifting
(front)Operate
Other than the
above
0 or 5
JMJIA0119ZZ
Driver seat control unit Lifting motor (front)
Continuity
Connector Terminal Connector Terminal
B452 19 B455 19 Existed
Revision: 2010 May2011 QX56
Page 104 of 5598
LIFTING SENSOR (REAR)ADP-95
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
LIFTING SENSOR (REAR)
Component Function CheckINFOID:0000000006248392
1.CHECK FUNCTION
1. Select “LIFT RR PULSE” in “Data monitor” mode with CONSULT-III.
2. Check lifting sensor (rear) signal under the following conditions.
*1 : The value at the seat position attained when the battery is connected is considered to be 32768.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-95, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000006248393
1.CHECK LIFTING SENSOR (REAR) SIGNAL
1. Turn ignition switch ON.
2. Read voltage signal between driver seat contro l unit harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace driver seat control unit.
NO >> GO TO 2.
2.CHECK LIFTING SENSOR (REAR) CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit and lifting motor (rear) connector.
3. Check the continuity between driver seat cont rol unit harness connector and lifting motor (rear) harness
connector.
4. Check the continuity between driver seat control unit harness connector and ground.
Monitor item Condition Value
LIFT RR PULSE Seat lifting (rear) Operate (up)
Change (increase)
*1
Operate (down)Change (decrease)*1
Release
No change*1
(+)
(-) Condition Voltage (V)
(Approx.)
Driver seat control unit
Connector Terminals
B452 20 Ground Seat Lifting
(rear)Operate
Other than the
above
0 or 5
JMJIA0119ZZ
Driver seat control unit Lifting motor (rear)
Continuity
Connector Terminal Connector Terminal
B452 20 B456 20 Existed
Revision: 2010 May2011 QX56
Page 106 of 5598
TILT SENSORADP-97
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
TILT SENSOR
Component Function CheckINFOID:0000000006248394
1.CHECK FUNCTION
1. Select “TILT PULSE” in “Data monitor” mode with CONSULT-III.
2. Check tilt sensor signal under the following conditions.
*1 : The value at the seat position attained when the battery is connected is considered to be 32768.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-97, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000006248395
1.CHECK TILT SENSOR SIGNAL
1. Turn ignition switch ON.
2. Check voltage signal between driver seat c ontrol unit connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace driver seat control unit.
NO >> GO TO 2.
2.CHECK TILT SENSOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit connector and tilt motor connector.
3. Check continuity between driver seat control unit harness connector and tilt motor harness connector.
4. Check continuity between driver s eat control unit harness connector and ground.
Monitor item Condition Value
TILT PULSE Steering column Operate (up)
Change (increase)
*1
Operate (down)Change (decrease)*1
Release
No change*1
(+)
(-) Condition Voltage (V)
(Approx.)
Driver seat control unit
Connector Terminals
B452 21 Ground Ste eri ng co l-
umnOperate
Other than the
above
0 or 5
JMJIA0119ZZ
Driver seat control unit Tilt motor
Continuity
Connector Terminal Connector Terminal
B452 21 M116 5 Existed
Driver seat control unit GroundContinuity
Connector Terminal
B452 21 Not existed
Revision: 2010 May2011 QX56
Page 108 of 5598
TELESCOPIC SENSORADP-99
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
TELESCOPIC SENSOR
Component Function CheckINFOID:0000000006248396
1.CHECK FUNCTION
1. Select “TELESCO PULSE” in “Dat a monitor” mode with CONSULT-III.
2. Check telescopic sensor signal under the following conditions.
*1 : The value at the seat position attained when the battery is connected is considered to be 32768.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-99, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000006248397
1.CHECK TELESCOPIC SENSOR SIGNAL
1. Turn ignition switch ON.
2. Check voltage signal between driver seat c ontrol unit connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace driver seat control unit.
NO >> GO TO 2.
2.CHECK TELESCOPIC SENSOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit connector and telescopic motor connector.
3. Check continuity between driver seat control unit harness connector and telescopic motor harness con-
nector.
4. Check continuity between driver s eat control unit harness connector and ground.
Monitor item Condition Value
TELESCO PULSE Steering column Operate (forward)
Change (increase)
*1
Operate (backward)Change (decrease)*1
Release
No change*1
(+)
(-) Condition Voltage (V)
(Approx.)
Driver seat control unit
Connector Terminals
B452 5 Ground Ste eri ng co l-
umnOperate
Other than the
above
0 or 5
JMJIA0119ZZ
Driver seat control unit Telescopic motor
Continuity
Connector Terminal Connector Terminal
B4525M1175Existed
Revision: 2010 May2011 QX56
Page 111 of 5598
ADP-102
< DTC/CIRCUIT DIAGNOSIS >
MIRROR SENSOR
MIRROR SENSOR
DRIVER SIDE
DRIVER SIDE : Component Function CheckINFOID:0000000006248398
1.CHECK FUNCTION
1. Select “MIR/SEN LH U-D”, “MIR/SEN LH R-L” in “Data monitor” with CONSULT-III.
2. Check mirror sensor (driver side) signal under the following condition.
Is the indication normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-102, "
DRIVER SIDE : DiagnosisProcedure".
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000006248399
1.CHECK DOOR MIRROR (DRIVER SIDE) SENSOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect door mirror (driver side) connector.
3. Turn ignition switch ON.
4. Check voltage between door mirror (driver side) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK DOOR MIRROR (DRIVER SIDE ) SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit connector.
3. Check continuity between automatic drive posit ioner control unit harness connector and door mirror
(driver side) harness connector.
4. Check continuity between automatic drive positioner control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace automatic drive positioner control unit.
NO >> Repair or replace harness or connector.
Monitor item Condition Value
MIR/SEN LH U-D Door mirror (driver side)Change between
3.4 [V] (close to peak)
0.6 [V] (close to valley)
MIR/SEN LH R-L Change between
0.6 [V] (close to left edge)
3.4 [V] (close to right edge)
(+)
(-)Voltage (V)
(Approx.)
Door mirror (driver side)
Connector Terminals D3 23 Ground 5
Automatic drive positioner control unit Door mirror (driver side) Continuity
Connector Terminal Connector Terminal
M7521D323Existed
Automatic drive positioner control unit GroundContinuity
Connector Terminal
M75 21 Not existed
Revision: 2010 May2011 QX56
Page 112 of 5598
MIRROR SENSORADP-103
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
3.CHECK DOOR MIRROR (DRIVER SIDE) SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control unit connector.
3. Check continuity between automatic drive posit ioner control unit harness connector and door mirror
(driver side) harness connector.
4. Check continuity between automatic drive positioner control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connector.
4.CHECK DOOR MIRROR (DRIVE R SIDE) SENSOR CIRCUIT
1. Check continuity between automatic drive posit ioner control unit harness connector and door mirror
(driver side) harness connector.
2. Check continuity between automatic drive positioner control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace door mirror sensor (built in driver side door mirror).
NO >> Repair or replace harness or connector.
PASSENGER SIDE
PASSENGER SIDE : Co mponent Function CheckINFOID:0000000006248400
1.CHECK FUNCTION
1. Select “MIR/SEN RH U-D”, “MIR/SEN RH R-L” in “Data monitor” with CONSULT-III.
2. Check the mirror sensor (passenger side) signal under the following conditions.
Is the indication normal?
YES >> INSPECTION END
Automatic drive positioner control unit Door mirror (driver side) Continuity
Connector Terminal Connector Terminal
M7520D324Existed
Automatic drive positioner control unit GroundContinuity
Connector Terminal
M75 20 Not existed
Automatic drive positioner control unit Door mirror (driver side) Continuity
Connector Terminal Connector Terminal
M75 6
D3 21
Existed
18 22
Automatic drive positioner control unit GroundContinuity
Connector Terminal
M75 6
Not existed
18
Monitor item Condition Value
MIR/SEN RH U-D Door mirror (passenger side)Change between
3.4 [V] (close to peak)
0.6 [V] (close to valley)
MIR/SEN RH R-L Change between
3.4 [V] (close to left edge)
0.6 [V] (close to right edge)
Revision: 2010 May2011 QX56
Page 115 of 5598
ADP-106
< DTC/CIRCUIT DIAGNOSIS >
SLIDING MOTOR
SLIDING MOTOR
Component Function CheckINFOID:0000000006248402
1.CHECK FUNCTION
1. Select “SEAT SLIDE” in “Act ive test” mode with CONSULT-III.
2. Check the sliding motor operation.
Is the operation of relevant parts normal?
YES >> INSPECTION END
NO >> Perform diagnosis procedure. Refer to ADP-106, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000006248403
1.CHECK SLIDING MOTOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect sliding motor connector.
3. Turn ignition switch ON.
4. Perform “Active test” (“SEAT SLIDE”) with CONSULT-III
5. Check voltage between sliding motor harness connector and ground.
Is the inspection result normal?
YES >> Replace sliding motor (built in seat slide cushion frame).
NO >> GO TO 2.
2.CHECK SLIDING MOTOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect driver seat control unit connector.
3. Check continuity between driver seat control uni t harness connector and sliding motor harness connector.
4. Check continuity between driver seat control unit harness connector and ground.
Te s t i t e m D e s c r i p t i o n
SEAT SLIDE OFF
Seat slidingStop
FR Forward
RR Backward
(+) (-) Condition Voltage (V)
(Approx.)
Sliding motor
Connector Terminals
B461 38
Ground SEAT SLIDE OFF 0
FR (forward) 12
RR (backward) 0
34 OFF 0
FR (forward) 0
RR (backward) 12
Driver seat control unit Sliding motor
Continuity
Connector Terminal Connector Terminal
B451 34
B461 34
Existed
38 38
Revision: 2010 May2011 QX56
