AV-154
< DTC/CIRCUIT DIAGNOSIS >
B2701 SENSOR HARNESS OPEN [CR-FL]
B2701 SENSOR HARNESS OPEN [CR-FL]
DTC LogicINFOID:0000000006216308
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000006216309
1.CHECK HARNESS CORNER SENSOR FRONT LH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect sonar control unit connector and corner sensor front LH connector.
3. Check continuity between sonar control unit harnes s connector and corner sensor front LH harness con-
nector.
4. Check continuity between sonar control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK HARNESS CORNER SENSOR FRONT LH GROUND CIRCUIT
Check continuity between sonar control unit harness c onnector and corner sensor front LH harness connector.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
DTC No. CONSULT-III indication DTC detection condition Troubleshooting B2701 SENSOR HARNESS
OPEN [CR-FL] [B2701]
Corner sensor front LH harness circuit is open. Check corner sensor front LH circuit.
Sonar control unit Corner sensor front LH
Continuity
Connector Terminal Connector Terminal
M47 3 E221 1 Existed
Sonar control unit GroundContinuity
Connector Terminal
M47 3 Not existed
Sonar control unit Corner sensor front LH Continuity
Connector Terminal Connector Terminal
M47 12 E221 2 Existed
Revision: 2010 May2011 QX56

AV-156
< DTC/CIRCUIT DIAGNOSIS >
B2703 SENSOR HARNESS OPEN [CR-FR]
B2703 SENSOR HARNESS OPEN [CR-FR]
DTC LogicINFOID:0000000006216311
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000006216312
1.CHECK HARNESS CORNER SENSOR FRONT RH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect sonar control unit connector and corner sensor front RH connector.
3. Check continuity between sonar control unit harne ss connector and corner sensor front RH harness con-
nector.
4. Check continuity between sonar control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK HARNESS CORNER SENSOR FRONT RH GROUND CIRCUIT
Check continuity between sonar control unit harness connector and corner sensor front RH harness connec-
tor.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
DTC No. CONSULT-III indication DTC detection condition Troubleshooting
B2703 SENSOR HARNESS
OPEN [CR-FR] [B2703]
Corner sensor front RH harness circuit is open. Check corner sensor front RH circuit.
Sonar control unit Corner sensor front RH
Continuity
Connector Terminal Connector Terminal
M47 4 E222 1 Existed
Sonar control unit GroundContinuity
Connector Terminal
M47 4 Not existed
Sonar control unit Corner sensor front RH Continuity
Connector Terminal Connector Terminal
M47 12 E222 2 Existed
Revision: 2010 May2011 QX56

AV-158
< DTC/CIRCUIT DIAGNOSIS >
B2705 SENSOR HARNESS OPEN [CR-RL]
B2705 SENSOR HARNESS OPEN [CR-RL]
DTC LogicINFOID:0000000006216314
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000006216315
1.CHECK HARNESS CORNER SENSOR REAR LH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect sonar control unit connector and corner sensor rear LH connector.
3. Check continuity between sonar control unit harne ss connector and corner sensor rear LH harness con-
nector.
4. Check continuity between sonar control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK HARNESS CORNER SENSOR REAR LH GROUND CIRCUIT
Check continuity between sonar control unit harness c onnector and corner sensor rear LH harness connector.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
DTC No. CONSULT-III indication DTC detection condition Troubleshooting B2705 SENSOR HARNESS
OPEN [CR-RL] [B2705]
Corner sensor rear LH harness circuit is open. Check corner sensor rear LH circuit.
Sonar control unit Corner sensor rear LH
Continuity
Connector Terminal Connector Terminal
M47 5 B252 1 Existed
Sonar control unit GroundContinuity
Connector Terminal
M47 5 Not existed
Sonar control unit Corner sensor rear LH Continuity
Connector Terminal Connector Terminal
M47 12 B252 2 Existed
Revision: 2010 May2011 QX56

AV-160
< DTC/CIRCUIT DIAGNOSIS >
B2707 SENSOR HARNESS OPEN [CR-RR]
B2707 SENSOR HARNESS OPEN [CR-RR]
DTC LogicINFOID:0000000006216317
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000006216318
1.CHECK HARNESS CORNER SENSOR REAR RH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect sonar control unit connector and corner sensor rear RH connector.
3. Check continuity between sonar control unit harne ss connector and corner sensor rear RH harness con-
nector.
4. Check continuity between sonar control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK HARNESS CORNER SENSOR REAR RH GROUND CIRCUIT
Check continuity between sonar control unit harness connector and corner sensor rear RH harness connector.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
DTC No. CONSULT-III indication DTC detection condition Troubleshooting B2707 SENSOR HARNESS
OPEN [CR-RR] [B2707]
Corner sensor rear RH harness circuit is open. Check corner sensor rear RH circuit.
Sonar control unit Corner sensor rear RH
Continuity
Connector Terminal Connector Terminal
M47 6 B253 1 Existed
Sonar control unit GroundContinuity
Connector Terminal
M47 6 Not existed
Sonar control unit Corner sensor rear RH Continuity
Connector Terminal Connector Terminal
M47 12 B253 2 Existed
Revision: 2010 May2011 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-161
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B A
O P
POWER SUPPLY AND GROUND CIRCUIT
AV CONTROL UNIT
AV CONTROL UNIT : Diagnosis ProcedureINFOID:0000000006216319
1.CHECK FUSE
Check for blown fuses.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between AV control unit harness connectors and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check harness between AV control unit and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AV control unit connectors.
3. Check continuity between AV control unit harness connectors and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
FRONT DISPLAY UNIT
FRONT DISPLAY UNIT : Diagnosis ProcedureINFOID:0000000006216320
1.CHECK FUSE
Check for blown fuses.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between front display unit harness connector and ground.
Power source Fuse No.
Battery 35
Ignition switch ACC or ON 19
Signal name Connector Terminal Ignition switch position Value (Approx.)
Battery power supply M208 19 OFF Battery voltage ACC power supply M208 7 ACC Battery voltage
Signal name Connector Terminal Ignition switch position Continuity Ground M208 20 OFF Existed
Power source Fuse No. Battery 35
Ignition switch ACC or ON 19
Revision: 2010 May2011 QX56

AV-162
< DTC/CIRCUIT DIAGNOSIS >
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check harness between front display unit and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front display unit connector.
3. Check continuity between front display unit harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
HEADREST DISPLAY UNIT
HEADREST DISPLAY UNIT : Diagnosis ProcedureINFOID:0000000006216321
1.CHECK FUSE
Check for blown fuses.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between headrest display unit harness connector and ground.
 *1: Headrest display unit LH
 *2: Headrest display unit RH
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check harness between headrest display unit and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect headrest display unit connector.
3. Check continuity between headrest display unit harness connector and ground.
 *1: Headrest display unit LH
 *2: Headrest display unit RH
Signal name Connector Terminal Ignition switch position Value (Approx.)
Battery power su pply M215 11 OFF Battery voltage
ACC power supply M215 23 ACC Battery voltage
Signal name Connector Terminal Ignition switch position Continuity Ground M215 12 OFF Existed
Power source Fuse No. Battery 35
Signal name Connector Terminal Ignition switch position Value (Approx.)
Battery power supply B554
*1
B574*2
2
OFF Battery voltage
4
Signal name Connector Terminal Ignition switch position Continuity
Ground B554
*1
B574*2
1
OFF Existed
3
Revision: 2010 May2011 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-163
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B A
O P
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
VIDEO DISTRIBUTOR
VIDEO DISTRIBUTOR : Diagnosis ProcedureINFOID:0000000006216322
1.CHECK FUSE
Check for blown fuses.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between video distributor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check harness between video distributor and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect video distributor connector.
3. Check continuity between video distributor harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
BOSE AMP.
BOSE AMP. : Diagnosis ProcedureINFOID:0000000006216323
1.CHECK FUSE
Check for blown fuses.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Power source Fuse No.
Battery 35
Ignition switch ACC or ON 19
Signal name Connector Terminal Ignition switch position Value (Approx.)
Battery power supply M217 2 OFF Battery voltage ACC power supply M217 4 ACC Battery voltage
Signal name Connector Terminal Ignition switch position Continuity Ground M217 1 OFF Existed
Ground M217 3 OFF Existed
Power source Fuse No. Battery 5
Battery 8
Revision: 2010 May2011 QX56

AV-164
< DTC/CIRCUIT DIAGNOSIS >
POWER SUPPLY AND GROUND CIRCUIT
Check voltage between BOSE amp. harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check harness between BOSE amp. and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BOSE amp. connector.
3. Check continuity between BOSE amp. harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
AROUND VIEW MONITOR CONTROL UNIT
AROUND VIEW MONITOR CONTRO L UNIT : Diagnosis ProcedureINFOID:0000000006216324
1.CHECK FUSE
Check for blown fuses.
Is inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUITS
Check voltage between around view monitor control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Check harness between around view monitor control unit and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect around view monitor control unit connector.
3. Check continuity between around view m onitor control unit harness connector and ground.
Is inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
Signal name Connector Terminal Ignition switch position Value (Approx.)
Battery power supply B229 10 OFF Battery voltage
Battery power supply B229 11 OFF Battery voltage
Signal name Connector Terminal Ignition switch position Continuity Ground B229 12 OFF Existed
Power source Fuse No. Battery 9
Ignition switch ACC 19
Signal name Connector Terminal Ignition switch position Value (Approx.)
Battery power supply M4 82OFFBattery voltage
ACC power supply M48 4 ACC Battery voltage
Signal name Connector Terminal Ignition switch position Continuity
Ground M48 1 OFF Existed
Revision: 2010 May2011 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-165
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B A
O P
SONAR CONTROL UNIT (WITH AROUND VIEW MONITOR)
SONAR CONTROL UNIT (WITH AROUND VIEW MONITOR) : Diagnosis Procedure
INFOID:0000000006216325
1.CHECK FUSE
Check for blown fuses.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between sonar control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace sonar control unit power supply harness.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect sonar control unit connector.
3. Check continuity between sonar control unit harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair or replace sonar control unit ground harness.
Power source Fuse No.
Ignition switch ACC or ON 19
Signal name Connector Terminal Ignition switch position Value (Approx.)
Battery power supply M47 13 ACC Battery voltage
Signal name Connector Terminal Ignition switch position Continuity Ground M47 24 OFF Existed
Revision: 2010 May2011 QX56

AV-166
< DTC/CIRCUIT DIAGNOSIS >
RGB DIGITAL IMAGE SIGNAL CIRCUIT
RGB DIGITAL IMAGE SIGNAL CIRCUIT
DescriptionINFOID:0000000006216326
Transmit the image displayed with AV control unit with RGB digital image signal to the front display unit.
Diagnosis ProcedureINFOID:0000000006216327
1.CHECK CONTINUITY RGB DIGI TAL IMAGE SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front display unit connector and AV control unit connector.
3. Check continuity between front display unit har ness connector and AV control unit harness connector.
4. Check continuity between front display unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB DIGITAL IMAGE SIGNAL
1. Connect AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between front display unit harness connector and ground.
Is the inspection result normal?
YES >> Replace front display unit. Refer to AV-213, "Removal and Installation".
NO >> Replace AV control unit. Refer to AV-212, "
Removal and Installation".
Front display unit AV control unit
Continuity
Connector Terminals Connector Terminals
M322 27
M321 157
Existed
28 158
Front display unit GroundContinuity
Connector Terminals
M322 27
Not existed
28
(+)
(− ) Condition Voltage
(Approx.)
Front display unit
Connector Terminal
M322 27
Ground — 1.3 V
28
Revision: 2010 May2011 QX56
