303 00 JAGUAR XFR 2010 1.G Workshop Manual

Fuel Charging and Controls - V8 S/C 5.0L Petrol - Fuel Rail LH
Removal and Installation

Special Tool(s)

303-1450
Spark Plug Remover/Installer
310-197
Remover, Fuel Injector
310-198
Installer, Teflon Seal
310-199
Re-shape Tool, Teflon Seal
310-200-01
Fuel Rail Installation Guide Pins - Threaded
310-200-02
Fuel Rail Installation Guide Pins - Unthreaded Removal


CAUTION: Make sure that tools and equipment are clean, free of foreign material and lubricant.

NOTES: Published: 21-Nov-2013

Removal steps in this procedure may contain installation details.


Some variation in the illustrations may occur, but the essential information is always correct.

1. Refer to: Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions (100-00 General Information, Description and Operation).

2. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

3. Refer to: Fuel System Pressure Release - V8 5.0L Petrol/V8 S/C 5.0L Petrol (310-00 Fuel System - General Information, General Procedures).

4. Refer to: Secondary Bulkhead Panel LH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).
5. Refer to: Fuel Injection Component Cleaning (303-04D Fuel Charging and Controls - V8 5.0L Petrol, General Procedures).


6. CAUTION: Be prepared to collect escaping fluids.
















7.
8. CAUTION: Be prepared to collect escaping fluids. www.JagDocs.com

9. CAUTION: Be prepared to collect escaping fluids.











10.
Refer to: Air Cleaner Outlet Pipe RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).




12.

11.

CAUTIONS:


Be
prepared to
collect
escaping
fluids.


Make
sure that all
openings
are sealed.
Use new
blanking
caps.

13.
14.
15.



















NOTE: RH shown LH similar.

Special Tool(s): 303-1450






















CAUTION: Make a note of the fuel injector clamp alignment to the fuel
rail prior to removal.

10.
















11.
12.
13. NOTE: Tighten in the sequence indicated.

Torque:
Bolt 2 30 Nm Bolt 3 30 Nm Bolt 1 30 Nm Bolt 4 30 Nm











NOTE: RH shown LH similar.

Special Tool(s): 303-1450 Torque: 20 Nm




















Torque: 7 Nm

14.
15. NOTES:


Lubricate
the union
threads with
clean engine
oil.


Do not
tighten at
this stage.


Remove and
discard the
blanking
caps.





Torque:
union 21 Nm bolts 8 Nm














16.
Torque: 21 Nm











17.
Refer to: Air Cleaner Outlet Pipe RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).

Removal steps in this procedure may contain installation details.

Some variation in the illustrations may occur, but the essential information is always correct.

1. Refer to: Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions (100-00 General Information, Description and Operation).

2. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

3. Refer to: Fuel System Pressure Release - V8 5.0L Petrol/V8 S/C 5.0L Petrol (310-00 Fuel System - General Information, General Procedures).

4. Refer to: Secondary Bulkhead Panel RH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).
5. Refer to: Fuel Injection Component Cleaning (303-04D Fuel Charging and Controls - V8 5.0L Petrol, General Procedures).


6. CAUTION: Be prepared to collect escaping fluids.
















7.
8. CAUTION: Be prepared to collect escaping fluids.











9. Refer to: Air Cleaner Outlet Pipe RH (303-12C Intake Air Distribution and Filtering - V8

18.
19.
20.
21.



















NOTE: LH shown RH similar.

















NOTE: LH shown RH similar.
















Special Tool(s): 303-1450

9.
















10.
11.
12. NOTE: LH shown RH similar.

Torque: 20 Nm













NOTES:


LH shown RH similar.


Tighten in the sequence indicated.

Torque:
Bolt 2 30 Nm Bolt 3 30 Nm Bolt 1 30 Nm Bolt 4 30 Nm























Special Tool(s): 303-1450 Torque: 20 Nm

28. Refer to: Air Cleaner Outlet Pipe RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).

29.
30.
31.












32. Refer to: Secondary Bulkhead Panel RH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).
33. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
