JAGUAR XFR 2010 1.G Workshop Manual

21.
22.
23.
24. CAUTIONS:

Be prepared to collect escaping fluids.

Make sure that all openings are sealed. Use new blanking caps.







































CAUTION: Be prepared to collect escaping fluids.
Loosen the Torx screws a turn each at a time.















CAUTION: Be prepared to collect escaping fluids.

Installation


1. NOTE: Lubricate the fuel rail high-pressure fuel pump bucket with
clean engine oil.
















2. CAUTION: Tighten the Torx screws a turn at a time until the
correct torque is achieved.

NOTE: Lubricate the fuel rail high-pressure fuel pump O-ring seal
with clean engine oil.
Torque: 12 Nm









3. Loosen the Torx screws half a turn each. 4. www.JagDocs.com

5. CAUTION: Install new high-pressure fuel supply lines.
NOTES:
Engine shown removed for clarity.

Remove and discard the blanking caps.

Install the bolt and unions fully finger tight before final
tightening.























6. CAUTION: Care must be taken when positioning the fuel rail
high-pressure fuel pump cover to one side.

NOTE: Fuel rail high-pressure fuel pump cover shown removed for
clarity.
Torque: 12 Nm





7. Lower the vehicle.
8. NOTES:

Do not tighten at this stage.

Remove and discard the blanking caps.








9. WARNING: Do not work on or under a vehicle supported only by a jack. Always

support the vehicle on safety stands.
Raise and support the vehicle.


10.





































11. CAUTION: Lubricate only the union threads with clean engine oil.

NOTE: Engine shown removed for clarity.
Torque: Unions (1) 21 Nm M6 (2) 11 Nm M8 (3) 25 Nm M5 nut (4) 6 Nm


























NOTE: Engine shown removed for clarity.
Torque: 21 Nm

12.
13.
14. NOTES:

Install the bolt and unions finger tight before final tightening.

Remove and discard the blanking caps.
Torque: Unions 21 Nm M6 11 Nm














Torque: 21 Nm


















NOTE: Engine shown removed for clarity.
Torque: M10 29 Nm M6 11 Nm

15.

















16. NOTE: Engine shown removed for clarity.
















Torque: 25 Nm

















17. Refer to: Generator - V8 5.0L Petrol (414-02C Generator and Regulator - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal and Installation).

18. Refer to: Engine Mount RH (303-01D, In-vehicle Repair).

19. Lower the vehicle.
20.

21. NOTES:

Lubricate
the
union
threads
with
clean
engine
oil.

Do
not tighten
at this
stage.

Remove
and
discard
the
blanking
caps.

22. Torque: Unions 21 Nm Bolts 8 Nm










23. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
24. www.JagDocs.com

Ornamentation, Removal and Installation).

28. Refer to: Secondary Bulkhead Panel RH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).
29. Refer to: Secondary Bulkhead Panel LH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).
30. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

Published: 11-May-2011
Fuel Charging and Controls - V8 S/C 5.0L Petrol - Right-Hand Fuel Rail High-Pressure
Fuel Pump Removal and Installation

Removal

CAUTION: Make sure that tools and equipment are clean, free of foreign material and lubricant.
NOTES:

Removal steps in this procedure may contain installation details.

Some variation in the illustrations may occur, but the essential information is always correct.
All vehicles
1. Refer to: Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions (100-00 General Information, Description and Operation).
2. Refer to: Fuel System Pressure Release - V8 5.0L Petrol/V8 S/C 5.0L Petrol (310-00 Fuel System - General Information, General Procedures).
3. Refer to: Secondary Bulkhead Panel LH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation). 4. Refer to: Secondary Bulkhead Panel RH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation). 5. Refer to: Engine Cover - V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-05 Interior Trim and Ornamentation, Removal and Installation).
6. Refer to: Fuel Injection Component Cleaning (303-04E Fuel Charging and Controls - V8 S/C 5.0L Petrol, General Procedures).

7. CAUTION: Be prepared to collect escaping fluids.

8.
9. CAUTION: Be prepared to collect escaping fluids.












10. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

11. CAUTIONS:

Be
prepared
to collect
escaping
fluids.

Make
sure that
all
openings
are sealed.
Use new
blanking
caps.
