JAGUAR XFR 2010 1.G Workshop Manual

7. CAUTIONS:


Make sure that the accessory drive belt is correctly
aligned to the pulleys. Failure to follow this instruction may
result in damage to the vehicle.


Clean and inspect the accessory drive belt pulleys for
damage.
NOTES:


Some variation in the illustrations may occur, but the
essential information is always correct.


Engine shown removed for clarity.


Note the fitted position.

Installation

1. To install, reverse the removal procedure.

Published: 11-May-2011
Accessory Drive - V8 S/C 5.0L Petrol - Accessory Drive Belt Idler Pulley
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Supercharger Belt (303-05, Removal and Installation).

3. Refer to: Air Cleaner Outlet Pipe LH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).


4. NOTE: Note the fitted position.
















5. Torque: 25 Nm

Installation 6. Torque: 40 Nm
1. CAUTIONS:


Make sure the accessory belt is correctly aligned to the pulleys.
Failure to follow this instruction may result in damage to the vehicle.


Clean and inspect the accessory drive belt pulleys for damage.

To install, reverse the removal procedure. www.JagDocs.com

Published: 11-May-2011
Accessory Drive - V8 S/C 5.0L Petrol - Accessory Drive Belt Tensioner
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Air Cleaner Outlet Pipe T-Connector (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

3. Refer to: Air Cleaner Outlet Pipe LH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).







Installation
4. NOTE: Note the fitted position.






5. Torque: 40 Nm
1. CAUTIONS:


Make sure the accessory belt is correctly aligned to the pulleys.
Failure to follow this instruction may result in damage to the vehicle.


Clean and inspect the accessory drive belt pulleys for damage.
To install, reverse the removal procedure.

Published: 11-May-2011
Accessory Drive - V8 S/C 5.0L Petrol - Supercharger Belt Idler Pulley
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

3. Refer to: Air Cleaner Outlet Pipe T-Connector (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).







Installation

4. NOTES:


Note the fitted position.


Engine shown removed for clarity.



















5. Torque: 40 Nm

1. CAUTION: Make sure the supercharger belt is correctly aligned to the
pulleys. Failure to follow this instruction may result in damage to
the vehicle.

To install, reverse the removal procedure.

Published: 11-May-2011
Accessory Drive - V8 S/C 5.0L Petrol - Supercharger Belt Tensioner
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

3. Refer to: Air Cleaner Outlet Pipe T-Connector (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).







Installation

4.

























5. Torque: 40 Nm

Make sure the supercharger belt is correctly aligned to the pulleys.
Failure to follow this instruction may result in damage to the vehicle.


Clean and inspect the accessory drive belt pulleys for damage.

To install, reverse the removal procedure. 1.CAUTIONS:

Starter motor retaining bolts 47 35 - Battery positive terminal connector retaining nut 10 7 - Solenoid terminal connector retaining nut 7 - 62 www.JagDocs.com

Published: 11-May-2011
Starting System - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Starting System - Component Location
Description and Operation


NOTE: Installation on supercharged engine shown, installation on naturally aspirated engine similar.
COMPONENT LOCATION

1 Bolt (2 off) 2 Heat shield 3 Starter solenoid 4 Solenoid power terminal 5 Pinion gear 6 Starter power terminal 7 Electric motor 8 Breather tube
