JAGUAR XFR 2010 1.G Workshop Manual
Page 1099 of 3039
6. CAUTION: Install new o-ring seals
Torque: 9 Nm
7.
8.
Page 1100 of 3039
9.
10.
11.
NOTE: Remove and discard the blanking caps.
Torque: 3 Nm
Torque: 9 Nm
Page 1101 of 3039
Torque: 10 Nm www.JagDocs.com
Page 1102 of 3039
Torque: 12 Nm
18.
Lower the vehicle.
Page 1127 of 3039
5. Torque: 2 Nm 6. CAUTION: Be prepared to collect escaping coolant.
NOTE: Only carry out the following step if the coolant
is to be drained from the engine.
7. NOTE: This step is only required if previously
removed.
Torque: 50 Nm
Filling
1. Refer to: Radiator Splash Shield (501-02 Front End Body Panels, Removal and Installation).
2. Lower the vehicle.
Page 1136 of 3039
Torque: 50 Nm
12.
Carry out the procedure up to step 1 in the filling section three times,
filling the cooling system with clean water at the first two drains. At the
third refill, use a suitable measuring tool to make sure that the cooling
system maintains a 50% mix.
Filling
1.
Page 1143 of 3039
Published: 14-Apr-2014
Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Coolant Expansion Tank
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. Using a syringe, remove the cooling fluid from the expansion tank.
3. CAUTION: Take extra care not to damage the
component.
Torque: 7 Nm
4.
Page 1147 of 3039
Page 1151 of 3039
8. CAUTION: A new O-ring seal is to be installed.
Torque: 8 Nm
9. CAUTION: A new O-ring seal is to be installed.
Torque: 8 Nm
10. Lower the vehicle.
11. Refer to: Air Cleaner Outlet Pipe LH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).
12. Refer to: Air Cleaner Outlet Pipe RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).
13. Refer to: Air Cleaner Outlet Pipe T-Connector (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
14. Refer to: Air Cleaner RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).
15. Refer to: Air Cleaner LH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).
Page 1152 of 3039
16.
17.
18.
19. NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.
Torque: 9 Nm
CAUTION: Be prepared to collect escaping coolant. www.JagDocs.com
