torque JAGUAR XFR 2010 1.G Workshop Manual

11.

12.

13.
14.


















Torque: 40 Nm




































WARNING: Fluid loss is unavoidable, use absorbent
cloth or a container to collect the fluid.


CAUTION: Engine coolant will damage the paint
finished surfaces. If spilt, immediately remove the coolant
and clean the area with water.
Torque: 11 Nm

9. Refer to: Air Cleaner Outlet Pipe RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).

10. Refer to: Air Cleaner Outlet Pipe T-Connector (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

11. Refer to: Air Cleaner RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).

12. Refer to: Air Cleaner LH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).


13.

















14. NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.
Torque: 9 Nm













CAUTION: Be prepared to collect escaping coolant. www.JagDocs.com

15.
16.
17. Torque: 7 Nm











































CAUTION: Be prepared to collect escaping coolant.

18.
19.
20.



















CAUTION: Be prepared to collect escaping coolant.























Torque: 7 Nm

21.

























22. NOTE: Support the air conditioning (A/C) condenser.

Torque: 7 Nm






















CAUTION: Be prepared to collect escaping coolant.

8.























9.
10. NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.
























NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.
























NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.
Torque: 10 Nm

Supercharger Cooling - V8 S/C 5.0L Petrol - Radiator
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 19-Nov-2013

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Air Cleaner LH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).

3. Refer to: Air Cleaner RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).


4. NOTE: Some variation in the illustrations may occur, but
the essential information is always correct.
Torque: 9 Nm












5. CAUTION: Be prepared to collect escaping coolant.

10.
11.
12. Torque: 7 Nm



















































CAUTION: Be prepared to collect escaping coolant.

Installation 13.



















14.
















15.


















16.



















NOTE: Support the air conditioning (A/C) condenser.

Torque: 7 Nm













Torque: 7 Nm

















CAUTION: Be prepared to collect escaping coolant.

1. To install, reverse the removal procedure. www.JagDocs.com

6. CAUTIONS:


Make sure that the area around the open fuel injector ports are clean
and free of foreign material and lubricant prior to installing the fuel injector.


When Installing the fuel injector(s), make sure that the Teflon seal is
clean and free of foreign material and lubricant.










7. CAUTIONS:


If new fuel injectors are installed, a new injector clamp must be
installed


Make sure that the fuel injector is aligned and installed into the fuel
rail correctly, as noted in the removal step.


Tighten the fuel rail retaining bolts a turn at a time until the correct
torque is achieved.


NOTE: Lubricate the fuel injector O-ring seals with clean engine oil.

Torque: 20 Nm







8. Special Tool(s): 310-200-01, 310-200-02 9. Torque: 20 Nm
