CLIMATE CONTROL
(cooling and dehumidification)
Proceed as follows
❒turn knob B to the blue sector to select
temperature;
❒turn knob A to the required speed;
❒set knob E to «;
❒set knob F to ….
❒press D
√(button led will turn on).
Cooling adjustment
Proceed as follows:
❒set knob F to Úto turn air recirculation off;
❒turn knob B to the right to raise temperature;
❒turn knob A to the left to reduce the fan speed.LOOKING AFTER THE SYSTEM
During the winter, the climate control system must
be turned on at least once a month for about ten
minutes. Before summer, have the system checked
at a Lancia Dealership.

88
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
AUTOMATIC TWO-ZONE CLIMATE CONTROL SYSTEM (where provided)
GENERAL
The car is fitted with a two-zone climate control
system which makes it possible to separately adjust
the air temperature on the driver’s side and on the
passenger’s side. Temperature control is based on
the “equivalent temperature” logic, i.e.: the system
continuously works to keep constant the comfort
inside the passenger compartment and to
compensate any variation of the outside climate
conditions, including sunshine detected by a proper
sensor provided for the purpose.
The climate control system automatically controls
and adjusts the following parameters and
functions:
❒air temperature at driver/front passenger vents;
❒air distribution at driver/front passenger vents;
❒fan speed (continuous air flow variation);❒compressor switching on (to cool/dehumidify
air);
❒air recirculation.
All the above functions can be changed manually at
any time, i.e.: you can always modify one or more
function settings. In this event, the system will no
longer implement the automatic control of the
functions changed manually (except for safety
reasons, e.g.: risk of window misting).
Manual selections prevail over automatic ones and
remain in storage until the user decides to resume
automatic control, except when the system cuts in
for particular safety conditions.
The control of functions not changed manually
remains automatic.
The amount of air admitted to the passenger
compartment does not depend on the car speed,
since it is electronically controlled by the fan.
In any case, the temperature of the air admitted to
the passenger compartment is controlled
automatically (except when the system is off)
according to the temperatures set on the driver’s
and front passenger’s displays or under certain
climatic conditions if the compressor is off).

89
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
The system enables to set or to change the
following parameters and functions
manually:
❒air temperatures on driver/front
passenger side;
❒fan speed (continuous variation);
❒air distribution on five levels
(driver/front passenger side);
❒climate control compressor on/off
enable;
❒monozone/two-zone distribution
priority;
❒fast demisting/defrosting;
❒air recirculation;
❒rear heated window;
❒system off;
CONTROLS
A MONO function button (for aligning set
temperatures)
B climate control compressor on/off
button
C inside air recirculation on/off button
D display showing climate control system
dataE climate control system off button
F MAX-DEF function button (front window fast
defrosting/demisting)
G rear window heating on/off button
H AUTO function button (automatic mode) and knob to
adjust temperature on passenger side
I buttons for air distribution on passenger side
L button for adjusting fan speed
M button for air distribution on driver side
N AUTO function button (automatic mode) and knob to
adjust temperature on driver side
L0D0065m

90
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
SWITCHING THE CLIMATE
CONTROL SYSTEM ON
The system can be started in different ways, but it is
advisable to press one of the AUTO buttons and
then to turn the knobs to set the temperatures
required on the display.
It is possible to personalise required temperatures
(driver and passenger) with a maximum difference
of 7 °C.
This way the system will start working completely
automatically to reach the temperatures set as
quickly as possible. The system will adjust the air
temperature, flow and distribution and will control
the air recirculation function and the conditioner
compressor on/off.
During fully automatic operation, the only manual
settings required are the following:
❒MONO, to align the air temperature and
distribution set on the passenger’s side (front or
rear) with that on the driver’s side;
❒…, air recirculation, to keep it always on or
off;
❒-, to speed up demisting/defrosting of
windscreen, front side windows, rear window
and door mirrors;
❒(, to demist/defrost the rear heated window
and the door mirrors.During completely automatic system operation, the
temperatures, air distribution and the fan speed set
can be changed at any time through the relevant
buttons or knobs: the system will automatically
change its settings to adjust to the new
requirements.
During full automatic operation (FULL AUTO),
any change in air distribution and/or air flow
and/or compressor turning on and/or air
recirculation will obtain FULL disappearing. In this
way functions will be controlled manually until
pressing the AUTO button again. The fan speed is
the same for all passenger compartment areas.
With one or more functions engaged manually, the
adjustment of the temperature of the air admitted to
the passenger compartment continues to be
controlled automatically by the system, except with
the climate control compressor off. In fact, in this
condition, the air admitted to the passenger
compartment cannot have a lower temperature than
the outside air.

91
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
CONTROLS
Air temperature
adjustment knobs H-N
Turning the knobs
clockwise or
counterclockwise,
highers or lowers the temperature of the air
required respectively in the left zone (knob N) or
right zone (knob H) of the passenger compartment.
It is possible to personalise required temperatures
(driver and passenger) with a maximum difference
of 7 °C.
The temperatures set are shown on the displays
near the relevant knobs.
Pressing button A (MONO) automatically aligns the
temperature on the front passenger’s side with that
on the driver’s side. It is therefore possible to set the
same temperature between the two zones simply
turning the knob on the driver’s side N.
This function is provided to simplify temperature
adjustment of the whole passenger compartment
when only the driver is on board.
Separate operation of the set temperatures is
automatically restored by turning knobs H or
pressing button A (MONO) again when the button
led is on.Turning the knobs clockwise or counterclockwise
until they reach the extreme selections HI or LO,
the maximum heating or cooling functions are
respectively engaged:
❒HI function (highest heating power):
this is activated by turning the temperature knob
clockwise above the max. value (32 °C). It can be
activated independently from the driver’s or
passenger’s side or both (also selecting the MONO
function).
This function can be engaged when requiring to
heat the passenger compartment as quickly as
possible, exploiting the maximum potential of the
system. This function uses the maximum
temperature of the coolant fluid, while air
distribution and fan speed are controlled according
to the system settings.
More particularly, max. fan speed will not be
immediately engaged if coolant is not hot enough;
this to prevent admitting air that is not warm
enough to the passenger compartment.
All manual settings are however possible with this
function on.

92
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
To switch the function off, simply turn the
temperature knob counterclockwise and set the
required temperature.
❒LO function (highest cooling power):
this is activated by turning the temperature knob
counterclockwise below the min. value (16 °C). It
can be activated independently from the driver’s or
passenger’s side or both (also selecting the MONO
function).
This function can be engaged when requiring to
cool the passenger compartment as quickly as
possible, exploiting the maximum potential of the
system. This function engages inside air
recirculation and climate control compressor, while
air distribution and fan speed are controlled
according to environmental conditions. All manual
settings are however possible with this function on.
To switch the function off, simply turn the
temperature knob clockwise and set the required
temperature.Front air distribution
selection buttons
I-M
Pressing the relevant
buttons it is possible to
manually choose one of the five possible air
distributions to the left and right side of the
passenger compartment:
▲Air flow to the windscreen and front side window
vents to demist or defrost them.
˙Air flow to dashboard central and side vents to
provide satisfactory ventilation to the chest and
face, specially during the summer.
▼Air flow towards the front and rear lower parts of
the passenger compartment. Due to the natural
tendency of heat to spread upwards, this type of
distribution allows heating of the passenger com-
partment in the shortest time, also giving a prompt
feeling of warmth to the coldest parts of the body.
˙
▼Splitting of the air flow between the vents to the
lower part of the passenger compartment
(warmest air) and the dashboard centre and side
outlets (coolest air). This air flow distribution is
particularly useful in spring and autumn, when
the sun is shining.
▲
▼Splitting of the air flow between the lower part of
the passenger compartment and the windscreen
and front side window demisting/defrosting vents.
This type of air distribution allows satisfactory
heating of the passenger compartment while pre-
venting possible misting of the windows.

93
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
Set air flow distribution is indicated by the
corresponding button led switching on.
With a combined function set, pressing a button will
turn on the main function of the button pressed,
together with the functions set yet. Pressing the
button of the active function will turn the function
off (led off).
To restore automatic air distribution control after a
manual selection, press button AUTO.
When the driver selects air distribution towards the
windscreen, also the air distribution on passenger’s
side will automatically be directed to the
windscreen. The passenger can however select a
different air distribution by pressing the relevant
buttons.Fan speed adjustment buttons L
Pressing the ends of button p
increases or decreases the fan speed
and therefore the amount of air
admitted to the passenger
compartment, although keeping the required
temperature.
The fan speed is shown by the lit bars on the
display
❒max fan speed = all bars lit
❒min fan speed = one bar lit.
The fan can be cut off only if the climate control
compressor has been switched off pressing button B.
IMPORTANT To restore automatic fan speed
control after a manual adjustment, press button
AUTO.

94
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
AUTO buttons
H-N
(automatic
operation)
Pressing the AUTO
button (on driver and/or front passenger side) the
system automatically adjusts the amount and
distribution of the air admitted to the passenger
compartment, cancelling all the previous manual
adjustments.
This condition is indicated by the message FULL
AUTO on the front system display.
Manual operation of at least one automatic function
(air recirculation, air distribution, fan speed or
climate control compressor off) will cause FULL
message going off the display. This means that
automatic control is not complete (except
temperature control which is always automatic).
IMPORTANT Should the system (after manual
settings) be no longer able to guarantee the required
temperature set in the passenger compartment, the
set temperature value will start flashing to indicate
this condition, after one minute the AUTO message
will turn off.
To restore automatic system control after one or
more manual selections, press button AUTO.MONO button A (alignment of set
temperatures and air distribution)
Pressing button MONO automatically
aligns the temperature on the front
passenger’s side with that on the
driver’s side. It is therefore possible to set the same
temperature and air distribution between the two
zones simply turning the knob on the driver’s side.
This function is provided to simplify temperature
adjustment of the whole passenger compartment
when only the driver is on board. Separate
operation of the set temperatures and air
distribution is automatically restored by turning
knob (H) or pressing button MONO (A) again when
the button led is on.
Air recirculation on/
off button C
Air recirculation is controlled
according to the following operating
logics:
❒forced switching on (air recirculation always
on), indicated by the turning on of the led on
button C and symbol íon the display;
❒forced switching off (air recirculation always off
with air inlet from the outside), indicated by the
turning off of the button led and êon the
display.

95
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
These operating conditions are obtained pressing in
sequence the air recirculation button C.
After a preset time, the climate control system will
turn air recirculation off automatically for safety
reasons, thus enabling outside air inlet.IMPORTANT The air recirculation system
makes it possible to reach the required heating or
cooling conditions faster.
It is however inadvisable to use it on rainy/cold
days as it would considerably increase the
possibility of the windows misting inside, especially
if the climate control system is off.
When the outside temperature is below 5-7°C, air
recirculation is switched off (air is taken from the
outside) to prevent misting.
WARNINGIt is inadvisable to use the air recirculation feature with low outside temperature
as the windows might mist over quickly.

96
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
Climate control compressor on/off
button B
Press the
√button, when the button
led is on, to switch the compressor
off. The led will go off. By pressing
again the button when the led is off, the system
automatic control of the compressor activation is
restored; this condition is indicated by button led
lighting up.
When the air conditioner compressor is off, the
system deactivates air recirculation to prevent
window misting up. Although the system is still able
to maintain the required temperature, the message
FULL on the display will go off. If the system is no
longer able to keep the required temperature, also
the message AUTO will turn off.
IMPORTANT Air at a temperature lower than that
of the outside air cannot be let into the passenger
compartment when the compressor is off.
Furthermore, in particular environmental
conditions, the windows could mist up fast because
the air is no longer dehumidified.Setting will be stored also when the engine is
stopped.
Either press again button √(in this case the system
operates as heater only) or AUTO to reset automatic
control of the compressor.
With compressor off, if the outside temperature is
higher than the set temperature, the system cannot
reach the required temperature. This will be
signalled by the flashing of set temperature value on
the display for a few seconds, then the message
AUTO will go off.
When the compressor is off, it is possible to reset
manually the fan speed (no bar displayed).
When the compressor is on and the engine is
running, fan speed cannot be lower than the
minimum (one bar displayed).
