When trouble arises
If the tire is inflated to more than the recommended level
Disconnect the hose from the valve.
Disconnect the hose from the valve, remove the air release cap from the hose
and then reconnect the hose.
Turn the compressor switch on and wait for several seconds, then turn it off.
Check that the air pressure indicator shows the recommended level. (P. 645)
If the air pressure is lower than the recommended level, turn the compressor
switch on again and repeat the inflation procedure until the recommended pres-
sure is reached. Install the air release cap to the end of the
hose and push the protrusion on the air
release cap into the valve to let some air
out.
WA R N I N G
Precautions for use of the sealant
Ingesting the sealant is hazardous to your health. If you ingest sealant, con-
sume as much water as possible, then immediately consult a doctor.
If sealant gets in eyes or adheres to skin, immediately wash it off with water.
If discomfort persists, consult a doctor.
1
2
3
4

6188-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
WA R N I N G
When fixing the flat tire
Stop your vehicle in a safe and flat area.
Connect the valve and hose securely with the tire installed on the vehicle.
If the hose is not properly connected to the valve, air leakage may occur or
sealant may be sprayed out.
If the hose comes off the valve while inflating the tire, there is a risk that the
hose will move abruptly due to air pressure.
After inflation of the tire has completed, the sealant may splatter when the
hose is disconnected or some air is let out of the tire.
Keep back from the tire while it is being repaired, as there is a chance of it
bursting while the repair operation is being performed. If you notice any
cracks or deformation of the tire, turn off the compressor switch and stop the
repair operation immediately.
The kit may overheat if operated for a long period of time. Do not operate the
compressor continuously for more than 10 minutes.
Parts of the kit become hot during operation. Be careful handling the kit
during and after operation.
Do not attach the vehicle speed warning sticker to an area other than the one
indicated. If the sticker is attached to an area where an SRS airbag is located,
such as the pad of the steering wheel, it may prevent the SRS air bag from
operating properly.
Driving to spread the liquid sealant evenly
Drive the vehicle carefully at a low speed. Be especially careful when turning
and cornering.
If the vehicle does not drive straight or you feel a pull through the steering
wheel, stop the vehicle and check the following:
• Tire condition. The tire may have separated from the wheel.
• Tire inflation pressure. If tire inflation pressure is 130 kPa (1.3 kgf/cm
2 or
bar, 19 psi) or below, this may indicate severe tire damage.

6198-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
8
When trouble arises
NOTICE
When performing an emergency repair
Perform the emergency repair without removing the nail or screw that has
punctured the tread of the tire. If the object that has punctured the tire is
removed, repair by the emergency tire puncture repair kit may not be possible.
The kit is not waterproof. Make sure that the kit is not exposed to water, such
as when it is being used in the rain.
Do not put the kit directly onto dusty ground such as sand at the side of the
road. If the kit vacuums up dust etc., a malfunction may occur.
Use the kit with the top facing upward. The kit cannot work properly if it is
laid on its side.
Handling the emergency tire puncture repair kit
The compressor power source should be 12 V DC suitable for vehicle use. Do
not connect the compressor to any other source.
If gasoline splatters on the kit, the kit may deteriorate. Take care not to allow
gasoline to contact it.
Store the kit in its assigned place out of reach of children.
Do not disassemble or modify the kit. Do not subject parts such as the air
pressure indicator to impacts. This may cause a malfunction.
To avoid damage to the tire pressure warning valves and transmitters (vehicles
with the tire pressure warning system)
When a tire is repaired with liquid sealants, the tire pressure warning valve and
transmitter may not operate properly. If a liquid sealant is used, contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional or other qualified service shop as soon as possible. Make sure to
replace the tire pressure warning valve and transmitter when replacing the tire.
(P. 511)

6208-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
If the hybrid system will not start
One of the following may be the cause of the problem:
The electronic key may not be functioning properly.* (P. 622)
There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle. (P. 8 3 )
There may be a malfunction in the immobilizer system.* (P. 8 7 )
There may be a malfunction in the P position control system.*
(P. 199, 581)
The hybrid system may be malfunctioning due to an electrical problem
such as electronic key battery depletion or a blown fuse. However,
depending on the type of malfunction, an interim measure is available
to start the hybrid system. (P. 621)
*: It may not be possible to shift the shift position other than P.
One of the following may be the cause of the problem:
The 12-volt battery may be discharged. (P. 624)
The 12-volt battery terminal connections may be loose or corroded.
(P. 504)
Reasons for the hybrid system not starting vary depending on the situa-
tion. Check the following and perform the appropriate procedure:
The hybrid system will not start even though the correct starting
procedure is being followed. (P. 196)
The interior lights and headlights are dim, or the horn does not
sound or sounds at a low volume.

6218-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
8
When trouble arises
One of the following may be the cause of the problem:
The 12-volt battery may be discharged. (P. 624)
One or both of the 12-volt battery terminals may be disconnected. (P.
504)
Contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional if the problem cannot be repaired, or if repair proce-
dures are unknown.
When the hybrid system does not start, the following steps can be used as
an interim measure to start the hybrid system if the power switch is func-
tioning normally. Do not use this starting procedure except in cases of
emergency.
Set the parking brake.
Turn the power switch to ACCESSORY mode.
Press and hold the power switch for about 15 seconds while depressing
the brake pedal firmly.
Even if the hybrid system can be started using the above steps, the system
may be malfunctioning. Have the vehicle inspected by any authorized
Lexus dealer or repairer, or another duly qualified and equipped profes-
sional.
The interior lights and headlights do not turn on, or the horn does
not sound.
Emergency start function
1
2
3

6228-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
If the electronic key does not operate properly
Use the mechanical key (P. 127)
in order to perform the following
operations:
Locks all the doors
Closes the windows
* (turn and
hold)
Unlocks all the doors
Opens the windows
* (turn and
hold)
*: These settings must be customized at any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional.
If communication between the electronic key and vehicle is interrupted (P.
145) or the electronic key cannot be used because the battery is depleted, the
smart entry & start system and wireless remote control cannot be used. In
such cases, the doors can be opened and the hybrid system can be started by
following the procedure below.
Locking and unlocking the doors and key linked functions
1
2
3
4

6238-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
8
When trouble arises
Depress the brake pedal.
Touch the Lexus emblem side of
the electronic key to the power
switch.
If any of the doors is opened or
closed while the key is being
touched to the switch, an alarm will
sound to indicate that the start func-
tion cannot detect the electronic key.
Press the power switch within 10 seconds of the buzzer sounding,
keeping the brake pedal depressed.
In the event that the hybrid system still cannot be operated, contact any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Stopping the hybrid system
Set the parking brake, shift the shift position to P and press the power switch as
you normally do when stopping the hybrid system.
Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the elec-
tronic key battery be replaced immediately when the battery is depleted. (P.
530)
Alarm (if equipped)
Using the mechanical key to lock the doors will not set the alarm system.
If a door is unlocked using the mechanical key when the alarm system is set, the
alarm may be triggered. (P. 9 3 )
Changing power switch modes
Within 10 seconds of the buzzer sounding, release the brake pedal and press the
power switch.
The hybrid system does not start and modes will be changed each time the switch
is pressed. (P. 198)
Starting the hybrid system
1
2
3

6248-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
If the 12-volt battery is discharged
If you have a set of jumper (or booster) cables and a second vehicle with a
12-volt battery, you can jump start your vehicle by following the steps
below.
Open the hood (P. 492) and
fuse box cover.
Open the exclusive jump starting
terminal cover.
The following procedures may be used to start the hybrid system if the
vehicle’s 12-volt battery is discharged.
You can also call any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
1
2

6258-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
8
When trouble arises
Connect the jumper cables according to the following procedure:
Connect a positive jumper cable clamp to the exclusive jump starting
terminal on your vehicle.
Connect the clamp on the other end of the positive cable to the positive
(+) battery terminal on the second vehicle.
Connect a negative cable clamp to the negative (-) battery terminal on
the second vehicle.
Connect the clamp at the other end of the negative cable to a solid, sta-
tionary, unpainted metallic point away from the exclusive jump starting
terminal and any moving parts, as shown in the illustration.3
1
2
3
4

6268-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
Start the engine of the second vehicle. Increase the engine speed
slightly and maintain at that level for approximately 5 minutes to
recharge the 12-volt battery of your vehicle.
Open and close any of the doors of your vehicle with the power switch
off.
Maintain the engine speed of the second vehicle and start the hybrid
system of your vehicle by turning the power switch to ON mode.
Make sure the “READY” indicator comes on. If the indicator light
does not come on, contact any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
Once the hybrid system has started, remove the jumper cables in the
exact reverse order from which they were connected.
Close the exclusive jump starting terminal cover, and reinstall the fuse
box cover to its original position.
Once the hybrid system starts, have the vehicle inspected at any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped
professional as soon as possible.
Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
To prevent 12-volt battery discharge
Turn off the headlights and the audio system while the hybrid system is off.
Turn off any unnecessary electrical components when the vehicle is running at
a low speed for an extended period, such as in heavy traffic.
When the 12-volt battery is removed or discharged
The hybrid system may not start. (P. 507)
If the 12-volt battery discharges while the shift position is in P, it may not be
possible to shift the shift position to other positions. In this case, the vehicle
cannot be towed without lifting both front wheels because the front wheels will
be locked. (P. 562)
When the 12-volt battery is reconnected, start the hybrid system and confirm
that the shift position can be changed to each position using the shift position
indicator.
Make sure that the key is not inside the vehicle when recharging or replacing
the 12-volt battery. The key may be locked in the vehicle if the alarm is acti-
vated. (P. 9 3 )
4
5
6
7
8
9
