Before Driving
Towing
Trailer Towing Tips
  Verify that your Mazda maintains a near-normal attitude when a loaded or unloaded trailer
is connected. Do not drive if it has an abnormal front-up or front-down \
position. Inspect
for incorrect tongue load, worn suspension parts, and trailer overloadin\
g.
   Make sure the trailer is properly loaded and the cargo is secure to prevent it from shifting.  Make sure the mirrors conform to all government regulations. If they do \
not, install
required rear view mirrors appropriate for towing purposes.

The three main causes of vehicle-trailer accidents are driver error, excessive speed, and
improper trailer loading.
Before driving
   Have your cooling and braking system checked by an Authorized Mazda Dealer.  Before starting out, inspect the operation of all vehicle and trailer li\
ghts and all vehicle-
to-trailer connections. Stop and re-inspect all lights and connections a\
fter driving a short
distance.

Driving
   Your Mazda will handle differently with a trailer in tow, so practice turning, backing, and
stopping in a traf fi c-free area.
   Take time to get accustomed to the extra weight and length.  Allow more room between your vehicle and the one in front because brakin\
g distance
increases with a trailer. For each 16 km/h (10 mph) of speed, allow at least one vehicle
and trailer length between your Mazda and the vehicle ahead.
   Avoid jerky starts or sudden acceleration.  Avoid sudden braking. It may cause loss of control and result in jackkni fi ng, especially so
on wet or slippery roads.
   Shift the shift lever to the D position when towing a trailer in hilly t\
errain or when heavily
loaded.

The D position will allow operating the vehicle without frequent shiftin\
g.
Lane changes and turning
Avoid quick lane changes, sudden turns, and tight turns. Slow down before\
turning to avoid
the need of sudden braking.
A turning trailer will make a tighter arc than the tow vehicle. Compensat\
e with turns that are
larger than normal.
CX-5_8FN1-EA-16L_Edition1.indb 612016/12/12 10:05:39

3–62
Before Driving
Towing
Passing
Plan well ahead to pass other vehicles, and provide plenty of room befor\
e changing lanes.
Crosswinds from passing vehicles, especially larger ones, and the effects of rough roads will
affect handling.
If swaying occurs, fi rmly grip the steering wheel and reduce speed immediately, but
gradually.
Steer straight ahead. If no extreme correction of steering or braking is\
made, the
combination of less speed and fi rm steering will result in stability.
Backing up
Backing a vehicle with a trailer requires practice and patience. Back sl\
owly, and have a
helper outside at the rear of the trailer to reduce the risk of an accid\
ent.
To turn the trailer, place your hand at the bottom of the steering wheel and turn it in the\

direction you want the trailer to go. Make only slight movements to prev\
ent sharp or
prolonged turning.
Ascending a hill
Shift into a lower gear to reduce the possibility of overloading or over\
heating the engine, or
both.
Descending a hill
Shift into a lower gear and use engine compression as a braking effect.
WARNING
Always use lower gears to reduce speed: Holding the brake pedal down too long or too frequently is dangerous as it could cause
the brakes to overheat and lose power, resulting in loss of control and a serious accident.
Use lower gears to help reduce speed. Pull off the road and allow brakes to cool down
whenever braking performance feels reduced.

Overheated engine
The extra weight of the trailer may strain the engine on hot days and on\
long or steep
upgrades.
If the temperature gauge indicates overheating, turn off the air conditioner, drive safely
to the side of the road, park off the right-of-way and wait for engine to cool. Refer to
Overheating on page 7-18 .
CX-5_8FN1-EA-16L_Edition1.indb 622016/12/12 10:05:39

3–63
Before Driving
Towing
Parking
Always make sure the tires of the trailer and the tow vehicle are blocke\
d while parked.
Apply the parking brake fi rmly and put the transaxle in P.
Avoid parking on an incline, but if you must, follow these instructions:
1. Depress and hold down the brake pedal.
2. Have a helper put wheel blocks against the downhill side of all vehicle \
and trailer tires.
3. Then release the brake pedal slowly until the blocks bear the load.
 If the grade is downhill, turn the steering wheel so that the front of t\
he front tires face the curb.
 If it is uphill, face the rear of the front tires against the curb.
4. Firmly apply the parking brake.
5. Shift the transaxle into P, and stop the engine.

To restart after parking on an incline:
1. With the transaxle in P, start the engine. (Be sure to depress and hold the brake pedal.)
2. Shift into gear.
3. Release the parking brake (also the foot brake) and pull away from the\
wheel blocks. Stop; apply the parking brake and shift into P.
4. Have a helper retrieve the wheel blocks.

Fuel consumption
Trailer towing causes higher fuel consumption.
Maintenance
If you tow a trailer frequently, have your vehicle serviced as shown in Scheduled
Maintenance (page 6-4 ).
CX-5_8FN1-EA-16L_Edition1.indb 632016/12/12 10:05:40

3–64
Before Driving
Towing
Recreational Towing
An example of "recreational towing" is
towing your vehicle behind a motorhome.
The transaxle is not designed for towing
this vehicle on all 4 wheels.
When doing recreational towing refer to
"Towing Description" (page 7-20 ) and
carefully follow the instructions.

CX-5_8FN1-EA-16L_Edition1.indb 642016/12/12 10:05:40

4–1*Some models.
4When Driving
Information concerning safe driving and stopping.

Start/Stop Engine ................................ 4-4 Ignition Switch ............................... 4-4
Starting the Engine ......................... 4-5
Turning the Engine Off ................ 4-10

Instrument Cluster and Display ...... 4-12 Meters and Gauges ....................... 4-12
Multi-information Display and INFO
Switch
* ......................................... 4-20
Active Driving Display * ............... 4-28
Warning/Indicator Lights ............. 4-32

Manual Transaxle Operation ........... 4-39 Manual Transaxle Shift Pattern .... 4-39

Automatic Transaxle ......................... 4-42 Automatic Transaxle Controls ..... 4-42
Shift-Lock System ....................... 4-43
Transaxle Ranges ......................... 4-43
Manual Shift Mode ...................... 4-45
Driving Tips ................................. 4-50
Switches and Controls ...................... 4-51
Lighting Control ........................... 4-51
Fog Lights
* ................................... 4-57
Turn and Lane-Change Signals .... 4-57
Windshield Wipers and Washer ... 4-58
Rear Window Wiper and
Washer .......................................... 4-62
Rear Window Defogger ............... 4-62
Horn ............................................. 4-65
Hazard Warning Flasher ............... 4-65
HomeLink Wireless Control
System
* ......................................... 4-66

Brake .................................................. 4-70 Brake System ............................... 4-70
AUTOHOLD ............................... 4-75
Hill Launch Assist (HLA) ............ 4-81

ABS/TCS/DSC ................................... 4-82 Antilock Brake System (ABS) ..... 4-82
Traction Control System (TCS) ... 4-83
Dynamic Stability Control
(DSC) ........................................... 4-85

Fuel Economy Monitor ..................... 4-86 Fuel Economy Monitor
* ............... 4-86

Drive Selection ................................... 4-88 Drive Selection ............................. 4-88

i-ACTIV AWD ................................... 4-89 i-ACTIV AWD Operation
* ........... 4-89

CX-5_8FN1-EA-16L_Edition1.indb 12016/12/12 10:05:40

4–2*Some models.
Power Steering................................... 4-91 Power Steering ............................. 4-91

i-ACTIVSENSE................................. 4-92 i-ACTIVSENSE
* .......................... 4-92
Adaptive Front Lighting System
(AFS)
* .......................................... 4-95
High Beam Control System
(HBC)
* .......................................... 4-96
Blind Spot Monitoring (BSM) * .... 4-99
Traffi c Sign Recognition System
(TSR)
* ........................................ 4-105
Distance Recognition Support System
(DRSS)
* ...................................... 4-112
Rear Cross Traffi c Alert
(RCTA)
* ..................................... 4-117
Mazda Radar Cruise Control with
Stop & Go function (MRCC with Stop
& Go function)
* .......................... 4-121
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)
* .................................... 4-135
Smart City Brake Support
(SCBS)
* ...................................... 4-148
Smart Brake Support (SBS) * ...... 4-153
Forward Sensing Camera
(FSC)
* ......................................... 4-156
Radar Sensor (Front) * ................. 4-162
Radar Sensors (Rear) * ................ 4-165

Cruise Control ................................. 4-167 Cruise Control
* ........................... 4-167

Tire Pressure Monitoring System ... 4-172
Tire Pressure Monitoring
System
* ....................................... 4-172
Rear View Monitor .......................... 4-176
Rear View Monitor
* ................... 4-176
CX-5_8FN1-EA-16L_Edition1.indb 22016/12/12 10:05:40

4–3
MEMO
CX-5_8FN1-EA-16L_Edition1.indb 32016/12/12 10:05:40

4–4
When Driving
Start/Stop Engine
*Some models.
Ignition Switch
Push Button Start Positions
The system operates only when the key is
within operational range.
Each time the push button start is pressed,
the ignition switches in the order of off,
ACC, and ON. Pressing the push button
start again from ON switches the ignition
off.
Indicator light
Push button start
NOTE
   The engine starts by pressing the push
button start while depressing the brake
pedal. To switch the ignition position,
press the push button start without
depressing the pedal.
  Do not leave the ignition switched ON
while the engine is not running. Doing
so could result in the battery going
dead. If the selector lever is in the P
position, and the ignition is in ACC, the
ignition switches off automatically after
about 25 minutes.

Off
The power supply to electrical devices
turns off and the push button start indicator
light (amber) also turns off.
In this position the steering wheel is
locked.
*
WARNING
Before leaving the driver's seat, always
switch the ignition off , set the parking
brake, and make sure the selector lever
is in P: Leaving the driver's seat without
switching the ignition off , setting the
parking brake, and shifting the selector
lever to P is dangerous. Unexpected
vehicle movement could occur which
could result in an accident.
In addition, if your intention is to leave
the vehicle for even a short period, it
is important to switch the ignition off ,
as leaving it in another position will
disable some of the vehicle's security
systems and run the battery down.

NOTE
(Locked steering wheel) *
If the push button start indicator light
(green) is fl ashing and the beep sound
is heard, this indicates that the steering
wheel is not unlocked. To unlock the
steering wheel, press the push button start
while moving the steering wheel left and
right.

ACC (Accessory)
Some electrical accessories will operate
and the indicator light (amber) illuminates.
In this position the steering wheel is
unlocked.
*
NOTE
The keyless entry system does not function
while the push button start has been
pressed to ACC, and the doors will not
lock/unlock even if they have been locked
manually.

CX-5_8FN1-EA-16L_Edition1.indb 42016/12/12 10:05:40

4–5
When Driving
Start/Stop Engine
ON
This is the normal running position after
the engine is started. The indicator light
(amber) turns off. (The indicator light
(amber) illuminates when the ignition
is switched ON and the engine is not
running.)
Some indicator lights/warning lights
should be inspected before the engine is
started (page 4-32 ).
NOTE
When the push button start is pressed to
ON, the sound of the fuel pump motor
operating near the fuel tank can be heard.
This does not indicate an abnormality.

Starting the Engine
WARNING
Radio waves from the key may aff ect
medical devices such as pacemakers: Before using the key near people who
use medical devices, ask the medical
device manufacturer or your physician
if radio waves from the key will aff ect
the device.

CX-5_8FN1-EA-16L_Edition1.indb 52016/12/12 10:05:40

4–6
When Driving
Start/Stop Engine
NOTE
  The key must be carried because the key
carries an immobilizer chip that must
communicate with the engine controls at
short range.
  The engine can be started when the
push button start is pressed from off,
ACC, or ON.
  The push button start system functions
(function which can start the engine
by only carrying the key) can be
deactivated to prevent any possible
adverse effect on a user wearing a
pacemaker or other medical device. If
the system is deactivated, you will be
unable to start the engine by carrying
the key. Consult an Authorized Mazda
Dealer for details. If the push button
start system functions have been
deactivated, you can start the engine by
following the procedure indicated when
the key battery goes dead.
 Refer to Engine Start Function When Key Battery is Dead on page 4-8 .
  After starting a cold engine, the engine
speed increases and a whining sound
from the engine compartment can be
heard.
 This is for improved exhaust gas purifi cation and does not indicate any
parts defect.
   Engine-starting is controlled by the
spark ignition system.
 This system meets all Canadian Interference-Causing Equipment
Standard requirements regulating the
impulse electrical fi eld strength of radio
noise.

1. Make sure you are carrying the key.
2. Occupants should fasten their seat belts.
3. Make sure the parking brake is on. 4. Continue to press the brake pedal
fi rmly until the engine has completely
started.
5. (Manual transaxle)
Continue to press the clutch pedal fi rmly until the engine has completely
started.
(Automatic transaxle)
Put the vehicle in park (P). If you must restart the engine while the vehicle is
moving, shift into neutral (N).
NOTE
  (Manual transaxle)  The starter will not operate if the clutch
pedal is not depressed suf fi ciently.
   (Automatic transaxle)  The starter will not operate if the
selector lever is not in P or N and the
brake pedal is not depressed suf fi ciently.

6. Verify that the KEY indicator light
(green) (if equipped) in the instrument
cluster and the push button start
indicator light (green) illuminate.



Indicator light
Push button start
CX-5_8FN1-EA-16L_Edition1.indb 62016/12/12 10:05:40
