MITSUBISHI 3000GT 1991 Service Manual

INTAKE AND EXHAUST - Intercooler
INTERCOOLER
/REMOVAL AND INSTALLATION18
/?1IO-13Nm
7-9ftJbs.
/Turbocharger
b-ring
05FOOO3MlSTA-
-
I
lo-13Nm7 - 9 ft.lbs.
OSPDOU24Nm
/ 17 ft.lbs.
ANm
7-.9 ft.lbs.
. .-...2.9 ft.lbs.lo-13Nm
’7 - 9 ft.lbs.2
_ .
Removal steps of intercooler right
**I. Air hose Cl *2. Air hose D3. Intercooler duct (RH)l *4. Intercooler rightRemoval steps of intercooler left
l *5. Air hoseG
6. Air pipe A
7. Heat protector F
I)* 8. Air hose Bl *9. Air hose E10. Air pipe BII. Air pope C** 12. Air hose F*I)13. Engine oil cooler
14. Intercooler duct (LH)
l * 15. Intercooler left
lo-13 Nm7 - 9 ft.lbs.OSFOC.02
(When equipped with intercooler left)
l Installation of Front Bumper
(Refer to GROUP 51 - Front Bumper.)Removal steps of air intake hose
16. Connection of boost hose
17. Air hoseA
18. Connection of air flow sensor connector
I)* 19. Air intake hose A** 20. Air intake hose B*a 21. Air intake hose C
22. Air cleaner
23. Air by-pass hose
24. Air by-pass valve
1 TSB Revision

15-12INTAKE AND EXHAUST - lntercooier
SERVICE POINT OF REMOVALMlSTSAC
13. REMOVAL OF ENGINE OIL COOLERIDisconnect the hose from the engine oil cooler and remove
the engine oil cooler only.
IL)
INSPECTIONMISTCAB
lCheck the intercooler fins for bending, damage, or foreign
matter.
lCheck the intercooler hoses for cracking, damage, or wear.
Air Intake hose B
Air hose
05FOO21
SERVICE POINTS OF INSTALLATIONMlSTDAC
21. INSTALLATION OF AIR INTAKE HOSE C
/ 20. AIR
INTAKE HOSE B
/ 19. AIR INTAKE HOSE A
Engaging the notch with the
n mark at points indicated by
the arrows, insert air intake hoses B and C until seated.
Insert the turbocharger end of air intake hoses B and C
completely.
15. INSTALLATION OF INTERCOOLER LEFT / 12. AIR HOSEF
/ 9. AIR HOSE E / 8. AIR HOSE B / 5. AIR HOSE G
Aligning the marks at the points indicated by the arrows,
insert securely into the stepped portion of the pipe or until
seated.
CautionBe careful not to allow any foreign matter to get into
the hoses, pipes, or the intercooler itself.
4.INSTALLATION OF INTERCOOLER RIGHT / 2. AIR HOSED
/ 1. AIR HOSE C
Aligning the marks at the points indicated by arrows, insert
securely into the stepped portion of the pipe.
CautionBe careful not to allow any foreign matter to get into
the hoses, pipes, or the intercooler itself.
1 ~
LJ~TSB Revision

INTAKE AND EXHAUST - Air Intake Plenum 15-13
AIR INTAKE PLENUM
/REMOVAL AND INSTALLATIQNMlWA-B
L/
i
I Post-installation ODeration
Adjustment of Accelerator Cable
(Refer to GROUP 13 - Engine Control.)
Removal steps7-9ft.lbs.
I. Connection air intake hose2. Connection of accelerator cable_*I)3. Throttle body assemblyl *4. Throttle body gasket
5. Connection of brake booster vacuum hose
6. Harness connecters8 60Nm;6Nm05FOO32
43 ft.lbs.13 ft.lbs.
7. Connection of VIC servo motor
8. EGR pipe
9. EGR valve California>
11. EGR temperature sensor
12. Accelerator cable bracket
13. Connection of air intake plenum stay14. Air intake plenum installation bolts
15. Air intake plenum installation nuts
16. Air intake plenum
17. Air intake plenum gasket
Throttle body
SERVICE POINT OF REMOVALM15UBC23. REMOVAL OF THROTTLE BODY ASSEMBLY
Leaving the water hoses and vacuum hoses in their
installed positions, remove from the air intake plenum.
INSPECTIONM15UCAD2
Check the following points; replace the part if a problem is
found.
AIR INTAKE PLENUM
(1) Check air intake plenum for defect or cracks. Replace if
defective or cracked.
(2) Check load (negative pressure) of drain port. Clean if
required.
SERVICE POINT OF INSTALLATIONMl5UDAB2
4. INSTALLATION OF THROTTLE BODY GASKET
Install with the gasket protrusion positioned as shown.
CautionIf installed in an incorrect direction, idling failure or
other problems may occur.
TSB Revision

15-14INTAKE AND EXHAUST - Air Intake Plenum
AIR INTAKE PLENUM MIBUA-C
REMOVAL AND INSTALLATION
(Refer to GROUP 13 - Engine Control.)
/TurbochargerO&gOSFOOOS5Nm
L
18 Nm18
19 Nm13 ft.lbs.
-05FOO31Removal steps
I. Connection.air hose A2. Connection of accelerator cablea*3. Throttle body assemblyl *4. Throttle body gasket
5. Air pipe A
6. Connection of vacuum hose
7. Connection of brake booster vacuum hose
8. Harness connecter
9. Connection of clutch booster vacuum hose
10. EGR temperature sensor California>
11. EGR valve
12. EGR valve gasket
13. EGR pipe installation bolts
14. EGR pipe gasket
15. Connection of air intake plenum stay
16. Air intake plenum installation bolts
17. Air intake plenum installation nuts
18. Air intake plenum
19. Air intake plenum gasket
SERVICE POINT OF REMOVALM15UBAU3. REMOVAL OF THROTTLE BODY ASSEMBLY
Leaving the water hoses and vacuum hoses in their
installed positions, remove from the air intake plenum.
TSB Revision

INTAKE AND EXHAUST - Air Intake Plenum 15-15
Throttle body
Protrusion
-+ $ik ‘,5,=,,,,57
INSPECTIONMlSUCAD3
Check the following points; replace the part if a problem is
found.
AIR INTAKE PLENUM
(1) Check air intake plenum for defect or cracks. Replace if
defective or cracked.
(2) Check load (negative pressure) of drain port. Clean if
required.
SERVICE POINT OF INSTALLATIONMl5UoAB3
4. INSTALLATION OF THROTTLE BODY GASKET
Install with the gasket protrusion positioned as shown.
CautionIf installed in an incorrect direction, idling failure or
other problems may occur.
TSB Revision1

15-16INTAKE AND EXHAUST - Intake Manifold
INTAKE MANIFOLD
REMOVAL AND INSTALLATION
Pre-removal Operationl Release of Residual Pressure fromHigh Pressure Fuel Hose(Refer to GROUP 13-ServiceAdjustment Procedures.)l Draining of Engine Coolant (Refer
to GROUP 00 -Maintenance Service,)
l Removal of Air Intake Plenum(Referto P.15-13, 14.)5Nm
lo-13Nm4 ft.lbs.8-9ftJbs. w2\I
Post-installation Operationl Installation of Air Intake Plenum
(Refer to P.1.5-13. 14.)l Filling of Engine Coolant
(Refer to GROUP 00 - Maintenance
Service.)
l Adjustment of Accelerator Cable(Referto GROUP 13-EngineControl.). Checkina for Fuel Leakage6
5
2 :‘;bs.)
gp,.qgs ~-zt!EJ8OSFOO24
Removal steps
I. Connection for high-pressure fuel hose
2. O-ring
3. Connection for fuel return hose
4. Connection for vacuum hoses
5. Connection for injector connector
6. Delivery pipe (with injectors)
7. Insulators
8. Timing belt upper cover
I)*9. Intake manifold mounting nut I)* 10. Intake manifold mounting nut II. Cone disc spring
12. Intake manifold-
** 13. Intake manifold gasket
TSB Revision

INTAKE AND EXHAUST - Intake Manifold.15-1705LOO84
ProtrusionFRONT
ProtrusionA\
\ProtrusionProtrusidnOIL0857
FRONT
Intake mamfold7lN0090
APPLY~~ lubricant
INSPECTIONMlIMCATZCheck the following points; replace the part if a problem is
found.
INTAKE MANIFOLD(1) Check for damage or cracking of any part.
(2) Clogging of the negative pressure (vacuum) outlet port, or
clogging of the gas passages.
(3) Check deflection of installation surface with straight edge
and thickness gauge.
Standard value
: 0.15 mm (.0059 in.) or less
Limit
: 0.2 mm (.008 in.)
SERVICE POINTS OF INSTALLATIONMISMDAH
13. INSTALLATION OF INTAKE MANIFOLD GASKETInstall with gasket protrusions in the position illustrated.
10. INSTALLATION OF INTAKE MANIFOLD MOUNTING
NUT
Tighten the intake manifold mounting nuts one bank after
the other by the following ‘procedure.
(1) Tighten the nuts in the front bank to 3 to 5 Nm (2.2 to
3.6 ft.lbs.).
(2) Tighten the nuts in the rear bank to 12 to 15 Nm (9 to 11ft.lbs.).
(3) Tighten the nuts in the front bank to 12 to 15 Nm (9 to
11 ft.lbs.).
(4) Repeat steps (2) and (3) one more time respectively.
9. INSTALLATION OF INTAKE MANIFOLD MOUNTING
NUT
Apply lubricant sparingly to the intake manifold mounting
nuts.
TSB Revision

15-18INTAKE AND EXHAUST - Turbocharger (Front)
TURBOCHARGER (FRONT)
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operationl Removal and Installation of Radiator(Refer to GROUP 14 - Radiator.)l Removal and Installation of Transmission
l Rerr
IPipeioval and Installation of Front Exhaust(Refer to P.15-31.)
lJl QG!?
IMlSLA-AI
40 - 47 ft.lbs.
1\29 - 11 ft.lbs.Removal steps
** 1. Air hose C*+2. Air intake hose B*+ 3. Air hose D4. Air hose Al *5. Air hose B.6. Air pipe B
l +7. Air hose E8. Air pipe C
9. Drive belt(Refer to GROUP 11 - Service
Adjustment Procedures.)
10. Alternator assembly(Referto GROUP 16-Alternator.)
11. Engine oil level gauge guide
12. Heat protector B-13Nm
‘9 ft.lbs.
-‘25
05FOO43
13. Water pipe A
14. Water pipe B
15. Connection of oxygen sensor
16. Turbocharger
& fitting assembly
17. Gasket
18. Ring
l * ** 19. Oxygen sensor
20. Turbocharger stay
21. Exhaust fitting
22. Gasket
23. Oil return pipe
l * 24. Turbocharger assemblyl *25. Air conditioner compressor
26. Tension pulley bracket
27. Air conditioner compressor bracket
28. Oil pipe
I
LJ
1 TSB Revision

INTAKE AND EXHAUST - Turbocharger (Front)15-19
05FOO2(
SERVICE POINTS OF REMOVALM15LBAE
19. REMOVAL OF OXYGEN SENSORDisconnect the connector of the oxygen sensor, and install
the special tool to the oxygen sensor.
25. DISCONNECTION OF AIR CONDITIONER COMPRES-
SORDisconnect air conditioner compressor with hoses from the
bracket.
NOTEThe removed air conditioner compressor should be fas-
tened (by using rope, etc.) in a position that will not interfere
with the removal/installation of the turbocharger assembly.
INSPECTION
TURBOCHARGER ASSEMBLY CHECKMlSLCADl
lVisually check the turbine wheel and the compressor wheel
for cracking or other damage.
l Check whether the turbine wheel and the compressor
wheel can be easily turned by hand.
l Check for oil leakage from the turbocharger assembly.
lCheck whether or not the waste gate valve remains open. If
any problem is found, replace the part after disassembly.
OIL PIPE AND OIL-RETURN PIPE CHECKCheck the oil pipe and oil-return pipe for clogging, bending, or
other damage.
If there is clogging, clean it.
SERVICE POINTS OF INSTALLATIONMllLDAE
24. INSTALLATION OF TURBOCHARGER ASSEMBLYClean the alignment surfaces shown in the illustration.
Supply clean engine oil through the oil pipe installation hole
of the turbocharger assembly.
CautionWhen cleaning, care must be taken so that a piece of
the gasket does not enter the oil passage hole.
TSB Revision

15-20INTAKE AND EXHAUST - Turbocharger (Front)
19. INSTALLATION OF OXYGEN SENSORUse the special tool to install the oxygen sensor.
I;,iI-
i=x---b05F004E
l MatchmarkHose end paintPipe end protrusion05F002F
l MatchmarkHose end paintPipe end protrusion
Intercoolerright
J
Air Intake hose B
05FOO237. INSTALLATION OF AIR HOSE E
/ 5. AIR HOSE B
Aligning the marks at the points indicated by the arrows,
insert securely into the stepped portion of the pipe or until
seated.
CautionBe careful not to allow any foreign matter to get into
the hoses or pipes.
3. INSTALLATION OF AIR HOSE D
/ 1. AIR HOSE C
Aligning the marks at the points indicated by the arrows,
insert securely into the stepped portion of the pipe.
CautionBe careful not to allow any foreign matter to get into
the hoses or pipes.
LJ2. INSTALLATION OF AIR INTAKE HOSE B
Engaging the notches with
LL marks at the points indicated
by the arrows, insert until seated.
Insert the turbocharger end of air intake hose B completely.
[ TSB RevisionI
