INTAKE AND EXHAUST -Secondary Air Supply System15-15
INSTALLATION SERVICE POINTS
"AAGASKET INSTALLATION
Install the gasket so that its salient can face towards the
direction as shown in the illustration.
"BAGASKET INSTALLATION
Install the gasket so that its protrusion can face towards the
direction as shown in the illustration.
Salient
Secondary air pipe assembly
Protrusion

INTAKE AND EXHAUST -Intake Manifold15-16
INTAKE MANIFOLD
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
DAir Duct Removal and Installation (Refer to P.15-8.)
DStrut Tower Bar Removal and Installation
(Refer to GROUP 42.)
DUnder Cover Removal and Installation
(Refer to GROUP 51 - Front Bumper.)
DEngine Coolant Draining and Supplying
(Refer to GROUP 14 - On-vehicle Service.)
DThrottle Body Removal and Installation (Refer to
GROUP 13A - Throttle Body.)DCrossmember Bar Removal and Installation (Refer
to GROUP 32 - Engine Roll Stopper, Centermember.)
DFront Exhaust Pipe Removal and Installation (Refer
to GROUP 15 - Exhaust Pipe and Main Muffler.)
DSecondary Air Control Valve Bracket Removal and
Installation (Refer to P.15-14.)
DEngine Oil Draining and Supplying
1
2
3 4
5 6 7
8 10
11
1214
13
15
16 17
18
9
11±1 N·m3.0±0.5 N·m
13±1 N·m
(Engine oil)
(Engine oil) 5.0±1.0 N·m
14 8
Removal steps
1. Center cover
2. Oxygen sensor connector
connection
3. Injector connector connection
4. Fuel pressure solenoid valve
connector connection
5. Purge control solenoid valve
connector connection
6. Knock sensor connector connection
7. Vacuum hose connection
8. Vacuum hose
9. Fuel return hose connection"AA10. Fuel high-pressure hose connection
11. O-ring
AA"12. Delivery pipe, Injector and fuel
pressure regulator assembly
13. Insulator
14. Insulator
15. Oil level gauge and guide
16. O-ring
17. Brake booster vacuum hose
connection
18. Purge hose connection

INTAKE AND EXHAUST -Intake ManifoldINTAKE AND EXHAUST -Intake Manifold15-17
28 2325
26
2719
20 2221
23
24
30
23
29
20±2 N·m
20±2 N·m5.0±1.0 N·m
20±2 N·m
9.0±1.0 N·m
22±4 N·m 20±2 N·m 36±6 N·m
9.0±1.0 N·m
31±3 N·m 9.0±1.0 N·m 11±1 N·m
19. Vacuum hose
20. Fuel pressure solenoid valve
21. PCV hose
DAlternator (Refer to GROUP 16.)
22. Vacuum hose and Vacuum pipe
assembly connecting bolt
23. Vacuum tank, EGR solenoid valve,
Secondary air control solenoid
valve, Vacuum hose assembly24. Intake manifold stay
25. EGR valve
26. EGR gasket
27. Alternator brace stay
28. Intake manifold
29. Intake manifold gasket
30. Purge control solenoid valve
assembly
REMOVAL SERVICE POINTS
AA"DELIVERY PIPE, INJECTOR AND FUEL
PRESSURE REGULATOR ASSEMBLY REMOVAL
The delivery pipe must be removed with the injector and
fuel pressure regulator attached.
Caution
Take care not to drop delivery pipe, injector, or fuel
pressure regulator assembly when removing those parts.

INTAKE AND EXHAUST -Intake Manifold15-18
INSTALLATION SERVICE POINTS
"AAFUEL HIGH-PRESSURE HOSE CONNECTION
1. Apply a drop of new engine oil to the O-ring.
Caution
Be sure not to let engine oil enter the delivery pipe.
2. While turning the injector, high-pressure fuel hose and
fuel pressure regulator to the right and left, install the
delivery pipe, while being careful not to damage the O-ring.
After installing, check that the hose turns smoothly.
3. If it does not turn smoothly, the O-ring may be trapped,
remove the injector, high-pressure fuel hose or fuel
pressure regulator and then re-insert it into the delivery
pipe and check once again.
4. Tighten the high-pressure fuel hose to the specified torque.
Tightening torque: 5.0±1.0 N⋅m
INSPECTION
Check the following points; replace the part if a problem is
found.
INTAKE MANIFOLD CHECK
1. Check for damage or cracking of any part.
2. Check for obstruction of the negative pressure (vacuum)
outlet port, and for obstruction of the water passage or
gas passage.
3. Using a straight edge and thickness gauge, check for
distortion of the cylinder head installation surface.
Standard value: 0.15 mm
Limit: 0.20 mm

INTAKE AND EXHAUST -Exhaust Manifold15-19
EXHAUST MANIFOLD
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
DUnder Cover Removal and Installation
(Refer to GROUP 51 - Front bumper.)
DRadiator Removal and Installation
(Refer to GROUP 14.)
DAir Intake Hose Removal and Installation
(Refer to P.15-8.)DAir Pipe A, Air Pipe C, Air Hose D, Air Pipe B Removal
and Installation (Refer to P.15-9.)
DCrossmember Bar Removal and Installation (Refer
to GROUP 32 - Engine Roll Stopper, Centermember.)
DFront Exhaust Pipe Removal and Installation
(Refer to P.15-26.)
13 12
3
6 5
8
9
11 192122
14¶1 N·m
4
7
11
12 15
16
17
18
20
1010
14
14±1 N·m
14±1 N·m
29±3 N·m
59±5 N·m
49±5 N·m
44±5 N·m
59±5 N·m
35±6 N·m
44±5 N·m
14±1 N·m9.0±1.0 N·m30±3 N·m
30±3 N·m10±1 N·m
42±7 N·m
10±1 N·m
10±1 N·m
17±2 N·m
31±2 N·m
49±5 N·m
42±7 N·m
19±1 N·m
Removal steps
1. Exhaust manifold heat protector
2. Air pipe assembly
AA"3. Oxygen sensor
4. Turbocharger heat protector
5. Turbocharger water feed pipe
assembly connection
6. Turbocharger water return hose
connection
AB"7. Oil feed pipe
8. Starter Motor
9. Oil return pipe
"CA10. Oil return pipe gasket
11. Vacuum hose connection12. Air outlet fitting
"BA13. Air outlet fitting gasket
14. Exhaust fitting bracket
"AA15. Turbocharger assembly
16. Turbocharger
17. Exhaust fitting gasket
18. Exhaust fitting
19. Turbocharger gasket
20. Turbocharger water return pipe
assembly connection
21. Exhaust manifold
22. Exhaust manifold gasket

INTAKE AND EXHAUST -Exhaust ManifoldINTAKE AND EXHAUST -Exhaust Manifold15-20
REMOVAL SERVICE POINT
AA"OXYGEN SENSOR REMOVAL
Use special tool to remove the oxygen sensor.
AB"OIL FEED PIPE REMOVAL
Take care not to let foreign objects get into the oil passage
hole of the turbocharger after the oil feed pipe is removed.
INSTALLATION SERVICE POINT
"AATURBOCHARGER INSTALLATION
1. Clean the oil feed pipe, oil return pipe, water pipe fitting,
the inside of eye bolt, and individual pipe for clogs.
2. Clean or blow the air if carbon particles are stuck to the
oil passage of the turbocharger.
Caution
Take care not to let foreign objects get into the
turbocharger.
3. Refill new engine oil at the oil feed pipe fitting hole of
the turbocharger.
"BAAIR OUTLET FITTING GASKET INSTALLATION
Install the gasket so that its protrusion can face towards the
direction as shown in the illustration.
MD998770
Oxygen sensor
View A
View A
TurbochargerProtrusion

INTAKE AND EXHAUST -Exhaust Manifold15-21
"CAOIL RETURN PIPE GASKET INSTALLATION
Install the gasket so that its print part can face towards the
oil pan side.
INSPECTION
Check the following points; replace the part if a problem is
found.
1. EXHAUST MANIFOLD CHECK
(1) Check for damage or cracking of any part.
(2) Using a straight edge and a feeler gauge, check for
distortion of the cylinder head installation surface.
Standard value: 0.15 mm or less
Limit: 0.20 mm
2. TURBOCHARGER ASSEMBLY CHECK
(1) Visually check the turbine wheel and the compressor
wheel for cracking or other damage.
(2) Check whether the turbine wheel and the compressor
wheel can be easily turned by hand.
(3) Check for oil leakage from the turbocharger assembly.
(4) Check whether or not the waste gate valve remains open.
If any problem is found, replace the part after disassembly.
Gasket
Print
Compressor wheel

INTAKE AND EXHAUST -Turbocharger15-22
TURBOCHARGER
DISASSEMBLY AND REASSEMBLY
5
11.3±1.5 Nm
4368
2
17
Disassembly steps
"FADInspection of turbocharger waste gate
actuator operation
1. E-ring
2. Waste gate actuator
"EA3. Coupling"DA4. Turbine housing
AA""CA5. Snap ring
AB""BA6. Turbine wheel assembly
7. Compressor cover
"AA8. O-ring

INTAKE AND EXHAUST -Turbocharger15-23
DISASSEMBLY SERVICE POINTS
AA"SNAP RING REMOVAL
Lay the unit with the compressor cover side facing down
and using snap ring pliers, remove the compressor cover
attaching snap ring.
Caution
When removing the snap ring, hold it with fingers to
prevent it from springing away.
AB"TURBINE WHEEL ASSEMBLY REMOVAL
Remove the turbine wheel assembly, striking the
circumference of the compressor cover with a plastic hammer.
The turbine wheel assembly may be a little hard to remove
due to an O-ring put on the outer circumference.
CLEANING
1. Use a clean cleaning oil commercially available. Do not
use corrosive cleaning oils as they could damage to some
parts.
2. Use a plastic scraper or hard brush to clean aluminum
parts.
REASSEMBLY SERVICE POINTS
"AAO-RING INSTALLATION
Apply a light coat of engine oil to a new O-ring and fit in
the turbine wheel assembly groove.
Caution
When installing the O-ring, use care not to damage it. A
damaged O-ring causes oil leaks.
"BATURBINE WHEEL ASSEMBLY
1. Apply a light coat of engine oil to the periphery of the
O-ring.
2. Install the turbine wheel assembly to the compressor cover
in relation to the dowel pin.
Caution
Use care not to damage the blades of turbine wheel
and compressor wheel.
Snap ring
Turbine
wheel
assembly
O-ring
Dowel pin
Dowel pin hole

INTAKE AND EXHAUST -Turbocharger15-24
"CASNAP RING INSTALLATION
Lay the assembly with the compressor cover facing down
and fit the snap ring.
Caution
Fit the snap ring with its chamfered side facing up.
"DATURBINE HOUSING INSTALLATION
Install the turbine housing in relation to the dowel pin.
Caution
Use care not to damage the blades of turbine wheel.
"EACOUPLING INSTALLATION
Install the coupling and tighten to the specified torque.
"FAWASTE GATE ACTUATOR OPERATION CHECK
Using a tester, apply a pressure of approx. 100.0 kPa to
the actuator and make sure that the rod moves.
Caution
Do not apply a pressure of more than 113.3 kPa to the
actuator. Otherwise, diaphragm may be damaged. Never
attempt to adjust the waste gate valve.
INSPECTION
TURBINE HOUSING
1. Check the housing for traces of contact with the turbine
wheel, cracks due to overheating, pitching, deformation
and other damage. Replace with a new turbine housing
if cracked.
2. Operate the waste gate valve lever manually to check
that the gate can be operated and closed smoothly.
Snap ring
Turbine wheel
assembly
Compressor
cover Chamfered edge
Dowel
pin
Dowel pin hole
Coupling
Traces of contact
