NISSAN NOTE 2016 Service Repair Manual
Manufacturer: NISSAN, Model Year: 2016, Model line: NOTE, Model: NISSAN NOTE 2016Pages: 3641, PDF Size: 28.72 MB
Page 1121 of 3641
![NISSAN NOTE 2016 Service Repair Manual EM-120
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
VALVE GUIDE
Unit: mm (in)
VALVE SEAT
Unit: mm (in)
Items
Standard part Service part
Va l v e g u i d e Ou](/img/5/57363/w960_57363-1120.png "NISSAN NOTE 2016 Service Repair Manual EM-120
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
VALVE GUIDE
Unit: mm (in)
VALVE SEAT
Unit: mm (in)
Items
Standard part Service part
Va l v e g u i d e Ou")
EM-120
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
VALVE GUIDE
Unit: mm (in)
VALVE SEAT
Unit: mm (in)
Items
Standard part Service part
Va l v e g u i d e Outer diameter
9.023 - 9.034 (0.3552 - 0.3556) 9.223 - 9.234 (0.3631 - 0.3635)
Inner diameter (Finished size) 5.000 - 5.018 (0.1968 - 0.1975)
Cylinder head valve guide hole diameter 8.975 - 9.001 (0.3533 - 0.3544) 9.175 - 9.201 (0.3612 - 0.3622)
Interference fit of valve guide 0.022 - 0.059 (0.0009 - 0.0023)
Items StandardLimit
Valve guide clearance Intake
0.020 - 0.053 (0.0008 - 0.0021) 0.1 (0.004)
Exhaust 0.030 - 0.063 (0.0012 - 0.0025) 0.1 (0.004)
Projection length “L” 11.4 - 11.8 (0.448 - 0.464)
PBIC0184E
ItemsStandardOversize [0.5 (0.02)] (Service)
Cylinder head seat recess diameter “D” Intake 29.75 - 30.25 (1.1713 - 1.1909) 30.43 - 30.73 (1.1980 - 1.2098)
Exhaust 25.991 - 26.007 (1.0233 - 1.0239) 26.491 - 26.507 (1.0430 - 1.0436)
Valve seat outer diameter “d” Intake 32.108 - 32.124 (1.2641 - 1.2647) 32.608 - 32.624 (1.2838 - 1.2844)
Exhaust 23.65 - 24.15 (.9311 - .9508) 23.69 - 26.007 (.9327 - 1.0239)
Valve seat interference fit Intake
0.081 - 0.124 (0.0032 - 0.0049)
Exhaust 0.064 - 0.107 (0.0025 - 0.0042)
Diameter “d1”*
1Intake 27.8 - 28.2 (1.0945 - 1.1102)
Exhaust 21.7 - 22.1 (.8543 - .8701)
Diameter “d2”*
2Intake 31.2 - 31.4 (1.228 - 1.236)
Exhaust 24.9 - 25.1 (0.980 - 0.988)
Angle “ α1” Intake
60°
Exhaust 45°
PBIC2745E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1122 of 3641
![NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)EM-121
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
*1: Diameter made by intersection point of conic angles
α1 and α2
*
2](/img/5/57363/w960_57363-1121.png "NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)EM-121
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
*1: Diameter made by intersection point of conic angles
α1 and α2
*
2")
SERVICE DATA AND SPECIFICATIONS (SDS)EM-121
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
*1: Diameter made by intersection point of conic angles
α1 and α2
*
2: Diameter made by intersection point of conic angles α2 and α3
*
3: Machining data
VALVE SPRING
Cylinder BlockINFOID:0000000012431748
CYLINDER BLOCK
Unit: mm (in)
Angle “ α2” Intake 88
°45 ′ - 90 °15 ′
Exhaust 88°45 ′ - 90 °15 ′
Angle “ α3” Intake
120°
Exhaust 120°
Contacting width “W”*
3Intake 1.44 - 2.1 (0.0567 - .0827)
Exhaust 1.1 - 1.9 (.0433 - .0748) or 0.9 - 2.1 (.0354 - .0827)
Height “h” Intake
4.7 (0.185) 4.15 (0.163)
Exhaust 6.0 (0.236) 5.43 (0.213)
Depth “H” Intake
4.7 (0.185)
Exhaust 6.0 (0.236)
Free height 46.73 mm (1.8398 in)
Installation height 32.40 mm (1.2756 in)
Installation load 136 - 154 N (13.9 - 15.7 kg, 30.6 - 34.6 lb)
Height during valve open 23.96 mm (0.9433 in)
Load with valve open 242 - 272 N (24.7 - 27.7 kg, 54.4 - 61.1 lb)
Surface distortionLimit 0.1 (0.004)
Cylinder bore Inner diameter Standard 78.000 - 78.015 (3.0709 - 3.0715)
Wear limit —
Out-of-round (Difference between “X” and “Y”) Limit 0.015 (0.0006)
Taper (Difference between “A” and “C”) 0.010 (0.0004)
PBIC3924E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1123 of 3641
![NISSAN NOTE 2016 Service Repair Manual EM-122
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
* : Always check with the Parts Department for the latest parts information.
AVAILABLE PISTON
Unit: mm (in](/img/5/57363/w960_57363-1122.png "NISSAN NOTE 2016 Service Repair Manual EM-122
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
* : Always check with the Parts Department for the latest parts information.
AVAILABLE PISTON
Unit: mm (in")
EM-122
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
* : Always check with the Parts Department for the latest parts information.
AVAILABLE PISTON
Unit: mm (in)
PISTON RING
Unit: mm (in)
PISTON PIN
Unit: mm (in)
Cylinder block main bearing housing inner diameter grade*Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W51.997 - 51.998 (2.0471 - 2.0472)
51.998 - 51.999 (2.0472 - 2.0472)
51.999 - 52.000 (2.0472 - 2.0472)
52.000 - 52.001 (2.0472 - 2.0473)
52.001 - 52.002 (2.0473 - 2.0473)
52.002 - 52.003 (2.0473 - 2.0474)
52.003 - 52.004 (2.0474 - 2.0474)
52.004 - 52.005 (2.0474 - 2.0474)
52.005 - 52.006 (2.0474 - 2.0475)
52.006 - 52.007 (2.0475 - 2.0475)
52.007 - 52.008 (2.0475 - 2.0475)
52.008 - 52.009 (2.0476 - 2.0476)
52.009 - 52.010 (2.0476 - 2.0476)
52.010 - 52.011 (2.0476 - 2.0477)
52.011 - 52.012 (2.0477 - 2.0477)
52.012 - 52.013 (2.0477 - 2.0478)
52.013 - 52.014 (2.0478 - 2.0478)
52.014 - 52.015 (2.0478 - 2.0478)
52.015 - 52.016 (2.0478 - 2.0479)
52.016 - 52.017 (2.0479 - 2.0479)
Difference in inner diameter between cylinders Standard Less than 0.03 (0.0012)
Piston skirt diameter “A”77.965 - 77.980 (3.0694 - 3.0700)
Piston height “H” dimension 37.1 (1.460)
Piston pin hole diameter 19.006 - 19.012 (0.7482 - 0.7485)
Piston to cylinder bore clearance 0.020 - 0.050 (0.0008 - 0.0020)
PBIC0188E
ItemsStandard Limit
Side clearance Top
0.04 - 0.08 (0.0016 - 0.0031) 0.11 (0.0043)
2nd 0.03 - 0.07 (0.0012 - 0.0028) 0.10 (0.0039)
Oil (rail ring) 0.045 - 0.125 (0.0018 - 0.0049) —
End gap Top
0.20 - 0.30 (0.0079 - 0.0118) —
2nd 0.35 - 0.50 (0.0138 - 0.0197) —
Oil (rail ring) 0.20 - 0.45 (0.0079 - 0.0177) —
Piston pin outer diameter 18.999 - 19.002 (0.7480 - 0.7481)
Piston to piston pin oil clearance Standard0.010 - 0.014 (0.0004 - 0.0006)
Connecting rod bushing oil clearance Standard–0.018 to –0.044 (–0.0007 to –0.0017)
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1124 of 3641
![NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)EM-123
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
CONNECTING ROD
Unit: mm (in)
*1 : After installing in connecting rod
*
2 :](/img/5/57363/w960_57363-1123.png "NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)EM-123
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
CONNECTING ROD
Unit: mm (in)
*1 : After installing in connecting rod
*
2 :")
SERVICE DATA AND SPECIFICATIONS (SDS)EM-123
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
CONNECTING ROD
Unit: mm (in)
*1 : After installing in connecting rod
*
2 : Always check with the Parts Department for the latest parts information.
CRANKSHAFT
Unit: mm (in)
Center distance 129.84 - 129.94 (5.1118 - 5.1157)
Bend [per 100 (3.94)] Limit 0.15 (0.0059)
Torsion [per 100 (3.94)] Limit 0.30 (0.0118)
Connecting rod bushing inner diameter*
118.958 - 18.978 (0.7463 - 0.7471)
Side clearance Standard 0.200 - 0.352 (0.0079 - 0.0138)
Connecting rod big end diameter grade*
2
Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N 43.000 - 43.001 (1.6929 - 1.6929)
43.001 - 43.002 (1.6929 - 1.6930)
43.002 - 43.003 (1.6930 - 1.6930)
43.003 - 43.004 (1 6930 - 1.6931)
43.004 - 43.005 (1.6931 - 1.6931)
43.005 - 43.006 (1.6931 - 1.6931)
43.006 - 43.007 (1.6931 - 1.6932)
43.007 - 43.008 (1.6932 - 1.6932)
43.008 - 43.009 (1.6932 - 1.6933)
43.009 - 43.010 (1.6933 - 1.6933)
43.010 - 43.011 (1.6933 - 1.6933)
43.011 - 43.012 (1.6933 - 1.6934)
43.012 - 43.013 (1.6934 - 1.6934)
Center distance “r” 41.68 - 41.76 (1.6409 - 1.6441)
Out-of-round Limit0.003 (0.0001)
Taper Limit0.004 (0.0002)
Runout [TIR*
1] Limit 0.10 (0.0039)
Crankshaft end play Standard
0.098 - 0.260 (0.0039 - 0.0102)
Limit 0.35 (0.0138)
SEM645PBIC3459J
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1125 of 3641
![NISSAN NOTE 2016 Service Repair Manual EM-124
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*1: Total indicator reading
*
2: Always check with the Parts Department for the latest parts information.](/img/5/57363/w960_57363-1124.png "NISSAN NOTE 2016 Service Repair Manual EM-124
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*1: Total indicator reading
*
2: Always check with the Parts Department for the latest parts information.")
EM-124
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*1: Total indicator reading
*
2: Always check with the Parts Department for the latest parts information.
*
3: Grade No. B through U reflects less than maximum specification.
*
4: Grade No. B through W reflects less than maximum specification.
Main BearingINFOID:0000000012431749
MAIN BEARING
Crankshaft pin journal diameter grade.*2“Dp”*3
Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U 39.970 - 39.971 (1.5736 - 1.5737)
39.969 - 39.970 (1.5736 - 1.5736)
39.968 - 39.969 (1.5735 - 1.5736)
39.967 - 39.968 (1.5735 - 1.5735)
39.966 - 39.967 (1.5735 - 1.5735)
39.965 - 39.966 (1.5734 - 1.5735)
39.964 - 39.965 (1.5734 - 1.5734)
39.963 - 39.964 (1.5733 - 1.5734)
39.962 - 39.963 (1.5733 - 1.5733)
39.961 - 39.962 (1.5733 - 1.5733)
39.960 - 39.961 (1.5732 - 1.5733)
39.959 - 39.960 (1.5732 - 1.5732)
39.958 - 39.959 (1.5731 - 1.5732)
39.957 - 39.958 (1.5731 - 1.5731)
39.956 - 39.957 (1.5731 - 1.5731)
39.955 - 39.956 (1.5730 - 1.5731)
39.954 - 39.955 (1.5730 - 1.5730)
39.953 - 39.954 (1.5729 - 1.5730)
Crankshaft main journal diameter grade.*
2
“Dm”*4
Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W 47.978 - 47.979 (1.8889 - 1.8889)
47.977 - 47.978 (1.8889 - 1.8889)
47.976 - 47.977 (1.8888 - 1.8889)
47.975 - 47.976 (1.8888 - 1.8888)
47.974 - 47.975 (1.8887 - 1.8888)
47.973 - 47.974 (1.8887 - 1.8887)
47.972 - 47.973 (1.8887 - 1.8887)
47.971 - 47.972 (1.8886 - 1.8886)
47.970 - 47.971 (1.8886 - 1.8886)
47.969 - 47.970 (1.8885 - 1.8886)
47.968 - 47.969 (1.8885 - 1.8885)
47.967 - 47.968 (1.8885 - 1.8885)
47.966 - 47.967 (1.8884 - 1.8885)
47.965 - 47.966 (1.8884 - 1.8884)
47.964 - 47.965 (1.8883 - 1.8884)
47.963 - 47.964 (1.8883 - 1.8883)
47.962 - 47.963 (1.8883 - 1.8883)
47.961 - 47.962 (1.8882 - 1.8883)
47.960 - 47.961 (1.8882 - 1.8882)
47.959 - 47.960 (1.8881 - 1.8882)
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 1126 of 3641
![NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)EM-125
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
*: Always check with the Parts Department for the latest par](/img/5/57363/w960_57363-1125.png "NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)EM-125
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
*: Always check with the Parts Department for the latest par")
SERVICE DATA AND SPECIFICATIONS (SDS)EM-125
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Undersize
Unit: mm (in)
Bearing Oil Clearance
Unit: mm (in)
Connecting Rod BearingINFOID:0000000012431750
CONNECTING ROD BEARING
Unit: mm (in)
Grade number*
ThicknessIdentification color Remarks
0 1.996 - 1.999 (0.0786 - 0.0787) Black
Grade and color are the same
for upper and lower bearings.
1
1.999 - 2.002 (0.0787 - 0.0788) Brown
2 2.002 - 2.005 (0.0788 - 0.0789) Green
3 2.005 - 2.008 (0.0789 - 0.0791) Yellow
4 2.008 - 2.011 (0.0791 - 0.0792) Blue
5 2.011 - 2.014 (0.0792 - 0.0793) Pink
01 UPR 1.996 - 1.999 (0.0786 - 0.0787)
Black
Grade and color are different
for upper and lower bearings.
LWR 1.999 - 2.002 (0.0787 - 0.0788)
Brown
12 UPR 1.999 - 2.002 (0.0787 - 0.0788)
Brown
LWR 2.002 - 2.005 (0.0788 - 0.0789) Green
23 UPR 2.002 - 2.005 (0.0788 - 0.0789)
Green
LWR 2.005 - 2.008 (0.0789 - 0.0791) Yellow
34 UPR 2.005 - 2.008 (0.0789 - 0.0791)
Yellow
LWR 2.008 - 2.011 (0.0791 - 0.0792) Blue
45 UPR 2.008 - 2.011 (0.0791 - 0.0792)
Blue
LWR 2.011 - 2.014 (0.0792 - 0.0793) Pink
SEM685D
ItemsThickness Main journal diameter
US 0.25 (0.0098) 2.126 - 2.134 (0.0837 - 0.0840) Grind so that bearing clearance is the specified value.
Main bearing oil clearance Standard0.024 - 0.034 (0.0009 - 0.0013)
Grade number*ThicknessIdentification color Remarks
1 1.501 - 1.504 (0.0591 - 0.0592) Brown
2 1.504 - 1.507 (0.0592 - 0.0593) Green
3 1.507 - 1.510 (0.0593 - 0.0594) Yellow
4 1.510 - 1.513 (0.0594 - 0.0596) Blue
5 1.513 - 1.516 (0.0596 - 0.0597) Pink
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1127 of 3641
![NISSAN NOTE 2016 Service Repair Manual EM-126
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Always check with the Parts Departm
ent for the latest parts information.
Undersize
Unit: mm (in)
Beari](/img/5/57363/w960_57363-1126.png "NISSAN NOTE 2016 Service Repair Manual EM-126
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Always check with the Parts Departm
ent for the latest parts information.
Undersize
Unit: mm (in)
Beari")
EM-126
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Always check with the Parts Departm
ent for the latest parts information.
Undersize
Unit: mm (in)
Bearing Oil Clearance
Unit: mm (in)
12UPR 1.501 - 1.504 (0.0591 - 0.0592)
Brown
Grade and color are different
between upper and lower bear-
ings.
LWR 1.504 - 1.507 (0.0592 - 0.0593)
Green
23 UPR 1.504 - 1.507 (0.0592 - 0.0593)
Green
LWR 1.507 - 1.510 (0.0593 - 0.0594) Yellow
34 UPR 1.507 - 1.510 (0.0593 - 0.0594)
Yellow
LWR 1.510 - 1.513 (0.0594 - 0.0596) Blue
56 UPR 1.513 - 1.516 (0.0596 - 0.0597)
Pink
LWR 1.516 - 1.519 (0.0597 - 0.0598) Purple
ItemsThickness Crankshaft pin journal diameter
US 0.25 (0.0098) 1.627 - 1.635 (0.0640 - 0.0644) Grind so that bearing clearance is the specified value.
Connecting rod bearing oil clearance Standard 0.020 - 0.030 (0.0008 - 0.0012)
Limit
0.10 (0.0039)
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1128 of 3641
EC-1
ENGINE
C
DE
F
G H
I
J
K L
M
SECTION EC
A
EC
N
O P
CONTENTS
ENGINE CONTROL SYSTEM
HR16DE
PRECAUTION ....... ........................................
8
PRECAUTIONS .............................................. .....8
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
8
On Board Diagnostic (OBD) System of Engine
and CVT ....................................................................
8
General Precautions .................................................9
PREPARATION ...........................................12
PREPARATION .............................................. ....12
Special Service Tools .......................................... ....12
Commercial Service Tools ......................................12
SYSTEM DESCRIPTION .............................14
COMPONENT PARTS ................................... ....14
ENGINE CONTROL SYSTEM ............................... ....14
ENGINE CONTROL SYSTEM :
Component Parts Location ....................................
14
ENGINE CONTROL SYSTEM : Component De-
scription ............................................................... ....
17
Accelerator Pedal Position Sensor ..........................18
Air Fuel Ratio Sensor 1 ...........................................19
Air Fuel Ratio Sensor 1 Heater ...............................19
Camshaft Position Sensor .......................................19
Clutch Pedal Position Switch ..................................20
Cooling Fan .............................................................20
Crankshaft Position Sensor .....................................20
ECM .................................................................... ....20
Electric Throttle Control Actuator ............................21
Engine Coolant Temperature Sensor ......................21
Engine Oil Pressure Sensor ....................................21
Engine Oil Temperature Sensor ..............................21
EVAP Canister Purge Volume Control Solenoid
Valve ................................................................... ....
22
EVAP Canister Vent Control Valve .........................22
EVAP Control System Pressure Sensor ..................22
Exhaust Valve Timing Cont rol Solenoid Valve ........23
Fuel Injector ......................................................... ....23
Fuel Pump ...............................................................23
Heated Oxygen Sensor 2 ........................................24
Heated Oxygen Sensor 2 Heater ............................24
Ignition Coil With Power Transistor .........................24
Intake Air Temperature Sensor ...............................24
Intake Valve Timing Control Solenoid Valve ...........25
Knock Sensor ...................................................... ....25
Battery Current Sensor (With Battery Tempera-
ture Sensor) .............................................................
25
Malfunction Indicator Lamp (MIL) ............................26
Mass Air Flow Sensor ..............................................26
Oil Pressure Warning Lamp ....................................26
Refrigerant Pressure Sensor ............................... ....27
Stop Lamp Switch & ASCD Brake Switch ...............27
Throttle Control Motor .......................................... ....27
Throttle Control Motor Relay ...................................27
Throttle Position Sensor ..........................................27
ASCD Steering Switch .............................................27
STRUCTURE AND OPERATION .....................28
Positive Crankcase Ventilation ................................28
On Board Refueling Vapor Recovery (ORVR) ........29
SYSTEM ............................................................30
ENGINE CONTROL SYSTEM ........................ ...........30
ENGINE CONTROL SYSTEM : System Diagram ....30
ENGINE CONTROL SYSTEM : System Descrip-
tion ...........................................................................
31
MULTIPORT FUEL INJECTION SYSTEM ................31
MULTIPORT FUEL INJECTION SYSTEM :
System Diagram ................................................. ....
32
MULTIPORT FUEL INJECTION SYSTEM : Sys-
tem Description ........................................................
32
ELECTRIC IGNITION SYSTEM .................................35
ELECTRIC IGNITION SYSTEM :
System Diagram ................................................. ....
35
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1129 of 3641
EC-2
ELECTRIC IGNITION SYSTEM : System De-
scription ............................................................... ...
35
AIR CONDITIONING CUT CONTROL ................... ...36
AIR CONDITIONING CUT CONTROL : System
Diagram ..................................................................
37
AIR CONDITIONING CUT CONTROL : System
Description ..............................................................
37
CAN COMMUNICATION ........................................ ...38
CAN COMMUNICATION : System Description ......38
COOLING FAN CONTROL .................................... ...38
COOLING FAN CONTROL : System Diagram .......38
COOLING FAN CONTROL : System Description ...38
EVAPORATIVE EMISSION SYSTEM .................... ...40
EVAPORATIVE EMISSION SYSTEM : System
Diagram ............................................................... ...
40
EVAPORATIVE EMISSION SYSTEM : System
Description ........................................................... ...
40
INTAKE VALVE TIMING CONTROL ..................... ...41
INTAKE VALVE TIMING CONTROL : System Di-
agram .................................................................. ...
41
INTAKE VALVE TIMING CONTROL : System De-
scription ............................................................... ...
41
EXHAUST VALVE TIMING CONTROL ................. ...42
EXHAUST VALVE TIMING CONTROL : System
Diagram ............................................................... ...
42
EXHAUST VALVE TIMING CONTROL : System
Description ........................................................... ...
42
ENGINE PROTECTION CONTROL AT LOW EN-
GINE OIL PRESSURE ..............................................
43
ENGINE PROTECTION CONTROL AT LOW EN-
GINE OIL PRESSURE : S ystem Diagram ..............
43
ENGINE PROTECTION CONTROL AT LOW EN-
GINE OIL PRESSURE : S ystem Description .........
43
FUEL FILLER CAP WARNING SYSTEM .............. ...44
FUEL FILLER CAP WARNING SYSTEM :
System Diagram ....................................................
44
FUEL FILLER CAP WARNING SYSTEM : System
Description ........................................................... ...
44
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ...45
AUTOMATIC SPEED CONTROL DEVICE (AS-
CD) : System Diagram ............................................
45
AUTOMATIC SPEED CONTROL DEVICE (AS-
CD) : System Description .......................................
45
OPERATION ......................................................47
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ...47
AUTOMATIC SPEED CONTROL DEVICE (AS-
CD) : Switch Name and Function ...........................
47
ON BOARD DIAGNOSTIC (OBD) SYSTEM .....49
Diagnosis Description .......................................... ...49
GST (Generic Scan Tool) .......................................49
DIAGNOSIS SYSTEM (ECM) ............................50
DIAGNOSIS DESCRIPTION .................................. ...50
DIAGNOSIS DESCRIPTION : 1st Trip Detection
Logic and Two Trip Detection Logic ........................
50
DIAGNOSIS DESCRIPTION : DTC and Freeze
Frame Data .......................................................... ...
50
DIAGNOSIS DESCRIPTION : Counter System ......51
DIAGNOSIS DESCRIPTION : Driving Pattern ..... ...54
DIAGNOSIS DESCRIPTION : System Readiness
Test (SRT) Code .................................................. ...
55
DIAGNOSIS DESCRIPTION : Permanent Diag-
nostic Trouble Code (Permanent DTC) ..................
56
DIAGNOSIS DESCRIPTION : Malfunction Indica-
tor Lamp (MIL) ..................................................... ...
57
On Board Diagnosis Function .................................57
CONSULT Function ................................................60
ECU DIAGNOSIS INFORMATION .............71
ECM ...................................................................71
Reference Value .................................................. ...71
Fail Safe .................................................................83
DTC Inspection Priority Chart ...............................85
DTC Index ..............................................................87
Test Value and Test Limit .......................................90
WIRING DIAGRAM ....................................99
ENGINE CONTROL SYSTEM ........................ ...99
Wiring Diagram .................................................... ...99
BASIC INSPECTION .................................120
DIAGNOSIS AND REPAIR WORKFLOW ...... ..120
Work Flow ............................................................ .120
Diagnostic Work Sheet .........................................123
ADDITIONAL SERVICE WHEN REPLACING
ECM ..................................................................
125
Description ........................................................... .125
Work Procedure ....................................................125
VIN REGISTRATION ........................................127
Description ........................................................... .127
Work Procedure ....................................................127
ACCELERATOR PEDAL RELEASED POSI-
TION LEARNING ............................................ ..
128
Description ........................................................... .128
Work Procedure ....................................................128
THROTTLE VALVE CLOSED POSITION
LEARNING .......................................................
129
Description ........................................................... .129
Work Procedure ....................................................129
IDLE AIR VOLUME LEARNING .......................130
Description ........................................................... .130
Work Procedure ....................................................130
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1130 of 3641
EC-3
C
DE
F
G H
I
J
K L
M
EC A
N
O P
MIXTURE RATIO SELF-LEARNING VALUE
CLEAR ............................................................ ..
132
Description .......................................................... ..132
Work Procedure ....................................................132
BASIC INSPECTION ........................................133
Work Procedure .................................................. ..133
FUEL PRESSURE CHECK ..............................137
Work Procedure .................................................. ..137
HOW TO SET SRT CODE ................................139
Description .......................................................... ..139
SRT Set Driving Pattern ........................................140
Work Procedure ....................................................142
HOW TO ERASE PERMANENT DTC ..............145
Description .......................................................... ..145
Work Procedure (Group A) ...................................146
Work Procedure (Group B) ...................................148
DTC/CIRCUIT DIAGNOSIS .......................151
TROUBLE DIAGNOSIS - SPECIFICATION
VALUE ............................................................ ..
151
Description .......................................................... ..151
Component Function Check ..................................151
Diagnosis Procedure .............................................152
POWER SUPPLY AND GROUND CIRCUIT ....159
Diagnosis Procedure ........................................... ..159
U0101 CAN COMM CIRCUIT ...........................162
Description .......................................................... ..162
DTC Logic .............................................................162
Diagnosis Procedure .............................................162
U0284 ACTIVE GRILLE SHUTTER .................163
DTC Logic ........................................................... ..163
Diagnosis Procedure .............................................163
U1001 CAN COMM CIRCUIT ...........................164
Description .......................................................... ..164
DTC Logic .............................................................164
Diagnosis Procedure .............................................164
U1040 ENG COMM CIRCUIT ...........................165
DTC Logic ........................................................... ..165
Diagnosis Procedure .............................................165
U1044 ENG COMM CIRCUIT ...........................166
DTC Logic ........................................................... ..166
Diagnosis Procedure .............................................166
P0011 IVT CONTROL ......................................167
DTC Logic ........................................................... ..167
Diagnosis Procedure .............................................168
Component Inspection ..........................................169
P0014 EVT CONTROL .....................................171
DTC Logic .............................................................171
Diagnosis Procedure .............................................172
Component Inspection ......................................... ..173
P0030, P0031, P0032 A/F SENSOR HEATER .174
DTC Logic ............................................................ ..174
Diagnosis Procedure .............................................174
Component Inspection ...........................................175
P0037, P0038 HO2S2 HEATER .....................177
DTC Logic ..............................................................177
Diagnosis Procedure .............................................177
Component Inspection ...........................................178
P0075 IVT CONTROL SOLENOID VALVE ....180
DTC Logic ..............................................................180
Diagnosis Procedure .............................................180
Component Inspection ...........................................181
P0078 EVT CONTROL SOLENOID VALVE ...182
DTC Logic ..............................................................182
Diagnosis Procedure .............................................182
Component Inspection ...........................................183
P0101 MAF SENSOR .....................................185
DTC Logic ..............................................................185
Diagnosis Procedure .............................................185
Component Inspection ...........................................187
P0102, P0103 MAF SENSOR .........................190
DTC Logic ..............................................................190
Diagnosis Procedure .............................................190
Component Inspection ...........................................192
P0111 IAT SENSOR .......................................195
DTC Logic ..............................................................195
Component Function Check ..................................196
Diagnosis Procedure .............................................196
Component Inspection ...........................................196
P0112, P0113 IAT SENSOR ...........................197
DTC Logic ..............................................................197
Diagnosis Procedure .............................................197
Component Inspection ...........................................198
P0116 ECT SENSOR ......................................199
DTC Logic ..............................................................199
Component Function Check ..................................200
Diagnosis Procedure .............................................200
Component Inspection ...........................................200
P0117, P0118 ECT SENSOR ..........................201
DTC Logic ..............................................................201
Diagnosis Procedure .............................................201
Component Inspection ...........................................202
P0122, P0123 TP SENSOR ............................203
DTC Logic ..............................................................203
Diagnosis Procedure .............................................203
Component Inspection ...........................................204
P0125 ECT SENSOR ......................................206
DTC Logic ..............................................................206
Diagnosis Procedure .............................................206
Revision: August 2015 2016 Versa Note
cardiagn.com
