NISSAN TEANA 2008 Service Manual

INSIDE KEY ANTENNA
DLK-235
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
INSIDE KEY ANTENNA
INSTRUMENT CENTER
INSTRUMENT CENTER : Exploded ViewINFOID:0000000003795128
INSTRUMENT CENTER : Removal and InstallationINFOID:0000000003795129
REMOVAL
1. Remove the AV C/U (audio unit). Refer to AV-37, "Removal and Installation".
2. Remove the key antenna (instrument center) mounting screws
(A), and then remove inside key antenna (instrument center) (1).
INSTALLATION
Install in the reverse order of removal.
CONSOLE
1. Inside key antenna (instrument center)
JMKIA2438ZZ
JMKIA2441ZZ

DLK-236
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
INSIDE KEY ANTENNA
CONSOLE : Exploded View
INFOID:0000000003795130
CONSOLE : Removal and InstallationINFOID:0000000003795131
REMOVAL
1. Remove the console pocket and rear finisher. Refer to IP-22, "Removal and Installation".
2. Remove the inside key antenna (console) mounting screws (A),
and then remove inside key antenna (console) (1) from console
rear finisher (2).
INSTALLATION
Install in the reverse order of removal.
TRUNK ROOM
1. Inside key antenna (console)
JMKIA2437ZZ
JMKIA2442ZZ

INSIDE KEY ANTENNA
DLK-237
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK ROOM : Exploded ViewINFOID:0000000003795132
TRUNK ROOM : Removal and InstallationINFOID:0000000003795133
REMOVAL
1. Remove the inside key antenna (trunk room) mounting clips (A),
and then remove inside key antenna (trunk room) (1).
INSTALLATION
Install in the reverse order of removal.
1. Inside key antenna (trunk room)
JMKIA2439ZZ
JMKIA2440ZZ

DLK-238
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
OUTSIDE KEY ANTENNA
OUTSIDE KEY ANTENNA
DRIVER SIDE
DRIVER SIDE : Exploded ViewINFOID:0000000003795134
Refer to DLK-224, "OUTSIDE HANDLE : Exploded View".
DRIVER SIDE : Removal and InstallationINFOID:0000000003795135
REMOVAL
Remove the front outside handle LH. Refer to DLK-224, "OUTSIDE HANDLE : Removal and Installation".
INSTALLATION
Install in the reverse order of removal.
PASSENGER SIDE
PASSENGER SIDE : Exploded ViewINFOID:0000000003795136
Refer to DLK-224, "OUTSIDE HANDLE : Exploded View".
PASSENGER SIDE : Removal and InstallationINFOID:0000000003795137
REMOVAL
Remove the front outside handle RH. Refer to DLK-224, "OUTSIDE HANDLE : Removal and Installation".
INSTALLATION
Install in the reverse order of removal.
REAR BUMPER
REAR BUMPER : Exploded ViewINFOID:0000000003795138
REAR BUMPER : Removal and InstallationINFOID:0000000003795139
REMOVAL
1. Remove the rear bumper fascia. Refer to EXT-16, "Removal and Installation".
1. Outside key antenna (rear bumper)
JMKIA2436ZZ

OUTSIDE KEY ANTENNA
DLK-239
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Remove the outside key antenna (rear bumper) mounting clips
(A), and then remove outside key antenna (rear bumper) (1).
INSTALLATION
Install in the reverse order of removal.
JMKIA2444ZZ

DLK-240
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY WARNING BUZZER
INTELLIGENT KEY WARNING BUZZER
Exploded ViewINFOID:0000000003795140
Removal and InstallationINFOID:0000000003795141
REMOVAL
1. Remove the Intelligent Key warning buzzer mounting nut (A),
and then remove the Intelligent Key warning buzzer (1).
INSTALLATION
Install in the reverse order of removal.
1. Intelligent Key warning buzzer
JMKIA2435ZZ
JMKIA2445ZZ

KEY SLOT
DLK-241
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
KEY SLOT
Exploded ViewINFOID:0000000003795142
Removal and InstallationINFOID:0000000003795143
REMOVAL
1. Remove the instrument lower panel LH. Refer to IP-12, "Removal and Installation".
2. Disconnect key slot connector.
3. Remove the key slot mounting screws (A), and then remove key
slot (1) from instrument lower panel LH.
INSTALLATION
Install in the reverse order of removal.
1. Key slot 2. Instrument lower panel
JMKIA1820ZZ
JMKIA2351ZZ

DLK-242
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
TRUNK LID OPENER REQUEST SWITCH
TRUNK LID OPENER REQUEST SWITCH
Exploded ViewINFOID:0000000003846685
Refer to EXT-38, "Exploded View".
Removal and InstallationINFOID:0000000003846686
REMOVAL
1. Remove the trunk lid finisher outer. Refer to EXT-38, "Removal and Installation".
2. Remove the trunk lid opener request switch mounting pawl (A),
and then remove trunk lid opener request switch (1) from inner
bracket.
INSTALLATION
Install in the reverse order of removal.
:Pawl
JMKIA2446ZZ

TRUNK LID OPENER SWITCH
DLK-243
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK LID OPENER SWITCH
Exploded ViewINFOID:0000000003846687
Refer to EXT-38, "Exploded View".
Removal and InstallationINFOID:0000000003846688
REMOVAL
1. Remove the instrument lower panel. Refer to IP-12, "Removal and Installation".
2. Remove the trunk lid opener switch from instrument driver lower
panel, and then remove pawl. Press trunk lid opener switch front
side to disengage from instrument driver lower panel.
INSTALLATION
Install in the reverse order of removal.
:Pawl
JMKIA2443ZZ

DLK-244
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
REMOTE KEYLESS ENTRY RECEIVER
REMOTE KEYLESS ENTRY RECEIVER
Exploded ViewINFOID:0000000003795146
Removal and InstallationINFOID:0000000003795147
REMOVAL
1. Remove the instrument lower panel RH. Refer to IP-12, "Removal and Installation".
2. Remove the remote keyless entry receiver mounting screws (A),
and then remove remote keyless entry receiver (1).
INSTALLATION
Install in the reverse order of removal.
1. Remote keyless entry receiver
JMKIA2178ZZ
JMKIA2171ZZ
