NISSAN TEANA 2008 Service Manual

EC-360
< ECU DIAGNOSIS >[VQ25DE, VQ35DE]
ECM
IDL A/V LEARN  Engine: RunningIdle air volume learning has not been per-
formed yet.YET
Idle air volume learning has already been
performed successfully.CMPLT
ENG OIL TEMP  Engine: After warming up More than 70°C (158°F)
TRVL AFTER MIL  Ignition switch: ONVehicle has traveled after MI has illumi-
nated.0 - 65,535 km
(0 - 40,723 miles)
A/F S1 HTR (B1) Engine: After warming up, idle the engine
(More than 140 seconds after starting engine)4 - 100%
A/F S1 HTR (B2) Engine: After warming up, idle the engine
(More than 140 seconds after starting engine)4 - 100%
AC PRESS SEN Engine: Idle
 Both A/C switch and blower fan switch: ON (Compressor operates)1.0 - 4.0 V
VHCL SPEED SE Turn drive wheels and compare CONSULT-III value with the speedometer in-
dication.Almost the same speed as
the speedometer indication
SET VHCL SPD  Engine: Running ASCD: OperatingThe preset vehicle speed is
displayed
MAIN SW  Ignition switch: ONMAIN switch: Pressed ON
MAIN switch: Released OFF
CANCEL SW  Ignition switch: ONCANCEL switch: Pressed ON
CANCEL switch: Released OFF
RESUME/ACC SW  Ignition switch: ONRESUME/ACCELERATE switch:
PressedON
RESUME/ACCELERATE switch: Re-
leasedOFF
SET SW  Ignition switch: ONSET/COAST switch: Pressed ON
SET/COAST switch: Released OFF
BRAKE SW1
(ASCD brake switch) Ignition switch: ONBrake pedal: Fully released ON
Brake pedal: Slightly depressed OFF
BRAKE SW2
(Stop lamp switch) Ignition switch: ONBrake pedal: Fully released OFF
Brake pedal: Slightly depressed ON
VHCL SPD CUT  Ignition switch: ON NON
LO SPEED CUT  Ignition switch: ON NON
AT OD MONITOR  Ignition switch: ON OFF
AT OD CANCEL  Ignition switch: ON OFF
CRUISE LAMP  Ignition switch: ONMAIN switch: Pressed at the 1st time →
at the 2nd timeON → OFF
SET LAMP MAIN switch: ON
 When vehicle speed is between
40 km/h (25 MPH) and 144 km/h
(89 MPH)ASCD: Operating ON
ASCD: Not operating OFF
ALT DUTY  Engine: Idle 0 - 80%
A/F ADJ-B1  Engine: Running−0.330 - 0.330
A/F ADJ-B2  Engine: Running−0.330 - 0.330
BAT CUR SEN Engine speed: Idle
 Battery: Fully charged*
2
 Selector lever: P or N
 Air conditioner switch: OFF
No loadApprox. 2,600 - 3,500 mV Monitor Item Condition Values/Status

ECM
EC-361
< ECU DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O*1: Accelerator pedal position sensor 2 signal and throttle position sensor 2 signal are converted by ECM internally. Thus, they differ
from ECM terminals voltage signal.
*2: Before measuring the terminal voltage, confirm that the battery is fully charged. Refer to PG-3, "
How to Handle Battery".
TERMINAL LAYOUT
PHYSICAL VALUES
NOTE:
 ECM is located in the engine room left side near battery. For this inspection, remove passenger side instru-
ment lower panel.
 Specification data are reference values.
 Pulse signal is measured by CONSULT-III.
ALT DUTY SIG Power generation voltage variable control: Operating ON
 Power generation voltage variable control: Not operating OFF Monitor Item Condition Values/Status
PBIA9221J
Terminal No. Description
ConditionVa l u e
(Approx.)
+-– Signal nameInput/
Output
1
(P/B)
11 2
(B)Fuel injector No. 6
Output[Engine is running]
 Warm-up condition
 Idle speed
NOTE:
The pulse cycle changes de-
pending on rpm at idleBATTERY VOLTAGE
(11 - 14 V)
3
(L/W)Fuel injector No. 5
29
(LG/R)Fuel injector No. 4
30
(R/Y)Fuel injector No. 3
[Engine is running]
 Warm-up condition
 Engine speed: 2,000 rpmBATTERY VOLTAGE
(11 - 14 V)
31
(R/W)Fuel injector No. 2
32
(R/B)Fuel injector No. 1
2
(G/W)11 2
(B)Throttle control motor relay
power supplyInput [Ignition switch: ON]BATTERY VOLTAGE
(11 - 14 V)
4
(BR/Y)11 2
(B)A/F sensor 1 heater
(Bank 1)Output[Engine is running]
 Warm-up condition
 Idle speed
(More than 140 seconds after
starting engine)2.9 - 8.8 V
JMBIA0047GB
JMBIA0048GB
JMBIA0902GB

EC-362
< ECU DIAGNOSIS >[VQ25DE, VQ35DE]
ECM
5
(L)11 2
(B)Throttle control motor (Open) Output[Ignition switch: ON]
 Engine stopped
 Selector lever: D
 Accelerator pedal: Fully de-
pressed0 - 14 V
[Ignition switch: ON]
 Engine stopped
 Selector lever: D
 Accelerator pedal: Fully re-
leased0 - 14 V
6
(P)11 2
(B)Throttle control motor (Close) Output[Ignition switch: ON]
 Engine stopped
 Selector lever: D
 Accelerator pedal: Fully re-
leased0 - 14 V
8
(SB)11 2
(B)A/F sensor 1 heater (Bank 2) Output[Engine is running]
 Warm-up condition
 Idle speed
(More than 140 seconds after
starting engine)2.9 - 8.8 V
9
(L/B)
11 2
(B)Ignition signal No. 3
Output[Engine is running]
 Warm-up condition
 Idle speed
NOTE:
The pulse cycle changes de-
pending on rpm at idle0 - 0.2 V
10
(G/R)Ignition signal No. 2
11
(Y/R)Ignition signal No. 1
18
(GR/R)Ignition signal No. 6
[Engine is running]
 Warm-up condition
 Engine speed: 2,000 rpm0.1 - 0.4 V
19
(P)Ignition signal No. 5
21
(W)Ignition signal No. 4
12
(B)— ECM ground — — — Terminal No. Description
ConditionVa l u e
(Approx.)
+ -– Signal nameInput/
OutputJMBIA0031GB
JMBIA0032GB
JMBIA1125GB
JMBIA0030GB
JMBIA0035GB
JMBIA0036GB

ECM
EC-363
< ECU DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
13
(P/B)11 2
(B)Heated oxygen sensor 2 heat-
er (Bank 1)Output[Engine is running]
 Engine speed: Below 3,600
rpm after the following condi-
tions are met
- Engine: after warming up
- Keeping the engine speed be-
tween 3,500 and 4,000 rpm
for 1 minute and at idle for 1
minute under no load10 V
[Ignition switch: ON]
 Engine stopped
[Engine is running]
 Engine speed: Above 3,600
rpmBATTERY VOLTAGE
(11 - 14 V)
14
(GR)11 2
(B)Fuel pump relay Output[Ignition switch: ON]
 For 1 second after turning ig-
nition switch ON
[Engine is running]0 - 1.5 V
[Ignition switch: ON]
 More than 1 second after turn-
ing ignition switch ONBATTERY VOLTAGE
(11 - 14 V)
15
(O)11 2
(B)Throttle control motor relay Output[Ignition switch: ON → OFF]0 - 1.0 V → BATTERY VOLTAGE
(11 - 14 V) → 0 V
[Ignition switch: ON] 0 - 1.0 V
16
(B/Y)— ECM ground — — —
17
(R)11 2
(B)Heated oxygen sensor 2 heat-
er (Bank 2)Output[Engine is running]
 Engine speed: Below 3,600
rpm after the following condi-
tions are met
- Engine: after warming up
- Keeping the engine speed be-
tween 3,500 and 4,000 rpm
for 1 minute and at idle for 1
minute under no load10 V
[Ignition switch: ON]
 Engine stopped
[Engine is running]
 Engine speed: Above 3,600
rpmBATTERY VOLTAGE
(11 - 14 V)
24
(W/B)11 2
(B)ECM relay
(Self shut-off)Output[Engine is running]
[Ignition switch: OFF]
 A few seconds after turning
ignition switch OFF0 - 1.5 V
[Ignition switch: OFF]
 More than a few seconds after
turning ignition switch OFFBATTERY VOLTAGE
(11 - 14 V) Terminal No. Description
ConditionVa l u e
(Approx.)
+-– Signal nameInput/
Output
JMBIA0902GB
JMBIA0902GB

EC-364
< ECU DIAGNOSIS >[VQ25DE, VQ35DE]
ECM
25
(P/L)11 2
(B)EVAP canister purge volume
control solenoid valveOutput[Engine is running]
 Idle speed
 Accelerator pedal: Not de-
pressed even slightly, after
engine startingBATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
 Engine speed: About 2,000
rpm (More than 100 seconds
after starting engine)BATTERY VOLTAGE
(11 - 14 V)
26
(GR/B)11 2
(B)VIAS control solenoid valve 2 Output[Engine is running]
 Warm-up condition
 Idle speedBATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
 Warm-up condition
 When revving engine up to
5,000 rpm quicklyBATTERY VOLTAGE (11 - 14 V)
↓
0 - 1.0 V
↓
BATTERY VOLTAGE (11 - 14 V)
27
(V)11 2
(B)VIAS control solenoid valve 1 Output[Engine is running]
 Warm-up condition
 Idle speedBATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
 Warm-up condition
 When revving engine up to
5,000 rpm quicklyBATTERY VOLTAGE (11 - 14 V)
↓
0 - 1.0 V
↓
BATTERY VOLTAGE (11 - 14 V)
28
(BR/W)11 2
(B)Electronic controlled engine
mount control solenoid valveOutput[Engine is running]
 Idle speed0 - 1.0 V
[Engine is running]
 Engine speed: More than 950
rpmBATTERY VOLTAGE
(11 - 14 V)
33
(W)35
(B)Heated oxygen sensor 2
(Bank 1)Input[Engine is running]
 Revving engine from idle to
3,000 rpm quickly after the fol-
lowing conditions are met
- Engine: after warming up
- Keeping the engine speed be-
tween 3,500 and 4,000 rpm
for 1 minute and at idle for 1
minute under no load0 - 1.0 V
34
(W/L)35
(B)Heated oxygen sensor 2
(Bank 2)Input[Engine is running]
 Revving engine from idle to
3,000 rpm quickly after the fol-
lowing conditions are met
- Engine: after warming up
- Keeping the engine speed be-
tween 3,500 and 4,000 rpm
for 1 minute and at idle for 1
minute under no load0 - 1.0 V Terminal No. Description
ConditionVa l u e
(Approx.)
+ -– Signal nameInput/
Output
JMBIA0039GB
JMBIA0040GB

ECM
EC-365
< ECU DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O35
(B)—Sensor ground
(Heated oxygen sensor 2)—— —
36
(B)—Sensor ground
(Throttle position sensor)—— —
37
(W)36
(B)Throttle position sensor 1 Input[Ignition switch: ON]
 Engine stopped
 Selector lever: D
 Accelerator pedal: Fully re-
leasedMore than 0.36 V
[Ignition switch: ON]
 Engine stopped
 Selector lever: D
 Accelerator pedal: Fully de-
pressedLess than 4.75 V
38
(R)36
(B)Throttle position sensor 2 Input[Ignition switch: ON]
 Engine stopped
 Selector lever: D
 Accelerator pedal: Fully re-
leasedLess than 4.75 V
[Ignition switch: ON]
 Engine stopped
 Selector lever: D
 Accelerator pedal: Fully de-
pressedMore than 0.36 V
39
(R)40
(G)Refrigerant pressure sensor Input[Engine is running]
 Warm-up condition
 Both A/C switch and blower
fan motor switch: ON (Com-
pressor operates)1.0 - 4.0 V
40
(G)—Sensor ground
(Refrigerant pressure sensor)—— —
41
(O/B)48
(B/P)Power steering pressure sen-
sorInput[Engine is running]
 Steering wheel: Being turned0.5 - 4.5 V
[Engine is running]
 Steering wheel: Not being
turned0.4 - 0.8 V
42
(BR)44
(G/B)Battery current sensor Input[Engine is running]
 Battery: Fully charged*
2
 Idle speed2.6 - 3.5 V
44
(G/B)—Sensor ground
(Battery current sensor)—— —
45
(P)49
(L)A/F sensor 1 (Bank 1) Input [Ignition switch: ON] 2.2 V
46
(Y)52
(B/R)Engine coolant temperature
sensorInput [Engine is running]0 - 4.8 V
Output voltage varies with engine
coolant temperature.
47
(G)36
(B)Sensor power supply
(Throttle position sensor)— [Ignition switch: ON] 5 V
48
(B/P)—Sensor ground
(Power steering pressure
sensor)—— —
49
(L)11 2
(B)A/F sensor 1 (Bank 1) Input[Engine is running]
 Warm-up condition
 Engine speed: 2,000 rpm1.8 V
Output voltage varies with air fuel
ratio. Terminal No. Description
ConditionVa l u e
(Approx.)
+-– Signal nameInput/
Output

EC-366
< ECU DIAGNOSIS >[VQ25DE, VQ35DE]
ECM
50
(L/Y)56
(G/B)Intake air temperature sensor Input [Engine is running]0 - 4.8 V
Output voltage varies with intake
air temperature.
51
(R/Y)44
(G/B)Sensor power supply
(Battery current sensor)— [Ignition switch: ON] 5 V
52
(B/R)—Sensor ground
(Engine coolant temperature
sensor/Engine oil tempera-
ture sensor)—— —
53
(V)57
(LG)A/F sensor 1 (Bank 2) Input [Ignition switch: ON] 2.2 V
54
(G)52
(B/R)Engine oil temperature sensor Input [Engine is running]0 - 4.8 V
Output voltage varies with engine
oil temperature.
55
(SB)48
(Y)Sensor power supply
(Power steering pressure
sensor)— [Ignition switch: ON] 5 V
56
(G/B)—Sensor ground
(Mass air flow sensor/Intake
air temperature sensor)—— —
57
(LG)11 2
(B)A/F sensor 1 (Bank 2) Input[Engine is running]
 Warm-up condition
 Engine speed: 2,000 rpm1.8 V
Output voltage varies with air fuel
ratio.
58
(O)56
(G/B)Mass air flow sensor Input[Engine is running]
 Warm-up condition
 Idle speed0.9 - 1.2 V
[Engine is running]
 Warm-up condition
 Engine speed: 2,500 rpm1.6 - 1.9 V
59
(G/W)64
(B/R)Sensor power supply
[Camshaft position sensor
(PHASE) (Bank 1)]— [Ignition switch: ON] 5 V
60
(Y/B)—Sensor ground
[Crankshaft position sensor
(POS)]—— —
61
(B)67
(GR)Knock sensor (Bank 1) Input[Engine is running]
 Idle speed2.5 V*
1
62
(W)67
(GR)Knock sensor (Bank 2) Input[Engine is running]
 Idle speed2.5 V*1
63
(R/W)68
(Y/G)Sensor power supply
[Camshaft position sensor
(PHASE) (Bank 2)]— [Ignition switch: ON] 5 V
64
(B/R)—Sensor ground
[Camshaft position sensor
(PHASE) (Bank 1)]—— — Terminal No. Description
ConditionVa l u e
(Approx.)
+ -– Signal nameInput/
Output

ECM
EC-367
< ECU DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
65
(W/B)60
(Y/B)Crankshaft position sensor
(POS)Input[Engine is running]
 Warm-up condition
 Idle speed
NOTE:
The pulse cycle changes de-
pending on rpm at idle4.0 - 5.0 V
[Engine is running]
 Engine speed: 2,000 rpm4.0 - 5.0 V
67
(GR)—Sensor ground
(Knock sensor)—— —
68
(Y/G)—Sensor ground
[Camshaft position sensor
(PHASE) (Bank 2)]—— —
69
(BR/W)68
(Y/G)Camshaft position sensor
(PHASE) (Bank 2)Input[Engine is running]
 Warm-up condition
 Idle speed
NOTE:
The pulse cycle changes de-
pending on rpm at idle3.0 - 5.0 V
[Engine is running]
 Engine speed is 2,000 rpm3.0 - 5.0 V
70
(W/R)64
(B/R)Camshaft position sensor
(PHASE) (Bank 1)Input[Engine is running]
 Warm-up condition
 Idle speed
NOTE:
The pulse cycle changes de-
pending on rpm at idle3.0 - 5.0 V
[Engine is running]
 Engine speed is 2,000 rpm3.0 - 5.0 V Terminal No. Description
ConditionVa l u e
(Approx.)
+-– Signal nameInput/
OutputJMBIA0041GB
JMBIA0042GB
JMBIA0045GB
JMBIA0046GB
JMBIA0045GB
JMBIA0046GB

EC-368
< ECU DIAGNOSIS >[VQ25DE, VQ35DE]
ECM
72
(BR/W)40
(G)Sensor power supply
(Refrigerant pressure sensor)— [Ignition switch: ON] 5 V
75
(Y)11 2
(B)Intake valve timing control so-
lenoid valve (Bank 2)Output[Engine is running]
 Warm-up condition
 Idle speedBATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
 Warm-up condition
 Engine speed: 2,000rpm7 - 12 V
76
(R/G)60
(Y/B)Sensor power supply
[Crankshaft position sensor
(POS)]— [Ignition switch: ON] 5 V
77
(W/L)11 2
(B)Power supply for ECM (Back-
up)Input [Ignition switch: OFF]BATTERY VOLTAGE
(11 - 14 V)
78
(R/L)11 2
(B)Intake valve timing control so-
lenoid valve (Bank 1)Output[Engine is running]
 Warm-up condition
 Idle speedBATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
 Warm-up condition
 Engine speed: 2,000rpm7 - 12 V
81
(W)84
(B)Accelerator pedal position
sensor 1Input[Ignition switch: ON]
 Engine stopped
 Accelerator pedal: Fully re-
leased0.5 - 1.0 V
[Ignition switch: ON]
 Engine stopped
 Accelerator pedal: Fully de-
pressed4.2 - 4.8 V
82
(O)100
(G)Accelerator pedal position
sensor 2Input[Ignition switch: ON]
 Engine stopped
 Accelerator pedal: Fully re-
leased0.25 - 0.50 V
[Ignition switch: ON]
 Engine stopped
 Accelerator pedal: Fully de-
pressed2.0 - 2.5 V
83
(BR)84
(B)Sensor power supply
(Accelerator pedal position
sensor 1)— [Ignition switch: ON] 5 V
84
(B)—Sensor ground
(Accelerator pedal position
sensor 1)—— — Terminal No. Description
ConditionVa l u e
(Approx.)
+ -– Signal nameInput/
Output
JMBIA0038GB
JMBIA0038GB

ECM
EC-369
< ECU DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
85
(Y)92
(BR)ASCD steering switch Input[Ignition switch: ON]
 ASCD steering switch: OFF4 V
[Ignition switch: ON]
 MAIN switch: Pressed0 V
[Ignition switch: ON]
 CANCEL switch: Pressed1 V
[Ignition switch: ON]
 RESUME/ACCELERATE
switch: Pressed3 V
[Ignition switch: ON]
 SET/COAST switch: Pressed2 V
87
(GR)100
(G)Sensor power supply
(Accelerator pedal position
sensor 2)— [Ignition switch: ON] 5 V
88
(O)— Data link connectorInput/
Output——
92
(BR)—Sensor ground
(ASCD steering switch)—— —
93
(BR)11 2
(B)Ignition switch Input[Ignition switch: OFF] 0 V
[Ignition switch: ON]BATTERY VOLTAGE
(11 - 14 V)
94
(GR)11 2
(B)Engine speed output signal Output[Engine is running]
 Warm-up condition
 Idle speed
NOTE:
The pulse cycle changes de-
pending on rpm at idle1 V
[Engine is running]
 Engine speed: 2,000 rpm1 V
97
(P)— CAN communication lineInput/
Output——
98
(L)— CAN communication lineInput/
Output——
100
(G)—Sensor ground
(Accelerator pedal position
sensor 2)—— —
102
(R)11 2
(B)PNP signal Input[Ignition switch: ON]
 Selector lever: P or NBATTERY VOLTAGE
(11 - 14 V)
[Ignition switch: ON]
 Selector lever: Except above0 V
105
(V)11 2
(B)Power supply for ECM Input [Ignition switch: ON]BATTERY VOLTAGE
(11 - 14 V)
Terminal No. Description
ConditionVa l u e
(Approx.)
+-– Signal nameInput/
Output
JMBIA0076GB
JMBIA0077GB
