AUTO LIGHT SYSTEM
AUTO LIGHT SYSTEM
Wiring Diagram - AUTO LIGHT SYSTEM -INFOID:0000000003894337
JCLWM1445GB

AUTO LIGHT SYSTEM
EXL-253
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
JCLWM1446GB

EXL-254
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
AUTO LIGHT SYSTEM
JCLWM1447GB

AUTO LIGHT SYSTEM
EXL-255
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
JCLWM1448GB

EXL-256
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
HEADLAMP AIMING CONTROL SYSTEM (MANUAL)
HEADLAMP AIMING CONTROL SYSTEM (MANUAL)
DescriptionINFOID:0000000003773585
The headlamp levelizer adjusts the headlamp light axis upward and downward with the aiming motor inte-
grated in the front combination lamp.
Wiring Diagram - HEADLAMP AIMING CONTROL SYSTEM (MANUAL) -INFOID:0000000003773586
JCLWM1449GB

HEADLAMP AIMING CONTROL SYSTEM (MANUAL)
EXL-257
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Component InspectionINFOID:0000000003773587
1.CHECK HEADLAMP AIMING SWITCH
1. Remove the headlamp aiming switch.
JCLWM1450GB

EXL-258
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
HEADLAMP AIMING CONTROL SYSTEM (MANUAL)
2. Check the resistance among each headlamp aiming switch ter-
minal.
Is the measurement value normal?
YES >> Headlamp aiming switch is normal.
NO >> Replace the headlamp aiming switch.
Headlamp aiming switch Condition
Resistance
(Approx.)
Terminal Switch position
120 A: 2000 Ω
1 B: 590 Ω
2 C: 324 Ω
3 D: 169 Ω
3 — E: 390 Ω
JSLIA0084ZZ

FRONT FOG LAMP SYSTEM
EXL-259
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
FRONT FOG LAMP SYSTEM
Wiring Diagram - FRONT FOG LAMP -INFOID:0000000003894338
JCLWM1455GB

EXL-260
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
FRONT FOG LAMP SYSTEM
JCLWM1456GB

FRONT FOG LAMP SYSTEM
EXL-261
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
JCLWM1457GB
