NISSAN TEANA 2008 Service Manual

EXL-232
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
FRONT FOG LAMP CIRCUIT
4. With operating the test items, check the voltage between the IPDM E/R harness connector and the
ground.
Is the measurement value normal?
YES >> GO TO 5.
NO >> Replace IPDM E/R.
5.CHECK FRONT FOG LAMP OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between the IPDM E/R harness connector and the front fog lamp harness connector.
Does continuity exist?
YES >> GO TO 6.
NO >> Repair the harnesses or connectors.
6.CHECK FRONT FOG LAMP GROUND CIRCUIT OPEN CIRCUIT
Check continuity between the front fog lamp harness connector and the ground.
Does continuity exist?
YES >> Replace the front fog lamp.
NO >> Repair the harnesses or connectors.
Te r m i n a l s
Te s t i t e m
Voltag e
(Approx.) (+) (−)
IPDM E/R
GroundEXTERNAL
LAMPS
Connector Terminal
RH
E34586FogBattery
voltage
Off 0 V
LH 87FogBattery
voltage
Off 0 V
IPDM E/R Front fog lamp
Continuity
Connector Terminal Connector Terminal
RH
E34586 E332 1
Existed
LH 87 E331 1
Front fog lamp
GroundContinuity
Connector Terminal
RH E332 2
Existed
LH E331 2

PARKING LAMP CIRCUIT
EXL-233
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
PARKING LAMP CIRCUIT
Component Function CheckINFOID:0000000003894321
1.CHECK PARKING LAMP OPERATION
IPDM E/R AUTO ACTIVE TEST
1. Activate IPDM E/R auto active test. Refer to PCS-11, "
Diagnosis Description".
2. Check that the parking lamp is turned ON.
CONSULT-III ACTIVE TEST
1. Select “EXTERNAL LAMPS” of IPDM E/R active test item.
2. With operating the test items, check that the parking lamp is turned ON.
Is the parking lamp turned ON?
YES >> Parking lamp circuit is normal.
NO >> Refer to EXL-233, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003894322
1.CHECK PARKING LAMP FUSE
1. Turn the ignition switch OFF.
2. Check that the following fuses are not fusing.
Is the fuse fusing?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK PARKING LAMP SHORT CIRCUIT
1. Disconnect IPDM E/R connector and the front combination lamp connector.
2. Check continuity between the IPDM E/R harness connector and the ground.
Does continuity exist?
YES >> Repair the harnesses or connectors. And then replace the fuse.
NO >> Replace the fuse. (Replace IPDM E/R if fusing is found again.)
3.CHECK PARKING LAMP BULB
Check the applicable lamp bulb.
Is the bulb normal?
YES >> GO TO 4.
NO >> Replace the bulb.
4.CHECK PARKING LAMP OUTPUT VOLTAGE
CONSULT-III ACTIVE TEST
1. Disconnect the front combination lamp connector.
2. Turn the ignition switch ON.
3. Select “EXTERNAL LAMPS” of IPDM E/R active test item. TAIL : Parking lamp ON
Off : Parking lamp OFF
Unit Location Fuse No. Capacity
Parking lamp IPDM E/R #52 10 A
IPDM E/R
GroundContinuity
Connector Terminal
RH
E34691
Not existed
LH 92

EXL-234
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
PARKING LAMP CIRCUIT
4. With operating the test items, check the voltage between the IPDM E/R harness connector and the
ground.
Is the measurement value normal?
YES >> GO TO 5.
NO >> Replace IPDM E/R.
5.CHECK PARKING LAMP OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between the IPDM E/R harness connector and the front combination lamp harness con-
nector.
Does continuity exist?
YES >> GO TO 6.
NO >> Repair the harnesses or connectors.
6.CHECK PARKING LAMP GROUND OPEN CIRCUIT
Check continuity between the front combination lamp harness connector and the ground.
Does continuity exist?
YES >> Replace the front combination lamp.
NO >> Repair the harnesses or connectors.
Te r m i n a l s
Te s t i t e m
Voltag e
(Approx.) (+) (−)
IPDM E/R
GroundEXTERNAL
LAMPS
Connector Terminal
RH
E34691TA I LBattery
voltage
Off 0 V
LH 92TA I LBattery
voltage
Off 0 V
IPDM E/R Front combination lamp
Continuity
Connector Terminal Connector Terminal
RH
E34691 E319 1
Existed
LH 92 E318 1
Front combination lamp
GroundContinuity
Connector Terminal
RH E319 4
Existed
LH E318 4

TURN SIGNAL LAMP CIRCUIT
EXL-235
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
TURN SIGNAL LAMP CIRCUIT
DescriptionINFOID:0000000003894323
BCM performs the high flasher operation (fail-safe) if any bulb or harness of the turn signal lamp circuit is
open.
NOTE:
The turn signal lamp blinks at normal speed when using the hazard warning lamp.
Component Function CheckINFOID:0000000003894324
1.CHECK TURN SIGNAL LAMP
CONSULT-III ACTIVE TEST
1. Select “FLASHER” of BCM (FLASHER) active test item.
2. With operating the test items, check that the turn signal lamp is turned ON.
Is the turn signal lamp turned ON?
YES >> Turn signal lamp circuit is normal.
NO >> Refer to EXL-235, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003894325
1.CHECK TURN SIGNAL LAMP BULB
Check the applicable lamp bulb.
Is the bulb normal?
YES >> GO TO 2.
NO >> Replace the bulb.
2.CHECK TURN SIGNAL LAMP OUTPUT VOLTAGE
1. Turn the ignition switch OFF.
2. Disconnect the front combination lamp connector, the door mirror connector or the rear combination lamp
connector.
3. Turn the ignition switch ON.
4. With operating the turn signal switch, check the voltage between the BCM harness connector and the
ground.LH : Turn signal lamps (LH) ON
RH : Turn signal lamps (RH) ON
Off : Turn signal lamps OFF

EXL-236
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
TURN SIGNAL LAMP CIRCUIT
Is the measurement value normal?
YES >> GO TO 3.
NO >> Replace BCM. Refer to BCS-78, "
Exploded View".
3.CHECK TURN SIGNAL LAMP OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between the BCM harness connector and the front combination lamp, the door mirror or
the rear combination lamp harness connector.
Front turn signal lamp
Side turn signal lamp
Rear turn signal lamp
Does continuity exist?
YES >> GO TO 4.
NO >> Repair the harnesses or connectors.
4.CHECK TURN SIGNAL LAMP SHORT CIRCUIT
Te r m i n a l s
Condition
Voltage (Approx.) (+) (−)
BCM
GroundTurn signal
switch
Connector Terminal
Front/side RH
M11917
LH or RH
Front/side LH 18
OFF 0 V
Rear RH
M12020
LH or RH
Rear LH 25
OFF 0 V
PKID0926E
PKID0926E
BCM Front combination lamp
Continuity
Connector Terminal Connector Terminal
RH
M11917 E319 2
Existed
LH 18 E318 2
BCM Door mirror
Continuity
Connector Terminal Connector Terminal
RH
M11917 D43 2
Existed
LH 18 D3 2
BCM Rear combination lamp
Continuity
Connector Terminal Connector Terminal
RH
M12020 B59 1
Existed
LH 25 B80 1

TURN SIGNAL LAMP CIRCUIT
EXL-237
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Check continuity between the BCM harness connector and the ground.
Does continuity exist?
YES >> Repair the harnesses or connectors.
NO >> GO TO 5.
5.CHECK TURN SIGNAL LAMP GROUND OPEN CIRCUIT
Check continuity between the front combination lamp, the door mirror or the rear combination lamp and the
ground.
Front turn signal lamp
Side turn signal lamp
Rear turn signal lamp
Does continuity exist?
YES >> Replace the front combination lamp, door mirror assembly or the rear combination lamp.
NO >> Repair the harnesses or connectors.
BCM
GroundContinuity
Connector Terminal
Front/side RH
M11917
Not existed Front/side LH 18
Rear RH
M12020
Rear LH 25
Front combination lamp
GroundContinuity
Connector Terminal
RH E319 4
Existed
LH E318 4
Door mirror
GroundContinuity
Connector Terminal
RH D43 10
Existed
LH D3 10
Rear combination lamp
GroundContinuity
Connector Terminal
RH B59 5
Existed
LH B80 5

EXL-238
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
OPTICAL SENSOR
OPTICAL SENSOR
DescriptionINFOID:0000000003894326
Optical sensor converts the outside brightness (lux) to voltage and transmits the optical sensor signal to BCM.
Component Function CheckINFOID:0000000003894327
1.CHECK OPTICAL SENSOR SIGNAL BY CONSULT-III
CONSULT-III DATA MONITOR
1. Turn the ignition switch ON.
2. Select "OPTICAL SENSOR" of BCM (HEADLAMP) data monitor item.
3. Turn the lighting switch AUTO.
4. With the optical sensor illuminating, check the monitor status.
*: Illuminates the optical sensor. The value may be less than the standard value if brightness is weak.
Is the item status normal?
YES >> Optical sensor is normal.
NO >> Refer to EXL-238, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003894328
1.CHECK OPTICAL SENSOR POWER SUPPLY INPUT
1. Turn the ignition switch ON.
2. Turn the lighting switch AUTO.
3. Check the voltage between the optical sensor harness connector and the ground.
Is the measurement value normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK OPTICAL SENSOR GROUND INPUT
Check the voltage between the optical sensor harness connector and the ground.
Is the measurement value normal?
YES >> GO TO 3.
NO >> GO TO 6.
3.CHECK OPTICAL SENSOR SIGNAL OUTPUT
Monitor item Condition Voltage (Approx.)
OPTICAL SENSOR Optical sensorWhen illuminating 3.1 V or more *
When shutting off light 0.6 V or less
Te r m i n a l s
Voltag e
(Approx.) (+) (−)
Optical sensor
Ground Connector Terminal
M17 1 5 V
Te r m i n a l s
Voltag e
(Approx.) (+) (−)
Optical sensor
Ground Connector Terminal
M17 3 0 V

OPTICAL SENSOR
EXL-239
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
With illuminating the optical sensor, check the voltage between the optical sensor harness connector and the
ground.
*: Illuminate the optical sensor. The value may be less than the standard if brightness is weak.
Is the measurement value normal?
YES >> GO TO 7.
NO >> Replace the optical sensor.
4.CHECK OPTICAL SENSOR OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect the optical sensor connector and BCM connector.
3. Check continuity between the optical sensor harness connector and the BCM harness connector.
Does continuity exist?
YES >> GO TO 5.
NO >> Repair the harnesses or connectors.
5.CHECK OPTICAL SENSOR SHORT CIRCUIT
Check the continuity between the optical sensor harness connector and the ground.
Does continuity exist?
YES >> Repair the harnesses or connectors.
NO >> Replace BCM.
6.CHECK OPTICAL SENSOR GROUND OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect the optical sensor connector and BCM connector.
3. Check continuity between the optical sensor harness connector and the BCM harness connector.
Does continuity exist?
YES >> Replace BCM.
NO >> Repair the harnesses or connectors.
7.CHECK OPTICAL SENSOR SIGNAL OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect the optical sensor connector and BCM connector.
Te r m i n a l s
Condition
Vo l ta g e
(Approx.) (+) (−)
Optical sensor
GroundOptical sen-
sor
Connector Terminal
M17 2When illumi-
nating3.1 V or
more *
When shut-
ting off light0.6 V or less
Optical sensor BCM
Continuity
Connector Terminal Connector Terminal
M17 1 M123 138 Existed
Optical sensor
GroundContinuity
Connector Terminal
M17 1 Not existed
Optical sensor BCM
Continuity
Connector Terminal Connector Terminal
M17 3 M123 137 Existed

EXL-240
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
OPTICAL SENSOR
3. Check continuity between the optical sensor harness connector and the BCM harness connector.
Does continuity exist?
YES >> GO TO 8.
NO >> Repair the harnesses or connectors.
8.CHECK OPTICAL SENSOR SHORT CIRCUIT
Check the continuity between the optical sensor harness connector and the ground.
Does continuity exist?
YES >> Repair the harnesses or connectors.
NO >> Replace BCM.
Optical sensor BCM
Continuity
Connector Terminal Connector Terminal
M17 2 M123 113 Existed
Optical sensor
GroundContinuity
Connector Terminal
M17 2 Not existed

HAZARD SWITCH
EXL-241
< COMPONENT DIAGNOSIS >[HALOGEN TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
HAZARD SWITCH
Component Function CheckINFOID:0000000003894329
1.CHECK HAZARD SWITCH SIGNAL BY CONSULT-III
CONSULT-III DATA MONITOR
1. Turn the ignition switch ON.
2. Select “HAZARD SW” of BCM (FLASHER) data monitor item.
3. With operating the hazard switch, check the monitor status.
Is the item status normal?
YES >> Hazard switch circuit is normal.
NO >> Refer to EXL-241, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003894330
1.CHECK HAZARD SWITCH SIGNAL INPUT
With operating the hazard switch, check the voltage between the BCM harness connector and the ground.
Is the measurement value normal?
YES >> Replace BCM. Refer to BCS-78, "Exploded View".
NO >> GO TO 2.
2.CHECK HAZARD SWITCH SIGNAL OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect the hazard switch connector and BCM connector.
3. Check continuity between the hazard switch harness connector and the BCM harness connector.
Does continuity exist?
YES >> GO TO 3.
NO >> Repair the harnesses or connectors.
3.CHECK HAZARD SWITCH SIGNAL SHORT CIRCUIT
Check continuity between the hazard switch harness connector and the ground.
Monitor item Condition Monitor status
HAZARD SW Hazard switchON On
OFF Off
Te r m i n a l s
Condition
Voltage (Approx.) (+) (−)
BCM
GroundHazard switch
Connector Terminal
M122 110ON 0 V
OFF
JPMIA0154GB
Hazard switch BCM
Continuity
Connector Terminal Connector Terminal
M45 2 M122 110 Existed
