NISSAN TEANA 2008 Service Manual

GW-8
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003825365
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIRBAG” and
“SEAT BELT” of this Service Manual.
WARNING:
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIRBAG”.
 Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.
Precaution for Procedure without Cowl Top CoverINFOID:0000000003825366
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
Handling for Adhesive and PrimerINFOID:0000000003825367
 Never use an adhesive which is past its usable date. Shelf life of this product is limited to six months after the
date of manufacture. Carefully adhere to the expiration or manufacture date printed on the box.
 Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
 Open the seal of the primer and adhesive just before application. Discard the remainder.
 Before application, be sure to shake the primer container to stir the contents. If any floating material is found,
do not use it.
 If any primer or adhesive contacts the skin, wipe it off with gasoline or equivalent and wash the skin with
soap.
 When using primer and adhesive, always observe the precautions in the instruction manual.
PIIB3706J

PREPARATION
GW-9
< PREPARATION >
C
D
E
F
G
H
I
J
L
MA
B
GW
N
O
P
PREPARATION
PREPARATION
Commercial Service ToolsINFOID:0000000003825369
Tool name Description
Engine ear Locating the noise
Suction lifter Holding the door glass
Remover tools Removes clips, pawls and metal clips
SIIA0995E
PIIB1805J
PIIB7923J

GW-10
< ON-VEHICLE REPAIR >
WINDSHIELD GLASS
ON-VEHICLE REPAIR
WINDSHIELD GLASS
Exploded ViewINFOID:0000000003825397
JMKIA2306GB

WINDSHIELD GLASS
GW-11
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
GW
N
O
P
Removal and InstallationINFOID:0000000003825398
REMOVAL
1. Remove front pillar garnish (LH/RH). Refer to INT-39, "Removal and Installation".
2. Remove partially headlining (front edge). Refer to INT-50, "
NORMAL ROOF : Removal and Installation"
for normal roof or INT-54, "SUNROOF : Removal and Installation" for sunroof.
3. Remove front wiper arms (LH/RH). Refer to WW-105, "
Removal and Installation".
4. Remove front fender cover (LH/RH). Refer to DLK-199, "
Exploded View".
5. Remove cowl top cover. Refer to EXT-20, "
Removal and Installation".
6. Remove roof side molding (LH/RH). Refer to EXT-29, "
Removal and Installation".
7. Remove glass using piano wire or power cutting tool (A) and an inflatable pump bag (B) after removing
moldings.
NOTE:
Mark the body and the glass with matching marks if the windshield glass is reused.
WARNING:
Always wear safety glasses and heavy gloves to prevent injury.
CAUTION:
 Never use a cutting knife or power cutting tool when the windshield glass is reused.
 Be careful not to scratch the glass when removing.
 Never set or stand the glass on its edge. Small chips may develop into cracks.
INSTALLATION
 The dam sealant rubber should be installed in position.
 Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions provided
with it.
 Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by
passenger compartment air pressure when all door windows are closed.
 The molding must be installed securely so that it is in position and leaves no clearance.
 Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (approximately 24 hours). Curing time varies with temperature and humidity.
WARNING:
 Keep heat and open flames away as primers and adhesive are flammable.
 The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let
them come in contact with skin or eyes.
1. Windshield molding (upper) 2. Dam sealant rubber 3. Spacer (LH/RH)
4. Windshield glass assembly 5. Roof side molding (LH/RH) 6. Front fender cover
7. Roof side molding fastener 8. Mirror base 9. Adhesive
10. Primer 11. Cowl top center 12. Cowl top cover
13. Roof 14. Headlining assembly 15. Front roof rail
16. Body side outer 17. Front pillar inner upper 18. Front pillar garnish
19. Front sunroof glass
: Clip
Unit : mm (in)
Note : D and E on the exploded view are sections of sunroof models.
Refer to GI-4, "
Components" for symbols in the figure.
PIIB5779E

GW-12
< ON-VEHICLE REPAIR >
WINDSHIELD GLASS
 Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.
Move immediately to an area with fresh air if affected by vapor inhalation.
 Driving the vehicle before the urethane adhesive has completely cured may affect the performance
of the windshield in case of an accident.
CAUTION:
 Perform adjustment of front wiper arms stop location. Refer to WW-105, "
Adjustment".
 Never use an adhesive which is past its usable term. Shelf life of this product is limited to six months
after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the
box.
 Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
 Never leave primers or adhesive cartridge unattended with their caps open or off.
 Never drive the vehicle within 24 hours or until the urethane adhesive has completely cured. Curing
time varies depending on temperature and humidity. The curing time increases under lower temper-
ature and lower humidity.
InspectionINFOID:0000000003825399
REPAIRING WATER LEAKAGE FOR WINDSHIELD
Leakage can be repaired without removing the glass.
Determine the extent of leakage if water is leaking between the urethane adhesive material and body or glass.
This can be done by applying water to the windshield area while pushing glass outward.
Apply primer (if necessary) and then urethane adhesive to the leakage point to stop the leakage.

SIDE WINDOW GLASS
GW-13
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
GW
N
O
P
SIDE WINDOW GLASS
Exploded ViewINFOID:0000000003825400
Removal and InstallationINFOID:0000000003825401
REMOVAL
1. Remove rear seatback and rear seat cushion. Refer to SE-99, "Removal and Installation".
2. Remove rear pillar finisher. Refer to INT-39, "
Removal and Installation".
3. Apply protective tape around the side window to protect the painted surface from damage.
4. Remove side window glass using piano wire.
1. Side window glass 2. Side window glass assembly 3. Primer
4. Adhesive 5. Body side outer 6. Clip
Unit : mm (in)
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA2308GB

GW-14
< ON-VEHICLE REPAIR >
SIDE WINDOW GLASS
WARNING:
Always wear safety glasses and heavy gloves to prevent injury.
CAUTION:
 Be careful not to scratch the glass when removing.
 Never set or stand the glass on its edge. Small chips may develop into cracks.
INSTALLATION
 Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions provided
with it.
 Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by
passenger room air pressure when all door windows are closed.
 The molding must be installed securely so that it is in position and leaves no clearance.
 Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (approximately 24 hours). Curing time varies with temperature and humidity.
WARNING:
 Keep heat and open flames away as primers and adhesive are flammable.
 The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let
them come in contact with skin or eyes.
 Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.
Move immediately to an area with fresh air if affected by vapor inhalation.
 Driving the vehicle before the urethane adhesive has completely cured may affect the performance
of the side window in case of an accident.
CAUTION:
 Never use an adhesive which is past its usable term. Shelf life of this product is limited to six months
after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the
box.
 Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
 Never leave primers or adhesive cartridge unattended with their caps open or off.
 Never drive the vehicle within 24 hours or until the urethane adhesive has completely cured. Curing
time varies depending on temperature and humidity. The curing time will increase under lower tem-
perature and lower humidity.
InspectionINFOID:0000000003825402
Repairing Water Leakage for side window glass
Leakage can be repaired without removing glass.
Determine the extent of leakage if water is leaking between the urethane adhesive material and body or glass.
This can be done by applying water to the side window glass area while pushing glass outward.
Apply primer (if necessary) and then urethane adhesive to the leakage point to stop the leakage.

REAR WINDOW GLASS
GW-15
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
GW
N
O
P
REAR WINDOW GLASS
Exploded ViewINFOID:0000000003825403
Removal and InstallationINFOID:0000000003825404
REMOVAL
1. Remove rear seatback and rear seat cushion. Refer to SE-99, "Removal and Installation".
2. Remove rear pillar finisher (RH/LH). Refer to INT-39, "
Removal and Installation".
1. Rear window glass 2. Dam sealant rubber 3. Spacer
4. Roof 5. Primer 6. Adhesive
7. Body side outer 8. Parcel shelf 9. Headlining assembly
10. Rear pillar finisher 11. Trunk lid outer 12. Rear parcel shelf finisher
Unit : mm (in)
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA2307GB

GW-16
< ON-VEHICLE REPAIR >
REAR WINDOW GLASS
3. Remove rear parcel shelf finisher. Refer to INT-43, "Removal and Installation".
4. Remove partially the headlining assembly (rear edge). Refer to INT-50, "
NORMAL ROOF : Removal and
Installation"for normal roof and to INT-54, "SUNROOF : Removal and Installation" for sunroof.
5. Remove connectors and ground from the rear window defogger.
6. Remove glass using piano wire or power cutting tool (A) and an inflatable pump bag (B) after removing
molding using pliers.
NOTE:
Mark the body and the glass with matching marks if the rear window glass is reused.
WARNING:
Always wear safety glasses and heavy gloves to prevent injury.
CAUTION:
 Never use a cutting knife or power cutting tool when the rear window glass is reused.
 Be careful not to scratch the glass when removing.
 Never set or stand the glass on its edge. Small chips may develop into cracks.
INSTALLATION
 The dam sealant rubber should be installed in position.
 Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions provided
with it.
 Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by
passenger compartment air pressure when all door windows are closed.
 Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely
cured (approximately 24 hours). Curing time varies with temperature and humidity.
WARNING:
 Keep heat and open flames away as primers and adhesive are flammable.
 The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never
let them come in contact with skin or eyes.
 Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.
Move immediately to an area with fresh air if affected by vapor inhalation.
 Driving the vehicle before the urethane adhesive has completely cured may affect the performance
of the rear window in case of an accident.
CAUTION:
 Never use an adhesive which is past its usable term. Shelf life of this product is limited to six
months after the date of manufacture. Carefully adhere to the expiration or manufacture date
printed on the box.
 Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
 Never leave primers or adhesive cartridge unattended with their caps open or off.
 Never drive the vehicle within 24 hours or until the urethane adhesive has completely cured. Cur-
ing time varies depending on temperature and humidity. The curing time increases under lower
temperature and lower humidity.
InspectionINFOID:0000000003825405
REPAIRING WATER LEAKAGE FOR REAR WINDOW GLASS
Leakage can be repaired without removing the glass.
Determine the extent of leakage if water is leaking between the urethane adhesive material and body or glass.
This can be done by applying water to the back door window glass area while pushing glass outward.
Apply primer (if necessary) and then urethane adhesive to the leakage point to stop the leakage.
PIIB5779E

FRONT DOOR GLASS
GW-17
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
GW
N
O
P
FRONT DOOR GLASS
Exploded ViewINFOID:0000000003825379
Removal and InstallationINFOID:0000000003825380
REMOVAL
1. Remove front door finisher. Refer to INT-30, "DRIVER SIDE : Removal and Installation".
2. Remove front door corner cover. Refer to MIR-15, "
DOOR MIRROR ASSEMBLY : Exploded View".
3. Remove front door inside seal.
4. Remove both seals (A) as shown in the figure.
1. Front door glass run 2. Front door glass 3. Module base
4. Power window motor 5. Regulator assembly 6. Front door inside seal
7. Corner cover 8. Front door panel
: Clip
: Vehicle front
JMKIA2309ZZ
JMKIA2310ZZ
