HEADLINING
SUNROOF : Removal and Installation
INFOID:0000000003826878
REMOVAL
1. Remove front body side welt (LH/RH) and front pillar garnish (LH/RH). Refer to INT-39, "Removal and
Installation".
2. Disconnect the roof harness (1) connector (B), antenna feeder (2) harness connector (C) and then
remove all the clips (A) as shown in the figure below.
3. Remove sun visor assembly (LH/RH).
 Remove sun visor cover.
 Remove sun visor assembly (1) mounting screws (B) with a
screwdriver (A).
 Disconnect vanity mirror lamp harness connectors.
4. Rotate 90 degrees and remove sun visor holder (1) (LH/RH).
: Pawl
: Metal clip
: Clip
JMJIA1785ZZ
JMJIA1786ZZ
JMJIA1787ZZ

HEADLINING
INT-55
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
INT
N
O
P
5. Remove mounting plastic clips (A) using a flat-bladed screw-
driver (B) of front and rear assistance grips (1), and then remove
assist grips.
6. Remove the front seat assembly. Refer to SE-92, "
Removal and Installation".
7. Remove rear seat assembly. Refer to SE-99, "
Removal and Installation".
8. Remove front kicking plate inner (LH/RH), center pillar upper garnish (LH/RH) and rear pillar finisher (LH/
RH).
Refer to INT-39, "
Removal and Installation".
9. On the rear right side of the vehicle, disconnect the harness
connector (A) and (C), remove the bolt (B) and then disengage
the pawls as shown in the figure.
10. With a removal tool, remove body side mounting plastic clip from rear end of headlining.
11. Pull map lamp assembly toward vehicle lower, and disengage
dual-lock fastener (A) and metal clips (B).
CAUTION:
Map lamp assembly is crimped from back of headlining.
Remove it by disengaging the crimped area of back of map
lamp assembly after removing headlining from the vehicle.
12. Remove headlining assembly (1) as shown in the figure below.
JMJIA0096GB
: Pawl
JMJIA1788ZZ
JMJIA1008ZZ
JMJIA1789ZZ

INT-56
< ON-VEHICLE REPAIR >
HEADLINING
CAUTION:
 When removing, 2 workers are required. (1 for the front and rear of headlining)
 Cover center console finisher upper surface with a shop cloth to prevent it from being damaged.
 Never bend headlining when removing.
13. Remove the following parts after removing headlining.
 Map lamp assembly. Refer to INL-89, "
Removal and Installation".
 Personal lamp assembly. Refer to INL-96, "
Removal and Installation".
 Roof harness assembly.
 Antenna feeder assembly. Refer to AV-44, "
Harness Layout".
INSTALLATION
Install in the reverse order of removal.
CAUTION:
 Install headlining assembly after inserting clips to clip holder of headlining rear end.
 Never bend headlining when installing.

TRUNK ROOM TRIM
INT-57
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
INT
N
O
P
TRUNK ROOM TRIM
Exploded ViewINFOID:0000000003819232
Removal and InstallationINFOID:0000000003819233
REMOVAL
1. Fully open trunk lid assembly.
1. Trunk front finisher upper 2. Rear seatback center finisher (Nor-
mal roof models)3. Rear seatback center finisher lid
4. Rear wheel house finisher (LH) 5. Trunk floor spacer (LH) 6. Trunk center box assembly
7. Trunk rear finisher 8. Rear wheel house finisher (RH) 9. Trunk front finisher center
10. Trunk floor carpet 11. Trunk floor spacer (RH) 12. Rear seatback center finisher (Sun-
roof models)
: Clip
: Metal clip
JMJIA1806ZZ

INT-58
< ON-VEHICLE REPAIR >
TRUNK ROOM TRIM
2. Remove trunk floor carpet.
3. Remove trunk center box.
4. Remove trunk floor spacer (LH/RH).
5. Remove trunk rear finisher mounting clips and metal clips, and then remove trunk rear finisher.
6. Remove trunk weather-strip.
7. Remove trunk front finisher center fixing clips, and then remove trunk front finisher center.
8. Remove trunk front finisher upper fixing clips, and then remove the trunk front finisher upper.
9. Remove rear wheel house finisher (LH/RH).
 Remove rear wheel fixing clips
 Remove rear seat assembly. Refer to SE-99, "
Removal and Installation".
 Remove rear seat support (1) fixing bolts, shown by the arrows in the figure below and then remove rear
wheel house finisher (2)
10. Disengage rear seatback center finisher assembly fixing clips with a remover tool (A), and then remove
rear seatback center finisher assembly.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
Check that clips, pawls, metal clips are securely fitted in panel holes on body when installing, and then
press them in.
: Bolt
JMJIA1791ZZ

TRUNK LID TRIM
INT-59
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
INT
N
O
P
TRUNK LID TRIM
Exploded ViewINFOID:0000000003819234
Removal and InstallationINFOID:0000000003819235
REMOVAL
1. Fully open trunk lid assembly.
2. Disengage the trunk lid pull handle (1) fixing pawls with a remover tool (A), and then remove the trunk lid
pull handle.
1. Trunk lid finisher inner 2. Trunk lid assembly 3. Emergency handle
4. Trunk lid pull handle
: Pawl
JMJIA1807ZZ
: Pawl
JMJIA1792ZZ

INT-60
< ON-VEHICLE REPAIR >
TRUNK LID TRIM
3. Remove trunk lid emergency handle holder (1).
4. Remove trunk lid finisher mounting clips, and then remove trunk lid finisher inner.
INSTALLATION
Install in the reverse order of removal.
: Clip
JMJIA1793ZZ

REAR SUNSHADE CONTROL UNIT
INT-61
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
INT
N
O
P
REAR SUNSHADE CONTROL UNIT
Exploded ViewINFOID:0000000003840071
Removal and InstallationINFOID:0000000003840072
REMOVAL
1. Remove the rear parcel shelf finisher.
Refer to INT-43, "
Removal and Installation".
2. Remove the rear sunshade control unit bracket bolt (A).
3. Remove the rear sunshade control unit. (1) Pull toward the
direction of the arrow.
INSTALLATION
Install in the reverse order of removal.
1. Rear sunshade control unit
JMJIA1949ZZ
JMJIA1950ZZ
JMJIA1951ZZ

INT-62
< ON-VEHICLE REPAIR >
REAR SUNSHADE SWITCH
REAR SUNSHADE SWITCH
FRONT
FRONT : Exploded ViewINFOID:0000000003840075
FRONT : Removal and InstallationINFOID:0000000003840076
REMOVAL
1. Remove the instrument lower panel LH.
Refer to IP-12, "
Removal and Installation".
2. Rear sunshade switch (front) (1) is removed from instrument
lower panel LH using flat-bladed screw driver (A) etc.
CAUTION:
Never fold pawl of instrument lower panel LH.
INSTALLATION
Install in the reverse order of removal.
REAR
1. Rear sunshade switch (front) 2. Instrument lower panel LH
JMJIA1730ZZ
JMJIA1731ZZ

REAR SUNSHADE SWITCH
INT-63
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
INT
N
O
P
REAR : Exploded ViewINFOID:0000000003840077
REAR : Removal and InstallationINFOID:0000000003840078
REMOVAL
1. Remove the control switch panel.
Refer to SE-98, "
Exploded View".
2. Rear sunshade switch (rear) (1) is removed from control switch
panel using flat-bladed screw driver (A) etc.
CAUTION:
Never fold the pawl of control switch panel.
INSTALLATION
Install in the reverse order of removal.
1. Rear sunshade switch (rear) 2. Control switch panel
JMJIA1722ZZ
JMJIA1723ZZ
