NISSAN TEANA 2008 Service Manual

INSTRUMENT PANEL ASSEMBLY
IP-21
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
IP
N
O
P
 Put selector lever in the [D] position.
 Pull back instrument panel assembly, and then remove front
squawker LH harness clip (A).
 Remove instrument panel from passenger door opening portion.
CAUTION:
 Cover center console upper surface with a shop cloth to prevent it from being damaged.
 When removing instrument panel assembly, 2 workers are required so as to prevent it from drop-
ping.
48. Remove the following parts after removing instrument panel assembly.
 Front passenger air bag module. Refer to SR-12, "
Removal and Installation".
 Side ventilator grille LH/RH. Refer to VTL-46, "
SIDE VENTILATOR GRILLE : Removal and Installation".
 Side defroster nozzle LH/RH. Refer to VTL-47, "
SIDE DEFROSTER GRILLE : Removal and Installa-
tion".
 Ventilator duct LH/RH. Refer to VTL-48, "
VENTILATOR DUCT : Removal and Installation".
 Defroster nozzle. Refer to VTL-49, "
SIDE DEFROSTER NOZZLE : Removal and Installation".
 Antenna feeder. Refer to AV-44, "
Harness Layout".
INSTALLATION
Install in the reverse order of removal.
JMJIA1923ZZ

IP-22
< ON-VEHICLE REPAIR >
CENTER CONSOLE ASSEMBLY
CENTER CONSOLE ASSEMBLY
Exploded ViewINFOID:0000000003816779
Removal and InstallationINFOID:0000000003819349
REMOVAL
1. Ashtray lamp harness 2. Cigarette lighter complete 3. Cigarette lighter ring
4. Console ashtray assembly 5. Instrument lower cover RH 6. Instrument lower cover LH
7. Center console assembly 8. Console switch panel 9. Console bracket
10. Inside key antenna 11. Console rear ashtray 12. Console rear finisher
13. Rear ventilator grille 14. Power socket cap 15. Power socket inner case
16. Console mask 17. Console lid assembly 18. Cup holder assembly
19. Console finisher assembly 20. Indicator lamp harness 21. Shift lock switch
22. Inner ashtray 23. Control device upper case 24. Auxiliary input jacks
JMJIA1924ZZ

CENTER CONSOLE ASSEMBLY
IP-23
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
IP
N
O
P
1. Remove instrument finisher D.
 Remove instrument finisher D (1) fixing clips with remover tool
(A).
 Pull back instrument finisher D, and then remove instrument
finisher D.
2. Remove instrument finisher E.
 Remove instrument finisher E (1) fixing clips with remover tool
(A).
 Pull back instrument finisher E, and then remove instrument
finisher E.
3. Remove front body side welt LH. Refer to INT-39, "
Removal and Installation".
4. Remove hood opener lever fixing bolts. Refer to DLK-220, "
Removal and Installation".
5. Remove fuse block lid.
 Open the fuse block lid (1).
 Pull fuse block lid, backward to disengage from instrument
lower panel LH.
6. Remove instrument lower panel LH.
 Remove instrument lower panel LH (1) fixing screw (A).
 Pull instrument lower panel LH, backward to disengage from
instrument panel assembly.
 Release data link connector (pawl) then remove it from instru-
ment lower panel LH.
 Disconnect harness connectors and aspirator duct.
: Clip
JMJIA1892ZZ
: Clip
JMJIA1893ZZ
: Pawl
JMJIA1896ZZ
: Clip
: Pawl
JMJIA1897ZZ

IP-24
< ON-VEHICLE REPAIR >
CENTER CONSOLE ASSEMBLY
7. Remove instrument lower cover LH.
 Disengage instrument lower cover LH (1) fixing pawl and
metal clips.
 Pull back instrument lower cover LH.
8. Remove front body side welt RH. Refer to INT-39, "
Removal and Installation".
9. Remove instrument side finisher RH.
 Insert a remover tool (A) into lower space.
 Pull the instrument side finisher RH (1) crosswise.
10. Remove glove box assembly.
 Remove glove box assembly (1) fixing screws (A).
 Open the glove box lid.
 Remove glove box assembly fixing screws (B).
 Pull back glove box assembly.
 Disconnect harness connector.
11. Remove instrument side panel RH.
 Remove instrument side panel RH (1) fixing screw (A).
 Pull toward the direction the arrow is pointing.
: Pawl
: Metal clip
JMJIA1898ZZ
: Pawl
: Metal clip
JMJIA1900ZZ
: Pawl
JMJIA1901ZZ
: Clip
: Pawl
JMJIA1902ZZ

CENTER CONSOLE ASSEMBLY
IP-25
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
IP
N
O
P
12. Remove instrument lower cover RH.
 Disengage instrument lower cover LH (1) fixing clip, pawl and
metal clips.
 Pull the instrument lower cover RH crosswise.
13. Remove selector lever knob. Refer to TM-155, "
Removal and Installation".
14. Remove console switch panel.
 Disengage pawls of console switch panel (1) with remover tool
(A).
 Pull up console switch panel.
15. Remove console finisher assembly.
 Put selector lever in the [N] position.
 Remove console finisher assembly (1) fixing metal clips and
pawls sequentially from the front side with remover tool.
 Pull console finisher assembly, upward to disengage from cen-
ter console.
 Disconnect harness connectors.
16. Remove control device upper case.
 Put selector lever in the [P] position.
 Remove control device upper case (1) mounting screws (A).
 Pull control device upper case, upward to disengage from con-
trol device assembly.
 Disconnect harness clip (B).
17. Remove console rear finisher.
 Pull back console rear finisher (1) by using a remover tool (A),
then disengage pawls and metal clips.
 Disconnect inside key antenna connector.
: Clip
: Pawl
: Metal clip
JMJIA1903ZZ
: Pawl
JMJIA1904ZZ
: Pawl
: Metal clip
JMJIA1905ZZ
JMJIA1906ZZ
: Pawl
: Metal clip
JMJIA1907ZZ

IP-26
< ON-VEHICLE REPAIR >
CENTER CONSOLE ASSEMBLY
18. Remove center console assembly.
 Remove center console fixing screws (A).
 Put front seat to the front most position.
 Remove center console fixing screws (B).
 Put front seat to the rear most position.
 Lift up center console assembly back side.
 Disconnect harness connectors.
INSTALLATION
Install in the reverse order of removal.
Disassembly and AssemblyINFOID:0000000003816781
DISASSEMBLY
1. Remove center console assembly. Refer to IP-22, "Removal and Installation".
2. Remove console lid assembly.
 Open the console lid.
 Remove console mask (1) fixing pawls with remover tool (A).
JMJIA1908ZZ
JMJIA1909ZZ
: Pawl
JMJIA1925ZZ

CENTER CONSOLE ASSEMBLY
IP-27
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
K
L
MA
B
IP
N
O
P
 Remove console lid assembly (1) fixing screws (A) and then
remove console lid assembly.
3. Remove power outlet. Refer to PWO-8, "
Removal and Installation".
4. Remove auxiliary input jacks. Refer to AV-663, "
Removal and Installation".
ASSEMBLY
Assemble in the reverse order of disassembly.
JMJIA1926ZZ
