AV
PRECAUTIONS
AV-647
< PRECAUTION >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003960544
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIRBAG” and
“SEAT BELT” of this Service Manual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIRBAG”.
Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.
Precaution for Trouble DiagnosisINFOID:0000000003765979
AV COMMUNICATION SYSTEM
Do not apply voltage of 7.0 V or higher to the measurement terminals.
Use the tester with its open terminal voltage being 7.0 V or less.
Be sure to turn ignition switch OFF and disconnect the battery cable from the negative terminal before
checking the circuit.
Precaution for Harness RepairINFOID:0000000003765980
AV COMMUNICATION SYSTEM
Solder the repaired parts, and wrap with tape. [Frays of twisted line
must be within 110 mm (4.33 in).]
Do not perform bypass wire connections for the repair parts. (The
spliced wire will become separated and the characteristics of
twisted line will be lost.)
PKIA0306E
PKIA0307E
Page 792 of 5121
AV-648
< ON-VEHICLE REPAIR >[BOSE AUDIO WITH NAVIGATION]
AV CONTROL UNIT
ON-VEHICLE REPAIR
AV CONTROL UNIT
Exploded ViewINFOID:0000000003765981
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
Removal and InstallationINFOID:0000000003765982
REMOVAL
1. Remove instrument finisher C. Refer to IP-12, "Removal and Installation".
2. Remove cluster lid D. Refer to IP-12, "
Removal and Installation".
3. Remove AV control unit with A/C amp. as a single unit from the body.
4. Remove bracket screws, and then remove AV control unit.
INSTALLATION
Installation is the reverse order of removal.
1. AV control unit 2. Bracket LH 3. A/C auto amp.
4. Bracket RH
JPNIA1034ZZ
Page 793 of 5121
AV
NAVI CONTROL UNIT
AV-649
< ON-VEHICLE REPAIR >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NAVI CONTROL UNIT
Exploded ViewINFOID:0000000003765983
DISASSEMBLY
Removal and InstallationINFOID:0000000003765984
REMOVAL
1. Remove NAVI control unit mounting screws.
2. Disconnect NAVI control unit connector and remove the NAVI control unit.
INSTALLATION
Install in the reverse order of removal.
1. NAVI control unit 2. Bracket LH 3. Bracket RH
JPNIA1088ZZ
Page 794 of 5121
AV-650
< ON-VEHICLE REPAIR >[BOSE AUDIO WITH NAVIGATION]
DISPLAY UNIT
DISPLAY UNIT
Exploded ViewINFOID:0000000003765985
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
Removal and InstallationINFOID:0000000003765986
REMOVAL
1. Remove cluster lid D. Refer to IP-12, "Removal and Installation".
2. Remove display unit mounting screws, and then disconnect the display unit connector.
3. Remove display unit.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1035ZZ
1. Display unit
Page 795 of 5121
AV
FRONT DOOR SPEAKER
AV-651
< ON-VEHICLE REPAIR >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
FRONT DOOR SPEAKER
Exploded ViewINFOID:0000000003765987
Removal and InstallationINFOID:0000000003765988
REMOVAL
1. Remove front door finisher. Refer to INT-30, "DRIVER SIDE : Removal and Installation" (driver side) or
INT-33, "
PASSENGER SIDE : Removal and Installation" (passenger side).
2. Remove front door speaker mounting bolts, disconnect the front door speaker connector.
3. Remove front door speaker.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1036ZZ
1. Front door speaker
Page 796 of 5121
AV-652
< ON-VEHICLE REPAIR >[BOSE AUDIO WITH NAVIGATION]
REAR DOOR SPEAKER
REAR DOOR SPEAKER
Exploded ViewINFOID:0000000003765989
Removal and InstallationINFOID:0000000003765990
REMOVAL
1. Remove rear door finisher. Refer to INT-36, "Removal and Installation".
2. Remove rear door speaker mounting bolts, disconnect the rear door speaker connector.
3. Remove rear door speaker.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1037ZZ
1. Rear door speaker
Page 797 of 5121
AV
FRONT SQUAWKER
AV-653
< ON-VEHICLE REPAIR >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
FRONT SQUAWKER
Exploded ViewINFOID:0000000003765991
Removal and InstallationINFOID:0000000003765992
REMOVAL
1. Remove the speaker grille with squawker. Refer to IP-12, "Removal and Installation".
2. Remove front squawker mounting screws, lift up the front squawker and disconnect front squawker con-
nector.
3. Remove front squawker.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1038ZZ
1. Front squawker
Page 798 of 5121
AV-654
< ON-VEHICLE REPAIR >[BOSE AUDIO WITH NAVIGATION]
REAR SQUAWKER
REAR SQUAWKER
Exploded ViewINFOID:0000000003765993
Removal and InstallationINFOID:0000000003765994
REMOVAL
1. Remove rear parcel shelf finisher. Refer to INT-43, "Removal and Installation".
2. Remove rear squawker mounting screws.
3. Remove rear squawker.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1040ZZ
1. Rear squawker
Page 799 of 5121
AV
CENTER SPEAKER
AV-655
< ON-VEHICLE REPAIR >[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
CENTER SPEAKER
Exploded ViewINFOID:0000000003765995
Removal and InstallationINFOID:0000000003765996
REMOVAL
1. Remove center speaker grille. Refer to IP-12, "Removal and Installation".
2. Remove center speaker mounting screws, lift up the center speaker and disconnect center speaker con-
nector.
3. Remove center speaker.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1039ZZ
1. Center speaker
Page 800 of 5121
AV-656
< ON-VEHICLE REPAIR >[BOSE AUDIO WITH NAVIGATION]
WOOFER
WOOFER
Exploded ViewINFOID:0000000003765997
Removal and InstallationINFOID:0000000003765998
REMOVAL
1. Remove rear parcel shelf finisher. Refer to INT-43, "Removal and Installation".
2. Remove woofer mounting bolts, lift up the woofer and disconnect woofer connector.
3. Remove woofer.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1041ZZ
1. Woofer
