NISSAN TEANA 2014 Service Manual

EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-153
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
• Use a reliable straightedge and f
eeler gauge to check the flatness
of the exhaust manifold mating surfaces.
• Replace the exhaust manifold if the measurement exceeds specifi- cations.
INSTALLATION
Installation is in the reverse order of removal.
1. Install the studs in the exhaust manifold (if removed), and tighten to specification.
2. Install the exhaust manifold gasket in the direction shown. CAUTION:
Do not reuse exhaust manifold gaskets.
3. Install the exhaust manifold (LH) nuts and tighten to specifica- tion in the order shown.
NOTE:
Number 7 and 8 are tightened a second time.
CAUTION:
• Before installing a heated oxyg en sensor 2 or air fuel ratio (A/F) sensor 1, clean the exhaust
manifold threads using the oxyg en sensor thread cleaner tool and apply anti-seize lubricant.
• Do not over-tighten the air fuel ratio (A/F) senso r 1 or heated oxygen sensors 2. Doing so may
cause damage.
Removal and Installation (RH)INFOID:0000000009460547
REMOVAL
WARNING: Limit : 0.3 mm (0.012 in)
PBIC1173E
Exhaust manifold studs : 15.4 N·m (1.6 kg-m, 11 ft-lb)
(A) : Bank 1
(B) : Triangle press
(C) : Bank 2
: Engine front
PBIC4954E
: Engine front
AWBIA1208GB
Oxygen sensor thread cleaner : (J-43897-18)
Oxygen sensor thread cleaner : (J-43897-12)
Tool numbers : KV10114400 (J-38365) : KV991J0050 (J-44626)
Revision: November 20132014 Altima NAM

EM-154
< REMOVAL AND INSTALLATION >[VQ35DE]
EXHAUST MANIFOLD AND THREE WAY CATALYST
• Perform the work when the exhaust and co
oling system have completely cooled down.
• When removing the front and rear engine mounting th rough bolts and nuts, lift the engine up slightly
for safety. For engine slingers, refer to EM-220, "Removal and Installation"
.
1. Remove the engine and transaxle assembly. Refer to EM-220, "Removal and Installation"
.
2. Remove the RH three way catalyst supports.
3. Remove rear engine mount bracket. Refer to EM-220, "Removal and Installation"
.
4. Remove heated oxygen sensor 2 (bank 1), air fuel ratio (A/F) sensor 1 (bank 1).
a. Remove harness connector from heated oxygen sensor 2 and air fuel ration (A/F) sensor 1, and discon-
nect the harness from the bracket and middle clamp.
b. Remove both heated oxygen sensors 2 and air fuel ratio (A/F) sensors 1 using Tool.
CAUTION:
• Be careful not to damage heated oxygen sen sors 2 or air fuel ratio (A/F) sensors 1.
• Discard any heated oxygen sensor 2 which has been dropped from a height of more than 0.5 m
(19.7 in) onto a hard surface such as a co ncrete floor; replace with a new sensor.
5. Remove exhaust manifold heat shield (RH) and three way catalyst heat shields (RH) using power tool.
6. Remove the three way catalyst (bank 1) by loosening the bolts first and then removing the nuts and through bolts.
7. Loosen the exhaust manifold nuts in the reverse order as shown and remove the exhaust manifold (RH).
NOTE:
Number 7 and 8 are not applicable to removal.
INSPECTION AFTER REMOVAL
Surface Distortion
• Use a reliable straightedge and feeler gauge to check the flatness of the exhaust manifold mating surfaces.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Do not reuse exhaust manifold gaskets. Tool numbers : KV10114400 (J-38365)
: KV991J0050 (J-44626)
: Engine front
AWBIA1209GB
Limit : 0.3mm (0.012 in)
PBIC1173E
Revision: November 20132014 Altima NAM

EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-155
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
• Install the exhaust manifold nuts in the order as shown (A).
CAUTION:
• Before installing a heated oxygen sensor 2 or air fuel ratio (A /F) sensor 1, clean the exhaust mani-
fold threads using the oxygen sensor thread cleaner tool , and apply anti-seize lubricant.
• Do not over-tighten the air fuel ratio (A/F) senso r 1 or heated oxygen sensors 2. Doing so may
cause damage. :Engine front
ALBIA0237ZZ
Tool numbers : J-43897-18
: J-43897-12
Tool numbers : KV10114400 (J-38365) : KV991J0050 (J-44626)
Revision: November 20132014 Altima NAM

EM-156
< REMOVAL AND INSTALLATION >[VQ35DE]
OIL PAN AND OIL STRAINER
OIL PAN AND OIL STRAINER
Exploded ViewINFOID:0000000009460548
Removal and Installation (Lower Oil Pan)INFOID:0000000009460549
REMOVAL
WARNING:
• Do not remove the oil pan until the exhaust system and cooling system have completely cooled off.
1. Drain the engine oil. Refer to LU-26, "Changing Engine Oil"
.
2. Loosen the lower oil pan bolts in the reverse order as shown using power tool.
3. Remove the lower oil pan.
1. Oil pan baffle 2. O-ring 3. Gasket
4. Oil pressure switch 5. Oil cooler O-ring 6. Oil cooler
7. Oil cooler connection 8. Oil filter 9. Lower oil pan
10. Oil strainer 11. Rear plate cover 12. Crankshaft position sensor (POS)
13. O-ring 14. Upper oil pan
AWBIA1770ZZ
AWBIA1357ZZ
Revision: November 20132014 Altima NAM

OIL PAN AND OIL STRAINEREM-157
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
a. Insert Tool (A) between the lower oil pan and the upper oil pan.
CAUTION:
• Be careful not to damage the mating surface.
• Do not insert a screwdriver or similar tool, this will dam-
age the mating surfaces.
b. In areas where the cutter is difficult to use, use a plastic hammer to lightly tap (1) the cutter where the liquid gasket is applied. Use
a plastic hammer to slide (2) the cutter by tapping on the side.
4. If re-installing the original lower oil pan, remove the old liquid gasket from the mating surfaces using a scraper.
• Also remove the old liquid gasket from mating surface of the upper oil pan.
• Remove the old liquid gasket from the bolt holes and threads.
CAUTION:
Do not scratch or damage the mating surf aces when cleaning off the old liquid gasket.
INSPECTION AFTER REMOVAL
Clean oil strainer if any object is attached.
INSTALLATION
1. Apply a continuous bead of liquid gasket to the lower oil pan.
• Use Genuine Silicone RTV Sealant, or equivalent. Refer to GI-
21, "Recommended Chemical Products and Sealants".
• Be sure the liquid gasket is 4.5 - 5.5 mm (0.177 - 0.217 in) wide.
• Installation must be done within 5 minutes after applying liquid gasket.
2. Install the lower oil pan. Tighten the lower oil pan bolts in order as shown.
• Wait at least 30 minutes before refilling the engine with oil.
INSPECTION AFTER INSTALLATION
• Start the engine and check for leaks. Refer to LU-25, "Inspection".
• Inspect the engine oil level. Refer to LU-25, "Inspection"
.
Removal and Installation (Upper Oil Pan)INFOID:0000000009460550
REMOVAL
WARNING:
• Do not remove the oil pan until the exhaust system and cooling syst em have completely cooled off.
• When removing the front and rear engine through bolt s and nuts, lift the engine up slightly for safety.
For engine slingers, refer to EM-220, "Removal and Installation"
.
CAUTION:
When removing the upper oil pan from the engine , first remove the crankshaft position sensor (POS).
Be careful not to damage senso r edges or signal plate teeth.
Tool number : KV10111100 (J-37228)
AWBIA1249GB
SEM159F
AWBIA1357ZZ
Revision: November 20132014 Altima NAM

EM-158
< REMOVAL AND INSTALLATION >[VQ35DE]
OIL PAN AND OIL STRAINER
1. Remove the engine from the vehicle. Refer to
EM-220, "Removal and Installation".
2. Drain the engine oil. Refer to LU-26, "Changing Engine Oil"
.
3. Remove the oil level gauge guide.
4. Remove the drive belt. Refer to EM-134, "Removal and Installation"
.
5. Disconnect the A/C compressor harness connector.
6. Remove the A/C compressor bolts and remove the A/C compressor. Refer to HA-30, "COMPRESSOR :
Removal and Installation".
7. Remove coolant pipe bolts. Refer to CO-51, "Removal and Installation"
.
8. Disconnect the coolant lines from the engine oil cooler.
9. Remove the oil filter and engine oil cooler from the upper oil pan.
10. Remove the oil pressure switch, and the cranks haft position sensor (POS) from the upper oil pan.
11. Remove the lower oil pan. Refer to EM-156, "Removal and Installation (Lower Oil Pan)"
.
12. Remove the upper oil pan.
a. Loosen the bolts in the order as shown, using power tool.
b. Insert an appropriate size tool into the notch (1) of the upper oil pan as shown.
c. Pry off the upper oil pan by moving the tool up and down (2) as shown.
13. Remove the O-ring seals from the bottom of the cylinder block and oil pump housing. Use new O-rings for installation.
CAUTION:
Do not reuse O-rings.
LBIA0358E
SEM155F
WBIA0327E
Revision: November 20132014 Altima NAM

OIL PAN AND OIL STRAINEREM-159
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
14. Remove front cover gasket and rear oil seal retainer gasket.
CAUTION:
Do not reuse gaskets.
15. Remove the oil strainer.
16. If re-installing the original oil pan, remove the old sealant from the mating surfaces using a scraper.
• Also remove the old sealant from mating surface of the cylin-
der block.
• Remove the old sealant from the bolt holes and threads.
CAUTION:
Do not scratch or damage th e mating surfaces when clean-
ing off the old sealant.
INSPECTION AFTER REMOVAL
Clean oil strainer if any object is attached.
INSTALLATION
1. Install oil strainer and tighten bolts to specified torque. Refer to EM-156, "Exploded View".
2. Apply Genuine Silicone RTV Sealant or equivalent, to the front cover gasket and the rear oil seal retainer gasket as shown.
Refer to GI-21, "Recommended Chemical Products and Seal-
ants".
CAUTION:
The components must be installed within 5 minutes of the
liquid gasket appli cation. Then allow 30 minutes for the liq-
uid gasket to set before operating the engine.
3. Install the front cover gasket and rear oil seal retainer gasket as shown.
CAUTION:
Do not reuse gaskets.
WBIA0328E
MEM108A
SEM964E
WBIA0328E
Revision: November 20132014 Altima NAM

EM-160
< REMOVAL AND INSTALLATION >[VQ35DE]
OIL PAN AND OIL STRAINER
4. Apply a bead of sealant to the cylinder block mating surface of
the upper oil pan to a limited portion as shown.
• Use Genuine Silicone RTV Sealant, or equivalent. Refer to GI-
21, "Recommended Chemical Products and Sealants".
• Be sure the sealant is applied to a limited portion as shown, and the sealant is 4.5 - 5.5 mm (0.177 - 0.217 in) wide.
• Attaching should be done within 5 minutes after coating.
CAUTION:
The components must be instal led within 5 minutes of the
liquid gasket applicat ion. Then allow 30 minutes for the liq-
uid gasket to set before operating the engine.
5. Install new O-rings on the cylinder block and oil pump body. CAUTION:
Do not reuse O-rings.
6. Install the upper oil pan. • Tighten upper oil pan bolts in the order as shown.
• Wait at least 30 minutes before refilling the engine with oil.
7. Install the lower oil pan. Refer to EM-156, "Removal and Installation (Lower Oil Pan)"
.
8. Installation of the remaining components is in the reverse order of removal.
INSPECTION AFTER INSTALLATION
• Before starting engine, check oil/fluid levels incl uding engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to MA-11, "FOR USA AND CANADA : Fluids and Lubricants"
.
• Use procedure below to check for fuel leakage.
• Turn ignition switch ON (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leak- age at connection points.
• Start engine. With engine speed increased, che ck again for fuel leakage at connection points.
:Engine front
:Cut here
AWBIA1350ZZ
SEM159F
WBIA0327E
LBIA0359E
Revision: November 20132014 Altima NAM

OIL PAN AND OIL STRAINEREM-161
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
• Run engine to check for unusual noise and vibration.
NOTE:
If hydraulic pressure inside timing chain tensioner dr ops after removal and installation, slack in the guide
may generate a pounding noise during and just after engine start. However, this is normal. Noise will stop
after hydraulic pressure rises.
• Warm up engine thoroughly to make sure there is no leak age of fuel, exhaust gas, or any oils/fluids including
engine oil and engine coolant.
• Bleed air from passages in lines and hoses, such as in cooling system.
• After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to spec-
ified level, if necessary.
• Summary of the inspection items:
*Power steering fluid, brake fluid, etc. Item Before starting engine Engine running After engine stopped
Engine coolant Level Leakage Level
Engine oil Level Leakage Level
Transmission/
transaxle fluid A/T and CVT Models Leakage Level/Leakage Leakage
M/T Models Level/Leakage Leakage Level/Leakage
Other oils and fluids* Level Leakage Level
Fuel Leakage Leakage Leakage
Exhaust gas — Leakage —
Revision: November 20132014 Altima NAM

EM-162
< REMOVAL AND INSTALLATION >[VQ35DE]
IGNITION COIL
IGNITION COIL
Exploded ViewINFOID:0000000009460551
Removal and Installation LHINFOID:0000000009460552
REMOVAL
1. Remove engine room cover. Refer to
EM-143, "Removal and Installation".
2. Disconnect ignition coil harness connector.
3. Remove the ignition coil. CAUTION:
Do not shock ig nition coil.
INSTALLATION
Installation is in the reverse order of removal.
Removal and Installation RHINFOID:0000000009460553
REMOVAL
1. Disconnect the battery negative terminal. Refer to PG-73, "Removal and Installation (Battery)".
2. Remove the intake manifold collector. Refer to EM-146, "Removal and Installation"
.
3. Disconnect ignition coil harness connector.
4. Remove the ignition coil. CAUTION:
Do not shock ig nition coil.
INSTALLATION
Installation is in the reverse order of removal.
1. Ignition coil 2. Spark plug 3. Rocker cover (RH)
4. Rocker cover (LH)
AWBIA1347ZZ
Revision: November 20132014 Altima NAM
