SERVICE DATA AND SPECIFICATIONS (SDS)EM-113
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Valve Clearance
Unit: mm (in)
* Approximately 80
°C (176 °F)
Available Valve Lifter
Unit: mm (in)
Valve length (L) Intake 101.72 (4.0074)
Exhaust 102.78 (4.0464)
Valve stem diameter (d) Intake 5.965 - 5.980 (0.2348 - 0.2354)
Exhaust 5.955 - 5.970 (0.2344 - 0.2350)
Valve seat angle α Intake
45°15 ′ - 45 °45 ′
Exhaust
Valve margin (T) Intake 1.08 (0.0425)
Exhaust 1.38 (0.0543)
Cold Hot*
Intake 0.24 - 0.32 (0.009 - 0.013) 0.304 - 0.416 (0.012 - 0.016)
Exhaust 0.26 - 0.34 (0.010 - 0.013) 0.308 - 0.432 (0.012 - 0.017)
Thickness Identification mark (Stamp)*
3.00 (0.1181) 300H
3.02 (0.1189) 302H
3.04 (0.1197) 304H
3.06 (0.1205) 306H
3.08 (0.1213) 308H
3.10 (0.1220) 310H
3.12 (0.1228) 312H
3.14 (0.1236) 314H
3.16 (0.1244) 316H
3.18 (0.1252) 318H
3.20 (0.1260) 320H
3.22 (0.1268) 322H
3.24 (0.1276) 324H
3.26 (0.1283) 326H
3.28 (0.1291) 328H
3.30 (0.1299) 330H
3.32 (0.1307) 332H
3.34 (0.1315) 334H
3.36 (0.1323) 336H
KBIA0119E
Revision: November 20132014 Altima NAM
Page 2112 of 4801
![NISSAN TEANA 2014 Service Manual
EM-114
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Always check with the Parts Department for the latest parts information.
Valve Spring
Valve Lifter
Un](/img/5/57390/w960_57390-2111.png "NISSAN TEANA 2014 Service Manual
EM-114
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Always check with the Parts Department for the latest parts information.
Valve Spring
Valve Lifter
Un")
EM-114
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Always check with the Parts Department for the latest parts information.
Valve Spring
Valve Lifter
Unit: mm (in)
Valve Oil Seal
Unit: mm (in)
Valve Guide
3.38 (0.1331) 338H
3.40 (0.1339) 340H
3.42 (0.1346) 342H
3.44 (0.1354) 344H
3.46 (0.1362) 346H
3.48 (0.1370) 348H
3.50 (0.1378) 350H Thickness Identification mark (Stamp)*
KBIA0119E
Free height standard
mm (in) Intake 47.92 - 48.12 (1.8866 - 1.8945)
Exhaust 48.65 - 48.85 (1.9154 - 1.9232)
Installation height mm (in) Intake 36.96 (1.4551)
Exhaust 36.96 (1.4551)
Installation load N (kg - f, lb–f) Intake 151 - 175 (15.4 - 17.8, 34 - 39)
Exhaust 151 - 175 (15.4 - 17.8, 34 - 39)
Height during valve open mm (in) Intake 26.76 (1.0535)
Exhaust 28.46 (1.1205)
Load with valve open N (kg-f, lb-f) Intake 335 - 383 (34.2 - 39.1, 75.3 - 86.1)
Exhaust 300 - 342 (30.6 - 34.9, 67.4 - 76.9)
Identification color Intake White
Exhaust Light blue
Out-of-square mm (in) 1.0 (0.0394) 1.0 (0.0394)
Description Standard
Valve lifter outer diameter 33.977 - 33.987 (1.3377 - 1.3381)
Valve lifter bore inner diameter 34.000 - 34.021 (1.3386 - 1.3394)
Clearance between lifter and lifter guide 0.013 - 0.044 (0.0005 - 0.0017)
Description Standard
Valve oil seal installation height (A) 12.1 (0.476)
Revision: November 20132014 Altima NAM
Page 2113 of 4801
![NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)EM-115
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
Valve Seat
Unit: mm (in)
Description Standard Service
Val](/img/5/57390/w960_57390-2112.png "NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)EM-115
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
Valve Seat
Unit: mm (in)
Description Standard Service
Val")
SERVICE DATA AND SPECIFICATIONS (SDS)EM-115
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
Valve Seat
Unit: mm (in)
Description Standard Service
Valve guide Outer diameter 10.023 - 10.034
(0.3946 - 0.3950) 10.223 - 10.234
(0.4025 - 0.4029)
Inner diameter (Finished size) 6.000 - 6.018 (0.2362 - 0.2369)
Cylinder head valve guide hole diameter 9.975 - 9.996
(0.3927 - 0.3935) 10.175 - 10.196
(0.4006 - 0.4014)
Interference fit of valve guide 0.027 - 0.059 (0.0011 - 0.0023) Standard
Valve guide clearance (Stan-
dard) Intake 0.020 - 0.053 (0.0008 - 0.0021)
Exhaust 0.030 - 0.063 (0.0012 - 0.0025)
Valve guide clearance (Limit) Intake 0.08 (0.003)
Exhaust 0.09 (0.004)
Projection length (L) Intake 10.1 - 10.3 (0.398 - 0.406)
Exhaust 10.0 - 10.4 (0.394 - 0.409)
PBIC0184E
Description Standard Service
Cylinder head seat recess diameter
(D) Intake 36.500 - 36.516 (1.4370 - 1.4376) 37.000 - 37.016 (1.4567 - 1.4573)
Exhaust 31.500 - 31.516 (1.2402 - 1.2408) 32.000 - 32.016 (1.2598 - 1.2605)
Valve seat interference fit Intake 0.081 - 0.113 (0.0032 - 0.0044)
Exhaust 0.084 - 0.116 (0.0033 - 0.0046)
Valve seat outer diameter (d) Intake 36.597 - 36.613 (1.4408 - 1.4415) 37.097 - 37.113 (1.4605 - 1.4611)
Exhaust 31.600 - 31.616 (1.2441 - 1.2447) 32.100 - 32.116 (1.2638 - 1.2644)
Diameter (d1) Intake 33.5 (1.319)
Exhaust 28.0 (1.102)
Diameter (d2) Intake 34.8 - 35.3 (1.370 - 1.390)
Exhaust 29.6 - 30.1 (1.165 - 1.185)
PBIC2745E
Revision: November 20132014 Altima NAM
Page 2114 of 4801
![NISSAN TEANA 2014 Service Manual
EM-116
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*1 Machining data
CAMSHAFT AND CAMSHAFT BEARING
Unit: mm (in)
*: Total indicator reading
CYLINDER BLOCK
A](/img/5/57390/w960_57390-2113.png "NISSAN TEANA 2014 Service Manual
EM-116
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*1 Machining data
CAMSHAFT AND CAMSHAFT BEARING
Unit: mm (in)
*: Total indicator reading
CYLINDER BLOCK
A")
EM-116
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*1 Machining data
CAMSHAFT AND CAMSHAFT BEARING
Unit: mm (in)
*: Total indicator reading
CYLINDER BLOCK
Angle (
α1) Intake 60
°
Exhaust 60 °
Angle ( α2) Intake 88
° 46' - 90 ° 14'
Exhaust 88 ° 46' - 90 ° 14'
Angle ( α3) Intake 120
°
Exhaust 120 °
Contacting width (W)*1 Intake 0.99 - 1.35 (0.0390 - 0.0531)
Exhaust 1.19 - 1.55 (0.0469 - 0.0610)
Standard
Camshaft runout [TIR*] Less than 0.02 (0.0008)
Cam height (A) Intake 45.865 - 46.055 (1.8057 - 1.8132)
Exhaust 44.175 - 44.365 (1.7392 - 1.7467)
Outer diameter of camshaft journal No. 1
27.935 - 27.955 (1.0998 - 1.1006)
No. 2, 3, 4, 5
23.435 - 23.455 (0.9226 - 0.9234)
Inner diameter of camshaft bracket No.1
28.000 - 28.021 (1.1024 - 1.1032)
No.2, 3, 4, 5
23.500 - 23.521 (0.9252 - 0.9260)
Camshaft journal clearance 0.045 - 0.086 (0.0018 - 0.0034)
Camshaft end play 0.115 - 0.188 (0.0045 - 0.0074)
Camshaft sprocket runout [TIR*] Less than 0.15 (0.0059)
SEM671
Revision: November 20132014 Altima NAM
Page 2115 of 4801
![NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)EM-117
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
PISTON, PISTON RING, AND PISTON PIN
Available Piston
Surfa](/img/5/57390/w960_57390-2114.png "NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)EM-117
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
PISTON, PISTON RING, AND PISTON PIN
Available Piston
Surfa")
SERVICE DATA AND SPECIFICATIONS (SDS)EM-117
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
PISTON, PISTON RING, AND PISTON PIN
Available Piston
Surface distortion Limit
0.1 (0.004)
Cylinder bore Inner diameter StandardGrade No. 2 89.010 - 89.020 (3.5043 - 3.5047)
Grade No. 3 89.020 - 89.030 (3.5047 - 3.5051)
Wear limit 0.2 (0.008)
Out-of-round (X − Y) Less than 0.015 (0.0006)
Taper (C − A) Less than 0.01 (0.0004)
Main journal inner
diameter grade
(Without bearing) Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W
Grade No. X
Grade No. Y
Grade No. 4
Grade No. 7 58.944 - 58.945 (2.3206 - 2.3207)
58.945 - 58.946 (2.3207 - 2.3207)
58.946 - 58.947 (2.3207 - 2.3207)
58.947 - 58.948 (2.3207 - 2.3208)
58.948 - 58.949 (2.3208 - 2.3208)
58.949 - 58.950 (2.3208 - 2.3209)
58.950 - 58.951 (2.3209 - 2.3209)
58.951 - 58.952 (2.3209 - 2.3209)
58.952 - 58.953 (2.3209 - 2.3210)
58.953 - 58.954 (2.3210 - 2.3210) 58.954 - 58.955 (2.3210 - 2.3211)
58.955 - 58.956 (2.3211 - 2.3211)
58.956 - 58.957 (2.3211 - 2.3211)
58.957 - 58.958 (2.3211 - 2.3212)
58.958 - 58.959 (2.3212 - 2.3212)
58.959 - 58.960 (2.3212 - 2.3213)
58.960 - 58.961 (2.3213 - 2.3213)
58.961 - 58.962 (2.3213 - 2.3213)
58.962 - 58.963 (2.3213 - 2.3214)
58.963 - 58.964 (2.3214 - 2.3214)
58.964 - 58.965 (2.3214 - 2.3215)
58.965 - 58.966 (2.3215 - 2.3215)
58.966 - 58.967 (2.3215 - 2.3215)
58.967 - 58.968 (2.3215 - 2.3216)
Difference in inner
diameter between
cylinders Standard Less than 0.03 (0.0012)
PBIC0281E
Revision: November 20132014 Altima NAM
Page 2116 of 4801
![NISSAN TEANA 2014 Service Manual
EM-118
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Piston Ring
Uni](/img/5/57390/w960_57390-2115.png "NISSAN TEANA 2014 Service Manual
EM-118
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Piston Ring
Uni")
EM-118
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Piston Ring
Unit: mm (in)
Piston Pin
Unit: mm (in)
CONNECTING ROD
Unit: mm (in)
Piston skirt diameter (A) StandardGrade* Dimension
Grade No. 2 88.990 - 89.000 (3.5035 - 3.5039)
Grade No. 3 89.000 - 89.010 (3.5039 - 3.5043)
(H) dimension 37.5 (1.476)
Piston pin bore diameter Grade No. 0 19.993 - 19.999 (0.7871 - 0.7874)
Grade No. 1 19.999 - 20.005 (0.7874 - 0.7876)
Piston clearance to cylinder block Standard 0.010 - 0.030 (0.0004 - 0.0012)
Limit 0.08 (0.0031)
PBIC0188E
Standard Limit
Side clearance Top 0.040 - 0.080 (0.0016 - 0.0031) 0.11 (0.0043)
2nd 0.030 - 0.070 (0.0012 - 0.0028) 0.10 (0.0039)
Oil ring 0.045 - 0.125 (0.0018 - 0.0049) —
End gap Top 0.21 - 0.31 (0.0083 - 0.0122) 0.53 (0.0209)
2nd 0.37 - 052 (0.0146 - 0.0205) 0.71 (0.0280)
Oil (rail ring) 0.20 - 0.45 (0.0079 - 0.0177) 0.80 (0.0315)
Piston pin outer diameter Grade No.0 19.989 - 19.995 (0.7870 - 0.7872)
Grade No.1 19.995 - 20.001 (0.7872 - 0.7874)
Piston to piston pin clearance (Standard) 0.002 - 0.006 (0.0001 - 0.0002)
Piston pin to connecting rod bushing clear-
ance Standard 0.005 - 0.017 (0.0002 - 0.0007)
Center distance 143.00 - 143.10 (5.63 - 5.63)
Bend [per 100 (3.94)] Limit 0.15 (0.0059)
Torsion [per 100 (3.94)] Limit 0.30 (0.0118)
Connecting rod small end inner diameter 22.000 - 22.012 (0.7874 - 0.7879)
Connecting rod small end inner
bushing diameter
1
Grade2Dimension
Grade No. 0 20.000 - 20.006 (0.7874 - 0.7876)
Grade No. 1 20.006 - 20.012 (0.7876 - 0.7879)
Connecting rod big end inner diameter 48.000 - 48.013 (1.8898 - 1.8903)
Revision: November 20132014 Altima NAM
Page 2117 of 4801
![NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)EM-119
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
1: After installing in connecting rod.
2: Always check with the Parts De](/img/5/57390/w960_57390-2116.png "NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)EM-119
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
1: After installing in connecting rod.
2: Always check with the Parts De")
SERVICE DATA AND SPECIFICATIONS (SDS)EM-119
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
1: After installing in connecting rod.
2: Always check with the Parts Department for the latest parts information.
CRANKSHAFT
Unit: mm (in)
Side clearance
Standard 0.20 - 0.35 (0.0079 - 0.0138)
Limit 0.50 (0.0197)
Connecting rod bearing housing Grade
2Dimension
Grade No. 0
Grade No. 1
Grade No. 2
Grade No. 3
Grade No. 4
Grade No. 5
Grade No. 6
Grade No. 7
Grade No. 8
Grade No. 9
Grade No. A
Grade No. B
Grade No. C 48.000 - 48.001 (1.8898 - 1.8898)
48.001 - 48.002 (1.8898 - 1.8898)
48.002 - 48.003 (1.8898 - 1.8899)
48.003 - 48.004 (1.8899 - 1.8899)
48.004 - 48.005 (1.8899 - 1.8899)
48.005 - 48.006 (1.8899 - 1.8900)
48.006 - 48.007 (1.8900 - 1.8900)
48.007 - 48.008 (1.8900 - 1.8901)
48.008 - 48.009 (1.8901 - 1.8901)
48.009 - 48.010 (1.8901 - 1.8902)
48.010 - 48.011 (1.8902 - 1.8902)
48.011 - 48.012 (1.8902 - 1.8902)
48.012 - 48.013 (1.8902 - 1.8903)
Pin journal dia. (DP) Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U 44.974 - 44.973 (1.7706 - 1.7706)
44.973 - 44.972 (1.7706 - 1.7705)
44.972 - 44.971 (1.7705 - 1.7705)
44.971 - 44.970 (1.7705 - 1.7705)
44.970 - 44.969 (1.7705 - 1.7704)
44.969 - 44.968 (1.7704 - 1.7704)
44.968 - 44.967 (1.7704 - 1.7704)
44.967 - 44.966 (1.7704 - 1.7703)
44.966 - 44.965 (1.7703 - 1.7703)
44.965 - 44.964 (1.7703 - 1.7702)
44.964 - 44.963 (1.7702 - 1.7702)
44.963 - 44.962 (1.7702 - 1.7702)
44.962 - 44.961 (1.7702 - 1.7701)
44.961 - 44.960 (1.7701 - 1.7701)
44.960 - 44.959 (1.7701 - 1.7700)
44.959 - 44.958 (1.7700 - 1.7700)
44.958 - 44.957 (1.7700 - 1.7700)
44.957 - 44.956 (1.7700 - 1.7699)
SEM645SEM715
Revision: November 20132014 Altima NAM
Page 2118 of 4801
![NISSAN TEANA 2014 Service Manual
EM-120
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Total indicator reading
MAIN BEARING
Unit: mm (in)
Main journal dia. (Dm) grade Grade No. A
Grade No.](/img/5/57390/w960_57390-2117.png "NISSAN TEANA 2014 Service Manual
EM-120
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Total indicator reading
MAIN BEARING
Unit: mm (in)
Main journal dia. (Dm) grade Grade No. A
Grade No.")
EM-120
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Total indicator reading
MAIN BEARING
Unit: mm (in)
Main journal dia. (Dm) grade Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W
Grade No. X
Grade No. Y
Grade No. 4
Grade No. 7 54.979 - 54.978 (2.1645 - 2.1645)
54.978 - 54.977 (2.1645 - 2.1644)
54.977 - 54.976 (2.1644 - 2.1644)
54.976 - 54.975 (2.1644 - 2.1644)
54.975 - 54.974 (2.1644 - 2.1643)
54.974 - 54.973 (2.1643 - 2.1643)
54.973 - 54.972 (2.1643 - 2.1642)
54.972 - 54.971 (2.1642 - 2.1642)
54.971 - 54.970 (2.1642 - 2.1642)
54.970 - 54.969 (2.1642 - 2.1641)
54.969 - 54.968 (2.1641 - 2.1641)
54.968 - 54.967 (2.1641 - 2.1641)
54.967 - 54.966 (2.1641 - 2.1640)
54.966 - 54.965 (2.1640 - 2.1640)
54.965 - 54.964 (2.1640 - 2.1639)
54.964 - 54.963 (2.1639 - 2.1639)
54.963 - 54.962 (2.1639 - 2.1639)
54.962 - 54.961 (2.1639 - 2.1638)
54.961 - 54.960 (2.1638 - 2.1638)
54.960 - 54.959 (2.1638 - 2.1637)
54.959 - 54.958 (2.1637 - 2.1637)
54.958 - 54.957 (2.1637 - 2.1637)
54.957 - 54.956 (2.1637 - 2.1636)
54.956 - 54.955 (2.1636 - 2.1636)
Center distance (r) 49.60 - 50.04 (1.9528 - 1.9701)
Out-of-round (X − Y) Standard Less than 0.005 (0.0002)
Taper (A − B) Standard Less than 0.005 (0.0002)
Runout [TIR*] Limit Less than 0.05 (0.002)
Free end play Standard 0.10 - 0.26 (0.0039 - 0.0102)
Limit 0.30 (0.0118)
Grade number* Thickness Identification color Remarks 0 1.973 - 1.976 (0.0777 - 0.0778) Black
Grade and color are the same
for upper and lower bearings.
1 1.976 - 1.979 (0.0778 - 0.0779) Brown
2 1.979 - 1.982 (0.0779 - 0.0780) Green
3 1.982 - 1.985 (0.0780 - 0.0781) Yellow
4 1.985 - 1.988 (0.0781 - 0.0783) Blue
5 1.988 - 1.991 (0.0783 - 0.0784) Pink
6 1.991 - 1.994 (0.0784 - 0.0785) Purple
7 1.994 - 1.997 (0.0785 - 0.0786) White
SEM685D
Revision: November 20132014 Altima NAM
Page 2119 of 4801
![NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)EM-121
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
*: Always check with the Parts Department for the latest parts informati](/img/5/57390/w960_57390-2118.png "NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)EM-121
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
*: Always check with the Parts Department for the latest parts informati")
SERVICE DATA AND SPECIFICATIONS (SDS)EM-121
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
*: Always check with the Parts Department for the latest parts information.
Undersize
Unit: mm (in)
Bearing Clearance
Unit: mm (in)
CONNECTING ROD BEARING
01
UPR 1.973 - 1.976 (0.0777 - 0.0778) Black
Grade and color are different
for upper and lower bearings.
LWR 1.976 - 1.979 (0.0778 - 0.0779) Brown
12 UPR 1.976 - 1.979 (0.0778 - 0.0779) Brown
LWR 1.979 - 1.982 (0.0779 - 0.0780) Green
23 UPR 1.979 - 1.982 (0.0779 - 0.0780) Green
LWR 1.982 - 1.985 (0.0780 - 0.0781) Yellow
34 UPR 1.982 - 1.985 (0.0780 - 0.0781) Yellow
LWR 1.985 - 1.988 (0.0781 - 0.0783) Blue
45 UPR 1.985 - 1.988 (0.0781 - 0.0783) Blue
LWR 1.988 - 1.991 (0.0783 - 0.0784) Pink
56 UPR 1.988 - 1.991 (0.0783 - 0.0784) Pink
LWR 1.991 - 1.994 (0.0784 - 0.0785) Purple
67 UPR 1.991 - 1.994 (0.0784 - 0.0785) Purple
LWR 1.994 - 1.997 (0.0785 - 0.0786) White
Size U.S. Thickness Main journal diameter
0.25 (0.0098) 2.106 - 2.114 (0.0829 - 0.0832) Grind so that bearing clearance is the spec-
ified value.
Main bearing oil clearance StandardNo.1, 3, and 5 0.012 - 0.022 (0.0005 - 0.0009)
No.2 and 4 0.018 - 0.028 (0.0007 - 0.0011)
Limit 0.1 (0.004)
Grade number* Thickness mm (in) Identification color (mark) 0 (upper) 1.496 - 1.493 (0.0589 - 0.0588) Black-Black0 (lower) 1.496 - 1.493 (0.0589 - 0.0588) Black-Black
01 (upper) 1.496 - 1.493 (0.0589 - 0.0588) Black-Black 01 (lower) 1.499 - 1.496 (0.0590 - 0.0589) Brown-Brown 1 (upper) 1.499 - 1.496 (0 .0590 - 0.0589) Brown-Brown
1 (lower) 1.499 - 1.496 (0 .0590 - 0.0589) Brown-Brown
12 (upper) 1.499 - 1.496 (0.0590 - 0.0589) Brown-Brown 12 (lower) 1.502 - 1.499 (0.0591 - 0.0590) Green-Green 2 (upper) 1.502 - 1.499 (0.0591 - 0.0590) Green-Green2 (lower) 1.502 - 1.499 (0.0591 - 0.0590) Green-Green
23 (upper) 1.502 - 1.499 (0.0591 - 0.0590) Green-Green 23 (lower) 1.505 - 1.502 (0.0593 - 0.0591) Yellow-Yellow 3 (upper) 1.505 - 1.502 (0.0593 - 0.0591) Yellow-Yellow3 (lower) 1.505 - 1.502 (0.0593 - 0.0591) Yellow-Yellow
34 (upper) 1.505 - 1.502 (0.0593 - 0.0591) Yellow-Yellow 34 (lower) 1.508 - 1.505 (0.0594 - 0.0593) Blue-Blue 4 (upper) 1.508 - 1.505 (0.0594 - 0.0593) Blue-Blue4 (lower) 1.508 - 1.505 (0.0594 - 0.0593) Blue-Blue
Revision: November 20132014 Altima NAM
Page 2120 of 4801
![NISSAN TEANA 2014 Service Manual
EM-122
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Always check with the Parts Department for the latest parts information.
Undersize
Unit: mm (in)
Beari](/img/5/57390/w960_57390-2119.png "NISSAN TEANA 2014 Service Manual
EM-122
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Always check with the Parts Department for the latest parts information.
Undersize
Unit: mm (in)
Beari")
EM-122
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Always check with the Parts Department for the latest parts information.
Undersize
Unit: mm (in)
Bearing Clearance
Unit: mm (in)
Size U.S. Thickness Crank pin journal diameter
0.25 (0.0098) 1.622 - 1.630 (0.0639 - 0.0642) Grind so that bearing clearance is the spec-
ified value.
Connecting rod bearing clear-
ance Standard 0.035 - 0.045 (0.0014 - 0.0018)
Limit 0.10 (0.0039)
Revision: November 20132014 Altima NAM
