NISSAN TEANA 2014 Service Manual

DEF-6
< SYSTEM DESCRIPTION >
COMPONENT PARTS
Component Description
INFOID:0000000009463023
1: With auto A/C
2: With manual A/C
3: With heated mirrors Component Description
BCM • Operates the rear window defogger with the operation of rear window defogger switch.
• Performs the timer control of rear window defogger.
Rear window defogger relay • Operates the rear window defogger and the door mirror defogger with the control signal from
BCM.
A/C auto amp
1• Displays the rear window defogger ON to the display when detecting the operation of the rear window defogger.
A/C switch assembly
1 (rear
window defogger switch) • The rear window defogger switch is turned ON.
Front air control
2 (rear window
defogger switch) • The rear window defogger switch is turned ON.
• Turns the indicator lamp ON when detecting the operation of rear window defogger.
Rear window defogger • Heats the heating wire with the power supply from the rear window defogger relay to prevent
the rear window from fogging up.
Door mirror defogger
3• Heats the heating wire with the power supply from the rear window defogger relay to prevent the door mirror from fogging up.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

SYSTEMDEF-7
< SYSTEM DESCRIPTION >
C
D E
F
G H
I
J
K
M A
B
DEF
N
O P
SYSTEM
System DiagramINFOID:0000000009463024
System DescriptionINFOID:0000000009463025
Operation Description
• When rear window defogger switch is turned ON while ignition switch is ON, the rear window defogger switch transmits rear window defogger switch signal to BCM.
• BCM turns rear window defogger relay ON when rear window defogger switch signal is received.
• Rear window defogger and door mirror defogger (with door mirror defogger) are supplied with power and
operate when rear window defogger relay turns ON.
• Rear window defogger ON is displayed when front air c ontrol (manual A/C) or A/C switch assembly (auto A/
C) receives signals.
Timer function
• BCM turns rear window defogger relay ON for approx imately 15 minutes when rear window defogger switch
is turned ON while ignition switch is ON. It makes rear window defogger and door mirror defogger (with door
mirror defogger) operate.
• Timer is canceled after pressing rear window defogger switch again during timer operation. Then BCM turns
rear window defogger relay OFF. The same reaction also occurs during timer operation, if the ignition switch
is turned OFF.
INPUT/OUTPUT SIGNAL CHART
*: With door mirror defogger
ALLIA1146GB
Switch Input signal to BCM BCM function Actuator
Rear window defogger switch Defogger switch signal Rear window defogger and door
mirror defogger
* control Rear window defogger
Door mirror defogger *Push button ignition switch Ignition signal
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DEF-8
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Function (BCM - COMMON ITEM)INFOID:0000000009956271
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentially causing a di scharged battery and a no-start condition.
APPLICATION ITEM
CONSULT performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions.
Direct Diagnostic Mode Description
Ecu Identification The BCM part number is displayed.
Self Diagnostic Result The BCM self diagnostic results are displayed.
Data Monitor The BCM input/output data is displayed in real time.
Active Test The BCM activates outputs to test components.
Work support The settings for BCM functions can be changed.
Configuration • The vehicle specification can be read and saved.
• The vehicle specification can be written when replacing BCM.
CAN Diag Support Mntr The result of transmit/receive diagnosis of CAN communication is displayed.
System Sub System Direct Diagnostic Mode
Ecu Identification
Self Diagnostic Result
Data Monitor
Active Test
Work support
Configuration
CAN Diag Su pport Mntr
Door lock DOOR LOCK ××××
Rear window defogger REAR DEFOGGER ×××
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Remote keyless entry system MULTI REMOTE ENT ×××
Exterior lamp HEADLAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ××
Air conditioner AIR CONDITIONER ×
Intelligent Key system INTELLIGENT KEY ××××
Combination switch COMB SW ×
BCM BCM × × ×××
Immobilizer IMMU ×××
Interior room lamp battery saver BATTERY SAVER ××
Trunk open TRUNK ×
Vehicle security system THEFT ALM ×××
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DIAGNOSIS SYSTEM (BCM)DEF-9
< SYSTEM DESCRIPTION >
C
D E
F
G H
I
J
K
M A
B
DEF
N
O P
REAR DEFOGGER
REAR DEFOGGER : CONSULT Func tion (BCM - REAR DEFOGGER)INFOID:0000000009956272
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentiall y causing a discharged battery and a no-start condition.
DATA MONITOR
ACTIVE TEST
WORK SUPPORT
* : Initial setting RAP system RETAINED PWR
×
Signal buffer system SIGNAL BUFFER ×
TPMS AIR PRESSURE MONITOR ××××
System Sub System
Direct Diagnostic Mode
Ecu Identification
Self Diagnostic Result
Data Monitor
Active Test
Work support
Configuration
CAN Diag Support Mntr
Monitor Item [Unit] Description
PUSH SW [On/Off] Indicates condition of push-button ignition switch.
REAR DEF SW [On/Off] Indicates condition of rear window defogger switch.
Test Item Description
REAR DEFOGGER This test is able to check rear window defogger operation [Off/On].
Support Item Setting Description
SET R-DEF TIMER MODE3 Rear defogger turns OFF after 1 minute.
MODE2 Rear defogger remains ON until turned OFF.
MODE1* Rear defogger turns OFF after 15 minutes.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DEF-10
< ECU DIAGNOSIS INFORMATION >
BCM (BODY CONTROL MODULE)
ECU DIAGNOSIS INFORMATION
BCM (BODY CONTROL MODULE)
List of ECU ReferenceINFOID:0000000009463028
ECU Reference
BCM BCS-31, "Reference Value"

BCS-50, "Fail Safe"
BCS-50, "DTC Inspection Priority Chart"
BCS-52, "DTC Index"
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

REAR WINDOW DEFOGGER SYSTEMDEF-11
< WIRING DIAGRAM >
C
D E
F
G H
I
J
K
M A
B
DEF
N
O P
WIRING DIAGRAM
REAR WINDOW DEFOGGER SYSTEM
Wiring DiagramINFOID:0000000009463029
ABLWA2244GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DEF-12
< WIRING DIAGRAM >
REAR WINDOW DEFOGGER SYSTEM
ABLIA5200GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

REAR WINDOW DEFOGGER SYSTEMDEF-13
< WIRING DIAGRAM >
C
D E
F
G H
I
J
K
M A
B
DEF
N
O P
ABLIA5175GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DEF-14
< WIRING DIAGRAM >
REAR WINDOW DEFOGGER SYSTEM
ABLIA5176GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

REAR WINDOW DEFOGGER SYSTEMDEF-15
< WIRING DIAGRAM >
C
D E
F
G H
I
J
K
M A
B
DEF
N
O P
ABLIA5177GB
