NISSAN TEANA 2014 Service Manual

DEF-36
< SYMPTOM DIAGNOSIS >
REAR WINDOW DEFOGGER DOES NOT OPERATE BUT BOTH OF DOOR MIR-
ROR DEFOGGER OPERATE.
REAR WINDOW DEFOGGER DOES NO T OPERATE BUT BOTH OF DOOR
MIRROR DEFOGGER OPERATE.
Diagnosis ProcedureINFOID:0000000009463055
1. CHECK REAR WINDOW DEFOGGER POWER SUPPLY AND GROUND CIRCUIT
Check rear window defogger power supply and ground circuit.
Refer to DEF-28, "Component Function Check"
.
Is the inspection result normal?
YES >> Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BOTH DOORS MIRROR DEFOGGER DON’T OPERATE BUT REAR WINDOW DEFOGGER OPERATES
DEF-37
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
DEF
N
O P
BOTH DOORS MIRROR DEFOGGER DON’T OPERATE BUT REAR WIN-
DOW DEFOGGER OPERATES
Diagnosis ProcedureINFOID:0000000009463056
Regarding Wiring Diagram information, refer to DEF-11, "Wiring Diagram".
1. CHECK DOOR MIRROR DEFOGGER FUSE
Check if the following fuse in fuse block (J/B) is blown.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the blown fuse after repairing the affected circuit.
2. CHECK DOOR MIRROR DEF OGGER POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between fuse block (J/B) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace fuse block (J/B).
3. CHECK BOTH DOOR MIRROR DEFOGGER
1. Check door mirror LH. Refer to DEF-30, "Component Function Check"
.
2. Check door mirror RH. Refer to DEF-32, "Component Function Check"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
COMPONENT PARTS AMPERE FUSE NO.
Fuse block (J/B) 10A 22
(+) (–) Condition Voltage (V)
(Approx.)
Fuse block (J/B)
Connector Terminal
M5 5P Ground Rear window de-
fogger switch ON Battery voltage
OFF 0
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DEF-38
< SYMPTOM DIAGNOSIS >
DRIVER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
DRIVER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
Diagnosis ProcedureINFOID:0000000009463057
1. CHECK DOOR MIRROR DEFOGGER LH
Check door mirror defogger LH.
Refer to DEF-30, "Component Function Check"
.
Is the inspection result normal?
YES >> Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

PASSENGER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
DEF-39
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
DEF
N
O P
PASSENGER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
Diagnosis ProcedureINFOID:0000000009463058
1. CHECK DOOR MIRROR DEFOGGER RH
Check door mirror defogger RH.
Refer to DEF-32, "Component Function Check"
.
Is the inspection result normal?
YES >> Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DEF-40
< SYMPTOM DIAGNOSIS >
REAR WINDOW DEFOGGER SWITCH DOES NOT LIGHT, BUT REAR WINDOW
DEFOGGER OPERATES
REAR WINDOW DEFOGGER SWITCH DOES NOT LIGHT, BUT REAR WIN-
DOW DEFOGGER OPERATES
Diagnosis ProcedureINFOID:0000000009463059
1. CHECK REAR WINDOW DEFOGGER SWITCH
Check that the rear window defogger switch is operating normally.
Is the inspection result normal?
YES >> Refer to GI-43, "Intermittent Incident".
NO >> Refer to DEF-19, "WITH MANUAL A/C : Diagnosis Procedure"
or DEF-22, "WITH AUTO A/C :
Diagnosis Procedure".
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

FILAMENTDEF-41
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
K
M A
B
DEF
N
O P
REMOVAL AND INSTALLATION
FILAMENT
Inspection and RepairINFOID:0000000009463060
INSPECTION
1. When measuring voltage, wrap tin foil around the top of the neg- ative probe. Then press the foil against the wire with your finger.
2. Attach probe circuit tester (in Volt range) to middle portion of each filament.
3. If a filament is burned out, circuit tester registers 0 or battery voltage.
4. To locate burned out point, move probe to left and right along fil- ament. Test needle will swing abruptly when probe passes the
point.
REPAIR
REPAIR EQUIPMENT
• Conductive silver composition (Dupont No. 4817 or equivalent)
SEL122R
SEL263
SEL265
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

DEF-42
< REMOVAL AND INSTALLATION >
FILAMENT
• Ruler 30 cm (11.8 in) long
• Drawing pen
• Heat gun
• Alcohol
• Cloth
REPAIRING PROCEDURE
1. Wipe broken heat wire and its surrounding area clean with a
cloth dampened in alcohol.
2. Apply a small amount of conductive silver composition to tip of drawing pen.
NOTE:
Shake silver composition container before use.
3. Place ruler on glass along broken line. Deposit conductive silver composition on break with drawing pen. Slightly overlap existing
heat wire on both sides [preferably 5 mm (0.20 in)] of the break.
4. After repair has been completed, check repaired wire for conti- nuity. This check should be conducted 10 minutes after silver
composition is deposited.
CAUTION:
Do not touch repaired area wh ile test is being conducted.
5. Apply a constant stream of hot air directly to the repaired area for approximately 20 minutes with a heat gun. A minimum dis-
tance of 3 cm (1.2 in) should be kept between repaired area and
hot air outlet.
NOTE:
If a heat gun is not available, let the repaired area dry for 24
hours.
PIIA0215E
SEL012D
SEL013D
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

CONDENSERDEF-43
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
K
M A
B
DEF
N
O P
CONDENSER
Removal and InstallationINFOID:0000000009463061
REMOVAL
1. Remove the rear pillar finisher. Refer to INT-25, "REAR PILLAR FINISHER : Removal and Installation".
2. Disconnect the harness connector from the condenser.
3. Remove the bolt (A) and the condenser (1).
INSTALLATION
Installation is in the reverse order of removal.
ALLIA1144ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
