NISSAN TERRANO 2004 Service Repair Manual

A/T Fluid Temperature Sensor and TCM Power
Source
DESCRIPTION
The A/T fluid temperature sensor detects the A/T fluid temperature
and sends a signal to the TCM.
ON BOARD DIAGNOSIS LOGIC
Diagnostic trouble codeMalfunction is detected when ... Check items
(Possible cause)
: BATT/FLUID TEMP SEN
TCM receives an excessively low or
high voltage from the sensor.I
Harness or connectors
(The sensor circuit is open or
shorted.)
I A/T fluid temperature sensor
: 8th judgement flicker
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Remarks: Specification data are reference values.
Monitor item ConditionSpecification
A/T fluid temperature sensor Cold [20ÉC (68ÉF)]
"
Hot [80ÉC (176ÉF)] Approximately
1.5V"
Approximately 0.5V
SELF-DIAGNOSIS CODE CONFIRMATION PROCEDURE
After the repair, perform the following procedure to confirm the
malfunction is eliminated.
1) Start engine.
2) Select ªSELF-DIAG RESULTSº mode with CONSULT-II.
3) Drive vehicle under the following conditions:Selector lever in ªDº position, vehicle speed higher than
10 km/h (6 MPH), throttle opening greater than 1/8 of the
full open position, engine speed higher than 450 rpm
and driving for more than 10 minutes.
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- -OR------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
1) Start engine.
2) Drive vehicle under the following conditions:
Selector lever in ªDº position, vehicle speed higher than
10 km/h (6 MPH), throttle opening greater than 1/8 of the
full open position, engine speed higher than 450 rpm
and driving for more than 10 minutes.
3) Perform self-diagnosis. Refer to SELF-DIAGNOSTIC PROCEDURE (Without
CONSULT-II), AT-15.
SAT342HA
SAT821H
TROUBLE DIAGNOSIS FOR BATT/FLUID TEMP SEN
AT-78
http://vnx.su/

DIAGNOSTIC PROCEDURE
CHECK TCM POWER SOURCE.
1. Turn ignition switch to ªONº position.(Do not start engine.)
2. Check voltage between TCM terminals q
10,q19and ground.
Battery voltage should exist.
OK
ENG Check the following items:
IHarness for short or
open between ignition
switch and TCM (Main
harness)
I Ignition switch and fuse
Refer to EL section
(ªPOWER SUPPLY
ROUTINGº).
CHECK A/T FLUID TEMPERATURE
SENSOR WITH TERMINAL CORD
ASSEMBLY.
1. Turn ignition switch to ªOFFº position.
2. Disconnect terminal cord assembly connector in engine compartment.
3. Check resistance between terminals q
6
andq7when A/T is cold.
Resistance: Cold [20ÉC (68ÉF)]Approximately 2.5 kW
4. Reinstall any part removed.
OK
ENG 1. Remove oil pan.
2. Check the following items:
I A/T fluid temperature
sensor
Refer to ªCOMPONENT
INSPECTIONº on next
page.
I Harness of terminal cord
assembly for short or
open
qA
(Go to next page.)
YAT418
YAT317
H
H
TROUBLE DIAGNOSIS FOR BATT/FLUID TEMP SEN
A/T Fluid Temperature Sensor and TCM Power
Source (Cont'd)
AT-79
http://vnx.su/

qA
CHECK INPUT SIGNAL OF A/T FLUID
TEMPERATURE SENSOR.
1. Start engine.2. Select ªECU INPUT SIGNALSº in Data Monitor.
3. Read out the value of ªFLUID TEMP SEº.
Voltage:
Cold [20ÉC (68ÉF)] ®
Hot [80ÉC (176ÉF)]: Approximately
1.5V ®0.5V
---------------------------------------------------------------------------------------------------------------------- -OR -----------------------------------------------------------------------------------------------------------------------
1. Start engine.
2. Check voltage between TCM ter- minal q
47and ground while warm-
ing up A/T.
Voltage:
Cold [20ÉC (68ÉF)] ®
Hot [80ÉC (176ÉF)]: Approximately
1.5V ®0.5V
OK
ENG
Check the following item:
IHarness for short or
open between TCM and
terminal cord assembly
(Main harness)
Perform ªSELF-DIAGNOSIS CODE CON-
FIRMATION PROCEDUREº, AT-78.
OK
ENG
1. Perform TCM input/
output signal inspection.
2. If NG, recheck TCM pin terminals for damage or
loose connection with
harness connector.
INSPECTION END
COMPONENT INSPECTION
A/T fluid temperature sensor
I For removal, refer to AT-118.
I Check resistance between terminals q
6andq7while chang-
ing temperature as shown at left.
Temperature ÉC (ÉF) Resistance
20 (68) Approximately 2.5 kW
80 (176) Approximately 0.3 kW
YAT419
YAT319
H
H
H
TROUBLE DIAGNOSIS FOR BATT/FLUID TEMP SEN
A/T Fluid Temperature Sensor and TCM Power
Source (Cont'd)
AT-80
http://vnx.su/

Wiring Diagram Ð AT Ð ENGSS
YAT271
TROUBLE DIAGNOSIS FOR ENGINE SPEED SIG
AT-81
http://vnx.su/

Engine Speed Signal
