DLK-632
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
U1010 CONTROL UNIT (CAN)
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000001397232
CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Modern
vehicle is equipped with many electronic control unit, and each control unit shares information and links with
other control units during operation (not independent). In CAN communication, control units are connected
with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less
wiring. Each control unit transmits/receives data but selectively reads required data only.
CAN Communication Signal Chart, refer to XX-XX, "*****"
.
DTC LogicINFOID:0000000001397233
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000001397234
1.REPLACE BCM
When DTC [U1010] is detected, replace BCM.
>> Replace BCM. Refer to BCS-57, "
Removal and Installation of BCM".
Special Repair RequirementINFOID:0000000001397235
1.REQUIRED WORK WHEN REPLACING INTELLIGENT KEY UNIT
Initialize control unit. Refer to CONSULT-III operation manual.
>> Work end.
DTCCONSULT-III display de-
scriptionDTC Detection Condition Possible cause
U1010 CONTROL UNIT (CAN)When detecting error during the initial diagnosis of CAN control-
ler of BCM.BCM

POWER SUPPLY AND GROUND CIRCUIT
DLK-633
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
POWER SUPPLY AND GROUND CIRCUIT
BCM
BCM : Diagnosis ProcedureINFOID:0000000001530747
Refer to BCS-30, "Diagnosis Procedure".

DLK-634
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR LOCK AND UNLOCK SWITCH
DOOR LOCK AND UNLOCK SWITCH
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000001530748
Transmits door lock/unlock operation to BCM.
DRIVER SIDE : Component Function CheckINFOID:0000000001530749
1.CHECK FUNCTION
With CONSULT-III
Check “CDL LOCK SW ”and “CDL UNLOCK SW” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door lock and unlock switch is OK.
NO >> Refer to DLK-634, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000001530750
1.CHECK DOOR LOCK AND UNLOCK INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect door lock and unlock switch connector.
3. Using an oscilloscope, check voltage between door lock and
unlock switch harness connector (A) D7 terminal 6, connector
(B) D8 terminal 18 and ground.
Is the inspection result normal?
YES >> GO TO 3.
Monitor item Condition
CDL LOCK SW LOCK : ON
UNLOCK : OFF
CDL UNLOCK SW LOCK : OFF
UNLOCK : ON
ALKIA0737ZZ
Te r m i n a l
Signal
(Reference value) (+)
(–)
Door lock and unlock switch
connectorTe r m i n a l
D7 6
Ground
D8 18
JPMIA0154GB

DOOR LOCK AND UNLOCK SWITCH
DLK-635
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
NO >> GO TO 2.
2.CHECK DOOR LOCK AND UNLOCK SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM connector (A) M18 terminals 6,
25 and door lock and unlock switch connector (B) D7 terminal 6,
connector (C) D8 terminal 18.
4. Check continuity between BCM connector (A) M18 terminals 6, 25 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
3.CHECK DOOR LOCK AND UNLOCK SWITCH GROUND
Check continuity between main power window and door lock/unlock
switch connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
4.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
ALKIA0738ZZ
BCM connector TerminalDoor lock and unlock
switch connectorTerminal Continuity
M186D8 18
Ye s
25 D7 6
BCM connector Terminal
GroundContinuity
M186
No
25
LIIA0392E
Main power window and door lock/unlock
switch connectorTe r m i n a l
GroundContinuity
D8 17 Yes

DLK-636
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR LOCK AND UNLOCK SWITCH
2. Check signal between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 6.
5.CHECK DOOR LOCK AND UNLOCK SWITCH
Check door lock and unlock switch
Refer to DLK-636, "
DRIVER SIDE : Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace door lock and unlock switch. Refer to XX-XX, "*****"
.
6.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
DRIVER SIDE : Component InspectionINFOID:0000000001530751
1.CHECK DOOR LOCK AND UNLOCK SWITCH
Check continuity between main power window and door lock/unlock
switch terminals.
ALKIA0739ZZ
Te r m i n a l
Signal
(Reference value) (+)
(–)
BCM connector Terminal
M186
Ground
25
JPMIA0154GB
ALKIA0740ZZ

DOOR LOCK AND UNLOCK SWITCH
DLK-637
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Is the inspection result normal?
YES >> Main power window and door lock/unlock switch is OK.
NO >> Replace main power window and door lock/unlock switch. Refer to XX-XX, "*****"
.
PASSENGER SIDE
PASSENGER SIDE : DescriptionINFOID:0000000001530752
Transmits door lock/unlock operation to BCM.
PASSENGER SIDE : Component Function CheckINFOID:0000000001530753
1.CHECK FUNCTION
With CONSULT-III
Check “CDL LOCK SW ”and “CDL UNLOCK SW” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Power window and door lock/unlock switch (passenger side) is OK.
NO >> Refer to DLK-637, "
PASSENGER SIDE : Diagnosis Procedure".
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000001530754
1.CHECK DOOR LOCK AND UNLOCK INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect power window and door lock/unlock switch (passenger side) connector.
3. Using an oscilloscope, check voltage between passenger door
lock and unlock switch harness connector (A) D105 terminals 1,
2 and ground.
Door lock and unlock switch Terminals Condition Continuity
D7, D86
17UNLOCK Yes
NEUTRAL/LOCK No
18LOCK Yes
NEUTRAL/UNLOCK No
Monitor item Condition
CDL LOCK SW LOCK : ON
UNLOCK : OFF
CDL UNLOCK SW LOCK : OFF
UNLOCK : ON
ALKIA0829ZZ

DLK-638
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR LOCK AND UNLOCK SWITCH
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK PASSENGER DOOR LOCK AND UNLOCK SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM connector (A) M18 terminals 6,
25 and passenger door lock/unlock switch connector (B) D105
terminals 1, 2.
4. Check continuity between BCM connector (A) M18 terminals 6, 25 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
3.CHECK PASSENGER DOOR LOCK AND UNLOCK SWITCH GROUND
Te r m i n a l
Signal
(Reference value) (+)
(–) Power window and door lock/
unlock switch (passenger side)
connectorTe r m i n a l
D1051
Ground
2
JPMIA0154GB
ALKIA0830ZZ
BCM connector TerminalPassenger door lock
and unlock switch
connectorTerminal Continuity
M186
D1051
Ye s
25 2
BCM connector Terminal
GroundContinuity
M186
No
25

DOOR LOCK AND UNLOCK SWITCH
DLK-639
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Check continuity between power window and door lock/unlock
switch (passenger side) connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
4.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
2. Check signal between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 6.
5.CHECK DOOR LOCK AND UNLOCK SWITCH
Check door lock and unlock switch
Refer to DLK-640, "
PASSENGER SIDE : Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace power window and door lock/unlock switch (passenger side). Refer to XX-XX, "*****"
.
ALKIA0831ZZ
Power window and door lock/unlock switch
(passenger side) connectorTe r m i n a l
GroundContinuity
D105 3 Yes
ALKIA0739ZZ
Te r m i n a l
Signal
(Reference value) (+)
(–)
BCM connector Terminal
M186
Ground
25
JPMIA0154GB

DLK-640
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR LOCK AND UNLOCK SWITCH
6.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
PASSENGER SIDE : Component InspectionINFOID:0000000001530755
1.CHECK DOOR LOCK AND UNLOCK SWITCH
Check continuity between power window and door lock/unlock
switch (passenger side) terminals.
Is the inspection result normal?
YES >> Power window and door lock/unlock switch (passenger side) is OK.
NO >> Replace power window and door lock/unlock switch (passenger side). Refer to XX-XX, "*****"
.
WIIA1108E
Door lock and unlock switch Terminals Condition Continuity
D1051
3LOCK Yes
NEUTRAL/UNLOCK No
2UNLOCK Yes
NEUTRAL/LOCK No

INSTRUMENT PANEL WARNING LAMP ASSEMBLY
DLK-641
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
INSTRUMENT PANEL WARNING LAMP ASSEMBLY
DescriptionINFOID:0000000001530756
The door lock and unlock switch indicates door lock status. The indicator will illuminate when a lock operation
is accomplished, and during this status, if any door is opened, the indicator will turn OFF.
Component Function CheckINFOID:0000000001530757
1.CHECK FUNCTION
With CONSULT-III
Check “DOOR LOCK IND” in “Active Test” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door lock and unlock switch is OK.
NO >> Refer to DLK-641, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001530758
1.CHECK DOOR LOCK AND UNLOCK SWITCH INDICATOR INPUT SIGNAL
Lock and unlock the door lock system using the main power window and door lock/unlock switch.
Does the door lock system operate properly?
YES >> GO TO 2.
NO >> Repair the power door lock system. Refer to DLK-634, "
DRIVER SIDE :
ComponentFunctionCheck".
2.CHECK DOOR LOCK AND UNLOCK SWITCH INDICATOR INPUT SIGNAL
1. Turn ignition switch OFF.
2. Open and keep the driver door open for the duration of this test.
3. Disconnect instrument panel warning lamp assembly.
4. Check voltage between instrument panel warning lamp assem-
bly connector M37 terminals 3 and 5.
Is the inspection result normal?
YES >> Replace instrument panel warning lamp.
NO >> GO TO 3.
Test item Condition
DOOR LOCK IND:ON Illuminated
:OFF Not illuminated
ALKIA0832ZZ
Instrument panel warning lamp assembly connector
ConditionVo l ta g e
(Approx.)
Te r m i n a l s
3 (+) 5(-)Press the door lock switch to the
LOCK positionBattery voltage
Press the door lock switch to the
UNLOCK position0
