NISSAN TIIDA 2007 Service Repair Manual

DLK-642
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
INSTRUMENT PANEL WARNING LAMP ASSEMBLY
3.CHECK DOOR LOCK AND UNLOCK SWITCH INDICATOR INPUT SIGNAL
Check continuity between instrument panel warning lamp assembly
connector M37 terminal 5 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness ground.
4.CHECK DOOR LOCK AND UNLOCK SWITCH CIRCUIT
1. Disconnect BCM.
2. Check continuity between BCM connector (A) M18 terminal 32
and instrument panel warning lamp assembly connector (B)
M37 terminal 3.
3. Check continuity between BCM connector (A) M18 terminal 32 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
5.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
ALKIA0833ZZ
instrument panel warning lamp assembly
connectorTe r m i n a l
GroundContinuity
M37 5 Yes
ALKIA0834ZZ
BCM connector TerminalInstrument panel warning lamp
assembly connectorTerminal Continuity
M18 32 M37 3 Yes
BCM connector Terminal
GroundContinuity
M18 32 No

INSTRUMENT PANEL WARNING LAMP ASSEMBLY
DLK-643
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace BCM. Refer to BCS-57, "
Removal and Installation of BCM".
6.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
ALKIA0835ZZ
Terminal
ConditionVo l ta g e
(Approx.) (+)
(–)
BCM connector Terminal
M18 32 GroundPress the door lock switch to the
LOCK positionBattery voltage
Press the door lock switch to the
UNLOCK position0

DLK-644
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR SWITCH
DOOR SWITCH
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000001530759
Detects door open/closed condition.
DRIVER SIDE : Component Function CheckINFOID:0000000001530760
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-DR” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-644, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000001530761
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
Monitor item Condition
DOOR SW-DR OPEN :ON
CLOSE :OFF
ALKIA0745ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M18 29 GroundOPEN 0
CLOSE
JPMIA0011GB

DOOR SWITCH
DLK-645
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
1. Disconnect BCM and driver door switch connectors.
2. Check continuity between BCM connector (A) M18 terminal 29
and door switch connector (B) B34 terminal 2.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and door switch.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-645, "
DRIVER SIDE : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace front door switch (driver side). Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
DRIVER SIDE : Component InspectionINFOID:0000000001530762
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Check door switch.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace front door switch (driver side). Refer to XX-XX, "*****"
.
PASSENGER SIDE
BCM connector TerminalDoor switch
connectorTerminal Continuity
M18 29 B34 2 Yes
BCM connector Terminal
GroundContinuity
M18 29 No
ALKIA0746ZZ
ALKIA0747ZZ
Te r m i n a l
Door switch condition Continuity
Door switch
2 Ground part of door switchPressed Yes
Released No

DLK-646
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR SWITCH
PASSENGER SIDE : Description
INFOID:0000000001530763
Detects door open/closed condition.
PASSENGER SIDE : Component Function CheckINFOID:0000000001530764
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-AS” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-646, "
PASSENGER SIDE : Diagnosis Procedure".
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000001530765
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM and passenger door switch connectors.
Monitor item Condition
DOOR SW-ASOPEN : ON
CLOSE : OFF
ALKIA0749ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M18 30 GroundOPEN 0
CLOSE
JPMIA0011GB

DOOR SWITCH
DLK-647
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM connector (A) M18 terminal 30
and passenger door switch connector (B) B27 terminal 2.
3. Check continuity between BCM connector (A) M18 terminal 30
and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and door switch.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-647, "
PASSENGER SIDE : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace front door switch (passenger side). Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
PASSENGER SIDE : Component InspectionINFOID:0000000001530766
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Check passenger door switch.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace front door switch (passenger side). Refer to XX-XX, "*****"
.
REAR LH
BCM connector TerminalDoor switch
connectorTerminal Continuity
M18 30 B27 2 Yes
BCM connector Terminal
GroundContinuity
M18 30 No
ALKIA0748ZZ
ALKIA0747ZZ
Te r m i n a l
Door switch condition Continuity
Door switch
2 Ground part of door switchPressed Yes
Released No

DLK-648
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR SWITCH
REAR LH : Description
INFOID:0000000001530767
Detects door open/closed condition.
REAR LH : Component Function CheckINFOID:0000000001530768
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-RL” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-648, "
REAR LH : Diagnosis Procedure".
REAR LH : Diagnosis ProcedureINFOID:0000000001530769
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector and rear door switch LH.
Monitor item Condition
DOOR SW-RLOPEN :ON
CLOSE :OFF
ALKIA0750ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M19 59 GroundOPEN 0
CLOSE
JPMIA0011GB

DOOR SWITCH
DLK-649
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM connector (A) M19 terminal 59
and rear door switch LH connector (B) B71 terminal 1.
3. Check continuity between BCM connector (A) M19 terminal 59
and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and rear door switch LH.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-649, "
REAR LH : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace rear door switch LH. Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
REAR LH : Component InspectionINFOID:0000000001530770
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Check rear door switch LH.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace rear door switch LH. Refer to XX-XX, "*****"
.
REAR RH
BCM connector TerminalRear door switch LH
connectorTerminal Continuity
M19 59 B71 1 Yes
BCM connector Terminal
GroundContinuity
M19 59 No
ALKIA0751ZZ
ALKIA0752ZZ
Te r m i n a l
Door switch condition Continuity
Door switch
1Ground part of door
switchPressed Yes
Released No

DLK-650
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR SWITCH
REAR RH : Description
INFOID:0000000001530771
Detects door open/close condition.
REAR RH : Component Function CheckINFOID:0000000001530772
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-RR” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-650, "
REAR RH : Diagnosis Procedure".
REAR RH : Diagnosis ProcedureINFOID:0000000001530773
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector.
Monitor item Condition
DOOR SW-RROPEN :ON
CLOSE :OFF
ALKIA0754ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M19 60 GroundOPEN 0
CLOSE
JPMIA0011GB

DOOR SWITCH
DLK-651
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM connector (A) M19 terminal 60
and rear door switch RH connector (B) B53 terminal 1.
3. Check continuity between BCM connector (A) M19 terminal 60
and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and rear door switch RH.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-651, "
REAR RH : Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace rear door switch RH. Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
REAR RH : Component InspectionINFOID:0000000001530774
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Check rear door switch RH.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Replace rear door switch RH. Refer to XX-XX, "*****"
.
BACK DOOR
BCM connector TerminalRear door switch
RH connectorTerminal Continuity
M19 60 B53 1 Yes
BCM connector Terminal
GroundContinuity
M19 60 No
ALKIA0753ZZ
ALKIA0752ZZ
Te r m i n a l
Door switch condition Continuity
Door switch
1 Ground part of door switchPressed Yes
Released No
