P0115 ECT SENSOR
P0115 ECT SENSOR
DescriptionINFOID:0000000001162581
The engine coolant temperature sensor is used to detect the engine coolant temperature. The sensor modifies
a voltage signal from the ECM. The modified signal returns to the ECM as the engine coolant temperature
input. The sensor uses a thermistor which is sensitive to the change in temperature. The electrical resistance
of the thermistor decreases as temperature increases.
DTC LogicINFOID:0000000001162582
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC is declared present after the ignition has been switched on for at least 10 seconds.
If the DTC is present:
- Cooling fan motor is always operate.
- Air conditioner is not operate.
Diagnosis ProcedureINFOID:0000000001162583
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK ENGINE COOLANT TEMPERATURE SENSOR SUPPLY CIRCUIT
1. Disconnect engine coolant temperature sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between engine coolant temperature sensor connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
3.CHECK ENGINE COOLANT TEMPERATURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between engine coolant temperature sensor harness connector and ECM harness
connector.
DTC No. Trouble diagnosis name Possible cause
P0115ENGINE COOLANT TEMPERATURE SENSOR CIRCUIT
 CC.0: Short circuit to ground
 CO.1: Open circuit or short circuit to +12V
 1.DEF: Micro-breaks
 2.DEF: Signal incoherence Harness or connectors
(Engine coolant temperature sensor cir-
cuit is open or shorted.)
 Engine coolant temperature sensor
Engine coolant temperature sensor
Ground Voltage
Connector Terminal
F6 3 Ground Approx. 5V
Engine coolant temperature sensor ECM
Continuity
Connector Terminal Connector Terminal
F6 2 F10 33 Existed

P0115 ECT SENSOR
EC-1133
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK ENGINE COOLANT TEMPERATURE SENSOR
Refer to EC-1133, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace engine coolant temperature sensor.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001162584
1.CHECK ENGINE COOLANT TEMPERATURE SENSOR
Check resistance between engine coolant temperature sensor terminals 2 and 3 under the following condi-
tions.
Is the inspection result normal?
YES >>INSPECTION END
NO >> Replace Engine coolant temperature sensor.
Terminal Condition Resistance (Ω)
2 and 325°C (77°F) 2,252 ± 112.16
50°C (112°F) 810 ± 39
80°C (176°F) 283 ± 8

EC-1134
< COMPONENT DIAGNOSIS >[K9K]
P0120 ELECTRIC THROTTLE CONTROL ACTUATOR
P0120 ELECTRIC THROTTLE CONTROL ACTUATOR
DescriptionINFOID:0000000001162585
By default the valve is open when in the rest position and is actuated only when the engine is stopped; this has
a damping effect and helps to stop the engine.
DTC LogicINFOID:0000000001162586
DTC DETECTION LOGIC
NOTE:
 The electric throttle control actuator function is no longer ensured when the engine is stopped or the valve is
closed, then the engine stalls or starting is impossible.
Diagnosis ProcedureINFOID:0000000001162587
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK ELECTRIC THROTTLE CONTROL ACTUATOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect electric throttle control actuator harness connector.
3. Turn ignition switch ON.
4. Check the voltage between electric throttle control actuator harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Check the following.
 IPDM E/R
 Harness connectors E8, F8
 Harness for open or short between IPDM E/R and electric throttle control actuator
 Harness for open or short between ECM and electric throttle control actuator
>> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK ELECTRIC THROTTLE CONTROL ACTUATOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
DTC No. Trouble diagnosis name Possible cause
P0120ELECTRIC THROTTLE CONTROL ACTUATOR CIRCUIT
 CC.0: Short circuit to ground
 CC.1: Short circuit to +12V
CO: Open circuit Harness or connectors
(Electric throttle control actuator circuit is
open or shorted.)
 Throttle position sensor
 Throttle control motor
Electric throttle control actua-
tor
Ground Voltage
Connector Terminal
F7 1 Ground Battery voltage

P0120 ELECTRIC THROTTLE CONTROL ACTUATOR
EC-1135
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
3. Check the continuity between electric throttle control actuator harness connector and ECM harness con-
nector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace electric throttle control actuator.
NO >> Repair or replace.
Electric throttle control actuator ECM
Continuity
Connector Terminal Connector Terminal
F75
F1172
Existed 294
490

EC-1136
< COMPONENT DIAGNOSIS >[K9K]
P0180 FPT SENSOR
P0180 FPT SENSOR
DescriptionINFOID:0000000001162588
Fuel pump temperature sensor is built in the fuel pump. The sensor detects the fuel temperature in the fuel
pump and calibrates the fuel injection amount change by fuel temperature.
DTC LogicINFOID:0000000001162589
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC is declared present after the ignition has been switched on for at least 10 seconds.
Diagnosis ProcedureINFOID:0000000001162590
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK FUEL PUMP TEMPERATURE SENSOR SUPPLY CIRCUIT
1. Disconnect fuel pump temperature sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between fuel pump temperature sensor connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
3.CHECK FUEL PUMP TEMPERATURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between fuel pump temperature sensor harness connector and ECM harness con-
nector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
DTC No. Trouble diagnosis name Possible cause
P0180FUEL PUMP TEMPERATURE SENSOR CIRCUIT
 CC.0: Short circuit to ground
 CO.1: Open circuit or short circuit to +12V
 1.DEF: Micro-breaks
 2.DEF: Signal incoherence Harness or connectors
(Fuel pump temperature sensor circuit is
open or shorted.)
 Fuel pump temperature sensor
Fuel pump temperature sensor
Ground Voltage
Connector Terminal
F29 1 Ground Approx. 5V
Fuel pump temperature sensor ECM
Continuity
Connector Terminal Connector Terminal
F29 2 F10 29 Existed

P0180 FPT SENSOR
EC-1137
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
4.CHECK FUEL PUMP TEMPERATURE SENSOR
Refer to EC-1137, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace fuel pump temperature sensor.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001162591
1.CHECK FUEL PUMP TEMPERATURE SENSOR
Check resistance between fuel pump temperature sensor terminals 1 and 2 under the following conditions.
Is the inspection result normal?
YES >>INSPECTION END
NO >> Replace Engine coolant temperature sensor.
Condition Resistance (Ω)
25°C (77°F) 2,051 ± 123
50°C (112°F) 811 ± 47
80°C (176°F) 309 ± 17

EC-1138
< COMPONENT DIAGNOSIS >[K9K]
P0190 FRP SENSOR
P0190 FRP SENSOR
DescriptionINFOID:0000000001162592
The fuel rail pressure (FRP) sensor is placed to the fuel rail. It measures the fuel pressure in the fuel rail. The
sensor sends voltage signal to the ECM. As the pressure increases, the voltage rises.The ECM controls the
fuel pressure in the fuel rail. The ECM uses the signal from fuel rail pressure sensor as a feedback signal.
DTC LogicINFOID:0000000001162593
DTC DETECTION LOGIC
NOTE:
If DTC P0190 is displayed with DTC P0641, first perform trouble diagnosis for DTC P0641. Refer to
EC-1180, "
DTC Logic".
Conditions for applying the diagnostic procedure to the stored DTCs:
- The DTC is declared present after the ignition is switched on when the engine is running outside idle speed.
If the DTC is present:
-Malfunction indicator (Red) lights up.
Diagnosis ProcedureINFOID:0000000001162594
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK FUEL RAIL PRESSURE SENSOR POWER SUPPLY CIRCUIT
1. Disconnect fuel rail pressure sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between fuel rail pressure sensor connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
3.CHECK FUEL RAIL PRESSURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between fuel rail pressure sensor harness connector and ECM harness connector.
DTC No. Trouble diagnosis name Possible cause
P0190FUEL RAIL PRESSURE SENSOR CIRCUIT
 CO.0: Short circuit to ground
 CO.1: Open circuit or short circuit to +12V
 1.DEF: malfunctioning sensor
 2.DEF: Signal outside upper level
 3.DEF: Micro-breaks Harness or connectors
(Fuel rail pressure sensor circuit is open
or shorted.)
 Fuel rail pressure sensor
Fuel rail pressure sensor
Ground Voltage
Connector Terminal
F51 3 Ground Approx. 5V
Fuel rail pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
F51 2 F10 15 Existed

P0190 FRP SENSOR
EC-1139
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK FUEL RAIL PRESSURE SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between fuel rail pressure sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK FUEL RAIL PRESSURE SENSOR
Refer to EC-1139, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace fuel rail pressure sensor.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001162595
1.CHECK FUEL RAIL PRESSURE SENSOR
1. Turn ignition switch OFF and wait at least 1 minutes.
2. Reconnect harness connector disconnected.
3. Turn ignition switch ON.
4. Select “DATA MONITOR” mode with CONSULT-III.
5. Check that the “RAIL PRESSURE” indication.
If the value is lower than 30 bar?
YES >>INSPECTION END.
NO >> Replace fuel rail pressure sensor.
Fuel rail pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
F51 1 F10 19 Existed

EC-1140
< COMPONENT DIAGNOSIS >[K9K]
P0200 FUEL INJECTOR
P0200 FUEL INJECTOR
DTC LogicINFOID:0000000001162596
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC is declared present after the engine has been started.
If the DTC is present:
-Malfunction indicator (Red) lights up.
Diagnosis ProcedureINFOID:0000000001162597
1.CHECK FUEL INJECTOR POWER SUPPLY CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect fuel injector harness connector.
4. Check the continuity between fuel injector harness connector and ECM harness connector.
5. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
2.CHECK FUEL INJECTOR OUTPUT CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between fuel injector harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
3.CHECK FUEL INJECTOR
Refer to EC-1141, "
Component Inspection".
Is the inspection result normal?
DTC No. Trouble diagnosis name Possible cause
P0200FUEL INJECTOR CONTROL
 1.DEF: Voltage outside permitted range of values
 2.DEF: Configuration/ Initialisation
 3.DEF: Signal incoherence Harness or connectors
(The fuel injector circuit is open or
shorted.)
 Fuel injector
Fuel injector ECM
Continuity
Cylinder Connector Terminal Connector Terminal
1F17 1F108
Existed 2F18 1F107
3F19 1F106
4F20 1F105
Fuel injector ECM
Continuity
Cylinder Connector Terminal Connector Terminal
1F17 2F104
Existed 2F18 2F103
3F19 2F102
4F20 2F101

P0200 FUEL INJECTOR
EC-1141
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
YES >> GO TO 4.
NO >> Replace malfunctioning fuel injector.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001162598
1.CHECK FUEL INJECTOR
1. Turn ignition switch OFF.
2. Disconnect fuel injector harness connector.
3. Check resistance between fuel injector terminals as follows.
Is the inspection result normal?
YES >>INSPECTION END
NO >> Replace malfunctioning fuel injector.
Terminals Resistance
1 and 2 150 - 250Ω [at 20°C (68°F)]
