INSPECTION AND ADJUSTMENT
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Description
INFOID:0000000001724556
MEMORY RESET PROCEDURE
1. Please observe the following instructions while confirming the sunroof operation.
NOTE:
Do not disconnect the battery power while the sunroof is operating or within 5 seconds after the sunroof
stops (to wipe-out the memory of lid position and operating friction).
2. Initialization of system should be conducted after the following conditions.
 When the battery has been disconnected or discharged.
 When the sunroof motor has been disconnected from power.
 When the sunroof motor is changed.
 When the sunroof does not operate normally (Incomplete initialization conditions).
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Re-
quirement
INFOID:0000000001724557
INITIALIZATION PROCEDURE
If the sunroof does not close or open automatically, use the following procedure to return sunroof operation to
normal.
1. Turn ignition switch ON.
2. Push and release the tilt up switch to start the tilt up operation.
3. Push and hold the tilt up switch until the sunroof pops up.
NOTE:
The sunroof will move toward the tilt up direction and will be stopped mechanically, at which time it will be
automatically fully closed. Keep pushing the switch during this operation. Release the switch when the
operation is complete.
4. Push and hold the tilt up switch within 10 seconds of step 3.
5. After 4 seconds, the sunroof will be automatically cycled in sequence of slide open-tilt up-tilt down.
NOTE:
Keep pushing the switch during this operation.
6. When the sunroof stops, release the switch 0.5 second later.
7. If the slide switch operates normally, the initialization is complete.

RF-8
< FUNCTION DIAGNOSIS >
SUNROOF SYSTEM
FUNCTION DIAGNOSIS
SUNROOF SYSTEM
System DiagramINFOID:0000000001724558
SUNROOF
System DescriptionINFOID:0000000001724559
SUNROOF SYSTEM
INPUT/OUTPUT SIGNAL CHART
SUNROOF OPERATION
 The sunroof motor assembly is supplied with constant battery power. The BCM supplies power while the
ignition switch is ON or retained power is operating.
 The open & close signals from the sunroof switch enable the sunroof motor to move arbitrarily.
AUTO OPERATION
The sunroof AUTO feature makes it possible to slide open and slide close or tilt up and tilt down the sunroof
without holding the sunroof switch in the slide open/tilt down or slide close/tilt up position.
RETAINED POWER OPERATION
Retained power operation is an additional power supply function that enables the sunroof system to operate
up to 45 seconds after the ignition switch is turned OFF.
Retained power function cancel conditions
 When a front door is opened (door switch ON)
 When ignition switch is turned ON again.
 When 45 seconds elapse on the timer.
ANTI-PINCH FUNCTION
The CPU (central processing unit) of the sunroof motor assembly monitors the sunroof motor operatin and the
sunroof position (fully-closed or other) by signals from the sunroof motor.
When the sunroof motor detects an interruption during the slide close or tilt down operation, the sunroof motor
assembly will reverse to slide open or tilt up.
ALKIA0861GB
Item Input signal to sunroof motor assembly Sunroof motor function Actuator
Sunroof switchSunroof switch signal (open)
Sunroof control Sunroof motor Sunroof switch signal (close)
BCM RAP signal

SUNROOF SYSTEM
RF-9
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
Component Parts LocationINFOID:0000000001724560
Component DescriptionINFOID:0000000001724561
LIIA2597E
1.BCM M18, M20
(View with glove box removed)2. Sunroof switch R6 3. Sunroof motor assembly R4
4.Front door switch
LH B34
RH B27
Component Function
BCM Supplies power to the sunroof motor assembly.
Sunroof switch Transmits open & close operation signal to sunroof motor assembly.
Sunroof motor assemblyThe sunroof motor and integrated CPU enables tilt up/down & slide open/close as requested by
the sunroof switch.
Front door switch Detects door open/close condition and transmits to BCM.

RF-10
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Function (BCM - COMMON ITEM)INFOID:0000000001724562
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
RETAINED PWR
RETAINED PWR : CONSULT-III Function (BCM - RETAINED PWR)INFOID:0000000001724563
WORK SUPPORT
DATA MONITOR
ACTIVE TEST
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
SELF-DIAG RESULTS Displays the diagnosis results judged by BCM. Refer to XX-XX, "*****"
.
CAN DIAG SUPPORT MNTR Monitors the reception status of CAN communication viewed from BCM.
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.
ECU IDENTIFICATION The BCM part number is displayed.
CONFIGURATION This function is not used even though it is displayed.
Work Support Item Description
RETAINED PWR SETMODE 1
MODE 2
MODE 3
Monitor Item Description
IGN ON SW Indicates [ON/OFF] condition of the ignition switch.
DOOR SW-DR Indicates [ON/OFF] condition of the front door switch LH.
DOOR SW-AS Indicates [ON/OFF] condition of the front door switch RH.
Active Test Item Description
RETAINED PWR Turns retained power function [ON/OFF].

POWER SUPPLY AND GROUND CIRCUIT
RF-11
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
COMPONENT DIAGNOSIS
POWER SUPPLY AND GROUND CIRCUIT
SUNROOF MOTOR ASSEMBLY
SUNROOF MOTOR ASSEMBLY : Diagnosis ProcedureINFOID:0000000001724564
SUNROOF MOTOR ASSEMBLY
1. CHECK SUNROOF MOTOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect sunroof motor assembly connector R4.
3. Turn ignition switch ON.
4. Check voltage between sunroof motor assembly connector R4
terminals 7 and 9 and ground.
Is the voltage as specified?
YES >> GO TO 4
NO, TERMINAL 7>>Check sunroof motor circuit breaker, connector and harness. Refer to PG section, main
wire harness layout.
NO, TERMINAL 9>>GO TO 2
2. CHECK SUNROOF MOTOR RETAINED POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector M20.
3. Check continuity between BCM connector M20 (A) and sunroof
motor assembly connector R4 (B).
4. Check continuity between BCM connector M20 (A) and ground.
Are the continuity test results as specified?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK GROUND CIRCUIT
(+)
(–) Voltage
Connector Terminal
R47
Ground Battery voltage
9
ALKIA1176GB
AB
Continuity
Connector Terminal Connector Terminal
M20 78 R4 9 Yes
A
—Continuity
Connector Terminal
M20 78 Ground No
ALKIA1227GB

RF-12
< COMPONENT DIAGNOSIS >
POWER SUPPLY AND GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between sunroof motor assembly connector
R4 terminal 10 and ground.
Is the continuity test result as specified?
YES >> Power supply and ground circuits are OK.
NO >> Repair or replace harness.
SUNROOF MOTOR ASSEMBLY : Special Repair RequirementINFOID:0000000001724565
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to RF-7, "
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Requirement".
Does the sunroof motor assembly operate properly?
YES >> Repair is complete.
NO >> Check fitting adjustment.
Connector Terminal — Continuity
R4 10 Ground Yes
ALKIA1178GB

SUNROOF SWITCH CIRCUIT
RF-13
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
SUNROOF SWITCH CIRCUIT
DescriptionINFOID:0000000001724566
A circuit breaker supplies constant battery power to the sunroof motor assembly. The BCM supplies retained
power to the sunroof motor assembly when the key is ON or during retained power operation. The open and
close functions of the sunroof motor assembly are controlled by the sunroof switch.
Component Function CheckINFOID:0000000001724567
1. CHECK SUNROOF MOTOR FUNCTION
Do open and close functions operate normally with the sunroof switch?
Is the inspection result normal?
YES >> Sunroof motor assembly is OK.
NO >> Refer to RF-11, "
SUNROOF MOTOR ASSEMBLY : DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000001724568
1. CHECK SUNROOF SWITCH INPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between sunroof switch connector and ground.
Are the voltage measurements as specified?
YES >> Sunroof switch is operating normally.
NO >> GO TO 2
2. CHECK SUNROOF SWITCH CIRCUITS
1. Turn ignition switch OFF.
2. Disconnect sunroof motor assembly connector R4 and sunroof
switch connector R6.
3. Check continuity between sunroof motor assembly connector
R4 (A) and sunroof switch connector R6 (B) and.
4. Check continuity between sunroof motor assembly connector R4 (A) and ground.
Are the continuity test results as specified?
YES >> GO TO 3
NO >> Repair harness or connector.
ConnectorTe r m i n a l s
Sunroof switch positionVoltage (V)
(Approx.)
(+) (–)
R61
2CLOSE 0V
Other than above Battery voltage
3OPEN 0V
Other than above Battery voltage
ALKIA1229GB
AB
Continuity
Connector Terminal Connector Terminal
R45
R61
Ye s
13
A
—Continuity
Connector Terminal
R45
Ground No
1
ALKIA1180GB

RF-14
< COMPONENT DIAGNOSIS >
SUNROOF SWITCH CIRCUIT
3. CHECK SUNROOF SWITCH
1. Check continuity between sunroof switch terminals.
Are the continuity test results as specified?
YES >> Sunroof switch is operating normally.
NO >> Replace sunroof switch (map lamp assembly). Refer to
XX-XX, "*****"
.
Terminals Sunroof switch position Continuity
1
2CLOSE Yes
Other than above No
3OPEN Yes
Other than above No
ALKIA1181GB

DOOR SWITCH
RF-15
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
RF
N
O
P
DOOR SWITCH
DescriptionINFOID:0000000001724569
Detects door open/close condition and transmits the signal to BCM.
Component Function CheckINFOID:0000000001724570
1. CHECK DOOR SWITCH INPUT SIGNAL
Check (“DOOR SW-DR” and “DOOR SW-AS”) in “DATA MONITOR” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch circuit is OK.
NO >> Refer to RF-15, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001724571
1. CHECK FRONT DOOR SWITCH
Check front door switches.
Are the continuity test results as specified?
YES >> GO TO 2
NO >> Replace front door switch.
2. CHECK FRONT DOOR SWITCH INPUT SIGNAL
Check voltage between BCM connectors M18 and ground.
Are the voltage readings as specified?
YES >> Replace BCM. Refer to XX-XX, "*****".
NO >> GO TO 3
3. CHECK HARNESS CONTINUITY
Monitor item Condition
DOOR SW-DROPEN : ON
CLOSE : OFF
DOOR SW-ASOPEN : ON
CLOSE : OFF
Terminal Switch condition Continuity
2GroundPressed No
Released Yes
LIIA2377E
(+)
(–) Front door condition Voltage
Connector Terminal
M1829
GroundLHOPEN 0V
CLOSE Battery voltage
30 RHOPEN 0V
CLOSE Battery voltage
ALKIA1230GB

RF-16
< COMPONENT DIAGNOSIS >
DOOR SWITCH
1. Turn ignition switch OFF.
2. Disconnect BCM connectors M18 and front door switch connec-
tors B27 and B34.
3. Check continuity between BCM connectors M18 (A) and front
door switch connectors B27 and B34 (B).
4. Check continuity between BCM connectors M20 (A) and ground.
Are the continuity test results as specified?
YES >> Replace BCM. Refer to XX-XX, "*****".
NO >> Repair or replace harness.
AB
Continuity
Connector Terminal Connector Terminal
M1829 LH B34
2Yes
30 RH B27
A
— Continuity
Connector Terminal
M1829
Ground No
30
ALKIA1231GB
