NISSAN TIIDA 2007 Service Repair Manual

SR-8
< ON-VEHICLE REPAIR >
SPIRAL CABLE
6. Disconnect lighting and turn signal switch connector (1). Then
while pressing tabs (2), pull lighting and turn signal switch
toward driver door to remove.
7. Remove the screws, then release the tab at the top and pull the
spiral cable away from the steering column assembly.
8. Disconnect spiral cable connectors.
INSTALLATION
Installation is in the reverse order of removal.
 Align spiral cable correctly when installing steering wheel, refer to
ST-8, "
Removal and Installation". Make sure spiral cable alignment
and centering marks (B) are matched and in the neutral position.
The neutral position is detected by turning left 2.6 revolutions from
the right end position, ending with the locating pin (A) at the top.
Place steering wheel in straight ahead position, then install it with
the locating pin hole (C) directly over spiral cable locating pin.
 After the work is completed, perform self-diagnosis to make sure
no malfunction is detected. Refer to SRC-11, "
SRS Operation
Check".
WHIA0316E
PHIA1024J

FRONT PASSENGER AIR BAG MODULE
SR-9
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
FRONT PASSENGER AIR BAG MODULE
Removal and InstallationINFOID:0000000001350506
REMOVAL
WARNING:
 When servicing the SRS, do not work from directly in front of air bag module.
 Always place front passenger air bag module with pad side facing upward.
CAUTION:
 Before servicing SRS, turn the ignition switch OFF, disconnect both battery cables and wait at least
3 minutes.
 Do not use old bolts after removal; replace with new bolts.
 Do not insert any foreign objects (screwdriver, etc.) into air bag module or harness connectors.
 Do not disassemble air bag module.
 Do not expose the front passenger air bag module to temperatures exceeding 90°C (194°F).
 Replace the front passenger air bag module if it has been
dropped or sustained an impact.
 Do not allow oil, grease or water to come in contact with the
front passenger air bag module.
1. Disconnect the negative and positive battery cables, then wait at least 3 minutes.
2. Remove the side ventilator assembly (right). Refer to VTL-23, "
Removal and Installation".
3. Disconnect front passenger air bag module connector (1) and
remove the upper instrument panel assembly bolts (2).
⇐: Vehicle front
NOTE:
LHD shown, RHD similar
4. Remove the front passenger air bag module bolts (3) from the
steering member.
5. Release the pawls and remove the front passenger air bag mod-
ule (1) from the upper instrument panel assembly (2).
NOTE:
LHD shown, RHD similar
INSALLATION
Installation is in the reverse order of removal.
 After the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer to SRC-
11 , "SRS Operation Check".
WHIA0321E
WHIA0317E
WHIA0318E

SR-10
< ON-VEHICLE REPAIR >
SIDE CURTAIN AIR BAG MODULE
SIDE CURTAIN AIR BAG MODULE
ComponentINFOID:0000000001350507
Hatchback Models
Sedan Models
Removal and InstallationINFOID:0000000001350508
REMOVAL
WARNING:
WHIA0319E
1. Side curtain air bag module 2. Inflator 3. Ground bolt
⇐Vehicle front
LHIA0135E
1. Side curtain air bag module 2. Inflator 3. Side air bag module connector
⇐Vehicle front

SIDE CURTAIN AIR BAG MODULE
SR-11
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
 When servicing the SRS, do not work from directly in front of air bag module.
 Always place the curtain air bag module with deployment side facing upward.
 Do not reuse center pillar upper garnish if removed.
CAUTION:
 Before servicing SRS, turn the ignition switch OFF, disconnect both battery cables and wait at least
3 minutes.
 Do not use old bolts after removal; replace with new bolts.
 Do not insert any foreign objects (screwdriver, etc.) into air bag module or harness connectors.
 Do not disassemble air bag module.
 Do not expose the side curtain air bag module to temperatures exceeding 90°C (194°F).
 Replace the side curtain air bag module if it has been dropped
or sustained an impact.
 Do not allow oil, grease or water to come in contact with the
side curtain air bag module.
 Do not attempt to repair or replace damaged direct-connect
SRS component connectors. If a direct-connect harness con-
nector is damaged, the harness must be replaced.
1. Disconnect both the negative and positive battery cables, then wait at least 3 minutes.
2. Remove the headlining. Refer to INT-29, "
Component".
3. Disconnect side curtain air bag module connector.
NOTE:
For removal/installation of the direct-connect SRS connectors,
refer to SRC-9, "
Direct-connect SRS Component Connectors".
4. Remove the bolts in order starting at the rear, then remove the
side curtain air bag module.
INSTALLATION
Installation is in the reverse order of removal.
 For removal/installation of the direct-connect SRS connectors, refer to SRC-9, "
Direct-connect SRS Compo-
nent Connectors".
 After replacement of side curtain air bag module, perform self-diagnosis to check that no malfunction is
detected. Refer to SRC-11, "
SRS Operation Check".
WHIA0321E
PHIA0953J

SR-12
< ON-VEHICLE REPAIR >
SIDE AIR BAG (SATELLITE) SENSOR
SIDE AIR BAG (SATELLITE) SENSOR
Removal and InstallationINFOID:0000000001350510
REMOVAL
WARNING:
Do not reuse center pillar upper garnish if removed.
CAUTION:
 Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at least
3 minutes.
 Do not disassemble the side air bag (satellite) sensor.
 Do not use old nuts after removal; replace with new nuts.
 Replace the side air bag (satellite) sensor if it has been
dropped or sustained an impact.
 Check side air bag (satellite) sensor to make sure it is free of
deformities, dents, cracks or rust. If it shows any visible signs
of damage, replace it with a new one.
1. Disconnect both the negative and positive battery cables, then wait at least 3 minutes.
2. Remove the front seat belt retractor. Refer to SB-6, "
Removal and Installation of Front Seat Belt".
3. Remove the nuts (1) and remove side air bag (satellite) sensor
(2).
⇐: Vehicle front
4. Disconnect the side air bag (satellite) sensor harness connector
(3).
INSTALLATION
Installation is in the reverse order of removal.
 After the work is completed, perform self-diagnosis to make sure no malfunction is detected. Refer to SRC-
11 , "SRS Operation Check".
WHIA0321E
WHIA0322E

PASSENGER AIR BAG DEACTIVATION SWITCH
SR-13
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
PASSENGER AIR BAG DEACTIVATION SWITCH
Passenger Air Bag Deactivation SwitchINFOID:0000000001404301
REMOVAL
CAUTION:
Before servicing SRS, turn ingition switch OFF, disconnect both battery cables, then wait at least 3
minutes.
1. Disconnect the negative and positive battery cables, then wait at least 3 minutes.
2. Using a suitable tool, release the instrument panel side cover (1)
pawls.
NOTE:
LHD shown, RHD similar.
3. Lift the instrument panel side cover upward and away from the
instrument panel to remove.
4. Disconnect the passenger air bag deactivation switch harness
connector.
5. Pinch the side tabs and release switch from the instrument
panel side cover to remove.
INSTALLATION
CAUTION:
Passenger air bag deactivation switch is keyed for proper installation. Improper positioning or exces-
sive force of the switch will result in damage.
Installation is in the reverse order of removal.
NOTE:
After replacement, perform self-diagnosis for SRS. Refer to ....XXX.
ALHIA0045ZZ
ALHIA0046ZZ

SR-14
< ON-VEHICLE REPAIR >
FRONT SEAT BELT PRE-TENSIONER
FRONT SEAT BELT PRE-TENSIONER
Removal and InstallationINFOID:0000000001350511
For removal and installation procedures, refer to SB-6, "Removal and Installation of Front Seat Belt".

DIAGNOSIS SENSOR UNIT
SR-15
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
DIAGNOSIS SENSOR UNIT
Removal and InstallationINFOID:0000000001350512
REMOVAL
WARNING:
Before disconnecting diagnosis sensor unit harness connector(s), be sure to disconnect harness con-
nectors from air bag modules and front seat belt pre-tensioner to prevent deployment by static elec-
tricity.
CAUTION:
 Before servicing the SRS, turn the ignition switch OFF, disconnect both battery cables and wait at
least 3 minutes.
 Do not disassemble diagnosis sensor unit.
 Do not use old bolts; replace with new bolts.
 Replace the diagnosis sensor unit if it has been dropped or sustained an impact.
 Check diagnosis sensor unit bracket to make sure it is free of deformities, dents, cracks or rust. If it
shows any visible signs of damage, replace with new one.
 The diagnosis sensor unit must always be installed with the arrow mark "⇐" pointing toward the
front of the vehicle for proper operation.
1. Disconnect the negative and positive battery cables, then wait at least 3 minutes.
2. Disconnect the harness connectors for each air bag module and seat belt pre-tensioner. Refer to SR-4,
"Removal and Installation", SR-9, "Removal and Installation", SR-10, "Removal and Installation", SR-14,
"Removal and Installation".
3. Remove center console assembly. Refer to IP-11, "
Removal and Installation".
4. Disconnect diagnosis sensor unit connectors.
5. Remove the bolts and the ground bolt, then remove the diagnosis sensor unit.
INSTALLATION
Installation is in the reverse order of removal.
 The diagnosis sensor unit must always be installed with the arrow mark "⇐" pointing toward the front of the
vehicle.
 Follow the tightening sequence 1,2,3,4 as shown.
 After the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer to SRC-
11 , "SRS Operation Check".
ECU DISCRIMINATED NO.
After replacing the diagnosis sensor unit, confirm that the diagnosis sensor unit identification is correct for the
vehicle as equipped. Refer to SRC-13, "
CONSULT-III Function (AIR BAG)".
1. Diagnosis sensor unit connectors 2. Ground Bolt 3. Bolt
4. Diagnosis sensor unit⇐Vehicle front
WHIA0323E

SR-16
< ON-VEHICLE REPAIR >
DISPOSAL OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER
DISPOSAL OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER
Caution for Air Bag Module and Seat Belt Pre-tensionerINFOID:0000000001404296
 Before disposing of air bag module and seat belt pre-tensioner, or vehicles equipped with such systems,
deploy the systems. If such systems have already been deployed due to an accident, dispose of them as
indicated in Disposing of Air Bag Module and Seat Belt Pre-tensioner.
 When deploying the air bag module and seat belt pre-tensioner,always use the Special Service Tool; Deploy-
ment tool (SST: KV99106400).
 When deploying the air bag module and seat belt pre-tensioner,stand at least 5 m (16 ft) away from the
deployment component.
 When deploying air bag module and seat belt pre-tensioner, a fairlyloud noise is made, followed by smoke
being released. The smoke is not poisonous,however, be careful not to inhale smoke since it irritates the
throat and can cause choking.
 Always activate one air bag module at a time.
 Due to heat, leave air bag module unattended for more than 30 minutes after deployment. Also leave seat
belt pre-tensioner unattended for more than 10 minutes after deployment.
 Wear gloves when handling a deployed air bag module and seat belt pre-tensioner.
 Never apply water to the deployed air bag module and seat belt pre-tensioner.
 Wash your hands after finishing work.
 Place the vehicle outdoors with an open space of at least 6 m (20 ft) on all sides when deploying air bag
module and seat belt pre-tensioner while mounted in vehicle.
 Use a volt meter to make sure the vehicle battery is fully charged.
 Do not dispose of the air bag module and seat belt pre-tensioner undeployed.
CHECKING DEPLOYMENT TOOL
Connecting to Battery
CAUTION:
The battery must show voltage of 9.6 V or more.
Remove the battery from the vehicle and place it on dry wood blocks
approximately 5 m (16 ft) away from the vehicle.
 Wait 3 minutes after the vehicle battery is disconnected before pro-
ceeding.
 Connect red clip of deployment tool (A) to battery positive terminal
and black clip to negative terminal.
Check that the polarity is correct. The right side lamp in the
tool, marked “deployment tool power”, should glow with a
green light. If the right side lamp glows red, reverse the connec-
tions to the battery.
Deployment Tool Check
Press the deployment tool switch (C) to the ON position. The left
side lamp in the tool, marked “air bag connector voltage” should illu-
minate (B). If it does not illuminate, replace the deployment tool (A).
Air Bag Deployment Tool Lamp Illumination Chart (Battery Connected)
JMHIA0204ZZ
JMHIA0205ZZ
Switch operationLeft side lamp, green*
“AIR BAG CONNECTOR
VOLTAGE”Right side lamp, green*
“DEPLOYMENT TOOL
POWER”
OFF OFF ON
ON ON ON

DISPOSAL OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER
SR-17
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
*: If this lamp glows red, the tool is connected to the battery incorrectly.Reverse the connections and check the lamp glows green.
DEPLOYMENT OF AIR BAG MODULE (OUTSIDE OF VEHICLE)
Deployment of Driver Air Bag Module (Outside of Vehicle)
1. Unless the vehicle is being scrapped, deploying the air bag in
the vehicle is not recommended. This may cause damage to the
vehicle interior.
Anchor air bag module bracket (SST: KV99105300) (A) in a vice
secured to a firm foundation deployment.
2. Using wire (B), secure air bag module (1) to air bag module
bracket (SST: KV99105300) (A) at four places.
CAUTION:
 Use wire of at least 1 mm (0.04 in) diameter.
 If a gap exists between air bag module and air bag module
bracket, use a piece of wood (D) inserted in the gap to sta-
bilize the air bag module.
3. Firmly secure air bag module bracket (SST: KV99105300) (A)
with air bag module attached, in a vise (C).
4. Connect deployment tool adapter (SST: KV99110500) (B) to air
bag module (1) and deployment tool connector (SST:
KV99106400) (A).
5. Connect red clip of deployment tool (A) to battery positive termi-
nal and black clip to negative terminal (B).
6. The lamp on the right side of the tool, marked “deployment tool
power”, should glow green, not red.
7. Press the button on the deployment tool (A). The left side lamp
on the tool, marked “air bag connector voltage”, will illuminate
and the air bag module (1) will deploy.
CAUTION:
When deploying the driver air bag module, stand at least 5 m
(16 ft)away from the air bag module.
DEPLOYMENT OF AIR BAG MODULE (OUTSIDE OF VEHICLE)
Deployment of Front Passenger Air Bag Module (Outside of Vehicle)
JMHIA0208ZZ
JMHIA0206ZZ
JMHIA0207ZZ
JMHIA0209ZZ
